Blister makineler

Used blister packaging line CAM Italy in the years 2002 and 2003 (desription of all machines in the line below the photos) consisting of: blistering machine, cartoner and wrapper, chiller. The line is currently installed and in excellent working condition. Professional desmantling, packaging and shipment is available upon request (at additional cost). Used line for packing tablets (or capsules into blisters, blisters into cartons and wrapping. Manufacturer: CAM. The line includes: Blistering machine made by CAM Italy model M92X Year of manufacturing: 2002 Capacity: 30-35-40-45 cycles per minute Maximum stroke: 180 mm. Maximum foil width: 286 mm. Maximum filling depth: 12 mm Overall dimensions: L 4700 x W 2020 x H 2890 mm Hour counter: 14600 hours. Full technical documentation available. Videos of warking machine available machine upon req ...

Used blister and cartoner by IMA type. C80/A81; New: 2000; Available formats: 1.PVC/ Al thermoformed dim. blister 83x56 with 10 tablets, cardboard box …601886, 602586, 603586 604586, Foil 176/183 2. Thermoformed PVC/Al dim. blister 83x56 with 6 tablets 3.PVC/Al thermoformed dim. blister 96x66 with 10 tablets cardboard box …7018104, 7025104, 7035104, 7045104, 7058104, Film 209/213

• Blister size length 28 mm, blister width 100 mm, • Drawing depth 12 mm • Output knife 15-90 cyles/min • Sev. tool sets for blister size 28 x 100 m for capsules size 0, 1, 2 and 4, tablets and suppos (listing see photo), manual product feeding • Counter • IQ-OQ-documentation on French • Machine has no common punching tool but a lateral knife, connection 380V/50Hz This machine is offered at a special price and is sold as is - were is, without technical inspection.

• Color filling control for detection of under-mixing, size, position, fragments and overfilling • Adjustable illumination • Max. width of blister web 320 mm • Application: For tablets/oblongs/coated tablets/hard and soft gelatin capsules • Inspection for: Color/presence/size/shape/circumference/location/broken pieces/overfill • 21 CFR Part 11 compliant. • Format versions are stored separately • Suitable for Uhlmann blister machines, as equipped with Uhlmann rail system • All system units installed in one box • Update to latest version possible by manufacturer Scanware

Features: • Format range 100 x 153 mm • Output max 240 Blister/min (depending on product and format) • Drawing depth max. 12 mm (max. 24 mm after conversion) • Punching station output max. 60 cycles/min. • Pre-draw max. 125 mm • Plate sealing • Forming film rigid PVC, PVC/PVDC (Alu forming optional) • Film width max. 170 mm • Film thickness 0.1-0.35 mm • Sealing film aluminum • Perforating station • Batch embossing • Forming with air pressure • Blister transfer with bad ejection • Without format parts • Connection 380V/50Hz This blister machine has been mechanically overhauled in our specialist workshop. The entire electrical/pneumatic system has been renewed. The machine control system was equipped with the latest control technology. The following parts were replaced: • PLC B+R X20 with Automation Panel 12.1 WXGA TFT, system unit PPC3100 • Serv ...

Dedicated feeder for any tablets or capsules on blistering machines f.e. Uhlmann UPS 1070 • intermittent motion • for diverse product shapes • 60 strokes/min • format area max. 295 x 285 mm • own control unit, therefore universally applicable on different machines • suitable for Uhlmann rail system, easy mounting • incl. transport rack, mobile

Blister machine Manufacturer Uhlmann Type UPS 1070 Power 15 – 200/cycle min. Film width min. 150 mm – max. 300 mm including color and filling material control, scanware, type LYNX Spectra CL/HR Blister machine with side channel blower 2016 new sealing head with adjustment dome

• Set up for ALU/PVC operation • Output 15-50 forming cycles/min, max. 100 punching cycles/min, max. 400 blisters/min • Format range and die-cutting area max. (feed x width) 220 x 188 mm • Drawing depth max. 12 mm • Vibratory feeder with brush box for tablets/capsules • Product inspection from underside of blister with colour camera Scanware Lynx-Spectra HR and own PLC Bachmann MX 207/DIO 248 for error carry-over (retrofitted in 2010) • Roller stand • Perforating station • Film monitor • Bad ejection • Ejection counter control • Vacuum pump • Waste cutter • Transfer belt to cartoner • Electronic cam control Digitronic CamCon • MC control system • Drive 220/38V/50Hz • Without format tools

Set up for ALU/PVC and ALU/ALU operation • Format range blister (W x L) min 50 x 22 mm / max. 156 x 115 mm • Drawing depth max. 12 mm • Output 15 - 50 forming cycles/min • Transport length 42-115 mm • Film width 100-168 mm • Forming film Ø max. 450 mm, core Ø 76 mm (PVC) / 150 mm (ALU), pneumatic clamped • Cover film-Ø max. 240mm, core-Ø 76 mm, pneumatic clamped • Adhesive bonding point detection for sealing and forming film • Product feed by deticated feeder Uhlmann SimTab 2.1 for tablets/capsules • Forward feed after forming and sealing station • Tear and pore control for forme film and cover film Visiotec VisioScan MT-160/200 • Forming station with compressed air for PVC forming film • Heating station with extraction for the use of PVDC film • Mechanical forming station for ALU forming film • Filling control VisioChrom color with separ ...

Equipped for ALU/PVC and ALU/ALU operation • Blister format range (W x L) min. 50 x 22 mm / max. 156 x 115 mm • Drawing depth max. 12 mm • Capacity 15 - 50 mould cycles/min • Transport length 42-115 mm • Film width 100-168 mm • Moulded foil Ø max. 450 mm, core Ø 76 mm (PVC) / 150 mm (ALU), pneumatic clamps • Cover film Ø max. 240mm, core Ø 76 mm, pneumatic clamp • Glue joint detection for moulded and sealing film • Product feeder Uhlmann SimTab 2.1 for tablets/capsules • Feed according to moulds and seals • Print image control with cover film stretching • Crack and pore control moulding film and cover film Visiotec VisioScan MT-160/200 • Forming station with compressed air for PVC molding film • Heating station with suction for the use of PVDC foil • Mechanical forming station for ALU moulded foil • Contents control VisioChrom color wit ...

• For PVC/PVDC-Alu • Output max. 50 forming cycles/min, max. 200 punching cycles/min, max. 600 blisters/min • Max. Format range (feed x width) 220 x 284 mm • Feed single cycle max. 222 mm • Feed rate multi-cycle max. 90 mm • Max. punching area lengthwise x crosswise 220 x 284 mm • Forming depth max. 12 mm • Automatic vibratory feeder 12-lane for oblong tablets/capsules • Uhlmann MC programme control • 1 tool set for oblong tablets/capsules • Drive 15kW/380V/50Hz Optional retrofit/overhaul/modernization: - PLC B + R X20 with Touch Panel PPC2100, new - Servo drives, new - Foil take-off by linear servo, new - Electric installation, new - Mechanically outdated - Pneumatics, new - Cooling, new - Protective coating, new - Varnish, new Further options: - Feeder: Brush box, directed feed e.g. SimTab or linear guidance - Format replacement acco ...

Uhlmann UPS5ET blister machine for alu/alu blisters, including Uhlmann 149 buffer system. Maximum blister size 272 x 284mm (draw x width), maximum depth 40mm. SyPro feeding system for syringes etc with flexible robotic arm and vacuum grip head. Seidenader camera product presence checking system, VISIOtec VisoScan blister integrity tester, gas flushing with Dansensor MAP Check Combi for measuring the gas content within the pack. Domino D550+ laser printer with Seidenader print control camera. Output up to 400 blisters per minute. As new, with only 350 production hours.
