TEACH IN LATHE Inv. No. 11.581C1 Make CAZENEUVE Model HBCN S575 Year 1995 Mach.no. 9810 Control SOMAB PL+S3 Centre Distance 1.500 mm Max. Swing over Bed Ø 575 mm Max. Swing over Cross Slide Ø 300 mm Centre Height Ø 250 mm Spindle Bore Ø 51 mm R.P.M. 2 ranges 0 – 3000 kW 18,5 Volts 400 Cycles 50 Auction-ID: A1-50718-22
Machine is equipped with: - chip conveyor - tailstock - tool setter - 254mm chuck Mistfilter not included! Auction-ID: A1-50690-9
Machine is equipped with: - chip conveyor - tailstock - tool setter - collet chuck - mist filter Auction-ID: A1-50690-10
TEACH-IN LATHE Inv. No. 13.051C1 Make CMT URSUS Model URSUS PLUS 250 Year 1996 Serial number 12628 Centre Distance 1.000 mm Max. Swing over Bed Ø 480 mm Max. Swing over Cross slide Ø 400 mm Spindle bore Ø 105 mm 2 ranges stepless 0 – 2.000 kW 8/11 Volt 380 Cycles 50 Including Toolholder Multifix 3-jaw chuck Ø 315 Auction-ID: A1-50718-47
CNC LATHE Inv. No. 12.710C1 Make MONDIALE Model GALLIC 420 CNC Control FANUC 10TF Serial number CNCG16AC Centre distance 870 mm Max. swing over Bed Ø 420 mm Max. swing over Cross Slide Ø 214 mm Spindle bore Ø 69 mm R.P.M. 45 – 2500 (inf. var.) kW 11 Volts 400 Cycles 50 Including: 6 Pos. turret Coolant Auction-ID: A1-50718-28
Machine is equipped with: - chip conveyor - tailstock - 254mm chuck Auction-ID: A1-50690-14
CNC LATHE Inv. No. 12.711C1 Make MONDIALE Model GALLIC 420 CNC Control FANUC 10TF Serial number CNCG1685B17GE Centre distance 870 mm Max. swing over Bed Ø 420 mm Max. swing over Cross Slide Ø 214 mm Spindle bore Ø 69 mm R.P.M. 45 – 2500 (inf. var.) kW 11 Volts 400 Cycles 50 Including: 6 Pos. turret Coolant Auction-ID: A1-50718-32
Machine is equipped with: - chip conveyor - tailstock - 4 jaw chuck Auction-ID: A1-50690-4
Machine is equipped with: - 380mm chuck - tailstock - 3 toolholders Auction-ID: A1-50690-21
CAPACITY: Swing over bed: 630 mm Swing over saddle: 500 mm Recommended turning diameter: 255 mm Max. turning diameter: 420 mm Max. turning length: 1,030 mm Bar working diameter: 76 mm TRAVELS: X-axis travel: 242 mm Z-axis travel: 1,100 mm MAIN SPINDLE: Spindle speed: 3,500 rpm Spindle nose: ASA A2#8 Spindle bearing diameter: 130/120 mm Spindle through hole diameter: 86 mm Min. spindle indexing angle (C-axis): 0.001° TURRET: No. of tool stations: 12 OD tool size: 25 mm Boring bar diameter: 40 mm Indexing time: 0.15 sec Rotary tool spindle speed: 5,000 rpm TAIL STOCK: Quill diameter: 100 mm Quill bore taper: MT#5 Quill travel: 100 mm FEEDRATE: Rapid traverse (X/Z-axis): 20/24 m/min MOTORS: Main spindle motor: 18.5/22 kW Rotary tool spindle motor: 5.5 kW Feed motor (X/Z-axis): X: 3.0 / Z: 4.0 kW Coolant pump motor: 0.4 kW POWER SOURCE: Electric power supply: 40.6 kVA ...
Machine is equipped with: - chip conveyor - tailstock - tool setter - 254mm chuck Auction-ID: A1-50690-11
new controler from 2021,turning length - 1100mm,turning diameter over the bed - 400mmturning diameter over slide - 225mm,lift of the claws over the bed guide - 260mm,bed width - 320mm,support length - 520mmOffer not include other machines and parts which are visible on the photos but not belong to the machine. Auction-ID: A1-50601-17
turning diameter - 12 mm,turning length - 135 mm,approximate dimensions - 1500 mm x 770 mm x 1540 mm,machine equipped with bar feeder,machine dimensions - 2400x1200x2400,bar feeder dimensions - 4800x500x1500, Auction-ID: A1-50601-5
Fanuc 18i-TB control,5 axes (X, Z, Z2, C main spindle, C counter spindle),max workpiece diameter X600,max turning diameter X330,max turning length 500,max length Z2 axis 500,12-position tool head,12-position driven tools,10” main holder C axis,6” counter spindle C axisOther machines, devices and tools unrelated to the subject of sale visible in the photos are not part of the offer. Auction-ID: A1-50601-6
Böhringer DUS 560 with additional digital display with Siemens 805 control with Forkardt 3 jaw chuck D 250 mm Multifix Holder Auction-ID: A7-50850-3
turning diameter over bed: 297 mmturning diameter over slide rest: 160 mmturning length: 500 mmspindle bore: 36 mmturning speeds: 30 - 3550 U/minspindle nose: Kurzkegel Gr.5 DIN 55022 tailstock quill taper MT: 3 total power requirement: 2,2 kWweight of the machine ca.: 0,7 tdimensions of the machine ca.: 1,511,5 mOn customer order - Private machine - Accessories:3-jaw chuck4-jaw chuckCollet chuck with lever clampingMultifix A + various holdersOperating toolVarious turning toolsOriginal documentationThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
: gebraucht : 1992 : 010190 : prompt, Zwischenverkauf v : 17900 €: 1 : 320 mm: 650 mm: 160 mm: 40 mm: 192 mm: 205 mm: 5 : 5 MK: 16 : 48 - 2500 1/min: 24 : 0.02 - 0.63 mm/U: 0.006 - 0.2 mm/U: 0.25 - 8 mm: 0.2 - 4 : 150 mm: 100 mm: 40 mm: 3 MK: 85 mm: 2,4 / 3 kW: 1582 mm: 715 mm: 1245 mm: 680 kgHeidenhain 3-axis digital readoutNEWRöhm 3-jaw chuck, 160 mm diameter, with internal and external jawsQuick-change tool post with one rectangular insert and one round insertLive centreDrill chuckChuck guardLead and feed screw guardMotor brakeCoolant systemMounting feetOperating instructions in GermanBUYING USED MACHINERY IS A MATTER OF TRUST - OUR TRANSPARENCY PROMISEWe offer you maximum security and complete transparency.• HONEST INSIGHTS: Detailed photos and functional videos of the current condition• LIVE ON-SITE CHECK: Live testing is possible at our facility• DIGITAL DEMONSTRATION: Ind ...
turning diameter: 186 mmturning length: 350 mmcontrol: FANUC O/T turning speeds: 4.000 U/minspindle bore: 61,0 mmtool holder: 12 Stückchucking diameter: 170 mmoperating hours: htotal power requirement: 7,5 kWweight of the machine ca.: 2,4 t- FANUC - CNC control- SMB 600 bar feeder with magazine- Chip conveyor- 3-jaw lathe chuck, 170 mm- MK 4 tailstock- Various tool holders- Cooling system- Full enclosureThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Manufacturer: GILDEMEISTERYear: 1996Type: CNC latheNumerical control: Heidenhain ELECTRO PILOT turn plusAxes: 2 axes (X, Z)Turning diameter above the bench: Ø 500 mmTurning diameter above the carriage: Ø 290 mmMax. turning length: 640 mmSpindle: 20–5,000 rpm – 22 kW – max. torque 150 Nm – bore 72 mm – passage 65 mmStrokes: Z 650 mm / X 212 mmFast feeds X/Z: 10 m/minTailstock: sleeve Ø 80 mm – CM4 – stroke 100 mmEquipment: 3-jaw chuck Ø 250 mm, SAUTER turret 12 positions VDI 30, tailstock, full documentationDimensions: approx. 3300 × 1800 × 1900 mmWeight: approx. 5000 kgRemarks: Robust German-made CNC lathe. Auction-ID: A1-50714-4053
CNC control: MSX-850 IIINumber of axes: 2Strokes: X = 260 mm, Z = 590 mmSpindle speed: 50 – 5000 rpmPower: 15 kWBar capacity: Ø 65 mmSpindle bore: 73 mm Turret: 12 stations (BMT)Max turning diameter: 356 mmMax turning length: 510 mmChip conveyor: yes235L high-pressure pump: yes Lots sold as is, unchecked, without tools or tool holders. Auction-ID: A1-50714-4004
Year of manufacture: 1999CNC : Siemens Sinumerik 840CMax. turning diameter: 254 mmMax. turning length: 500 mmDiameter allowed above the bed: 440 mmBar passage: 51 mmBench inclination: 45°Spindle speed: 36 to 4,000 rpmSpindle nose: A2-6Engine power (cont./30 min): 11 kW / 15 kWChuck: Ø 210 mm (8 inches), hydraulic clampingTurret: 8 positions, indexing 0.5 s station-to-stationTools: square 25 x 25 mm / boring bar Ø 40 mmTailstock: programmable hydraulic sleeve, CM4 taperChip conveyor: hinged type, side outletDimensions (L x W x H): 2,600 x 1,700 x 1,750 mmWeight: approx. 4,200 kg Auction-ID: A1-50714-104
Manufacturer: HARDINGEYear: 2005Type: CNC Motorized Tool Lathe with C-AxisNumerical Control: FANUC 21i-TBBar Capacity: Ø 51 mmMax. Turning Circle: Ø 310 mmMax. Turning Length: 470 mmChuck: Ø 200 mm (8\")Bed Inclination: 45°Spindle: 50–5,000 rpm – 18.5 kW (max) / 11 kW (continuous)Turret: 12 stations, all motorable positionsMotorized implements: 4,000–5,000 rpm – 3.7 kWFast feeds: X/Z 19 / 24 m/minAccuracy: ±0.005 mmIncluded equipment: Programmable C-axis (0.001°), IEMCA Boss 545 bar feederWeight (kg): approx. 4200 Auction-ID: A1-50714-4029
Year of manufacture: 1998Serial No.: 93742Numerical control: Fanuc 18-TTurrets: 2.6 positions per turretMaximum turning diameter: 125 mmDiameter above the bed: 200 mmTurning length: approx. 300 mmTailstock: noPower supply: 400 V three-phase – 50 HzControl circuit: 110 VWeight: approx. 2,600 kg Auction-ID: A1-50714-4064
CNC Control: FANUC 21i-TBNumber of axes: 3 (including C-axis)Max. rotation diameter: 120 to 150 mm (depending on tooling)Max. turning length: 120 mmX/Z axis strokes: 340 / 240 mmMax. spindle speed: up to 8,000 rpmSpindle nose: designed for precision grippers or chuckC-axis: 0.001° resolution (positioning and milling)Turret: high-precision, 12 positions (VDI 16 or VDI 20)Motorized tools: radial and axial drilling/milling, speed 4,000 to 6,000 rpmDocumentation: completeWeight (kg): 2200Year & Manufacturer: 2007 – SPINNER Auction-ID: A1-50714-4019
CNC lathe for turning and machining metal parts. CNC control: Fanuc 16 T AAMax. turning diameter: 165 mmTurning length: 100 – 340 mmDiameter above bed: 220 mmMain spindle speed: 50 – 5,000 rpmMain spindle power: 5.5 / 7.5 kWMain spindle bar passing: 65 mmSub-spindle speed: 50 – 5,000 rpmCounter-spindle power: 3.7 / 5.5 kWCounter-spindle bar passage: 42 mmC-axis: 0.001°Turrets: 2Tool positions: 2 × 16Motorized tools: 2 × 16 positionsStrokes: X 175 mm / Z 240 – 680 mmTotal power: 41 kVADimensions (mm): 3,500 × 2,800 × 2,000Weight (kg): 5,500Serial No.: 1105-02957 Auction-ID: A1-50714-4047
CNC Control: SIEMENS 840 DNumber of axes: 2Max. turning diameter: 420 mmMax. turning length: 1000 mmX/Z axis strokes: 200 / 1000 mmSpindle bore: 82 mmSpindle speed: 0 – 3,000 rpmSpindle motor power: 14.5 kWTurret: VDI 40, 12 stationsChuck: Autoblok Ø 250 mmTailstock: Chip Conveyor: PresentRemarks: Machine in good working order. Weight (kg): approx. 5500Year & Manufacturer: 2001 – MENTI Auction-ID: A1-50714-4025
CNC Control: FANUC Series 18-TNumber of axes: 3 (including C-axis)Maximum machining diameter: 200 mmDistance between tips: 300 mmMax. spindle speed: 3,000 rpmSpindle power: approx. 17.5 kWTurret: 12 fixed positions + 6 rotating positionsChuck: Ø 200 mmSpindle: direct collet mounting possibleWeight (kg): approx. 4200Year & Manufacturer: 1993 – HARDINGE Auction-ID: A1-50714-4031
