Fabricant:
(Catégorie: 106)
pressure:250 tpassage width:1280 mmstroke:bis 500 mmtotal power requirement:47 kWweight of the machine ca.:23 tdimensions of the machine ca.:2200 x 1850 x 4600 mmtable surface area:1250 x 1000 mmdayligth:800 mmdaylight between the side columns:520 x 750 mmtable height above floor:1000 mmDocuments: vorhanden
Pressure:315 tdistance between columns:1350 mmstroke:600 mmdistance table/ram, max. stroke up, adjustment up:1000 mmtable surface area:1200 x 1300 mmtable height over floor:1245 mmside window:1250 mmram surface:1200 x 1300 mmspeed down:750 mm/sspeed up:680 mm/sworking speed:180 mm/soil volume:2000 lpower requirement:150,0 kWweight:35,0 tDimensions (WxDxH):3,3 x 3,3 x 5,5 mheight over floor:5,5 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 cutting impact cushioning:motorisch verstellbar ram interlocking:hydraulisch
pressure:160 tthroat:360 mmstroke:500 mmtotal power requirement:17 kWweight of the machine ca.:7,2 tdimensions of the machine ca.:2,0 x 0,95 x 3,70 mtable-size:900 x 630 mmDocuments:vorhanden
pressure:200 tthroat:360 mmstroke:560 mmdistance table/ram, max. stroke up, adjustment up:780 mmtable surface area:740 x 720 mmpressure of drawing cushion in table:80 tstroke of drawing cushion in table:200 mmdie cushion area:530 x 530 mmtable height over floor:920 mmram surface:560 x 560 mmslide drill hole x depth:70 mmpower requirement:35,0 kWweight:10,0 tdimensions:1,3 x 2,0 x 3,4 m
pressure:160 tthroat:360 mmstroke:500 mmDocuments:vorhanden
pressure:160 tthroat:370 mmstroke:150 mmtotal power requirement:45 kWweight of the machine ca.:22 tdimensions of the machine ca.:2,75 x 1,85 x x 4,80 mrules for accident prevention:Vorhanden work table::1500 x 700 mmDocuments:vorhanden
pressure:160 tdistance between columns:1340 mmstroke:300 mmDistance table/ram, max. stroke up, adjustment up:620 mmtable surface area:1300 x 900 mmtable height over floor:930 mmside window:600 mmram surface:1300 x 900 mmspeed down:367 mm/sspeed up:390 mm/sworking speed:58 mm/spower requirement:30,0 kWweight:15,0 tDimensions (WxDxH):2,5 x 2,2 x 4,0 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 foundation pit:not necessary
pressure:20 tStroke:230 mmtable surface area:Ø600 mmdistance table - lower edge of ram:770 mmweight:595 kg
pressure:063 tstroke:70 fix mmno. of strokes:15 - 60 /mindistance between columns:1340 mmwidth between oil collecting pans:1180 mmdistance table/ram, max. stroke up, adjustment up:328 mmtable surface area:1260 x 700 mmhole in the table:1000 x 100 mmtable height over floor:1000 mmcolumn travel -side:470 mmram surface:1300 x 650 mmram adjustment:100 mmpower requirement:27,5 kWweight:13,7 tDimensions (WxDxH):3,4 x 2,1 x 3,4 mclutch:pneumatic overload protection in ram:hydraulic ram counterbalance:pneumatic ram adjustment:motoric
Pressure:063 tthroat:250 mmstroke:10 - 100 mmno. of strokes:120 /mindistance table/ram, max. stroke up, adjustment up:380 mmtable surface area:700 x 500 mmhole in the table:180 x 140 mmtable height over floor:700 mmram surface:360 x 275 mmram adjustment:60 mmpower requirement:5,5 kWweight:3,8 tDimensions (WxDxH):1,9 x 1,7 x 2,4 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:hydraulic overload protection in ram:mechanical
pressure:150 tthroat:400 mmstroke:30 - 150 mmno. of strokes:50 /mindistance table/ram, max. stroke up, adjustment up:620 mmtable surface area:1000 x 750 mmhole in the table:320 x 200 mmtable height over floor:800 mmram surface:800 x 600 mmram adjustment:85 mmweight:10,0 tDimensions (WxDxH):1,4 x 2,2 x 3,1 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic ram counterbalance:pneumatic
nominal force:2500 tstroke:600 mmcycle time:13 - 18 sdistance between columns:1720 mmDistance table/ram, max. stroke up, adjustment up:2600 mmtable surface area:1720 x 1800 mmallowed max. force:4000 tblow die to die:5000 tram surface:2100 x 1320 mmcapacity of ejector in table:40 tejector stroke in table:250 mmejector surface area in table:900 x 820 mmcapacity of ejector in ram:6 tejector stroke in ram:40 mmspindle diameter:425 mmpower requirement:900,0 kWweight:335,0 tDimensions (WxDxH):3,4 x 4,6 x 9,7 mheight over floor:8,3 mfully-automated forging line:to produce axle shaft
pressure:100 tthroat:380 mmstroke:650 mmdistance table/ram, max. stroke up, adjustment up:950 mmtable surface area:800 x 700 mmhole in the table:200 mmtable height over floor:920 mmram surface:630 x 600 mmspeed down:65 mm/sspeed up:375 mm/sworking speed:17 mm/soil volume:350 lpower requirement:18,5 kWweight:9,0 tDimensions (WxDxH):1,5 x 2,5 x 4,0 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 §20
pressure:250 tdistance between columns:1125 mmstroke:250 mmdistance table/ram, max. stroke up, adjustment up:800 mmtable surface area:1100 x 900 mmpressure of drawing cushion in table:63 tstroke of drawing cushion in table:100 mmdie cushion area:700 x 400 mmtable height over floor:960 mmside window:700 mmram surface:1080 x 900 mmoil volume:1000 lpower requirement:35,0 kWweight:23,0 tDimensions (WxDxH):2,5 x 2,3 x 4,5 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard:Sick foundation pit:not necessary
pressure:250 tthroat:450 mmstroke:36 - 126 mmno. of strokes:40 /mindistance table/ram, max. stroke up, adjustment up:525 mmtable surface area:1000 x 750 mmhole in the table:400 x 360 mmtable height over floor:1000 mmram surface:600 x 500 mmram adjustment:111 mmpower requirement:19,0 kWweight:13,5 tDimensions (WxDxH):1,3 x 3,2 x 3,35 mclutch:pneumatic overload protection in ram:mechanical ram adjustment:motoric
pressure:100 tdistance between columns:1230 mmstroke:20 - 200 mmno. of strokes:20 - 60 /mindistance table/ram, max. stroke up, adjustment up:650 mmtable surface area:1050 x 750 mmtable height over floor:760 mmside window:540 mmram surface:1000 x 750 mmram adjustment:100 mmpower requirement:18,0 kWweight:20,5 tDimensions (WxDxH):2,8 x 1,9 x 4,3 minfinitely variable drive:PIV clutch:pneumatic overload protection in ram:hydraulic ram counterbalance:pneumatic ram adjustment:motoric
pressure:160 tdistance between columns:880 mmstroke:150 mmdistance table/ram, max. stroke up, adjustment up:400 mmtable surface area:830 x 1000 mmhole in the table:265 x 365 mmtable height over floor:850 mmside window:610 mmram surface:860 x 1000 mmpower requirement:55,0 kWweight:14,7 tDimensions (WxDxH):2,2 x 2,0 x 4,3 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20 depth stop:motoric adjustable table:motoric foundation pit:not necessary
Pressure:250 tthroat:450 mmstroke:8 - 135 mmno. of strokes:50 /mindistance table/ram, max. stroke up, adjustment up:635 mmtable surface area:1250 x 850 mmhole in the table:355 mmtable height over floor:950 mmpassage to the back:660 mmram surface:790 x 610 mmram adjustment:120 mmpower requirement:18,5 kWweight:14,0 tDimensions (WxDxH):1,5 x 2,8 x 3,65 mGerman Safety: permitted for manual loading:CE-Norm - EN 692, BGR 500 clutch:pneumatisch overload protection in ram:mechanisch ram counterbalance:pneumatisch
pressure:500 tdistance between columns:2400 mmstroke:400 fix mmno. of strokes:13 - 23 /minDistance table/ram, max. stroke up, adjustment up:1600 mmtable surface area:2300 x 1800 mmcolumn travel -side:1600 mmram surface:2170 x 1800 mmram adjustment:300 mmtotal power requirement:110,0 kWWeight:135,0 tDimensions (WxDxH):3,35 x 4,85 x 7,0 mclutch:pneumatic overload protection in ram:hydraulic ram adjustment:motoric
pressure:300 tdistance between columns:2500 mmstroke:350 mmdistance table/ram, max. stroke up, adjustment up:1280 mmtable surface area:2500 x 1500 mmtable height over floor:850 mmside window:900 mmram surface:2500 x 1500 mmspeed down:300 mm/sspeed up:240 - 450 mm/sworking speed:23 - 44 mm/soil volume:3000 lpower requirement:132,0 kWweight:54,0 tDimensions (WxDxH):3,25 x 3,2 x 4,8 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 ram interlocking:SITEMA
nominal force:100 tstroke:320 mmno. of strokes:35 /mindistance between columns:360 / 250 mmDistance table/ram, max. stroke up, adjustment up:500 mmtable surface area:320 x 450 mmtable height over floor:660 mmram surface:250 x 280 mmspindle diameter:125 mmpower capacity:3,0 kWweight:4,5 tDimensions (WxDxH):2,0 x 1,6 x 3,1 m
Pressure:100 tdistance between columns:910 mmstroke:600 mmdistance table/ram, stroke up:1000 mmtable surface area:1340x680 / 910x1085 mmhole in the table:700 x 510 mmtable height over floor:800 mmside window:680 mmram surface:1230x680 / 910x1000 mmcapacity of ejector:7,5 tejector stroke:150 mmpower requirement:15,0 kWweight:9,5 tDimensions (WxDxH):2,3 x 1,9 x 3,6 mlight guard:Sick blank holder / ejector in ram:hydraulisch
pressure:150 tthroat:450 mmstroke:115 fix mmno. of strokes:45 /mindistance table/ram, max. stroke up, adjustment up:400 mmtable surface area:2250 x 1090 mmtable height over floor:900 mmpassage to the back:1900 mmram surface:1900 x 900 mmram adjustment:100 mmpower requirement:16,0 kWweight:19,5 tDimensions (WxDxH):3,0 x 2,3 x 3,9 m
pressure:200 tdistance between columns:1800 mmstroke:710 mmDistance table/ram, max. stroke up, adjustment up:1100 mmtable surface area:1600 x 1300 mmpressure of drawing cushion in table:80 tstroke of drawing cushion in table:250 mmdie cushion area:1400 x 1080 mmtable height over floor:800 mmside window:1300 mmram surface:1660 x 1300 mmspeed down:400 mm/sspeed up:410 mm/sworking speed:14,3 - 49,7 mm/spower requirement:46,0 kWweight:25,0 tDimensions (WxDxH):3,65 x 3,3 x 5,4 mheight over floor:5,05 mheight beneath floor:0,4 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard at front and back:Sick drawing cushion in table:hydraulic ejector in ram:hydraulic depth stop:mechanical
pressure:50 tdistance between columns:1750 mmstroke:500 mmDistance table/ram, max. stroke up, adjustment up:800 mmtable surface area:1700 x 750 mmtable height over floor:800 mmside window:650 x 750 mmram surface:1700 x 750 mmpower requirement:11,0 kWweight:11,0 tDimensions (WxDxH):2,1 x 1,15 x 3,4 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 foundation pit:not necessary
pressure:015 tthroat:200 mmstroke:4 - 70 mmno. of strokes:140 /mindistance table/ram, max. stroke up, adjustment up:310 mmtable surface area:430 x 395 mmhole in the table:165 x 160 mmtable height over floor:560 - 735 mmtable adjustable:175 mmram surface:160 x 130 mmram adjustment:80 mmpower requirement:1,2 kWweight:0,9 tDimensions (WxDxH):1,0 x 1,25 x 1,8 mclutch:Drehkeil overload protection in ram:mechanical
pressure:030 tstroke:8 - 40 mmno. of strokes:100 - 600 /mindistance between columns:325 mmdistance table/ram, max. stroke up, adjustment up:250 mmtable surface area:540 x 300 / 325 x 395 mmhole in the table:315 x 110 mmtable height over floor:1000 mmcolumn travel -side:290 mmram surface:250 mmmaterial width of feeder:120 mmmaterial thickness of feeder:3,0 mmfeed length:60 mmpower requirement:5,5 kWweight:2,6 tDimensions (WxDxH):1,5 x 1,2 x 2,2 mclutch:pneumatic roll feed:mechanical, Bruderer BBV 120/60
pressure:100 tthroat:350 mmstroke:6 - 100 mmno. of strokes:60 /mindistance table/ram, max. stroke up, adjustment up:400 mmtable surface area:850 x 700 mmhole in the table:470 x 150 mmtable height over floor:855 mmram surface:450 x 300 mmram adjustment:80 mmpower requirement:7,5 kWweight:5,0 tdimensions (WxDxH):1,5 x 2,3 x 2,6 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:mechanical
pressure:500 tdistance between columns:2240 mmstroke:1180 mmdistance table/ram, max. stroke up, adjustment up:1800 mmtable surface area:2050 x 1800 mmpressure of drawing cushion in table:250 tstroke of drawing cushion in table:380 mmdrawing cushion surface in table:1800 x 1200 mmpressure of drawing cushion in ram:122 tstroke of drawing cushion in ram:200 mmdrawing cushion area in ram:1800 x 1200 mmram surface:2215 x 1800 mmtable height over floor:500 mmspeed down:400 mm/sspeed up:10 - 400 mm/sworking speed:10 - 100 mm/sdepth of the foundation:3,0 mpower requirement:122 + 75 + 64,5 kWweight:110,0 tDimensions (WxDxH):3,6 x 2,2 x 8,5 mheight over floor:6,8 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table and ram:hydraulic
pressure:500 tdistance between columns:3200 mmstroke:1250 mmdistance table/ram, max. stroke up, adjustment up:1810 mmtable surface area:3000 x 1900 mmpressure of drawing cushion in ram:150 tstroke of drawing cushion in ram:200 mmdrawing cushion area in ram:2400 x 1200 mmram surface:3160 x 1900 mmspeed down:400 mm/sspeed up:250 mm/sworking speed:18 - 58 mm/sheight over floor:6,5 mpower requirement:90,0 + 36,5 kWweight:110 tGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in ram:hydraulic
