GASPARINI machine à vendre

Longueur de travail : 3 050 mm Capacité de coupe : acier de 6 mm Acier inoxydable de 4 mm Plage de butée arrière : 1 000 mm Réglage de l’angle de coupe : 0,5 - 2,5 degrés Équipé: - 4x bras de support en tôle -Pédale - Dispositif de maintien de la tôle à l’arrière - Barrière immatérielle de sécurité à l’arrière Pays d’origine : Italie Puissance moteur : 7,5 kW L x l x H : 3 500 x 2 200 x 1 700 mm Poids de la machine : 6.600 kg

N° Inv. : 6861 Type : X-Press 25 Producteur : Gasparini Création : 2005 Paramètres: Force de compression : 250 kN Distance maximale entre la table et le vérin : 340 mm Distance entre les parois du cadre : 1200 mm Course maximale : 150 mm Poids de la machine : 1770 kg

Longueur de pliage max. 3000 mm Pression max. 135 Ton Longueur de course 250 mm Contrôle DELEM DA 66 W Vitesse de déplacement rapide 0 - 100 mm/sec Vitesse de pressage 0 - 10 mm/sec Puissance du moteur principal 15 Kw

sheet width:approx. 300 mm plate thickness:approx 1,5 - 2,0 mm stations:8 column movement:80 mm Shaft adjustment - vertical -:170 The center height of lower roll is 234mm The longitudinal distance betwin roll centers is 600mm Available: only hardware from Gasparini + a hydraulic device and a small control cabinet for the cutting unit. There is no control cabinet or control included. No manufacturer number.

This GASPARINI 2040 Plasma Cutting Machine was manufactured in the year 2008 in Italy. It is equipped with a Plasma HYPERTHERM HPR 130. The machine has a cutting size of 4000x2000mm and the extension of the working area is of a 4000x2000mm. The max. sheet thickness is of 30mm and to be processed is of 60mm.

Hydraulic guillotine - Gasparini type CO-2504. Cutting length: 2550 mm x 4 mm, Cybelec DNC 10 CNC control. Full CNC change of the knife angle and the inter-knife gap, set by the computer after specifying the thickness. and length of the material. Cutting programs. Cutting sheet metal in the range of 0.4 - 4 mm. Very large loading depth of 520 mm into the machine body (photos), which enables endless cutting of sheet metal from a roll. CNC stop, departure 10 -1050 mm, retraction, programs. A very accurate and precise guillotine. Machine weight 5 tons. 2 supports and a 2000 mm long angle bracket at the front of the machine. Full original Operation and Maintenance Manual in English, BiHP position manual in Polish. A spare set of new cutting knives.

This GASPARINI XP 150/3000 Bending machine was manufactured in the 2008 in Italy. It is equipped with a DELEM DA-69W control unit. It is included with tools. The machine has a problem to starting up. There is an issue with the software, and the control screen is black.

Nominal Work Force T 100 Delem Control Da 66w Useful Bending Length Mm 3200 Controlled Axes N. 7 Notice Mm 500 Distance Of Uprights Mm 2600 Distance Of Table-rest Mm 500 Rest Stroke Mm 300 Approach Speed Mm/sec 200 Ascent Speed Mm/sec 180 Working Speed Mm/sec 10 Motor Power Kw 11 Weight T 9 Complete With: N.2 Motorized Drivers On Linear Guides Managed By Cnc Controlled Hydraulic Crowning Complete With Use And Maintenance Books Complete With Ce Certification

Press brake Gasparini PBS 105 machine currently in production in excellent condition of use CNC Delem 65 maintenance performed by photocells year 2002

pressure: 165 t chamfer lenght: 3100 mm distance between columns: 2600 mm column arm: 450 mm stroke: 250 mm dayligth: 440 mm ajustment speed: 100 mm/sec working feed: 1-10 mm/sec return speed: 120 mm/sec table height: 950 mm oil volume: 250 l operating pressure: 265 bar voltage: 380 V total power requirement: 18.5 KW weight of the machine ca.: 12600 kg range L-W-H: 3670 x 1830 x 3130 mm Machine in good / well-maintained condition () Furnishing: - DELEM CNC control - model DA 65 Swivel control panel, front right 2D graphical programming & product display Tool & program library - CNC controlled axes: Y1 + Y2 / X / R / Z1 + Z2 axis - CNC controlled back gauge (X axis) - CNC controlled height adjustment from the back gauge (R axis) - CNC controlled adjustment of the stop fingers (Z axis) - CNC controlled pneumatic table crowning (V axis) - GASPARINI hydraulic upper tool clamping - GASPA ...

pressure: 45,0 t chamfer lenght: 2050 mm distance between columns: 1600 mm column arm: 300 mm stroke: 150 mm dayligth: 395 mm ajustment speed: 100 mm/sec working feed: 1-10 mm/sec return speed: 70,0 mm/sec table width: 60,0 mm table height: 905 mm oil volume: 150 l operating pressure: 340 bar voltage: 400 V total power requirement: 5,5 KW weight of the machine ca.: 3500 kg range L-W-H: 2900 x 2100 x 2420 mm good / well-maintained condition () Furnishing: - DELEM CNC control model DA 65 Swivel control panel, front right 2D graphical programming & product display Tool & program library including new screen (installed 11/2023 .. 1.200 euros) - CNC controlled axes: Y1 + Y2 / X / R axis - CNC controlled back gauge (X axis) - CNC controlled height adjustment from the back gauge (R axis) - manual adjustment of the 2x stop fingers (Z axis) - AMADA-SYSTEM A upper tool clamping, including upp ...

Strength: 100T Folding length: 3000mm CNC: DELEM Working speed: 10mm/s State: good, fully working Status: visible

Capacity: 25 t Opening maximum: 1250 mm Workpiece height maximum: 150 mm CNC Brand: Delem CNC Model: Delem DA-66W PressbrakeGASPARINI - X-Press 25 MACH-ID 7555  Max. bending length:        1250mm Distance between column:    1200mm Max. pressing force:        25T Dis. Beam - Table:          150mm Troth beam:                 340mm Approch speed:              200mm/min. Working speed:              10mm/min. Return speed:               200mm/min. Adjustment X-Axis back gauge:500mm Number of controlled axis:  5 Power:                      3kW Length:          &nb ...

pressure: 105 t chamfer lenght: 3100 mm distance between columns: 2600 mm table width: 100 mm table height: 750 mm Control: DELEM DA 65 dayligth: 200 mm working feed: 0 - 10 mm/sec return speed: 0-100 mm/sec rapid traverse - up: max. 100 mm/sec voltage: 380 V / 50 Hz total power requirement: 11 kW weight of the machine ca.: 7,5 t dimensions of the machine ca.: 4 x 2,2 x 2,8 m Equipment: • manual back stop • upper and lower tools • 2 manual operation / foot switch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Épaisseur de la feuille: 8,00 mmvide: 0Longueur de table: 3000 mmLargeur de la table: 0 mmLongueur de couteau: 3000 mm MACH-id   4116 MAKE       Gasparini Italia TYPE         CO ANNÉE       2003 Spécifications Lecture de Controll    Digital Guillotine / Lazer / Table de découpe     Hydraulique Longueur       de coupe 3100 mm Épaisseur       maximale de la tôle 8 mm Gorge           500 mm Course de jauge     arrière X en mm      0 - 1000 mm Résonateur de puissance kW / Amp      11 kW taille Longueur       3100 mm Largeur         2100 mm Hauteur       1900 mm

Épaisseur de la tôle: 8,00 mmvide: 0Longueur de table: 3100 mmLargeur de table: 0 mmLongueur de couteau: 0 mm MACH-id    4417 MAKE        Gasparini Italia TYPE           CO 3006 ANNÉE            2003 Spécifications Guillotine / Lazer / Table à découper      Guillotine Longueur         de coupe 3100 mm Épaisseur         maximale de la tôle 8 mm Course de jauge arrière X en mm         1000 mm Résonateur de puissance kW / Amp       11 kW Contrôlel        DELEM DAC Gorge           500 mm taille Longueur          3300 mm Largeur           2800 mm Haut ...
