pressure:500 tstroke:fix 300 mmno. of strokes:20 - 70 Hub/mindistance between columns:3100 mmside window:1400 mmdistance table/ram, max. stroke up, adjustment up:1000 mmTable area:2800 x 1600 mmram surface:2800 x 1450 mmram adjustment:100 mmpower requirement:90,0 kWweight:100,0 tDimensions (WxDxH):5,75 x 3,2 x 7,8 mheight above floor:6,4 mheight beneath floor:1,4 mclutch:pneumatic; Ortlinghaus ram adjustment:motoric overload protection in ram:hydraulic ram counterbalance:pneumatic
pressure:063 tthroat:250 mmstroke:8 - 100 mmStroke rate:60 - 160 / minDistance table/ram, max. stroke up, adjustment up:415 mmTable surface area:710 x 500 mmHole in the table:250 / 280 mmTable height above floor:800 mmPassage to the back:290 mmRam surface:450 x 280 mmRam adjustment:63 mmWeight:4,3 tDimensions (WxDxH):1,5 x 1,7 x 2,7 minfinitely variable drive:PIV clutch:pneumatic overload protection in ram:mechanical
pressure:063 tthroat:250 mmstroke:8 - 100 mmStroke rate:47 - 140 / minDistance table/ram, max. stroke up, adjustment up:415 mmTable surface area:710 x 480 mmHole in the table:280 / 250 mmTable height above floor:800 mmPassage to the back:290 mmRam surface:450 x 280 mmRam adjustment:63 mmWeight:4,0 tDimensions (WxDxH):1,5 x 1,6 x 2,7 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 infinitely variable drive:PIV clutch:pneumatic overload protection in ram:mechanical
pressure:63 tthroat:270 mmstroke:160 mmDistance table/ram, max. stroke up, adjustment up:360 mmtable surface area:560 x 490 mmhole in the table:280 x 190 mmtable height above floor:850 mmram surface:450 x 360 mmoil volume:360 lpower requirement:23,0 kWweight:4,6 tdimensions (W x D x H):1,2 x 1,8 x 2,9 m
pressure:70 tdistance between columns:750 mmstroke:900 mmtable surface area:700 x 1000 mmDistance table/ram, stroke up:900 mmtable height over floor:680 mmram surface:700 x 1000 mmside window:600 mmmax. tool weight:5,0 tmax. capacity of swivelling ram plate:2,0 tSpeed down:0 - 50 mm/sSpeed up:0 - 48 mm/sWorking speed:0 - 8 mm/soil volume:140 lpower capacity:9,5 kWweight:8,0 tDimensions (WxDxH):2,2 x 1,2 x 3,7 m
pressure:250 ttable length:4000 mmtable width:3000 mmControls:SIEMENS SIMATIC C7 PRESS DESIGN:. - frame design : 4 column :. - moving bolster : yes :. PRESS FORCES:. - total force (nominal):250 toPRESS TABLE:. - clamping surface (left-right):4000 mm - clamping surface (front-back):3000 mm - tool weight max.:100000 kg - number of T-slots:12 - distance between T-slots:375 mm - height above floor level:390 mmRAM:. - clamping surface (left-right):4000 mm - clamping surface (front-back):3000 mm - number of T-slots:12 - distance between T-slots:375 mm - stroke:2900 mm - tool weight max.:50000 kgRAM (HYDR. PRESS):. - number of main-cylinders:1 - approximation velocity max.:180 mm/s - working velocity max.:50 mm/s - restoring force of ram:95 toTOOL ASSEMBLY DIMENSIONS:. - distance table - ram max.:2750 mm - distance between columns (H-frame):4100 mm - Free passage ...
pressure:40 tthroat:285 mmstroke:500 mmDistance table/ram, stroke up:630 mmtable surface area:560 x 560 mmpressure of drawing cushion in table:16 tstroke of drawing cushion in table:200 mmdie cushion area:425 x 425 mmtable height over floor:800 mmram surface:450 x 450 mmpower requirement:11,0 kWweight:4,0 tdimensions (WxDxH):1,15 x 1,8 x 2,85 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20 light guard:Sick
pressure:800 tdistance between columns:2900 mmstroke:350 mmControls:SIEMENS PRESS DESIGN:. - frame design : H-frame :. - Drive type : mechnical :. - openings in uprights : yes :. - number of cushions:0 - opening in table : yes :. - moving bolster : yes :. PRESS FORCES:. - total force (nominal):800 toPRESS TABLE:. - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - rectangular breakthrough (width):2000 mm - rectangular breakthrough (front-back):1800 mm - height above floor level:850 mmRAM:. - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - stroke:350 mm - number of strokes max:55 /minRAM (MECHAN. PRESS):. - ram adjustment:350 mmTOOL ASSEMBLY DIMENSIONS:. - shut height (stroke down, adjustment up):1100 mm - distance between columns (H-frame):2900 mm - Free passage between side columns (width):256 ...
pressure:30 tthroat:110 mmstroke:50 mmno. of strokes:35 - 80 /mindistance table/ram, max. stroke up, adjustment up:230 mmtable surface area:410 x 260 mmtable height over floor:790 mmpassage to the back:170 mmram surface:190 mmram adjustment:35 mmweight:1,3 tdimensions (WxDxH):1,0 x 1,1 x 1,8 mGerman Safety: moving screen:UVV 11.062 - VBG 7n5.1 § 6
pressure:160 tdistance between columns:1360 mmstroke:300 mmDistance table/ram, max. stroke up, adjustment up:620 mmtable surface area:1300 x 900 mmtable height over floor:950 mmside window:640 mmram surface:1300 x 900 mmpower requirement:45,0 kWweight:16,0 tDimensions (WxDxH):2,5 x 2,1 x 4,1 mcutting impact cushioning:hydraulic
pressure:600 tdistance between columns:3640 mmstroke:350 mmno. of strokes:11 - 44 /minDistance table/ram, max. stroke up, adjustment up:1550 mmtable surface area:3600 x 2500 mmsliding table:3600 x 2500 mmram surface:3600 x 2500 mmSide window:2200 mmram adjustment:400 mmmaterial width coil line:500 - 1950 mmMaterial thickness at 1200 mm material width:0,6 - 2,5 mmMaterial thickness at 1850 mm material width:0,6 - 2,0 mmMaterial thickness at 1950 mm material width:0,6 - 1,75 mmCoil weight:35,0 tcoil internal diameter:610 mmcoil external diameter:900 - 1900 mmno. of straightening rolls:13 straightening roll diameter:50 mmStack height:400 mmstacking dimensions - station 1+2 (L x W):150-2000 x 250-2000 mmstations:2 power requirement:112,0 + 35,0 kWWeight:390,0 tDimensions (WxDxH):7,3 x 5,1 x 15,0 mHeight above floor:9,1 mHeight below floor:5,9 mclutch-/ brake combination:pneumatic overload pr ...
pressure:315 tdistance between columns:1290 mmstroke:700 mmdistance table/ram, max. stroke up, adjustment up:950 mmtable surface area:1250 x 1100 mmpressure of drawing cushion in table:125 tstroke of drawing cushion in table:300 mmdie cushion area:900 x 900 mmCapacity of ejector in ram:20 tStroke of ejector in ram:250 mmtable height over floor:800 mmram surface:1250 x 1100 mmoil volume:1200 lpower requirement:40,0 kWweight:22,0 tdimensions (WxDxH):2,6 x 1,6 x 5,2 mheight over floor:4,05 mdrawing cushion in table:hydraulic ejector in ram:hydraulic cutting impact cushioning:hydraulic
Pressure:40 tthroat:330 mmstroke:250 mmdistance table/ram, max. stroke up, adjustment up:450 mmtable surface area:800 x 500 mmhole in the table:100 mmtable height over floor:900 mmram surface:100 mmSpeed down:406 mm/sSpeed up:393 mm/sWorking speed:14 mm/soil volume:350 lpower requirement:7,5 kWweight:4,6 tdimensions (WxDxH):1,3 x 2,3 x 3,4 mGerman Safety: permitted for manual loading:CE-sign depth stop:mechanical
pressure:40 tthroat:300 mmstroke:630 mmDistance table/ram, stroke up:900 mmTable surface area:620 x 520 mmHole in the table:150 mmtable height over floor:600 mmRam surface:150 mmPower capacity:15,0 kWWeight:4,5 tDimensions (WxDxH):1,0 x 1,9 x 3,0 mGerman Safety: permitted for manual loading:CE-sign
pressure:400 tdistance between columns:1060 mmstroke:450 mmno. of strokes:15 - 30 /mindistance table/ram, max. stroke up, adjustment up:1160 mmtable surface area:1000 x 700 mmcapacity of ejector in table:2 x 16 tejector stroke of ejector in table:125 mmDie cushion pressure in table:120 tDie cushion stroke in table:2 mmcapacity of ejector in ram:2 x 4 tstroke of ejector in ram:100 mmram surface:1000 x 700 mmcolumn travel -side:630 mmpower capacity:55,0 kWweight:50,0 tdie cushion in table:2. station
no. of strokes:150 /minimpact energy:420 kJdistance lower die block / ram gudeway:435 mmThroat:425 mmsteel forging - rectangular up to:110 mmsteel forging - diameter up to:125 mmpower requirement:22,0 kWweight of hammer:3,9 tweight of anvil:3,0 tram hammer weight:200 kgweight:6,9 tdimensions (WxDxH):1,1 x 2,3 x 2,4 m
Pressure:080 tthroat:345 mmstroke:20 - 160 mmno. of strokes:65 /mindistance table/ram, max. stroke up, adjustment up:495 mmtable surface area:920 x 610 mmtable height over floor:800 mmHole in the table:280 mmpassage to the back:670 mmram surface:650 x 400 mmram adjustment:50 mmpower capacity:10,0 kWweight:7,7 tDimensions (WxDxH):1,5 x 2,2 x 3,15 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:hydraulic ram adjustment:motoric
pressure:800 tdistance between columns:1050 mmstroke:200 mmno. of strokes:8 - 25 /mindistance table/ram, max. stroke up, adjustment up:1300 mmSide window:550 mmtable surface area:1030 x 900 mmCapacity of ejector in table:15 tStroke of ejector in table:85 mmram surface:1040 x 800 mmram adjustment:120 mmCapacity of ejector in ram:12 tejector stroke in ram :80 mmpower requirement:36,0 - 112,6 kWweight:65,0 tDimensions (WxDxH):3,0 x 3,1 x 6,07 mejector in table:hydraulic ejector in ram:hydraulic
pressure:315 tdistance between columns:2350 mmdistance table/ram, max. stroke up, adjustment up:1200 mmdistance between cutting impact cushioning:1600 mmDistance table/ram, stroke up:1200 mmstroke:800 mmtable surface area:2060 x 1260 mmtable height over floor:750 mmDie cushion pressure in table:100 tDie cushion stroke in table:400 mmdie cushion area:1250 x 1000 mmside window:780 mmram surface:2200 x 1500 mmCapacity of ejector in ram:63 tspeed down:500 mm/sspeed up:310 / 410 mm/sworking speed:20 - 73 mm/squantity of oil:3900 lpower requirement:80,0 + 45,0 kWweight:55,0 tDimensions (WxDxH):4,6 x 2,7 x 7,2 mHeight above floor:6,0 mHeight below floor:1,2 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 die cushion in table:hydraulic ejector in ram:hydraulic ram interlocking:hydraulic cutting impact absorption:hydraulic
pressure:160 tthroat:450 mmstroke:300 mmdistance table/ram, max. stroke up, adjustment up:580 mmtable surface area:1000 x 1000 mmdie cushion capacity:20 tdie cushion stroke:300 mmram surface:700 x 750 mmfeed down:400 mm/sfeed up:400 mm/stable height over floor:1350 mmdie cushion area:Ø 350 mmpower capacity:55 + 11 kWweight:19,5 tDimensions (WxDxH):1,5 x 3,5 x 4,6 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulisch depth stop:mechanisch
pressure:2,5 t
pressure:063 tthroat:250 mmstroke:8 - 100 mmno. of strokes:56 / 84 /mindistance table/ram, max. stroke up, adjustment up:415 mmtable surface area:710 x 500 mmhole in the table:320 mmtable height over floor:800 mmpassage to the back:320 mmram surface:450 x 280 mmram adjustment:63 mmweight:4,1 tdimensions (W x D x H):1,35 x 2,0 x 2,6 moverload protection in ram:mechanical
pressure:200 tdistance between columns:2100 mmstroke:550 mmDistance table/ram, stroke up:1800 mmtable surface area:2000 x 2800 mmtable height over floor:760 mmram surface:2000 x 2000 mmSide window:2000 mmfeed down:400 mm/spower requirement:51,0 kWweight:33,0 tdimensions (WxDxH):3,25 x 3,5 x 5,4 mHeight above floor:5,4 mfoundation pit:not necessary
pressure:200 tdistance between columns:2100 mmstroke:550 mmDistance table/ram, stroke up:1800 mmtable surface area:2000 x 2800 mmtable height over floor:760 mmram surface:2000 x 2000 mmSide window:2000 mmfeed down:400 mm/spower requirement:52,0 kWweight:33,0 tDimensions (WxDxH):3,25 x 3,5 x 5,4 mHeight above floor:5,4 mfoundation pit:not necessary
pressure:400 tdistance between columns:3250 mmdistance table/ram, max. stroke up, adjustment up:1000 mmstroke:800 mmtable surface area:3250 x 1400 mmtable height over floor:1250 mmdie cushion capacity:170 tdie cushion stroke:200 mmdie cushion area:1800 x 1000 mmdistance between cutting impact cushioning:2610 mmside window:800 mmram surface:3250 x 1400 mmreturn capacity:51 tspeed down:300 mm/sspeed up:300 mm/sworking speed:16 - 33 mm/squantity of oil:2900 lpower requirement:100,0 kWweight:70,0 tDimensions (WxDxH):4,9 x 3,1 x 7,6 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 cutting impact absorption:hydraulic
pressure:400 tdistance between columns:1250 mmstroke:250 fix mmno. of strokes:45 /mindistance table/ram, max. stroke up, adjustment up:825 mmtable surface area:1000 x 900 mmcolumn travel -side:400 x 700 mmram surface:1000 x 900 mmram adjustment:100 mmcapacity of ejector in table:40 tejector stroke:160 mmpower capacity:270,0 kWweight:44,0 tDimensions (WxDxH):2,4 x 3,6 x 7,2 mheight over floor:6,4 m
pressure:125 tstroke:25 fix mmno. of strokes:70 - 700 /mindistance between columns:1150 mmdistance table/ram, max. stroke up, adjustment up:400 mmtable surface area:1150 x 1000 mmhole in the table:900 x 220 mmside window:650 mmram surface:990 x 850 mmram adjustment:60 mmmaterial width:250 mmmaterial thickness:2,5 mmpower requirement:46,5 kWweight:29,5 troll feed:mechanical, Schuler, WK 8-250
Pressure:080 tthroat:380 mmstroke:8 - 112 mmno. of strokes:60 /mindistance table/ram, max. stroke up, adjustment up:472 mmtable surface area:840 x 610 mmtable height over floor:800 mmpassage to the back:520 mmram surface:650 x 400 mmram adjustment:70 mmpower capacity:7,5 kWweight:6,9 tDimensions (WxDxH):1,1 x 2,15 x 3,2 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:mechanical ram counterbalance:pneumatic clutch-/ brake combination:pneumatic
pressure:6 tstroke:1020 mmtotal power requirement:3,5 kWCan only adjust between tips
pressure:250 tdistance between columns:930 mmstroke:200 mmDistance table/ram, stroke up:600 mmtable surface area:900 x 860 mmdie cushion capacity:100 tdie cushion stroke:50 mmdie cushion area:350 x 400 mmtable height over floor:950 mmside window:380 x 380 mmram surface:850 x 700 mmfeed down:400 mm/sfeed up:400 mm/sworking feed:30 mm/soil volume:350 lpower capacity:45,0 kWweight:11,5 tDimensions (WxDxH):2,0 x 1,2 x 3,4 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic depth stop:mechanical foundation pit:not necessary
