Pressure:250 tthroat:450 mmstroke:8 - 135 mmno. of strokes:50 /mindistance table/ram, max. stroke up, adjustment up:635 mmtable surface area:1250 x 850 mmhole in the table:355 mmtable height over floor:950 mmpassage to the back:660 mmram surface:790 x 610 mmram adjustment:120 mmpower requirement:18,5 kWweight:14,0 tDimensions (WxDxH):1,5 x 2,8 x 3,65 mGerman Safety: permitted for manual loading:CE-Norm - EN 692, BGR 500 clutch:pneumatisch overload protection in ram:mechanisch ram counterbalance:pneumatisch
pressure:500 tdistance between columns:2400 mmstroke:400 fix mmno. of strokes:13 - 23 /minDistance table/ram, max. stroke up, adjustment up:1600 mmtable surface area:2300 x 1800 mmcolumn travel -side:1600 mmram surface:2170 x 1800 mmram adjustment:300 mmtotal power requirement:110,0 kWWeight:135,0 tDimensions (WxDxH):3,35 x 4,85 x 7,0 mclutch:pneumatic overload protection in ram:hydraulic ram adjustment:motoric
pressure:300 tdistance between columns:2500 mmstroke:350 mmdistance table/ram, max. stroke up, adjustment up:1280 mmtable surface area:2500 x 1500 mmtable height over floor:850 mmside window:900 mmram surface:2500 x 1500 mmspeed down:300 mm/sspeed up:240 - 450 mm/sworking speed:23 - 44 mm/soil volume:3000 lpower requirement:132,0 kWweight:54,0 tDimensions (WxDxH):3,25 x 3,2 x 4,8 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 ram interlocking:SITEMA
nominal force:100 tstroke:320 mmno. of strokes:35 /mindistance between columns:360 / 250 mmDistance table/ram, max. stroke up, adjustment up:500 mmtable surface area:320 x 450 mmtable height over floor:660 mmram surface:250 x 280 mmspindle diameter:125 mmpower capacity:3,0 kWweight:4,5 tDimensions (WxDxH):2,0 x 1,6 x 3,1 m
Pressure:100 tdistance between columns:910 mmstroke:600 mmdistance table/ram, stroke up:1000 mmtable surface area:1340x680 / 910x1085 mmhole in the table:700 x 510 mmtable height over floor:800 mmside window:680 mmram surface:1230x680 / 910x1000 mmcapacity of ejector:7,5 tejector stroke:150 mmpower requirement:15,0 kWweight:9,5 tDimensions (WxDxH):2,3 x 1,9 x 3,6 mlight guard:Sick blank holder / ejector in ram:hydraulisch
pressure:150 tthroat:450 mmstroke:115 fix mmno. of strokes:45 /mindistance table/ram, max. stroke up, adjustment up:400 mmtable surface area:2250 x 1090 mmtable height over floor:900 mmpassage to the back:1900 mmram surface:1900 x 900 mmram adjustment:100 mmpower requirement:16,0 kWweight:19,5 tDimensions (WxDxH):3,0 x 2,3 x 3,9 m
pressure:200 tdistance between columns:1800 mmstroke:710 mmDistance table/ram, max. stroke up, adjustment up:1100 mmtable surface area:1600 x 1300 mmpressure of drawing cushion in table:80 tstroke of drawing cushion in table:250 mmdie cushion area:1400 x 1080 mmtable height over floor:800 mmside window:1300 mmram surface:1660 x 1300 mmspeed down:400 mm/sspeed up:410 mm/sworking speed:14,3 - 49,7 mm/spower requirement:46,0 kWweight:25,0 tDimensions (WxDxH):3,65 x 3,3 x 5,4 mheight over floor:5,05 mheight beneath floor:0,4 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard at front and back:Sick drawing cushion in table:hydraulic ejector in ram:hydraulic depth stop:mechanical
pressure:50 tdistance between columns:1750 mmstroke:500 mmDistance table/ram, max. stroke up, adjustment up:800 mmtable surface area:1700 x 750 mmtable height over floor:800 mmside window:650 x 750 mmram surface:1700 x 750 mmpower requirement:11,0 kWweight:11,0 tDimensions (WxDxH):2,1 x 1,15 x 3,4 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 foundation pit:not necessary
pressure:015 tthroat:200 mmstroke:4 - 70 mmno. of strokes:140 /mindistance table/ram, max. stroke up, adjustment up:310 mmtable surface area:430 x 395 mmhole in the table:165 x 160 mmtable height over floor:560 - 735 mmtable adjustable:175 mmram surface:160 x 130 mmram adjustment:80 mmpower requirement:1,2 kWweight:0,9 tDimensions (WxDxH):1,0 x 1,25 x 1,8 mclutch:Drehkeil overload protection in ram:mechanical
pressure:030 tstroke:8 - 40 mmno. of strokes:100 - 600 /mindistance between columns:325 mmdistance table/ram, max. stroke up, adjustment up:250 mmtable surface area:540 x 300 / 325 x 395 mmhole in the table:315 x 110 mmtable height over floor:1000 mmcolumn travel -side:290 mmram surface:250 mmmaterial width of feeder:120 mmmaterial thickness of feeder:3,0 mmfeed length:60 mmpower requirement:5,5 kWweight:2,6 tDimensions (WxDxH):1,5 x 1,2 x 2,2 mclutch:pneumatic roll feed:mechanical, Bruderer BBV 120/60
pressure:100 tthroat:350 mmstroke:6 - 100 mmno. of strokes:60 /mindistance table/ram, max. stroke up, adjustment up:400 mmtable surface area:850 x 700 mmhole in the table:470 x 150 mmtable height over floor:855 mmram surface:450 x 300 mmram adjustment:80 mmpower requirement:7,5 kWweight:5,0 tdimensions (WxDxH):1,5 x 2,3 x 2,6 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:mechanical
pressure:500 tdistance between columns:2240 mmstroke:1180 mmdistance table/ram, max. stroke up, adjustment up:1800 mmtable surface area:2050 x 1800 mmpressure of drawing cushion in table:250 tstroke of drawing cushion in table:380 mmdrawing cushion surface in table:1800 x 1200 mmpressure of drawing cushion in ram:122 tstroke of drawing cushion in ram:200 mmdrawing cushion area in ram:1800 x 1200 mmram surface:2215 x 1800 mmtable height over floor:500 mmspeed down:400 mm/sspeed up:10 - 400 mm/sworking speed:10 - 100 mm/sdepth of the foundation:3,0 mpower requirement:122 + 75 + 64,5 kWweight:110,0 tDimensions (WxDxH):3,6 x 2,2 x 8,5 mheight over floor:6,8 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table and ram:hydraulic
pressure:500 tdistance between columns:3200 mmstroke:1250 mmdistance table/ram, max. stroke up, adjustment up:1810 mmtable surface area:3000 x 1900 mmpressure of drawing cushion in ram:150 tstroke of drawing cushion in ram:200 mmdrawing cushion area in ram:2400 x 1200 mmram surface:3160 x 1900 mmspeed down:400 mm/sspeed up:250 mm/sworking speed:18 - 58 mm/sheight over floor:6,5 mpower requirement:90,0 + 36,5 kWweight:110 tGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in ram:hydraulic
pressure:800 tdistance between columns:3010 mmstroke:300 mmdistance table/ram, max. stroke up, adjustment up:1350 mmtable surface area:3000 x 1800 mmtable height over floor:500 mmside window:1500 x 1400 mmram surface:3000 x 1800 mmspeed down:300 mm/soil volume:900 lheight over floor:5,4 mheight beneath floor:2,1 mpower requirement:200,0 kWweight:80,0 tDimensions (WxDxH):5,2 x 2,6 x 7,5 mram interlocking:in TDC depth stop:mechanical
nominal force:315 tstroke:300 mmno. of strokes:36 /mindistance between columns:540 mmdistance table/ram, max. stroke up, adjustment up:750 mmtable surface area:530 x 630 mmblow die to die:630 tAllowed max. force:500 tram surface:450 x 560 mmspindle diameter:180 mmpower capacity:18,0 kWweight:13,0 tDimensions (WxDxH):2,5 x 2,0 x 4,0 m
pressure:100 tdistance between columns:1060 mmstroke:700 mmdistance table/ram, max. stroke up, adjustment up:1250 mmtable surface area:1000 x 700 mmpressure of drawing cushion in table:40 tstroke of drawing cushion in table:200 mmdie cushion area:Ø 250 mmtable height over floor:950 mmside window:580 x 750 mmram surface:1000 x 700 mmoil volume:700 lpower requirement:47,0 kWweight:13,0 tDimensions (WxDxH):2,2 x 1,8 x 5,0 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 depth stop:mechanical; motoric adjustable ram interlocking:SITEMA
pressure:160 tdistance between columns:2050/1900 mmstroke:15 - 170 mmno. of strokes:15 - 40 /mindistance table/ram, max. stroke up, adjustment up:690 mmtable surface area:1600 x 800 mmside window:800 mmram surface:1620 x 700 mmram adjustment:140 mmpower requirement:15,0 kWweight:24,0 tDimensions (WxDxH):3,3 x 2,3 x 5,3 mheight over floor:4,8 mheight beneath floor:0,5 mclutch:pneumatic ram adjustment:motoric ram counterbalance:pneumatic
pressure:500 tstroke:40 - 160 mmno. of strokes:32 / 48 /mindistance between columns:1620 mmdistance table/ram, max. stroke up, adjustment up:660 mmtable surface area:1600 x 1300 mmtable height over floor:750 mmcolumn travel -side:400 x 430 mmram surface:1400 x 1200 mmram adjustment:120 mmpressure of drawing cushion in table:60 tstroke of drawing cushion in table:100 mmdrawing cushion surface in table:1300 x 810 mmmaterial width of feeder:1000 mmmaterial thickness of feeder:- 6,0 mmfeed length:350 mmheight beneath floor:0,3 mpower requirement:44,0 / 66,0 kWweight:56,0 tDimensions (WxDxH):3,55 x 2,55 x 5,1/5,8 mheight beneath floor without drawing cushion:0,3 mheight beneath floor with drawing cushion:1,0 mclutch-/ brake combination:pneumatic; Desch overload protection in ram:mechanical ram counterbalance:pneumatic ram adjustment:motoric drawing cushion in table:pneumatic Mechanical pincer ...
pressure:500 tstroke:40 - 160 mmno. of strokes:32 / 48 /mindistance between columns:1620 mmdistance table/ram, max. stroke up, adjustment up:660 mmtable surface area:1600 x 1300 mmtable height over floor:750 mmcolumn travel -side:400 x 430 mmram surface:1400 x 1200 mmram adjustment:120 mmmaterial width of feeder:1000 mmmaterial thickness of feeder:- 6,0 mmfeed length:350 mmpower requirement:44,0 / 66,0 kWweight:56,0 tDimensions (WxDxH):3,55 x 2,55 x 5,1/5,8 mheight beneath floor:0,3 mpneumatic clutch-brake combination:Desch Mechanical pincers feed:Obru, BVK 3.10.3
pressure:500 tstroke:40 - 160 mmno. of strokes:32 / 48 /mindistance between columns:1620 mmdistance table/ram, max. stroke up, adjustment up:660 mmtable surface area:1600 x 1300 mmtable height over floor:750 mmcolumn travel -side:400 x 430 mmram surface:1400 x 1200 mmram adjustment:120 mmpressure of drawing cushion in table:60 tstroke of drawing cushion in table:100 mmdrawing cushion surface in table:1300 x 810 mmmaterial width of feeder:1000 mmmaterial thickness of feeder:- 6,0 mmfeed length:350 mmpower requirement:44,0 / 66,0 kWweight:56,0 tDimensions (WxDxH):3,55 x 2,55 x 5,1/5,8 mheight beneath floor without drawing cushion:0,3 mheight beneath floor with drawing cushion:1,0 mpneumatic clutch-brake combination:Desch drawing cushion in table:pneumatic Mechanical pincers feed:Obru, BVK 3.10.3
pressure:6,3 tthroat:300 mmstroke:300 mmdistance table/ram, max. stroke up, adjustment up:800 mmtable surface area:450 x 400 mmhole in the table:80 mmtable height over floor:700 mmram surface:50 mmoil volume:90 lpower requirement:5,5 kWweight:1,35 tdimensions (WxDxH):1,8 x 2,0 x 2,7 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 depth stop:mechanical
pressure:040 tstroke:8 - 50 mmno. of strokes:50 - 300 /mindistance between columns:600 mmdistance table/ram, max. stroke up, adjustment up:285 mmtable surface area:590 x 500 mmhole in the table:590 x 40 - 100 mmtable height over floor:860 mmcolumn travel -side:280 mmram surface:590 x 380 mmram adjustment:80 mmmaterial width of feeder:150 mmpower requirement:7,5 kWclutch:pneumatic ram adjustment:motoric pincer feed:mechanical
pressure:035 tthroat:225 mmstroke:8 - 100 mmno. of strokes:110 /mindistance table/ram, max. stroke up, adjustment up:400 mmtable surface area:580 x 460 mmhole in the table:250 x 150 mmtable height over floor:700 mmtable adjustable:230 mmram surface:355 x 120 mmram adjustment:70 mmpower requirement:2,2 kWweight:1,5 tdimensions (WxDxH):1,0 x 1,5 x 2,05 mclutch:rolling key overload protection in ram:mechanical
pressure:160 tthroat:370 mmstroke:150 mmdistance table/ram, max. stroke up, adjustment up:500 mmtable surface area:1000 x 700 mmhole in the table:100 mmtable height over floor:820 mmram surface:600 x 520 mmspeed down:350 mm/sspeed up:350 mm/sworking speed:12 - 36 mm/soil volume:1100 lpower requirement:27,0 kWweight:16,5 tdimensions (WxDxH):1,8 x 2,7 x 3,95 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 depth stop:motoric adjustable
material width:450 mmmaterial thickness:0,5 - 1,0 mmno. of straightening rolls:6 straightening roll diameter:53 mmnumber of draw-in rolls:2 diameter of draw-in rolls:96 mmpower requirement:1,0 kWweight:0,65 tdimensions (WxDxH):1,0 x 1,0 x 1,55 m
pressure:100 tthroat:450 mmstroke:170 mmdistance table/ram, max. stroke up, adjustment up:450 mmtable surface area:3220 x 800 mmtable height over floor:850 mmram surface:3220 x 800 mmspeed down:50 mm/sspeed up:150 mm/sworking speed:7 mm/soil volume:600 lpower requirement:20,0 kWweight:16,0 tdimensions (WxDxH):3,7 x 2,5 x 2,6 m
pressure:080 tthroat:360 mmstroke:8 - 112 mmno. of strokes:78 /mindistance table/ram, max. stroke up, adjustment up:467 mmtable surface area:900 x 650 mmhole in the table:250 mmtable height over floor:800 mmpassage to the back:330 mmram surface:650 x 400 mmram adjustment:80 mmpower requirement:11,0 kWdimensions (WxDxH):1,2 x 2,2 x 2,9 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:mechanisch
pressure:160 tstroke:160 fix mmno. of strokes:30 - 120 /mindistance between columns:1190 mmdistance table/ram, max. stroke up, adjustment up:735 mmtable surface area:1200 x 1000 mmhole in the table:500 x 300 mmtable height over floor:900 mmside window:600 mmram surface:1000 x 800 mmram adjustment:125 mmmaterial width of feeder:550 mmmaterial thickness of feeder:0 - 6,0 mmfeed length:350 mmmaterial cross-cut:1100 mm²Feed speed:50 m/minpower requirement:45,0 kWweight:25,0 tdimensions (WxDxH):2,3 x 2,1 x 4,7 minfinitely variable drive:PIV overload protection in ram:hydraulic ram adjustment:motoric ram counterbalance:pneumatic pincer feed:mechanisch, RS 350/550 SL 90
pressure:315 tdistance between columns:1620 mmstroke:600 mmdistance table/ram, max. stroke up, adjustment up:1000 mmtable surface area:1600 x 1100 mmpressure of drawing cushion in ram:20 tstroke of drawing cushion in ram:100 mmdrawing cushion area in ram:300 x 300 mmside window:600 x 1100 mmtable height over floor:750 mmram surface:1600 x 1100 mmoil volume:1500 lpower requirement:110,0 kWweight:35,0 tdimensions (WxDxH):4,65 x 2,61 x 5,5 mheight over floor:5,05 mheight beneath floor:0,45 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in ram:hydraulic ram interlocking:pneumatic cutting impact cushioning:hydraulic
