Modello
(Fabbricante: WEINGARTEN)
usato
Pressa eccentrica per vigneto tipo AR160 tonnellate Con scudo protettivo. anno 1971 2 velocità di rotazione tramite riduttore meccanico Commutabile. Lubrificazione centralizzata. Giunto a filettatura ripida a bassa usura. Dimensioni tavola : 800x1000 mm Visite: possibili in qualsiasi momento. Peso totale circa 10,5 tonnellate
usato
Num. Inv. : 5723 Tipo: GDK 750 Produttore: Weingarten Creato: 1987 Parametri: Forza di chiusura: 866 t Dimensioni piastra: 1280x1280 mm Distanza tra i tiranti: 790x790 mm Diametro tirante: 165 mm Corsa di chiusura: 850 mm Apertura stampo: 400-900 mm Forza di iniezione: 73 t Posizioni di iniezione: 40/170/300 mm Peso: 36000 kg Dimensioni macchina: 8250x2000x3400 mm Attrezzatura: Forno Krownmatic KM 1200 (2011)
usato
WEINGARTEN ER 100 Pressa eccentrica Portata 100 t Tavolo 710 x 570 mm Spessore lamiera 12 mm Numero di colpi 55 spm Corsa pistone 8-112 Regolazione pistone 80 mm
usato
Indicazioni: Portata 40 tonnellate 2 tempi 57 + 86 H/min Sporgenza 250 mm Corsa del pistone 8 - 88 mm Regolazione dello stantuffo ca. 63 millimetri Tavolo , LxP ca. 570 x 450 millimetri Altezza massima di installazione ca. 330 millimetri
usato
Tipo/tipo: N 25 Anno di marca: 1977 Produttore / Marca: Weingarten Pressione nominale: 25 t Numero di colpi: 140 / min Raggio centro di scorrimento al telaio: 200 mm Finestra nel telaio: 240 mm Tavolo di distanza slitta: 250 mm Regolazione della corsa / regolazione della corsa: 8 ... 80 millimetri Regolabilità/regolazione ram della RAM: 50 mm Dimensioni ram / superficie della RAM: 355 x 220 mm Dimensioni della tavola / superficie del letto: 560x 400 mm Foro nel tavolo: 160 mm Potenza del motore principale: 3 kW Peso / peso: 2,23 t
usato
Weingarten Excenter Press
usato
vedere l'immagine nell'appendice
usato
usato
Press capacity: 30 ton Throat depth: 160 Ram stroke adjustable: 20 - 45 mm Slide adjustment: 10 / 60 mm Shut height (stroke down, adjustment up): 220 mm Table surface area : 470 x 300 mm Slide area: 250 x 190 mm Number of strokes: 80 - 240 s.p.m. Required power: 4 kW Dimensions L x W x H: 1.400 x 1.800 x 2.000 mm Weight of machine approx.: 2,67 ton
usato
Pressing force: 80t, max. sheet thickness: 11mm, stroke speed: 60/min, ram stroke: 8-112mm.
usato
Pressing force: 160t, max. sheet thickness: 14mm, stroke speed: 40-60/min, ram stroke: 20-120mm.
usato
Stroke speed: 57-86/min, ram adjustment: 63mm, including documentation.
usato
There are two identical eccentric presses available, nominal force: 1000kN, stroke speed: 30-85/min, stroke adjustment: 20-125mm, weight: 8t, year of construction machine 1/ 2: 1978/ 1981, with documentation.
usato
pressure:160 t throat:480 mm stroke fix:fix 180 mm no. of strokes:25 - 70 /min distance table/ram, max. stroke up, adjustment up:650 mm table surface area:1100 x 900 mm Hole in the table:450 mm table height over floor:900 mm passage to the back:700 mm ram surface:900 x 600 mm ram adjustment:144 mm power requirement:30,75 kW weight:15,3 t dimensions (WxDxH):2,0 x 2,4 x 3,75 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:pneumatic, Desch overload protection in ram:hydraulic ram counterbalance:pneumatic
usato
pressure:315 t throat:480 mm stroke:20 - 190 mm no. of strokes:36 + 45 /min distance table/ram, max. stroke up, adjustment up:615 mm table surface area:1400 x 880 mm hole in the table:250 mm table height over floor:800 mm passage to the back:950 mm ram surface:850 x 630 mm ram adjustment:125 mm power requirement:33,0 kW weight:30,0 t dimensions (WxDxH):2,0 x 3,0 x 4,4 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:pneumatic overload protection in ram:hydraulic stroke adjustment:semi-automatic ram adjustment:motoric ram counterbalance:pneumatic
usato
pressure:200 t stroke:30 - 160 mm no. of strokes:40 - 120 /min distance between columns:1500 mm distance between oil collecting pans:1300 mm distance table/ram, max. stroke up, adjustment up:860 mm hole in the table:550 x 300 mm table surface area:1250 x 1250 mm table height over floor:1000 mm column travel -side:600 x 530 mm ram surface:1250 x 1000 mm ram adjustment:125 mm Material width of feeder:30 - 500 mm Material thickness feeder:0,5 - 3,0 mm feeding length:0 - 999,9 mm power requirement:50,0 kW weight:34,0 t dimensions (WxDxH):4,0 x 1,7 x 5,2 m clutch-/ brake combination:pneumatisch, Ortlinghaus overload protection in ram:hydraulisch ram adjustment:automatisch stroke adjustment:automatisch ram counterbalance:pneumatisch roll feed:Weingarten, WE 60 Option: NEW electrical controls:Siemens S7-1500 F
usato
pressure:080 t throat:280 mm stroke:8 - 112 mm no. of strokes:30 - 120 /min distance table/ram, max. stroke up, adjustment up:500 mm table surface area:840 x 580 mm hole in the table:150 mm table height over floor:910 mm passage to the back:640 mm ram surface:560 x 300 mm ram adjustment:80 mm power requirement:7,5 kW weight:8,0 t dimensions (WxDxH):1,6 x 2,3 x 3,3 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:hydraulisch ram adjustment:motoric
usato
pressure:500 t stroke:fix 300 mm no. of strokes:20 - 70 Hub/min distance between columns:3100 mm side window:1400 mm distance table/ram, max. stroke up, adjustment up:1000 mm Table area:2800 x 1600 mm ram surface:2800 x 1450 mm ram adjustment:100 mm power requirement:90,0 kW weight:100,0 t Dimensions (WxDxH):5,75 x 3,2 x 7,8 m height above floor:6,4 m height beneath floor:1,4 m clutch:pneumatic; Ortlinghaus ram adjustment:motoric overload protection in ram:hydraulic ram counterbalance:pneumatic
usato
Pressure:080 t throat:345 mm stroke:20 - 160 mm no. of strokes:65 /min distance table/ram, max. stroke up, adjustment up:495 mm table surface area:920 x 610 mm table height over floor:800 mm Hole in the table:280 mm passage to the back:670 mm ram surface:650 x 400 mm ram adjustment:50 mm power capacity:10,0 kW weight:7,7 t Dimensions (WxDxH):1,5 x 2,2 x 3,15 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:hydraulic ram adjustment:motoric
usato
pressure:063 t throat:250 mm stroke:8 - 100 mm no. of strokes:56 / 84 /min distance table/ram, max. stroke up, adjustment up:415 mm table surface area:710 x 500 mm hole in the table:320 mm table height over floor:800 mm passage to the back:320 mm ram surface:450 x 280 mm ram adjustment:63 mm weight:4,1 t dimensions (W x D x H):1,35 x 2,0 x 2,6 m overload protection in ram:mechanical
usato
Pressure:080 t throat:380 mm stroke:8 - 112 mm no. of strokes:60 /min distance table/ram, max. stroke up, adjustment up:472 mm table surface area:840 x 610 mm table height over floor:800 mm passage to the back:520 mm ram surface:650 x 400 mm ram adjustment:70 mm power capacity:7,5 kW weight:6,9 t Dimensions (WxDxH):1,1 x 2,15 x 3,2 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:mechanical ram counterbalance:pneumatic clutch-/ brake combination:pneumatic
usato
Pressure:063 t throat:250 mm stroke:8 - 100 mm no. of strokes:120 /min distance table/ram, max. stroke up, adjustment up:415 mm table surface area:700 x 500 mm hole in the table:250 mm table height over floor:800 mm passage to the back:320 mm ram surface:450 x 280 mm ram adjustment:63 mm weight:4,5 t Dimensions (WxDxH):1,6 x 2,0 x 2,8 m overload protection in ram:mechanical
usato
pressure:500 t distance between columns:2400 mm stroke:400 fix mm no. of strokes:13 - 23 /min Distance table/ram, max. stroke up, adjustment up:1600 mm table surface area:2300 x 1800 mm column travel -side:1600 mm ram surface:2170 x 1800 mm ram adjustment:300 mm total power requirement:110,0 kW Weight:135,0 t Dimensions (WxDxH):3,35 x 4,85 x 7,0 m clutch:pneumatic overload protection in ram:hydraulic ram adjustment:motoric
usato
pressure:080 t throat:360 mm stroke:8 - 112 mm no. of strokes:78 /min distance table/ram, max. stroke up, adjustment up:467 mm table surface area:900 x 650 mm hole in the table:250 mm table height over floor:800 mm passage to the back:330 mm ram surface:650 x 400 mm ram adjustment:80 mm power requirement:11,0 kW dimensions (WxDxH):1,2 x 2,2 x 2,9 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:mechanisch
usato
pressure:080 t throat:300 mm stroke:8 - 112 mm no. of strokes:60 /min distance table/ram, max. stroke up, adjustment up:467 mm table surface area:710 x 560 mm hole in the table:240 x 115 mm table height over floor:800 mm ram surface:400 x 315 mm ram adjustment:80 mm power requirement:7,5 kW weight:5,1 t dimensions (WxDxH):1,4 x 1,9 x 2,7 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:mechanical
usato
pressure:060 t throat:220 mm stroke:6 - 94 mm no. of strokes:115 /min distance table/ram, max. stroke up, adjustment up:340 mm table surface area:680 x 400 mm hole in the table:120 x 70 mm table height over floor:750 mm passage to the back:290 mm ram surface:240 x 240 mm ram adjustment:57 mm power requirement:3,7 kW weight:2,8 t dimensions (WxDxH):1,5 x 1,5 x 2,2 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic
usato
Pressure:630 t distance between columns:1600 mm stroke:fix 250 mm no. of strokes:20 /min distance table/ram, max. stroke up, adjustment up:900 mm table surface area:1550 x 1200 mm table height over floor:800 mm side window:620 mm ram surface:1360 x 1200 mm ram adjustment:160 mm height over floor:5,9 m height beneath floor:0,6 m power requirement:32,0 kW weight:59,0 t dimensions (WxDxH):3,0 x 2,2 x 6,5 m clutch:pneumatisch overload protection in ram:hydraulisch ram adjustment:motorisch ram counterbalance:pneumatisch
usato
pressure:500 t distance between columns:3400 mm stroke:850 mm no. of strokes:9 - 18 /min distance table/ram, max. stroke up, adjustment up:2050 mm table surface area:3100 x 1900 mm table height over floor:400 mm side window:1550 mm ram surface:3100 x 1900 mm ram adjustment:350 mm pressure of drawing cushion in ram:70 t pressure of drawing cushion in table:140 t stroke of drawing cushion in table:0 - 250 mm stroke of drawing cushion in ram:150 mm height beneath floor:6,0 m height over floor:8,3 m weight:155,0 t dimensions (WxDxH):5,1 x 4,5 x 12,3 m Kind of drive:link drive tool changing unit:2 x
usato
pressure:500 t distance between columns:3400 mm stroke:850 mm no. of strokes:9 - 18 /min distance table/ram, max. stroke up, adjustment up:2050 mm table surface area:3100 x 1900 mm table height over floor:400 mm side window:1550 mm ram surface:3100 x 1900 mm ram adjustment:350 mm pressure of drawing cushion in ram:70 t pressure of drawing cushion in table:140 t stroke of drawing cushion in table:0 - 250 mm stroke of drawing cushion in ram:150 mm height beneath floor:6,0 m height over floor:8,3 m weight:155,0 t dimensions (WxDxH):5,1 x 4,5 x 12,3 m Kind of drive:link drive tool changing unit:2 x
usato
pressure:500 t distance between columns:3400 mm stroke:850 mm no. of strokes:9 - 18 /min distance table/ram, max. stroke up, adjustment up:2050 mm table surface area:3100 x 1900 mm table height over floor:400 mm side window:1550 mm ram surface:3100 x 1900 mm ram adjustment:350 mm pressure of drawing cushion in ram:70 t pressure of drawing cushion in table:140 t stroke of drawing cushion in table:0 - 250 mm stroke of drawing cushion in ram:150 mm height beneath floor:6,0 m height over floor:8,3 m weight:155,0 t dimensions (WxDxH):5,1 x 4,5 x 12,3 m Kind of drive:link drive tool changing unit:2 x
