Centros de processamento

x-travel: 1100 mmy-travel: 550 mmz-travel: 550 mmcontrol: Fanuc 0i-M Main spindle:: turning speed range - main spindle: 8000 min/-1power capacity - main spindel: 7,5 / 11 kWtool taper: SK 40 work table:: table surface area: 1200 x 600 mmmax. table load: 1200 kgTool-Presetter:: number of toolpositions: 24 pos.feeds:: rapid traverse: 30 m/minfeed: 12 m/mintotal power requirement: 25 kVAweight of the machine ca.: 7,5 tequipped with:- CNC control FANUC 0i-M and Manual Guide 0i- tool changer 24-fold (SK 40)- chip conveyor- 4 machine vices- ca. 48 Tools- Coolant system 4 bar- Spindle oil cooling system- Tapping without compensating chuckControl On 12.720h - runtime 1690hThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Centro de usinagem Alzmetall, Ano de fabricação 1996, quatro eixos, controle Heidenhein TNC 406/407. Acessórios estão disponíveis para a máquina. A máquina também estava apenas em operação de turno único no proprietário anterior. O fuso foi reinstalado em 2020.

Dados técnicos: - Capacidade de perfuração em aço ST 60 25 mm - Suporte de fuso de perfuração MK 3 8 Velocidades de fuso de perfuração 100 - 2700 rpm - Curso de fuso de perfuração de 130 mm - 4 alimenta 0,1 - 0,3 m/U - Extensão de 270 mm - Diâmetro da coluna 115 mm - Unidade de perfuração + ajustável à altura da mesa com manivela de mão sobre rack - Dimensão da mesa 350 mm - Unidade 400 V / 0,8 / 1,1 kW - Requisito de espaço aprox. W 800 x H 1850 x D 900 mm - Peso aprox. 250 kg

Key data: 3000 mm, 500 mm, 480 mm

Oferta Centro de usinagem vertical AXA VSC 2-3000 SMK construído em 1996 com copo pré-configurador de ferramentas Kalimat 250 + pico A1 Imagem 1-10 O centro de usinagem é vendido ao nosso cliente devido a uma mudança de negócios. O cliente deve participar na desmontagem e carregamento por profissionais. Guindaste interno 8t está disponível. Fabricante: AXA Maschinenbau Schöppingen Máquina no.85506 Ano construção:1996 Horas de funcionamento 21808 eleger. Curso do eixo X 3000mm /2 x 1000mm Curso do eixo Y 500mm Curso do eixo Z 480mm Versão do eixo SK 40 Trocador SMK para 30 ferramentas Painel de controle móvel com controle de caminho CNC Heidenhain TNC 407 direito Central telefónica Parafuso de rolo esférico Sistema de medição Heidenhain Unidade central de lubrificação Vogel Mini MFT Hydraulickapggregat Hydac Transportador de cavacos Conexã ...

Key data: 1000 mm, 600 mm, 650 mm

Fabricante: AXON Tipo VMC 1060 Ano de construção 2023 Controle Sinumerik 828 D Peso da máquina aprox. 5650 kg Porta-ferramentas SK 40 X-curso 1000 mm Curso Y 600 mm Curso Z 650 mm Faixa de velocidade 12.000 min-1 Carga máxima da mesa 1.000 kg Necessidade de espaço aprox. 2,90x2,20x2,9 m Tamanho da mesa: 1100 x 600 mm Número de ferramentas na revista 40 Pl Sonda 3D Renishaw OMP 40 Desligamento automático de energia M30 Pistola de refrigerante Transportador de chip de correia articulada

Key data: 1000 mm, 600 mm, 650 mm

Fabricante: AXON Tipo VMC 1060 Ano de construção 2023 Controle Heidenhain TNC 640 Peso da máquina aprox. 5650 kg Porta-ferramentas SK 40 X-curso 1000 mm Curso Y 600 mm Curso Z 650 mm Faixa de velocidade 12.000 min-1 Carga máxima da mesa 1.000 kg Necessidade de espaço aprox. 2,90x2,20x2,9 m Tamanho da mesa: 1100 x 600 mm Número de ferramentas na revista 40 Pl Fonte de refrigerante interna 12 bar Sonda 3D Renishaw OMP 40

x-viagem: 1191 mmy-travel: 1021 mmz-travel: 503 mmb-eixo: 90 c-eixo: 360 0total power requirement: kWpeso da máquina ca.c.: tdimensionais da máquina ca.m

Control: Mitsubishi Area of application: Production of chassis components made of cast iron in batches Nodular graphite in one clamping position, production of large series or largerones. Quantities, current cycle time

curso x: 1150 mmy-curso: 1000 mmz-curso: 700 mmpotência total necessária: kWpeso da máquina ca.: 23500 kgdimensões da máquina ca.: m

curso x: 1020 mmy-curso: 540 mmz-curso: 540 mmcontrolo: Fanuc potência total necessária: kWpeso da máquina ca.: 6000 kgdimensões da máquina ca.: m

Key data: 1016 mm, 610 mm, 660 mm

Bridgeport VMC 1000 - 30, Ano de fabrico 2003, Controle Heidenhain iTNC 530, Curso X/Y/Z 1016/610/660 mm, Trocador de ferramentas de 30 velocidades, BT 40 montagem, Velocidade do eixo até 12.000 rpm, Transportador Tamanho da mesa 1200 x 720 mm,

x-travel: 600 mmy-travel: 410 mmz-travel: 520 mmSpindle Speed: 8000 U/min.table length: 840 mmtable width: 420 mmengine output: 15 kWtool change unit: 16 control: SIEMENS 810 shopmill rapid traverse X- and Y-axis: 36 m/minrapid traverse Z-axis: 20 m/mintaper ISO: SK 40 dimensions: 2200x2300x2300 mmweight: 2500 kgYoutube-Video-Links:https://www.youtube.com/watch?v=lGP4FX8j_Gghttps ://www.youtube.com/watch?v=WSiuzCJw6G4The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

curso x: - mmy-curso: - mmz-curso: mmControlo: Siemens Requisito de potência total: kWpeso da máquina ca.: tdimensões da máquina ca.: m

curso x: 760 mmy-curso: 610 mmz-curso: 610 mmControle: Heidenhain 530 Necessidade de potência total: kWpeso da máquina ca.: 6700 kgdimensões da máquina ca.: m

curso x: 500 mm y-curso: 320 mm z-curso: 250+80 mm mmrequisito de potência total: kWpeso da máquina ca.: 3700 kgdimensões da máquina ca.: m

curso x: 550 mmy-curso: 320 mmz-curso: 420 mmpotência total necessária: kWpeso da máquina ca.: tdimensões da máquina ca.: m

x-travel: 550 mmy-travel: 400 mmz-travel: 360 mmControl: Sinumerik 840D total power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mCNC control Sinumerik 840D2-axes swivel rotary table (A- and C-axis)48-fold automatic tool changercoolant through spindle device (IKZ)measuring feelerchip conveyorcoolant deviceTechnische Daten / technical details:Verfahrweg X / X-Travel 550 mmVerfahrweg Y / Y-Travel 400 mmVerfahrweg Z / Z-Travel 360 mmC-Achse / C-axis 360 °A-Achse / A-axis +-100 °Rundtischdurchmesser / rotary table diameter 280 mmWerkzeugschaft / spindle taper HSK A63 Drehzahl / spindle speed 20-12000 UpM /rpmAnzahl der Werkzeugplätze / tool places in ATC 48 fachAntriebsleistung Spindel 100/60%ED / drive capacity spindle 100/60%ED 12/28 kWGewicht der Maschine ca. / weight 8700 kgTechnische Da ...

: 489-41 x-curso: 550 mmy-curso: 300 mmz-curso: 425 mmNúmero de horas de trabalho: lässt sich nicht auslesen hrefrigeração: Innen nein : máx. 10.500 4º eixo: controle de nein: Simens Sinuerik 810 peso: 4000 kg

curso x: 2000 mmy-curso: 425 mmz-curso: 425 mmNúmero de horas de trabalho: lässt sich nicht auslesen hrefrigeração: Kühlung ja : máx. 10.500 : ja controle: Simens Sinumerik 810 peso: 6700 kg

Key data: 540 mm, 540 mm, 560 mm

Fabricante: CINCINNATI Tipo CFV 550i Ano de construção 2006 Controle Heidenhain iTNC 530 Peso da máquina aprox. 4,2 t Porta-ferramentas SK 40 Curso X 540 mm Curso Y 540 mm z-curso 560 mm Faixa de velocidade 8.000 rpm Carga máxima da mesa 500 kg Necessidade de espaço aprox. 2,6 x 3 x 2,7 m Número de ferramentas na revista 30 pl. Fornecimento interno de refrigerante sim

x-travel: 730 mmy-travel: 560 mmz-travel: 560 mmcontrol: Heidenhain iTNC 530 table surface area: 1000 x 600/ Ø 600 mmtable load: 500 kgturning speeds: 12000 U/mintool magazin:: 24 tool taper: SK 40 rapid traverse: 30 m/minhead swivability: -120/+30 °range L-W-H: 3,5 x 2,4 x 2,4 mspindle drive: 15 kWinternal coolant system feed: 20 bar/ 40 l/min dimensions: 3,5 x 3,5 x 2,5 m mweight of the machine ca.: 7,0 t5- axis simultan machining centre- round table integraded in fixed table- sviable head- wireless 3D touch probe- 3D Quickset- bandfilter with 600 ltr. tank- Rotoclean- coolant pistol 2 bar- oil dust collector- elect. handwheel- safety package for power fail- user interface 4- chip conveyorThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 1.250 mmy-travel: 880 mmz-travel: 800 mmControl: HEIDENHAIN iTNC530 workpiece height max.: 1.230 mmmax. workpiece diameter: 1.250 mmNc rotary table: : numbers of pallets: 2 size of pallet: 1.000 x 800 mm: Ø 1.100 mmmax. table load: 1.000 kgc-axis: 360 x 0,001 °Universal Milling Head: - B-axis: + 180 / -7 ° - stufenlos resolution: 0,001 °max. power ED 40 %: 28 kWSpeed range, stepless: 20 - 18.000 min-1tool taper: HSK-63 DIN 69893 Form A feed, rapid traverse:: - feeds x/y/z -stepless: 0 - 15.000 mm/minrapid in X/Y/Z: 40.000 mm/mintool magazine: - Number of tool places: 60 Sttool taper: HSK-A63 voltage: 3x 400 Vconnected load: 58 kVAOverall size: - Space requirement: ca. 5,5 x 4,5 x 3,2 mweight of the machine ca.: 15.000 kg5-Axis Universal milling machine in a very sturdy design with NC rotary table, tool magazine and pallet changer, NC swivelling milling head (B-head) with  ...

x-travel: 635 mmy-travel: 510 mmz-travel: 460 mmcontrol: 840D ShopMill SiemensMain spindle:: turning speed range - main spindle: 20 - 12.000 min/-1power capacity - main spindel: 18,9 / 14 kWtool taper: SK 40 DIN 69871max. Torque: 100 / 74 Nmtension force: 8 kNwork table:: table surface area: 790 x 560 mmnumber of T-slots: 4 + 1 T-slot - distance: 100 mmT-slot - width: 4x 14H12 / 1x 14H7 mmmax. table load: 600 kgtable height over floor: 720 mmdistance spindle nose and table: 120 - 580 mmTool-Presetter:: number of toolpositions: 30 pos.Max. mould width: 80 / (130) mmmax. tool length: 250 mmmax. tool weight: 6 kgmax. total weight: 80 kgchange-time tool to tool: 1,6 secchange-time chip to chip: 6,0 secfeeds:: rapid traverse: 30 m/minfeed speeds: max. 20.000 mm/minFeed force: max. 5 kNtotal power requirement: 21 kVAweight of the machine ca.: 5,0 tdimensions of the machine ca.: 3,5 x 4,0 ...

Tampa Maho DMC 70H Ano de construção 2008 Controle: Siemens 840D Powerline Viagem X/Y/Z 800/810/810 Diâmetro máximo da peça: 880 mm Passagem rápida: 60m/min Revista de ferramentas com cadeia de 60 lugares Eixo do motor: SK 40 / 18.000 rpm Pistola de enxaguamento 1 bar / 40 l/min Extração de névoa de óleo e emulsão Painel de visualização rotativo Tanque de refrigerante com 980 l IKZ com 40 bar através do centro do eixo (filtro de correia de papel) Modo 4 Lâmpada de sinalização de 4 cores Volante elétrico Siemens 840D Transportador 2 paletes com ranhuras T 500x500 mm Sonda Renishaw MP 10 (novo)

Centro de usinagem de 5 eixos Fabricante: Deckel Maho Tipo: DMC 80 U duoBlock Ano de Marca: 2006 Controle: Siemens 840D Powerline com interface Shop Mill Percursos X/Y/Z: 800 x 800 x 800 mm Porta-paletes como eixo C (infinitamente variável) Eixo B (infinitamente variável) Tamanho da palete: 800 x 630 mm 2 paletes Eixo 20 – 10.000 rpm Trocador de ferramentas: 60 Interface: HSK A 100 IKZ 70ig Bar Tanque de refrigerante com filtro de correia de papel: aprox. 600 litros Pistola de enxaguamento Transportador Lavagem de cama Acessórios: Porta-ferramentas HSK 100 A: aprox. 190 peças Gravações Weldorn: aprox. 95 peças Suportes para cabeça de corte: aprox. 9 peças Suportes de berbequim MK: aprox. 12 peças Desparafusamento: aprox. 7 peças

x-travel: 800 mmy-travel: 800 mmz-travel: 800 mmControl: HEIDENHAIN MillPlus IT workpiece height max.: 1.330 mmtool length - max.: 450 mmmax. workpiece diameter: 800 mmNc rotary table: : surface area: Ø 800 x 630 mm: 0,001 °workpiece weight max.: 1.200 kgWidth of t-slots: 5 x Gr.14 Distance between t-slots: 100 mmcenter hole: Ø50H6 mmUniversal Milling Head: - B-axis: stufenlos 180 °resolution: 0,001 °max. power ED 40 %: 28 kWSpeed range, stepless: 20 - 18.000 min-1tool taper: HSK-63 DIN 69893 Form A feed, rapid traverse:: - feeds x/y/z -stepless: 0 - 60.000 mm/minrapid in X/Y/Z: 60.000 mm/mintool magazine: - Number of tool places: 120 Stworkpiece length: 450 mmweight of tools max.: 15 kgvoltage: 3x 400 Vconnected load: 64 kVAcontrol voltage: 24 VFuse: 100 Atotal connected load: 64 KVAOverall size: - Space requirement: ca. 4,5 x 4,6 x 3,4 mweight of the machine ca.: 17.000 kg•Eq ...

x-travel: 800 mmy-travel: 700 mmz-travel: 600 mmcontrol: iTNC 530 HeidenhainMain spindle:: turning speed range - main spindle: max. 18.000 min/-1power capacity - main spindel: 19 / 28 kWmax. Torque: 121 Nmtool taper: SK 40 DIN 69871b - axis: 0,001 °pallet changer:: numbers of pallets: 2 size of pallet: 800 x 630 mmpallet diameter: Ø 800 mmmax. table load: 800 / (1.600) kgrotatable: C: 360 °resolution: 0,001 °max. table speed: 13,6 U/minT-slots: 50 H6 tool magazin:: number of toolpositions: 60 pos.tool taper: SK 40 DIN 69871max. tool diameter: 100 mmmax. tool-dia with free toolbox: 160 mmmax. tool length: 350 / 315 mmmax. tool weight: 10 kgfeeds:: feed speeds: 20 - 15.000 mm/minrapid traverse: 50 m/mintotal power requirement: 59 kVAweight of the machine ca.: 10 tdimensions of the machine ca.: 4,0 x 7,0 x 2,7 mDocuments: Coolantsystem: high pressure coolant: 40 bar through spind ...

x-travel: 2.200 mmy-travel: 560 mmz-travel: 720 mmcontrol: 840 D Powerline ShopMill SiemensMain spindle:: turning speed range - main spindle: 20 - 12.000 min/-1power capacity - main spindel: 35 / 25 kWmax. Torque: 130 / 87 Nmtool taper: SK 40 internal coolant system feed: 40 barwork table:: table surface area: 2.600 x 600 mmmax. table load: 2.200 kgnumber of T-slots: 6 T-slot - width: 18 H7 mmT-slot - distance: 100 mmTool-Presetter:: number of toolpositions: 30 pos.max. tool length: 300 mmmax. tool weight: 6 kgmax. tool diameter: 80 / 125 mmfeeds:: feed speeds: 20.000 mm/mininput unit: 0,01 mmrapid traverse ( X / Y / Z ): 100 / 50 / 50 m/minmeasuring system: Resolution: 0,001 mmtotal power requirement: 60 kVAweight of the machine ca.: 12,5 tdimensions of the machine ca.: 6,0 x 3,7 x 2,9 mDocuments: Chip conveyor: Coolantsystem: high pressure coolant: through spindle coolant: 40 ...

x-travel: 1.000 mmy-travel: 1.000 mmz-travel: 1.000 mmControl: iTNC 530 HeidenhainMain spindle:: Max. rpm: 12.000 min/-1power capacity - main spindel: 28 / 19 kWmax. Torque: 121 / 82 Nmtool taper: HSK A63 swivellable: B: 0 - 190 °swivle time: 1,5 sNC-Rotary table:: table diameter: 1.100 x 900 mmmax. table load: 1.400 kgrotatable: C: 360 °tool magazin:: number of toolpositions: 40 pos.tool taper: HSK A63 change-time chip to chip: ca. 5,0 secfeeds:: rapid traverse ( X / Y / Z ): 60 m/minrapid traverse: B: 30 m/minrapid traverse: C: 30 m/minfeed speeds: max. 60.000 mm/mintotal power requirement: 69 kVAweight of the machine ca.: 16,8 tdimensions of the machine ca.: 6,0 x 6,5 x 3,2 mDocuments: Coolantsystem: high pressure coolant: through spindle coolant: 40 bar turning milling head: NC-rotary table: Tool Magazine: 40 pos. Chip conveyor: test probe: Heidenhain TS 640 tool monitor ...

x-travel: 1.600 mmy-travel: 1.250 mmz-travel: 1.000 mmControl: HEIDENHAIN iTNC530 Nc rotary table: : surface area: Ø 1.500 x 1.250 mm: 0,001 °workpiece weight max.: 4.000 kgUniversal Milling Head: - B-axis: stufenlos + 180 / - 7 °resolution: 0,001 °max. power ED 40 %: 28 kWSpeed range, stepless: 20 - 18.000 min-1feed, rapid traverse:: - feeds x/y/z -stepless: 0 - 15.000 mm/minrapid in X/Y/Z: 60.000 mm/mintool magazine: - Number of tool places: 60 Sttool taper: HSK-63 DIN 69893 Form A voltage: 3 x 400 Voperating frequency: 50 HzOverall size: - Space requirement: ca. 8,8 x 8,8 x 3,5 mweight of the machine ca.: 35.000 kgVersatile 5-axis universal machining center with NC – Rotary table, tool magazine and large loading door at the front.• NC-swivelling milling head with 18,000 rpm motor spindle for 5 -axis simultaneous machining• 3D CNC - -Control HEIDENHAIN iTNC530•  ...

Key data: 500 mm, 450 mm, 400 mm

1 Gebr. Centro de usinagem de 5 eixos Marca: Deckel Maho Modelo: DMU 50 Ano de Marca: 2014 Controle: Heidenhain iTNC 530 ______________________________________________________________________ _______________________________________ Especificações: Curso X - Eixo 500 mm Curso Y - Eixo 450 mm Eixo Z de curso 400 mm Área de fixação 630 x 500 mm Carga de mesa 500 kg Travessia rápida de 30 m/min. Velocidade 10.000 rqm Acionamento do eixo 13 kW Ferramenta revista lugares 60 Porta-ferramentas SK 40 Peso da máquina aprox. 4,5 t Acessórios: Torre ECO 60 Fa. Mesa rotativa giratória NC Eixo C+B Transportador Tanque de refrigerante 600 l Fonte de refrigerante interna 20 bar Volante eletrónico Sonda infravermelha Renishaw Documentação As máquinas podem ser visualizadas sob energia. O protocolo de medição está disponível. Dados  ...

Key data: 500 mm, 450 mm, 400 mm

Geral: Ano de construção 2006 Controle Heidenhain TNC 530 Distâncias de viagem X 500 mm Y 450 mm Z 400 mm Eixo: Velocidade 18.000 rpm Porta-ferramentas SK40 Trocador de ferramentas: Número de estações 60x Mesa rotativa giratória NC de 2 eixos: Eixo B 0° – 161,9° Eixo A 360° Tamanho da mesa: 500 x 380 mm Carga de mesa 200 kg Dimensões e peso: Dimensões: 3.140 mm x 2.260 mm x 2.520 mm Peso 6.500 kg Outros equipamentos e acessórios incluídos: Refrigeração da ferramenta interna IKZ 40bar Sonda M&H Transportador

x-travel: 500 mmy-travel: 420 mmz-travel: 380 mmcontrol: iTNC 530 HeidenhainMain spindle: power capacity - main spindel: 25 / 35 kWturning speeds: 20 - 18.000 U/minTorque: (40 / 100%) 130 / 87 Nmtool taper: SK 40 DIN 69871 Afeeds: Feed speed: 20.000 mm/minrapid traverse X-axis: 50 m/minrapid traverse Y-axis: 50 m/minrapid traverse Z-axis: 50 m/mintool magazin:: tools in tool magazin: 32 (2x16) max. tool length: 200 mmmax. tool weight: 6 kgmax. tool diameter: 50 mmNC-Tilting round table:: surface area: 500 x 380 mmcenter bore: 30 H6 T-slot - distance: 63 - 14H7 mmswivelling range: 0° / +180° (B-Achse) swivelling range: 360° / 0,001° (C-Achse) max. table load: 200 kgRapids C - Axes: 33 min -1rapid traverse B-axis: 26 min -1total power requirement: 38 kVAweight of the machine ca.: 6,0 tdimensions of the machine ca.: 4,7 x 5,4 x 2,6 mDocuments: Chip-Tray: Coolantsystem: oil mist ...

x-travel: 500 mmy-travel: 420 mmz-travel: 380 mmcontrol: iTNC 530 HeidenhainMain spindle: power capacity - main spindel: 25 / 35 kWturning speeds: 20 - 18.000 U/minTorque: (40 / 100%) 130 / 87 Nmtool taper: SK 40 feeds: Feed speed: 20.000 mm/minrapid traverse X-axis: 50 m/minrapid traverse Y-axis: 50 m/minrapid traverse Z-axis: 50 m/mintool magazin:: tools in tool magazin: 32 (2x16) max. tool length: 280 mmmax. tool weight: 6 kgNC-Tilting round table:: surface area: 500 x 380 mmcenter bore: 30 H6 T-slot - distance: 63 - 14H7 mmswivelling range: 0° / +180° (B-Achse) swivelling range: 360° / 0,001° (C-Achse) max. table load: 200 kgRapids C - Axes: 33 min -1rapid traverse B-axis: 26 min -1total power requirement: 38 kVAweight of the machine ca.: 6,0 tdimensions of the machine ca.: 4,7 x 5,4 x 2,6 mDocuments: Chip-Tray: Coolantsystem: oil mist extraction: W+W - EL-FI 1000 B-axis ...

curso x: 500 mmy-curso: 420 mmz-curso: 380 mmcontrole: Heidenhain requisito de potência total: kWpeso da máquina ca.: tdimensões da máquina ca.: m

x-travel: 500 mmy-travel: 400 mmz-travel: 400 mmControl: HEIDENHAIN TNC 426 Nc rotary table: : surface area: Ø 700 x 500 mmworkpiece weight max.: 200 kgSwivel range: + 95 / -10 manuell °Width of t-slots: 7 x 14 - H7 Rotation range C-axis: 360 ° manuell Distance between t-slots: 63 mmcenter hole: Ø 30 H6 mmmilling spindle: - max. power ED 40 %: 13 kWmax. torque: 1.070 NmSpeed range, stepless: 20 - 9.000 min-1tool taper: SK 40 tool claming: Mechanisch-pneumatisch feed, rapid traverse:: - feeds x/y/z -stepless: 2 - 10.000 mm/minrapid in X/Y/Z: 12.000 mm/mintool magazine: - Number of tool places: 16 Stworkpiece length: 290 mmdiameter of tools max.: 130 mmweight of tools max.: gesamt 50 kgconnected load: 17 kVAvoltage: 3x 400 Vcontrol voltage: 24 VOverall size: - Space requirement: ca. 3,5 x 3,0 x 2,5 mweight of the machine ca.: 3.000 kgEquipment / AccessoriesUniversal tool milling and ...

x-travel: 600 mmy-travel: 500 mmz-travel: 500 mmControl: iTNC 530 HSCI HeidenhainMain spindle:: turning speed range - main spindle: 20 - 18.000 min/-1power capacity - main spindel: 35 / 25 kWmax. Torque: 130 / 87 Nmtool taper: HSK-A63 swiveling-rotary-table:: table diameter: 600 x 500 mmrotatable: C: 360 °swivellable: B: +110° / -5 °speeds: B / C: 60 min/-1max. table load: 400 kgtool magazin:: number of toolpositions: 60 pos.max. tool weight: 6 kgmax. tool length: 300 mmmax. tool diameter: 80 mmmax. tool-dia with free toolbox: 130 mmfeeds:: feed speeds: 80.000 / 80.000 / 80.000 mm/minrapid traverse ( X / Y / Z ): 80 m/mintotal power requirement: 68 kVAweight of the machine ca.: 10 tdimensions of the machine ca.: 5,0 x 5,0 x 3,0 mDocuments: Chip conveyor: Coolantsystem: high pressure coolant: through spindle coolant: full splash guard: NC-Rotary Swiveling Table: tool setting ...

Key data: 630 mm, 560 mm, 560 mm

Fabricante: DECKEL MAHO Tipo DMU 60 T Ano de construção 2002 Moinho de controle Plus Peso da máquina aprox. 6,8 t Porta-ferramentas HSK 50 X-curso 630 mm Curso Y 560 mm z-curso 560 mm Faixa de velocidade 30.000 min-1 Carga máxima da mesa 500 kg Necessidade de espaço aprox. 2,45 x 3,60 x 2,30 m Tamanho da mesa 1000 x 600 mm Número de ferramentas na revista 2 x 12 Pos.

x-travel: 630 mmy-travel: 560 mmz-travel: 560 mmcontrol: iTNC 530 HeidenhainMain spindle:: turning speed range - main spindle: 20 - 12.000 min/-1power capacity - main spindel: 15 / 10 kWmax. Torque: 125 Nmtool taper: MAS BT 40 swivellable: B: 103 °feed:: feed speeds: 20 - 10.000 mm/minrapid traverse X-axis: 26 m/minrapid traverse Y-axis: 26 m/minrapid traverse Z-axis: 20 m/minResolution: 0,001 mminput unit: 0,001 mmwork table:: surface area: 1.000 x 600 mmrotary table dia.: 600 mmnumber of T-slots: 8 / 1 T-slot - width: 14 H12 / 14 H7 T-slot - distance: 63 mmmax. table loading capacity: 350 kgrotatable: C: 360 °Tool-Presetter:: number of toolpositions: 24 pos.max. tool diameter: 80 mmmax. tool-dia with free toolbox: 130 mmmax. tool length: 315 mmmax. tool weight: 8 kgtotal wight: max. 100 kgtotal power requirement: 26 kVAweight of the machine ca.: 6,7 tdimensions of the machine ca ...

x-travel: 880 mmy-travel: 630 mmz-travel: 630 mmcontrol: iTNC 530 HeidenhainMain spindle:: turning speed range - main spindle: max. 18.000 min/-1power capacity - main spindel: 28 / 19 kWmax. Torque: 121 / 82 Nmtool taper: HSK-A 63 swivellable: B: +30° / -120 °NC-Rotary table:: table surface area: Ø 700 / 1.250 x 700 mmmax. table load: 650 kgrotatable: C: 360 °max. workpiecediameter: 850 mmmax. workpiece height: 550 mmtool magazin:: number of toolpositions: 32 pos.tool taper: HSK-A 63 max. tool diameter: 80 mmmax. tool-dia with free toolbox: 160 mmmax. tool weight: 8,0 kgchange-time chip to chip: 10 secfeeds:: feed speeds: max. 30.000 mm/minrapid traverse: 30 m/minAccelaration: 5 m/s²total power requirement: 48 kVAweight of the machine ca.: 14,0 tdimensions of the machine ca.: 6,5 x 5,0 x 2,9 mDocuments: Chip conveyor: Coolantsystem: test probe: Heidenhain TS 641 3D quickSET: ...

x-travel: 880 mmy-travel: 630 mmz-travel: 630 mmcontrol: iTNC 530 HeidenhainMain spindle:: turning speed range - main spindle: 20 - 10.000 min/-1power capacity - main spindel: 13 kWTorque: 13 Nmtool taper: SK 40 work table:: table surface area: 1.250 x 700 mmmax. table load: ca. 500 kgtable diameter: 700 mmT-slots: 11x 14 x 63 mmmax. table speed: 15 min/-1tool magazin:: number of toolpositions: 32 (2x 16) pos.tool taper: SK 40 max. tool diameter: 80 / 130 mmmax. tool-dia with free toolbox: 160 mmmax. tool length: 315 mmmax. tool weight: 8,0 kgfeeds:: feed speeds: 20 - 15.000 mm/minrapid traverse: 12 m/mintotal power requirement: 30 kVAweight of the machine ca.: 9,0 tdimensions of the machine ca.: 4,0 x 3,0 x 2,5 mDocuments: swarf management system: Coolantsystem: NC-rotary table: elektr. hand wheel: Automatic Tool Changer: tool setting: CNC - MachiningCenter UniversalDECKEL M ...

x-travel: 600 mmy-travel: 700 mmz-travel: 600 mmControl: Siemens type: Millplus Table dimensions: 630x500 mmtool taper: ISO 40Cooling through the spindle: 40 barTool changer: 60 Pos.no. of tables: 2 chip conveyor: total power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 885 mmy-travel: 600 mmz-travel: 600 mmtotal power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mCNC control Heidenhain iTNC530NC swivel head (B-axis)NC-rotary table (C-axis)automatic tool changer for 60 toolschip conveyorcoolant through spindle deviceNew milling spindle mounted (0 hours)Technische Daten / technical details:X-Weg / X-travel 885 mmY-Weg / Y-travel 600 mmZ-Weg / Z-travel 600 mmB-Achse / B-axis -10 - +110 °C-Achse / C-axis 360 °Spindelaufnahme / spindle taper SK40 Drehzahlbereich Spindel / spindle speed 18000 Upm /rpmVorschub / infeed 90 m/minNC-Rundtischdurchmesser / NC-rotary table diameter 750 mmAntriebsleistung / drive capacity spindle 73 kWGewicht der Maschine ca. / weight 12000 KgTechnische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich -Tech ...

Tipo de controlo: CNC Sinumerik 840D-SL x-way 1135 mm y-way 1050 mm z-way 750 mm tamanho de mesa 1400 x 1050 mm Carga de mesa 2500 kg max. tamanho da peça de trabalho LxWxH 1400 x 1240 x 750 mm Velocidade 10000 rpm velocidades de alimentação X/Y/Z Eixo 40000 mm/min Expressspeeds x/y/z 4000mm/min Suporte de ferramentaHS KSK-A100 HSK Número de lugares na revista de ferramentas 30 lugares max. peso da ferramenta 20 kg comprimento da ferramenta 395 mm max. Diâmetro da ferramenta 110 mm Altura da máquina 3294 mm Potência de acionamento - motor de centrifugação 44 kW peso da máquina aprox. 17,9 t Requisitos de espaço aprox. 15 m2 Informação: Máquina de fresagem universal em design mono BLOCK (3 eixos) - disponível setembro 2019 - apenas 3800 horas de fuso, 13400 horas de alimentação Equipamento / Acessórios: - Sistema de refrigeração - ...

x-travel: 750 mmy-travel: 600 mmz-travel: 520 mmtotal power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mHeidenhain iTNC 530 CNC controlNC- swivel-rotary table (4. and 5. axis)32-fold tool changerchip conveyorcoolant deviceoperating mode 4Technische Daten / technical details:X-Weg längs / X-travel longitudinal 750 mmY-Weg quer / Y-travel cross 600 mmZ-Weg senkrecht / Z-travel vertical 520 mmC-Achse / C-axis 360 °B-Achse / B-axis 0- -180 °Spindelaufnahme / spindle taper SK40 Drehzahlbereich / spindle speed 18000 UpM /rpmVorschubbereich / feed range 20000 mm/minEilgang / rapid feed 50 m/minAnzahl der Werkzeugplätze / no. of tool places ATC 32 NC-Schwenkrundtischabmessungen / NC-swivel-rotary table dimensions 700x500 mmGewicht der Maschine ca. / weight 10000 KgTechnische Daten, Zubeh ...

x-travel: 880 mmy-travel: 630 mmz-travel: 630 mmControl: Heidemhain type: 426/430 spindle speed:: 18000 spindle taper: HSK 63 surface area: 1250x700 mmRotary table: 700 mmTable load: 1000 kgb-axis: Schwenkopf 0,001 °c-axis: 0-360° Rundtisch 0total power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

travel -x axis: 750 mmtravel -y axis: 600 mmtravel -z axis: 520 mmcontrol: HEIDENHAIN TNC 620 SLIMli max. Spindle speed: 12.000 U/min.capacity: 32 kVAnumbers of positions in the tool changer: 32 tool taper: SK40 max. workpiece diameter: 800 mmmax. workpiece height: 560 mmmax. workpiece weight: 350 kgMilling machining centers - universal | DMG - CMX 70 U equipped with ITC (12 bar), chip conveyor, tool changer and tool breakage controlAdditional equipment:+ B and C axisThe machine is in very good condition.Please refer to further technical details in the attachement of the offer.- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -#Tags: CMX70U | CMX 70-U | CMX 70U | DMG - CMX 70 UThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 600 mmy-travel: 560 mmz-travel: 560 mmControl: Siemens type: type of pallet-changer: size of pallet: 400x500 mmTable load: 300 kgfeed: 40.000 m/minspindle speed:: 20-8000 U/minspindle taper ISO: 40 Spindle capacity: 13/20 KWTorque: 191 NmTool changer: total power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 600 mmy-travel: 560 mmz-travel: 560 mmtable surface area: 500x400 mmcontrol: Siemens type: 840 D spindle taper ISO: 40 spindle turning speed range: 8000 U/min: type of pallet-changer: 2 Rotary table: 360 °Cooling through the spindle: barTool changer: 40 chip conveyor: total power requirement: kWweight of the machine ca.: 11,5 tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 635 mm, 510 mm, 460 mm

Geral Fabricante: DMG Tipo: DMC 635V eco Ano de Marca: 2010 Controle: Heidenhain TNC 620 Horas de ligação: 25.314 h Carga horária: 8.751 h Curso: X 635 mm Y 510 mm Z 460 mm Alimentação: X, Y, Z 0 – 20.000 mm/min Percurso rápido: 20 – 2.000 m/min Eixo Velocidade: 10.000 rpm Suporte para ferramentas: SK40 Trocador de ferramentas: 20 vezes Tabela Tamanho da mesa: 790 x 560 mm Carga da mesa: máx. 600 kg Dimensões e peso Dimensões: 2.050 mm x 2.530 mm x 2.650 mm Peso: aprox. 3.900 kg Condição Estado: Usado Funcional: Testado e totalmente funcional Outros equipamentos e acessórios incluídos: Arrefecimento interno do molde IKZ Transportador Pistola de enxaguamento Indicador luminoso LED Volante eletrónico
