Modelo
(Fabricante: MORI SEIKI)
This 3s MORI SEIKI SV-50s was manufactured in 1997. The CNC milling machine is in good working condition and has been used only a few times for prototype work. It features a FANUC spindle with a speed of 10,000 rpm and a tool changer with 30 positions. Consider the opportunity to buy this MORI SEIKI SV-50 vertical machining centre. Contact us for further details.
This 3-axis MORI SEIKI SL-403BMC/800 was manufactured in 2002. It features a maximum turning diameter of 650 mm and a maximum turning length of 863 mm. The machine offers an X-axis travel of 345 mm and a Z-axis travel of 995 mm. If you are looking to get high-quality turning capabilities, consider the MORI SEIKI SL-403BMC/800 horizontal turning machine we have for sale. Contact us for further details.
Centro de usinagem Mori Seiki M25 – FH 2/35
MORI SEIKI NT6600 CNC INTEGRADO MILL TURN CENTER COM MOAGEM AO VIVO BALANÇO MÁXIMO SOBRE CAMA: 42INCH DIÂMETRO MÁXIMO DA PEÇA DE TRABALHO: 42 polegadas COMPRIMENTO MÁXIMO DA PEÇA DE TRABALHO: 239INCH DIÂMETRO MÁXIMO DA BARRA: 6.4 polegadas FUSO BORE: 7inch X AXIS TRAVEL: 41inch Y AXIS TRAVEL: 26inch Z AXIS TRAVEL: 242inch EIXO B: +/- 120 DEG. VELOCIDADE DO FUSO PRINCIPAL: 1500 RPM MOTOR DO FUSO PRINCIPAL: 40 CV VELOCIDADE DO FUSO DE MOAGEM: 8000 RPM MOTOR DO FUSO DE MOAGEM: 40 CV ELÉTRICOS: 220V/3P/60Hz/216A OAD (APPROXIMATE): 490inch X 182inch X 169inch HIGH PESO (APROXIMADA): 120.560 LBS. EQUIPADO COM: EIXO C RIO YAXIS EIXO B FERRAMENTAS/MOAGEM AO VIVO CHUCK de 20inch Controlo CNC FS-31iA5 140 POSIÇÃO TROCA DE FERRAMENTAS AUTOMÁTICA TAILSTOCK PROGRAMÁVEL REFRIGERANTE ATRAVÉS DE FUSO (ALTA PRESSÃO) TRANSPORTADOR DE CHIPS Opções de controlo ...
x-travel:800 mm y-travel:460 mm z-travel:510 mm total power requirement:20 kW weight of the machine ca.:8 t Vertical Processing Centre 20kW is the nominal value. The spindle only needs 7.5kW. It looks like 15kW will be enough.
standard turning dia.:200 turning length:max. 810 mm control:MSX-701 MAPPS IV greates pass round over bed:800 mm Max. distance between centres:1130 mm max. turning diameter:320 mm max. workpiecediameter:300 mm bar material dia.:65 mm Traverse X-Axis 1:210 Traverse X-Axis 2:210 mm Traverse X-Axis 3:210 mm Traverse Y-Axis 1:110 (+65/-45) mm Traverse Y-Axis 2:110 (+45,/-65) mm Traverse Z-Axis 1:300 mm Traverse Z-Axis 3:300 mm Traverse Z-Axis 2:810 mm Traverse B-Axis:870 mm turning speed range - spindle:5.000 1/min Number of spindle speed ranges:2 . spindle nose:JIS A2-6 spindle bore:73 mm spindle bearing diameter:120 mm C-Axis:0,001 ° turning speed range - spindle:5.000 1/min spindle nose:JIS A2-6 spindle bore:73 mm bar material dia. max:65/52 mm spindle bearing diameter:120 mm C-Axis:0,001 ° Number of Turrets:3 . Number of tool stations:16 x 3=48 pos Schank height for square tool:20 mm D ...
turning diameter:356 mm turning length:705 mm control:MSX 850 MAPPS II swing dia.:755 mm standard turning diameter:275 mm travel -x axis:260 mm travel -y axis:100 (+-50) mm travel -z axis:795 mm rapid travel - longitudinal/face:30 / 30 m/min rapid traverse Y-axis:10 m/min Rapid travel B-axis (parts transfer subspindle):30 m/min Spindle 1 RPM:4000 1/min Spindle 1 Power:18,5/18,5/15 kW Spindle 1 max. bar diameter:80 mm Spindle 2 RPM:6000 1/min Spindle 2 power:11 / 7,5 kW turret stations / rotary tool stations:16 / 16 VDI 30 :5.5/5,5/3,7 kW speed of driven tools:6000 1/min total power requirement:39,2 kVA weight of the machine ca.:6,2 t dimensions of the machine ca.:3,1 x 2,0 x 2,2 m Spindle 1 Chuck:Kitagawa B 210 (250 mm) Spindle 2 Chuck:Kitagawa B 206 (160 mm) High precision Turning and Milling Centre with Y-axis and sub spindle. Easy programming by MAPPS II Control.
x-travel:800 mm y-travel:410 mm z-travel:510 mm control:Fanuc 10 MA rapid travel x/y/z:20/20/15 mm/min table surface area:1100 x 450 mm tool taper:BT 40 tool magazin::30 BT 40 max. tool length:250 mm max. tool weight:8 kg power requirement:7,5/5,5 kW turning speed range:6000 1/min weight of the machine ca.:6,3 t Under offer is a complete CNC tool shop, which will be given up due to old age of owner. The Mori Seiki is still highly accurate. All existing tool holders, tools, drills, vices etc. come with the machine. All measuring devices also come with the machine. Upon request orders for parts to be made can be passed on to new owner. This is a low cost all inclusive opportunity for a "Startup"
x-travel:1400 mm y-travel:1200 mm z-travel:1350 mm control:MSX- 701 Mapps III table surface area:800 x 800 mm rapid traverse:50 m/min table rotating:360.000 x 0,001 B-Achse ° table load:2,0 t numbers of pallets:2 turning speed range:8000 1/min power capacity - milling spindle:37 kW no. of tools in the magazine:60 Stück tool taper:HSK-A 100 weight:31 t dimensions:5,9 x 3,48 x 3,68 m Equipment: - Thru-the-spindel coolant system Mayfran Consep 2000 70 bar with chipconveyor - Helical cutting + Synchronized tapping - Parts program memory 1 MB - Knoll 70 bar high pressure and filter system - Electrostatic oil dust collector LTA - elect. hand wheel - renishaw probe - abso- scale i X/Y/Z- axis - 5 free m- funktions - 48 extra off sets - dual ballscrews on X/Y/Z- axis
x-travel:630 mm y-travel:600 mm z-travel:650 mm control:MSC 502 (Fanuc 16) Spindle RPM:12000 1/min spindle drive:22 / 18,5 kW rapid travel x/y/z:32 m/min Pallet dimension:500x500 mm numbers of pallets:2 table load:0,5 t working diameter:max. 610 mm Number of tool station:60 BT40 max. tool length:360 mm max. tool weight:12 kg tool changing time:1,3 sec B-axis positioning (non continuous):1 total power requirement:50 kVA weight of the machine ca.:14 t dimensions of the machine ca.:3,3 x 5,8 x 3,2 m spindle load monitor:Typ C This horizontal machining center comes with a pallet changer with 2 pallets, and has the following options: ATC 60 tool stations, High pressure coolant trough spindle interface,
turning diameter:356 mm turning length:700 mm y-axis:±60 mm spindle drive:18 kW counterspindle motor:15 kW Direct drive for driven tools:5,5 kW Motor starting torque:640 Nm Main spindle mount:A2-8 counter spindle mount:A2-6 Rod passage:80 mm main spindle speeds::4.000 U/min Drehzahl angetriebene Werkzeuge :6.000 U/min rapid traverse speed:30 m/min auf X- und Z-Achse machine weight ab.:5.800 kg 12-station turret, all positions driven C-axis on both spindles Belt-driven and infinitely variable drive on all motors Prismatic guideways on all axes Oil cooler for both spindles, manufacturer Daikin Automatic, dialog-guided programming system MAPPS Automatic monitoring of tool load and tool wear Two Renishaw measuring arms for automatic tool measurement Interfaces: USB, PCMCIA card, and RS-232 port Interface for bar feeder Automatic parts catcher Dual foot pedal for independent opening and clos ...
turning diameter: 430 mm turning length: 519-525 mm control: Mori seiki MSX-805 x-axis: 230 mm z-axis: 520 mm total power requirement: kW weight of the machine ca.: 4100 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 1.020 mm y-travel: 510 mm z-travel: 510 mm control: MSC 501 Fanuc table surface area: (APC) 1.200 x 480 mm max. table load: (APC) 550 kg Main spindle:: turning speed range - milling: 10.000 U/min power capacity - milling spindle: 22 / 18,5 kW tool taper: BT 40 Tool-Presetter:: number of toolpositions: 30 pos. tool taper: BT 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 300 mm max. tool weight: 8 kg rapid traverse: 32 m/min feed: 1 ~ 16.000 mm/min Tipp feed: 0 ~ 1.260 mm/min spindle bearing diameter: 85 mm total power requirement: 59,5 kVA weight of the machine ca.: 6,9 t dimensions of the machine ca.: 3,9 x 2,7 x 2,9 m Documents: Chip conveyor: 2x Coolantsystem: high pressure coolant: through spindle coolant: Signal-Light: pallet changer: 2 pos. CNC - Machining Center - Vertical MORI SEIKI - SV 500 B/40 - Clamping devices are NOT ...
Model: Mori Seiki MV-653/50 (Year 2000) Travels (X/Y/Z): 1530 x 660 x 650 mm (60" x 26" x 25.6") Table Size: 1700 x 660 mm (67" x 26") Spindle Taper: CAT 50 / BT 50 Spindle Speed: 6,000 RPM (High Torque) Motor Power: 22 kW (30 HP) ATC Capacity: 30 Stations Machine Weight: 16,000 kg (35,270 lbs) Find more here - / Contact us at -
x-travel: 560 mm y-travel: 560 mm z-travel: 660 mm Control: M 730 BM MAPPS IV distance spindle center to table: 80 - 640 mm distance Spindlenose and center of table: 70 - 730 mm Main spindle:: max. spindle speed: 12.000 min/-1 power capacity - main spindel: 15 / 11 kW tool taper: SK 40 spindle diameter in front bearing: 80 mm pallet changer:: numbers of pallets: 2 pos. work height max.: 1.050 mm size of pallet: 400 x 400 mm max. workpiece weight: 400 kg max. workpiecediameter: 630 mm Max. workpiece - hight: 900 mm B-Axis: 0,001 ° Indexing-time 90°: 1,3 sec change time of pallets: 8,0 sec Tool-Presetter:: number of toolpositions: 60 pos. tool taper: SK 40 max. tool diameter: 70 mm max. tool-dia with free toolbox: 170 mm max. tool length: 450 mm max. tool weight: 8 kg change-time tool to tool: 0,9 sec change-time chip to chip: 2,8 - max. 9,9 sec feeds:: feed speeds: max. 60.000 mm/mi ...
x-travel: 560 mm y-travel: 560 mm z-travel: 660 mm Control: M 730 BM MAPPS IV distance spindle center to table: 80 - 640 mm distance Spindlenose and center of table: 70 - 730 mm Main spindle:: max. spindle speed: 12.000 min/-1 power capacity - main spindel: 15 / 11 kW tool taper: SK 40 spindle diameter in front bearing: 80 mm pallet changer:: numbers of pallets: 2 pos. work height max.: 1.050 mm size of pallet: 400 x 400 mm max. workpiece weight: 400 kg max. workpiecediameter: 630 mm Max. workpiece - hight: 900 mm B-Axis: 0,001 ° Indexing-time 90°: 1,3 sec change time of pallets: 8,0 sec Tool-Presetter:: number of toolpositions: 60 pos. tool taper: SK 40 max. tool diameter: 70 mm max. tool-dia with free toolbox: 170 mm max. tool length: 450 mm max. tool weight: 8 kg change-time tool to tool: 0,9 sec change-time chip to chip: 2,8 - max. 9,9 sec feeds:: feed speeds: max. 60.000 mm/mi ...
turning diameter: 370 mm turning length: 424 mm control: Fanuc total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: 190 mm turning length: 235 mm control: FANUC/Mori MSX 501 spindle turning speed range: 50-5000 U/min turret head: 2x 16 weight of the machine ca.: 7.5 t Y- & B- axes Misc. accessories more details on www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: 190 mm turning length: 235 mm control: FANUC/Mori MSX 501 spindle turning speed range: 50-5000 U/min turret head: 2x 16 weight of the machine ca.: 7.5 t Y- & B- axes Misc. accessories more details on www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: - mm turning length: - mm control: - : ohne Gewähr total power requirement: - kW weight of the machine ca.: 4 t dimensions of the machine ca.: - m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: 660/275 mm turning length: 1498 mm control: Fanuc/Mori Seiki MSX 701 total power requirement: 90 kVA weight of the machine ca.: 26,6 t dimensions of the machine ca.: 5301 x 2997 x 2788 mm 9-axis CNC turning and milling centre Fanuc MSX-701 CNC control Milling spindle at top (B axis), as full 4th axis, positioning 0.0001 deg. 40-position tool magazine 10-position turret at bottom, all positions driven 2 x 3-jaw quick-change chuck KNCS-N 315/91 KNOLL high-pressure coolant system, pressure setting 12/25/35/45/55/62 and 72 bar, with maintenance-free rotary filter system Chip conveyor Drain system for main spindle chuck (controlled via M function) Drain system for tool cutting edge (controlled via M function) Coolant gun incl. accessories Oil mist extraction Direct measuring system X1, X2, Y-axis Bar loader interface Double foot switch for both spindles Island ...
turning diameter: 460 mm turning length: 795 mm control: MORI SEIKI M730 BM Swing diameter face slide: 590/360 mm spindle passage: 80 mm Traverse X/Z:: 260/795 mm Number of working hours: 19.552 h Cutting time: 10.704 h spindle drive: 18,5 kW total power requirement: 40 kVA weight of the machine ca.: 6,4 t dimensions of the machine ca.: 3.994 x 3.056 x 2.187 m Chip chuck Ø250 mm. Chuck sub-spindle Ø170 mm. Holder HAINBUCH chip conveyor suction Bar feeder Hydrafeed Multiservo mod MSV max. bar length 1,600 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 600 mm y-travel: 530 mm z-travel: 510 mm Control: M 730 BM MAPPS IV Main spindle:: max. spindle speed: 10.000 min/-1 power capacity - main spindel: 15 / 11 kW tool taper: SK 40 transmission ratio: 1 spindle diameter in front bearing: 80 mm work table:: table surface area: 900 x 600 mm max. table load: 800 kg T-slots: 6x 18 x 100 mm distance spindle /table: 150 - 660 mm Tool-Presetter:: number of toolpositions: 30 pos. tool taper: SK 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 150 mm max. tool length: 300 mm max. tool weight: 8,0 kg change-time tool to tool: ca. 1,3 sec change-time chip to chip: ca. 3,45 sec feeds:: rapid traverse ( X / Y / Z ): 30 m/min feed speeds: 1 - 30.000 mm/min Tipp feed: 0 - 5.000 : 20 mm/min total power requirement: 30 kVA weight of the machine ca.: 6,0 t dimensions of the machine ca.: 4,5 x 3,5 x 2,7 m Documents: Chip conveyor: ...
This 4-axis MORI SEIKI RL2500 was manufactured in 2003. It features a maximum turning diameter of 400 mm and includes two turrets with 12 stations each, providing efficient machining capabilities. The machine is equipped with a Mori Seiki MAPPS MSX-501 control and has a spindle speed of 3500 rpm. If you are looking to get high-quality turning capabilities, consider the MORI SEIKI RL2500 multi-spindle turning machine we have for sale. Contact us for further details.
CONTROLS CNC controls MORI SEIKI MSC 500 WORKING RANGE -CUBIC- number of processing axes (excl parallel axes): 3 X-axis travel: 560 mm Y-axis travel: 410 mm Z-axis travel: 460 mm TABLE table surface (left-right): 900 mm table surface (front-back): 450 mm workpiece load (max): 300 kg SPINDLE / HEAD spindle revolutions (min): 80 /min spindle revolutions (max): 8000 /min tool fixture: ISO BT 40 TOOL MAGAZINE number of positions: 20 ELECTRICAL SPECIFICATIONS mains power supply: 15.5 kVA DIMENSIONS / WEIGHTS space requirements -left/right-: 2210 mm space requirements -front/back-: 2242 mm total height: 2723 mm total weight approx.: 4200 kg
CONTROLS CNC controls MORI SEIKI MSG-501 WORKING RANGE -CUBIC- number of processing axes (excl parallel axes): 4 X-axis travel: 1300 mm Y-axis travel: 1200 mm Z-axis travel: 1100 mm TABLE table surface (left-right): 800 mm table surface (front-back): 800 mm workpiece load (max): 2000 kg SPINDLE / HEAD spindle revolutions (max): 0 /min spindle revolutions (max): 6000 /min tool fixture: ISO BT 50 AXIS DRIVES rapid traverse: 42000 mm/min TOOL MAGAZINE number of positions: 60 ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS space requirements -left/right-: 7400 mm space requirements -front/back-: 4300 mm total height: 3750 mm total weight approx.: 23500 kg ATTACHMENTS chip conveyor: yes coolant unit: yes band filtration unit: yes through spindle coolant att ...
CONTROLS CNC controls MITSUBISHI M720BM BASIC FUNCTIONS number of spindles: 2 number of turrets: 1 live positions: yes number of c-axes: 2 WORKING RANGE TURNING swing diameter (max): 700 mm turning diameter (max): 350 mm MAIN SPINDLE spindle revolutions (max): 4000 /min spindle bore diameter: 90 mm c-axis: yes X/Z SLIDE - rotation speeds (max): 6000 /min TOOL MAGAZINE number of positions: 24 ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS total weight approx.: 7500 kg ATTACHMENTS (TURNING) chip conveyor: yes coolant unit: yes hydraulic system: yes European CE standards: yes Machine in a good condition The spindle guides need to be replaced. Machine equipment (1500.- CHF (below)): - 1x double face and longitudinal turning tool holder - 3x face and longitudinal turnin ...
CONTROLS CNC controls FANUC 18 MB WORKING RANGE -CUBIC- number of processing axes (excl parallel axes): 4 .. among of them simultaneous CNC axes: 3 X-axis travel: 900 mm Y-axis travel: 800 mm Z-axis travel: 980 mm rotating range B-axis from: 0 ° rotating range B-axis up to: 360 ° TABLE table surface (left-right): 630 mm table surface (front-back): 630 mm workpiece load (max): 1200 kg SPINDLE / HEAD spindle type: horizontal spindle revolutions (max): 10000 /min AXIS DRIVES rapid traverse: 50000 mm/min TOOL MAGAZINE number of positions: 140 AUTOMATIC WORKLOAD EQUIPMENT store type: table changer number of store positions: 2 ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS total weight approx.: 19000 kg ATTACHMENTS chip conveyor: yes coolant unit: yes ban ...
MAchine está em boas condições de trabalho.
Dados técnicos mostrados na imagem. Peças mostradas à mão não vêm.
