124 MIKRON máquina utilizada para venda

This 3-axis MIKRON VCE 1000 Pro-X was manufactured in 2007. A vertical machining centre featuring a Heidenhain CNC control and a 24-tool changer, ideal for diverse and complex machining tasks. A robust choice for precision engineering. Contact us for further details regarding this vertical machining centre.

This 3-axis MIKRON VCP 1350 was manufactured in 2000. It features a Heidenhain TNC 426 M control system, X-axis travel of 1350 mm, Y-axis of 900 mm, and Z-axis of 750 mm. The machine supports a maximum workpiece weight of 1,800 kg and includes a high-speed Step-Tec HSK-A63 spindle capable of 24,000 rpm. Ideal for precision machining with a tool magazine capacity of 46 tools. Contact us for more information about this machine.

NÓS OFERECEMOS UMA MÁQUINA NOVA, MÁQUINA FOI MAIS NOVA USADA PARA O TRABALHO FOTOS ANEXADAS A MÁQUINA ESTÁ À ESPERA IMEDIATAMENTE

OFERECEMOS CONDIÇÕES MUITO BOAS - MIKRON WF3 S Detalhes técnicos: X-travel longitudinal 500 mm Y-travel cruz 500 mm Z-travel vertical 380 mm velocidade do fuso 12-passos 50-2240 UpM /rpm alimentação 1-750 mm/min eixo taper SK40 tamanho da mesa 800x445 mm capacidade de condução 7 kW peso 1650 kg

Centro de Maquinação Vertical MIKRON VCE1200+

x-travel:600 mm y-travel:500 mm z-travel:450 mm turning speeds:5 - 5000 U/min quill stroke:90 mm total power requirement:9 kW feed range:0-10.000 mm/min weight of the machine ca.:3260 kg dimensions of the machine ca.:2200x2800x2000 mm spindle:6 kW vertical milling head:SK 40 CNC universal milling machine with toolchanger, Equipped with CNC-Heidenhain TNC 407 el.handwheel coolant device oroginal table included

x-travel:600 mm y-travel:500 mm z-travel:450 mm turning speeds:5 - 5000 U/min quill stroke:90 mm total power requirement:9 kW feed range:0-10.000 mm/min weight of the machine ca.:3260 kg dimensions of the machine ca.:2200x2800x2000 mm spindle:6 kW vertical milling head:SK 40 CNC universal milling machine (without toolchanger), Equipped with CNC-Heidenhain TNC 407 el.handwheel coolant device

stations:24 weight of the machine ca.:3,5 t ·Precise serial production of part families and demanding workpieces ·Table index repeatability of ± 2.5 µm ·24 stations with up to 44 machining units for very high output rates ·Ideal for high volume production with fast cycle times

x-travel:600 mm y-travel:500 mm z-travel:450 mm weight of the machine ca.:3,5 t

Article: Transfer machine Manufacturer: Mikron Type: Multistep XS Yob: 2007 Number of modules: 4 (1 loading module, 3 process modules) Number of spindles: 6 Rotational speed : 15.000 rpm Control: Bosch Rexroth MTX Coolant unit: Knoll VRF450/2100 Extraction: Elektrostat / LTA 3D tool path correction 5/6-axis transfórmation Machine dimensions: 9.300 mm x 3.400 mm x 3.500 mm Wight per processing module: 4,5 t Wight per loading module: 2,5 t Clamping force: 10 kN Workpiece cange chip-to-chip time: 6s Workpiece: Diameter: 140 mm, Length: 180 mm, Weight: 21 kg Tool changer: Tools (2 discs with 12 positions) / processing module: 22 Weight of tool disc: 5 kg Max. tool weight: 2,5 kg Max. free tool length: 186 mm Max. tool diameter: 63 mm Max. tool diameter with free position: 105 mm Shortest chip-to-chip time:

x-travel: 600 mm y-travel: 450 mm z-travel: 450 mm control: Heidenhain iTNC530 total power requirement: kW weight of the machine ca.: 6100 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 800 mm y-travel: 600 mm z-travel: 500 mm control: Heidenhain iTNC 530 total power requirement: kW weight of the machine ca.: 8300 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Manufacturer: Mikron Model: UME600 Year of manufacture: 1995 Type of Machine: CNC milling machine Control unit: Heidenhain TNC407 Spindle taper: SK 40 Spindle speed: max. 5,000 rpm Feed rate: max. 10,000 mm/min Table size: approx. 900 × 530 mm Travel paths: X 600 mm / Y 500 mm / Z 450 mm without automatic tool changer Motor power: max. 9 kW Weight: approx: 3,200 kg Condition: - Used, good overall condition - Fully functional and ready for use Equipment / Accessories: - coolant pump - machine vice - 3D probe - Various collet sets / tool holders SK 40 - Toolbox with worktop and hand vice - Further accessories available upon request Find more here - / Contact us at -

x-travel: 500 mm y-travel: 500 mm z-travel: 400 mm table-size: 900 x 530 mm control: Heidenhain TNC 355 tool adaptor: ISO 40 | | turning speed range: 40- 4000 U/min rapid speed: 5 / 6 m/min feed speeds: 2 - 3000 | mm/min | power requirement: 6 kW table load: 350 kg dimensions: 2,6 x 1,8 x 2,2 m weight: 2,6 t Univers. milling machine 3 axis - external electric handweel - housing - universal head The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 600 mm y-travel: 500 mm z-travel: 450 mm Control: Heidenhain TNC 426 PB tool change unit: 22-fach tool taper: SK40 turning speeds: 5-6.300 U/min table-size: 900 x 530 mm table load: 400 kg total power requirement: 9 kW weight of the machine ca.: 3550 kg dimensions of the machine ca.: 2,2 x 2,7 x 2,05 m 3-axis vertical machining centre MIKRON UM 600, built in 1997 In excellent technical condition, all guides have been freshly scraped. The spindle has been re-mounted and has since been used for only 262 hours. New power unit for spindle drive installed. Accessories: Heidenhain TS 642 touch probe system 2 new vices SK40 tool holder The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 400 mm y-travel: 450 mm z-travel: 350 mm Control: Heidenhein iTNC 530 : 68 fach tool adaptor: HSK 40E turning speeds: 30.000 U/min fixed table - dimensions: 300 x 400 mm mm workpiece weight: 200 kg pallet table size: 320 x 320 mm feed speeds autom. x/y/z: 40 m/min. spindle drive motor: 13 kW Number of working hours: 32369 h total power requirement: 16 kW weight of the machine ca.: 7.500 kg Machine still in the delivery factory: Condition: ready for operation: CE signed: Electric 380 Volt: Palett changer: 7-fach Cabin: Tool magazin places number: 68 High-speed 3-axis universal machining center with 7-station pallet changer. Operating hours: 44,899 hours. Load hours: 32,369 hours. Spindle time since replacement: 13,350 hours. Gantry-style machine with a solid monoblock polymer concrete construction, compact linear ball bearings, Heidenhain direct measuring system, hydraulic  ...

x-travel: 1.200 mm y-travel: 600 mm z-travel: 675 mm Control: Heidenh.iTNC 620 HSCI FS table-size: 1.220 x 620 mm : 40 fach Distance between table and spindle: 735 mm turning speeds: 10.000 U/min spindle drive: 18 kW Internal cooling system: 30 bar total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m -Electronic steering wheel. -LINEAR RULES. -Laser probe measuring tools. -Preparation for piece measuring probes. PROBE NOT INCLUDED. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Manufacturer: Mikron Model: VCP 1000 (ITNC 530 Control) Year of Manufacture: 2004 Weight: 10,500 kg Power Supply: 400 V / 50 Hz / 3 Phases Current: 100 A Power Consumption: 40 kW Control Circuit Voltage: 24 VDC Sound Level: 68 dB(A) Find more here - / Contact us at -

Manufacturer: Mikron Model: VCP 1350 Year of Manufacture: 1999 Weight: 10,100 kg Power Supply: 3 Phase, 400 V, 50 Hz Current: 125 A Power Consumption: 46 kW Control Circuit Voltage: 24 VDC Sound Level: 75 dB(A) Certification: CE Find more here - / Contact us at -

x-travel: 1000 mm y-travel: 600 mm z-travel: 600 mm control: Heidenhain TNC 426 spindle nose: 100-700 mm work table:: 1.080 x 580 mm workpiece weight max.: 550 kg T-slots: 7 Stk. T-slot - width: 14 mm tool piece magazine with: 36 Plätzen weight of tools max.: 8 kg tool length - max.: 340 mm total power requirement: kW weight of the machine ca.: 6,2 t dimensions of the machine ca.: 4.790 x 5.330 x 2.905 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-axis: 1350 mm y-axis: 1150 mm z-axis: 895 mm control: HEIDENHAIN iTNC 530 turning speeds: 15000 U/min tool taper: HSK-A63 surface area: 1100 x 1000 mm max. table load: 1600 kg numbers of tools in magazin: 92 spindle drive: 30 / 38 kW A-Axis: -16 / +120 ° total power requirement: 58 kW weight of the machine ca.: 12,6 t dimensions of the machine ca.: 5100 x 2300 x 3090 m 2023 new Spindle machine equipped with: - CNC Control Heidenhain TNC 530 - swivel head, direct drive ‘High Torque’ motor - Autom. Tool change: 46-position tool magazine - High pressure cooling through spindle – Chip evacuator – Tool control with duallaser – Radio frequency probe – Airthrough spindle – APS(Advanced Process System) & ITC(Intelligent Thermal Control) - Renishaw probe Machine on: 6680h, active drives: 4876h, spindle: 2657h The data for this ad was created with ModulMWS - the software solutio ...

Manufacturer: Mikron Model: Multi X Year of Manufacture: 2020 Technical Specifications: - Weight: 24,500 kg - Rated Voltage: 400 Vac - Rated Current: 75 A - Power Consumption: 45 kW - Control Voltage: 24 Vdc - Auxiliary Voltage: 230 Vac - Frequency: 50 Hz - Max Fuse Rating: 80 A - Phases: 3P + PE (Three-phase with protective earth) - Air Pressure Requirement: 6 bar Certifications: - CE Marked Find more here - / Contact us at -

This 3-axis MIKRON UME600 was manufactured in 1995. It features a maximum spindle speed of 5,000 rpm and a feed rate of up to 10,000 mm/min. The table size is approximately 900 × 530 mm, providing ample workspace for various machining tasks. If you are looking to get high-quality milling capabilities, consider the MIKRON UME600 vertical machining centre we have for sale. Contact us for further details.

Máquina de fresagem universal MIKRON WF 3 DCM Controlo do Heidenhain TNC 151 Tabela 800x380 mm X-travel 500 mm Y-travel 500 mm Z-curso 400 mm Gama de velocidades 3150 rpm potência motriz 4 kW SK 40 Peso: 1700 kg Muitos acessórios e ferramentas

CONTROLS   CNC controls HEIDENHAIN ITNC 530 WORKING RANGE -CUBIC-   number of processing axes (excl parallel axes): 5   X-axis travel: 600 mm   Y-axis travel: 450 mm   Z-axis travel: 450 mm   rotating range B-axis from: -115 °   rotating range B-axis up to: 30 °   rotating range C-axis from: 0 °   rotating range C-axis up to: 360 ° TABLE   clamping surface diameter: 450 mm   workpiece load (max): 200 kg SPINDLE / HEAD   spindle revolutions (max): 20000 /min AXIS DRIVES   rapid traverse X: 22000 mm/min TOOL MAGAZINE   number of positions: 220 ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 4400 mm   space req ...

curso x: 710 mm y-curso: 500 mm z-curso: 500 mm tamanho da mesa: 1080x580 mm cone do fuso: SK40 faixa de velocidade de giro do eixo: 10000 U/min unidade de mudança de ferramenta: 30 peso da máquina ca.: 10 t HEIDENHAIN TNC430 Líquido de arrefecimento através do eixo

Controle: Fabricação: HEIDENHAIN iTNC 530 x-curso: 800 mm y-curso: 500 mm z-curso: 540 mm tamanho da mesa: 910x500 mm faixa de velocidade de giro do eixo: 10000 U/min ferramenta magazin:: 24 peso da máquina ca.: 8 t HEIDENHAIN TNC-426 Preparado para o 4º eixo

x-travel: 1600 mm y-travel: 900 mm z-travel: 800 mm control: HEIDENHAIN iTNC 530 for axes: 3 table surface area: 1700x850 mm tool magazin:: 30 spindle taper:: SK 40 spindle turning speed - stepless: 100-10000 U/min feeds infinitely variable to rapid traverse: 2-20000 mm/min voltage: 400 V dimensions of the machine ca.: 385x420x325 cm weight of the machine ca.: 18.6 t Coolant through spindle: pressure: 18 bar 3D measuring tracer: RENISHAW The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

with CNC-path-control: HEIDENHAIN type: iTNC 530 for axes: 3 x-travel: 1020 mm y-travel: 560 mm z-travel: 600 mm table surface area: 1000x560 mm table load: 1.35 t tool magazin:: numbers of tools: 40 max. tool diameter: 76 mm max. tool-dia with free toolbox: 125 mm max. tool length: 305 mm max. tool weight: 7 kg milling head: spindle taper:: SK40 spindle turning speed - stepless: 100-10000 U/min Power: 12/18 KW feeds -stepless-: 16000 mm/min rapid motion -longitudinal/cross/vertical: 40 m/min dimensions of the machine ca.: 3x2.3x2.6 m weight of the machine ca.: 6.8 t 3D measuring tracer: RENISHAW OMP40 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
