Frezarka do wytaczania pionowego FRORIEP CNC Podwójna kolumna PRZEBUDOWANY I MODERNIZACJA CNC W 1999 ROKU FUNKCJE: SIEMENS 840D STEROWANIE CNC 2-PIONOWE GŁOWICE PAMIĘCI RAM POJEMNOŚĆ: ŚREDNICA STOŁU: 10 000mm ŚREDNICA TOCZENIA Z PIONOWYMI TRYMAMI: 15 000 mm MAKSYMALNA WYSOKOŚĆ TOCZENIA: 5000 mm SKOK PIONOWY RAM: 2000 mm RAM OBROTOWY +/- 30/15 DEG MAKSYMALNA SIŁA SKRAWANIA PRAWEJ SZYNY HD: 25t ŁADOWNOŚĆ STOŁU: 200t TABELA ZAKRESÓW PRĘDKOŚCI, ZMIENNA INF: 4 PRĘDKOŚCI STOŁOWE: OD 0,13 DO 13 OBR./MIN SILNIK ELEWACJI POPRZECZNEJ: 40.23 KM LICZBA KANAŁÓW, PIONOWYCH I HORIZ: 30 SILNIK REGULACJI SZYNY POPRZECZNEJ 86 KM SILNIKI SZYBKIEGO OBROTU: 15,5 KM SILNIK GŁÓWNY: 250 KM WYPOSAŻONE: SIEMENS 840D STEROWANIE CNC NOWY 1999 PODWÓJNE STEROWANIE WISZĄCE 2-PIONOWE SIŁOWNIKI STEROWANE CNC STÓŁ Z ROWKIEM T O ŚREDNICY 10 000 MM 4-SZ ...
MORI SEIKI NT6600 CNC ZINTEGROWANE CENTRUM TOKARSKIE FREZARKI Z FREZOWANIEM NA ŻYWO MAKSYMALNA HUŚTAWKA NAD ŁÓŻKIEM: 42 cale MAKSYMALNA ŚREDNICA OBRABIANEGO PRZEDMIOTU: 42 cale MAKSYMALNA DŁUGOŚĆ OBRABIANEGO PRZEDMIOTU: 239 cali MAKSYMALNA ŚREDNICA PRĘTA: 6,4 cala OTWÓR WRZECIONA: 7 cali PRZESUW OSI X: 41 cali PRZESUW OSI Y: 26 cali PRZESUW OSI Z: 242 cale OŚ B: +/- 120 STOPNI. PRĘDKOŚĆ OBROTOWA GŁÓWNEGO WRZECIONA: 1500 OBR./MIN SILNIK WRZECIONA GŁÓWNEGO: 40 KM PRĘDKOŚĆ OBROTOWA WRZECIONA FREZUJĄCEGO: 8000 OBR./MIN SILNIK WRZECIONA FREZUJĄCEGO: 40 KM ELEKTRYKA: 220V / 3P / 60Hz / 216A OAD (W PRZYBLIŻENIU): 490 cali X 182 cale X 169 cali WYSOKOŚCI WAGA (W PRZYBLIŻENIU): 120 560 FUNTÓW. WYPOSAŻONE: OŚ C YAXIS OŚ B OPRZYRZĄDOWANIE/FREZOWANIE NA ŻYWO 20-calowy uchwyt FS-31iA5 STEROWANIE CNC 140-POZYCYJNY AUTOMATYCZNY ZMIENIACZ NARZĘD ...
TOKARKA PRZĘDZALNICZA CNC PRODUCENT: M+M MODELU: HF450TT / 2S NUMER SERYJNY: 26-2453-00 ROK: 2000 PRODUCENT I MODEL STEROWANIA: Tracktronic WYSOKOŚĆ ŚRODKA OSI Z: 419 mm ODLEGŁOŚĆ MIĘDZY ŚRODKAMI: 1200 mm ADAPTER NARZĘDZIOWY Z -AXIS: DIN 55027 / Rozmiar 15 MOC NAPĘDU Z-AXIS: 80kW NAPĘD Z -AXIS ZF WSPÓŁCZYNNIK REDUKCJI: 1:4 PRĘDKOŚĆ NAPĘDU Z-AXIS: 0-1000 obr./min krok mniej zmienna X - PRZESUW PROWADNICY: 500MM X - SIŁA NACISKU: 100kN X - PRĘDKOŚĆ POŚLIZGU: 400 mm / min Y - PRZESUW PROWADNICY: 275MM Y - SIŁA NACISKU: 100kN Y - PRĘDKOŚĆ POŚLIZGU: 400 mm / min SKOK KONIKA: 600mm SIŁA ZACISKU KONIKA: 80kN SKOK WYRZUTNIKA: 450mm PŁYN CHŁODZĄCY: tak ZASILANIE 3 FAZY / 50-60 Hz / 200 - 500 Woltów: 3PH / 60Hz / 480V istniejące CECHY SZCZEGÓLNE LUB DODATKOWE ELEMENTY: MOC ZNAMIONOWA 204 KM (152 Kw), NAPIĘCIE STERUJĄCE 110 V / 24 V DC M ...
turning diameter:33 mmturning length:330 mmcontrol: 840 total power requirement:20 kWweight of the machine ca.:6 tdimensions of the machine ca.:3850,2000,2100 m17 axes3 revolvers with the powered tools 1 gantry with the driven tools Main and counter spindle with C axesBarfeederMachine On-time 58,133 hours
turning diameter:480 mmturning length:800 mmtotal power requirement:30 kWturning diameter over bed slide:240 spindle bore:65 mmdisc turret:12 fachrapid travel range:20 / 10 m/minweight of the machine ca.:4,5 tdimensions of the machine ca.:4 x 2,2 x 2,1 mwith CNC TRAUB TX 8 H C-axis driven tooling, 6 positions 3,5 kW / 4000 rpmpower chuckcoolant attachment, chip conveyordiverse toolholders
turning length:400 mmtotal power requirement:45 kWweight of the machine ca.:4 tdimensions of the machine ca.:3,58 x 1,91 x 2,05 mspindle passage:45 mm
turning diameter:500 mmturning length:1000 mmweight of the machine ca.:7,3 tdimensions of the machine ca.:6,5 x 4,45 x 2,21 m
turning diameter:120 mmturning length:100 mmcontrol:Fanuc Spindle 1 power:7,5 kWSpindle 1 RPM:4500 1/minSpindle 2 power:7,5 kWSpindle 2 RPM:4500 1/minDistance between spindle noses:600 mmTurret No.1 stations / rotary tools:15/15 Power rotary tools turret 1:2,7 kWRPM of rotary tools turret 1:4000 1/minTurret No.2 stations / rotary tools:15/15 Power rotary tools turret 2:2,7 kWRPM of rotary tools turret 2:4000 1/minTravel x/z turret 1:250 / 300 mmTravel x/z turret 2:250 / 920 mmBar capacity spindle 1:51 mmBar capacity spindle 2:51 mmpower chuck:165 mm Spindle bore sp. 1:62 mmSpindle bore sp. 2:62 mmdimensions of the machine ca.:3700 x 2300 x 3000 mmweight of the machine ca.:5600 kgUsed CNC-2-spindle CNC turning and milling center with gantry loader- 2x 15 station turret-automatic gantry loader with turnaround station.14 station-magazin right sideMax. Parts size Ø 120 x 100 mmDoublegripper ...
turning diameter:370 mmturning length:200 mmSpindle 1 RPM:4000 1/mincontrol:Siemens 840 D Spindle 2 RPM:4000 1/minpower capacity:L / R 18/24 kWmax. torque on the spindle:630 nMC-Axis:0,001° Turret No.1 stations / rotary tools:12/12 VDI 40Turret No.2 stations / rotary tools:12/12 VDI 40turning speed range - milling:3000 1/minpower capacity - milling spindle:8,8 kWtorque rotary tools:28 NmBar capacity spindle 1:85 mmtotal power requirement:65 kVAweight of the machine ca.:13 tdimensions of the machine ca.:5,7x2,4x2,1 mTravel x1:260 mmTravel x2:260 mmTravel Y1:600 mmTravel y2:600 mmPower Chuck:2 x 250 mm manual tool eye:l & r High performance 6-axis subspindle CNC-Lathe with twin turren and rotating tools.
standard turning dia.:200 turning length:max. 810 mmcontrol:MSX-701 MAPPS IV greates pass round over bed:800 mmMax. distance between centres:1130 mmmax. turning diameter:320 mmmax. workpiecediameter:300 mmbar material dia.:65 mmTraverse X-Axis 1:210 Traverse X-Axis 2:210 mmTraverse X-Axis 3:210 mmTraverse Y-Axis 1:110 (+65/-45) mmTraverse Y-Axis 2:110 (+45,/-65) mmTraverse Z-Axis 1:300 mmTraverse Z-Axis 3:300 mmTraverse Z-Axis 2:810 mmTraverse B-Axis:870 mmturning speed range - spindle:5.000 1/minNumber of spindle speed ranges:2 .spindle nose:JIS A2-6 spindle bore:73 mmspindle bearing diameter:120 mmC-Axis:0,001 °turning speed range - spindle:5.000 1/minspindle nose:JIS A2-6 spindle bore:73 mmbar material dia. max:65/52 mmspindle bearing diameter:120 mmC-Axis:0,001 °Number of Turrets:3 .Number of tool stations:16 x 3=48 posSchank height for square tool:20 mmDiameter of boring bar:32 mm ...
turning diameter:640 / 400 mmturning length:1500 mmcontrol:Siemens 840 D Powerline Travel turret No.1 (milling spindle) x/y/z:550 / 180 (±90) / 1585 mmSwivle angle milling spindle (B-axis):±120° interpol. °Rapid traverse feeds turret 1 (milling head) x/y/z:40/24/60 m/minRPM milling spindle:12000 1/minpower capacity - milling spindle:12 / 23 kWTorque of milling spindle:100 NmTool magazine for milling spindle (turret 1):120 HSK-A 63 Tool change time tool/tool, milling spindle:1,6 sSpindle 1 RPM:4000 1/minSpindle 1 power:36/ 45 kWSpindle 1 Torque:730 NmSpindle 1 max. bar diameter:90 Spindle 2 RPM:4000 1/minSpindle 2 power:36 / 45 kWSpindle 2 torque:730 NmSpindle 2 max. bar diameter:90 c-axis:0,001 °Travel turret 2 x:225 mmTravel Turret 2 z:1595 mmRPM of rotary tools turret 2:4000 1/minno. of tools in turret 2:12 VDI 40 high-pressure pump:20 bartotal power requirement:110 kVAweight of t ...
turning diameter:500 mmturning length:1000 mmcontrol:Siemens 840 D spindle:42 / 28 kWspindle turning speed - stepless:31 - 4000 1/minmax. torque on the spindle:345 Nmc-axis:360000 x 0,001° feeds -stepless-:0 - 10000 mm/minrapid traverse:10000 mm/minturret stations / rotary tool stations:12/12 VDI 40 RPM of rotary tools:2000 1/mindiameter of quill:90 mmquill stroke:80 mmtailstock quill taper ISO:SK 30 Tailstock Travel:600 mmPower rotary tools:3,5 kW:22,5 NmRotary tool holders:4 ax./ 4 rad. spindle passage:66 mmtotal power requirement:30 kWweight of the machine ca.:7,5 tdimensions of the machine ca.:8x 3 x 4 m
turning diameter over bed:350 mmturning diameter over slide rest:240 mmturning length:800 mmSpindle RPM:40 - 2000 in 8 Stufen 1/mintotal power requirement:3 kWSpindle bore:26 mmtailstock quill taper MT:MK 2 dimensions of the machine ca.:1,5 x 1,0 x 1,6 mweight of the machine ca.:1,9 tVery well maintened center lathe with accessories- 3-jaw, 4-jaw chuck- tailstock with center- 1 boring head- RAPID quick tool change device with 3 holder- saddle mounted steady rest- collant device- set of collets appr. 75% size B 32
standard turning dia.:200 turning length:max. 810 mmcontrol:MSX-701 MAPPS III greates pass round over bed:800 mmMax. distance between centres:1130 mmmax. turning diameter:320 mmmax. workpiecediameter:300 mmbar material dia.:65 mmTraverse X-Axis 1:210 Traverse X-Axis 2:210 mmTraverse X-Axis 3:210 mmTraverse Y-Axis 1:110 (+65/-45) mmTraverse Y-Axis 2:110 (+45,/-65) mmTraverse Z-Axis 1:300 mmTraverse Z-Axis 3:300 mmTraverse Z-Axis 2:810 mmTraverse B-Axis:870 mmturning speed range - spindle:5.000 1/minNumber of spindle speed ranges:2 .spindle nose:JIS A2-6 spindle bore:73 mmspindle bearing diameter:120 mmC-Axis:0,001 °turning speed range - spindle:5.000 1/minspindle nose:JIS A2-6 spindle bore:73 mmbar material dia. max:65/52 mmspindle bearing diameter:120 mmC-Axis:0,001 °Number of Turrets:3 .Number of tool stations:16 x 3=48 posSchank height for square tool:20 mmDiameter of boring bar:32 m ...
turning diameter:410 mmturning length:500 mmcontrol:Fanuc 21i TB standard turning diameter:275 mmtravel -x axis:277 mmtravel -y axis:82 (±41) mmtravel -z axis:500 mmSpindle 1 RPM:4500 1/minSpindle 1 Power:18,5/18,5/15 kWSpindle 1 max. bar diameter:65 mmturret stations / rotary tool stations:12/12 Power rotary tools:5,5 kWRPM of rotary tools:6000 1/mintotal power requirement:39,2 kVAweight of the machine ca.:6,2 tdimensions of the machine ca.:3,1 x 2,0 x 2,2 mcollet chuck:Hainbuch High precision Turning and Milling Centre with Y-axis.Machine was running with oil, not coolant.A fire extinguisher system is installed.
max. turning diameter:320 mmturning length:1040 mmcontrol: OSP E 100 L Dialog Fanucgreates pass round over bed:530 mmstandard turning dia.:350 Max. distance between centres:1200 mmmax. workpiecediameter:525 mmTraverse X-Axis 1:500 Traverse X-Axis 2:350 mmTraverse Y-Axis 1:160 (+80/-80) mmTraverse Z-Axis 1:1200 mmTraverse Z-Axis 2:1200 mmSpindle 1 Power:22 kWSpindle 1 RPM:3800 1/minspindle nose:JIS A2-8 spindle bore:80 mmbar material dia.:65 mmC-Axis:0,001° Number of Turrets:2 Turret No.1 stations / rotary tools:12/12 Turret 1 tool RPM:4500 1/minTurret No.2 stations / rotary tools:12/12 rapid traverse X-axis:20 m/minrapid traverse Z-axis:25 m/mintotal power requirement:33 kVAweight of the machine ca.:10 tdimensions of the machine ca.:6,0 x 2,5x 2,3 mHigh pressure coolant system:INterlit 8/20 barspindle load monitor:B Spindle 1 Chuck:SMW 300 mm Soper solid CNC Turning-and Milling CenterT ...
turning diameter:1600 mmturning length:6200 mmturning diameter over bed slide:1250 Turning rate:5 - 710 U/min.total power requirement:37/52 kWweight of the machine ca.:16 tdimensions of the machine ca.:12 x 4 x 2 mCNC SIEMENS Sinumerik3-jaw chuck SCHUNK Rota Plus Dia. 630 mm3 x fixed steadies ( 1200 / 570 / 400 mm ) coolant attachment and chip conveyordiverse accessories
faceplate diameter:4000 mmswing diameter:4300 mmturning height:330 mmfaceplate turning speed range:1 - 92 U/minworkpiece weight:18 tfeeds:1 - 4000 mm/minmain drive motor:55 kWtotal power requirement:85 kVAweight of the machine ca.:64 tdimensions of the machine ca.:90, x 7,2 x 5,5 mwith CNC SIEMENS 840 D for 4 axis2 Vertical Supports tool Basic holderchip conveyor
faceplate diameter:4770 mmswing diameter:7000 mmturning height:1000 mmslide stroke:1000 mmworkpiece weight max.:100000 kgfaceplate turning speed range:2 - 20 U/minfeed speeds:1 - 10000 mm/minrapid traverse:10 m/minram head dimension:250 x 250 mmmain drive:100 kWtotal power requirement:200 kWwith CNC SIEMENS 840 D2 Vertical Supports with toolchanger 12 pockets C-axis and driven tooling SK 50 37 Kw 3000 rpmChip conveyor and coolant attachment
turning diameter over bed:100 mmturning diameter over slide rest:70 mmturning length:80 mmtotal power requirement:1,0 kWweight of the machine ca.:0,5 tdimensions of the machine ca.:0,7 x 0,6 x 1,2 mfacing lathe with manual feed, various accessories
turning diameter:626 mmturning length:3000 mmTurning diameter:600 mmspindle bore:100 mmspindle turning speed range:2800 U/minweight of the machine ca.:18 tMachine overhold and retrofit in 2003 with SIEMENS 840 D control- NC steady rest- 12-fold revolving head- splash doors- tailstock- coolant device
turning diameter over bed:930 mmturning diameter over slide rest:630 mmturning length:6000 mmturning dia. in gap:1250 mmspindle bore:95 mmturning speed range:8 - 800 U/mintotal power requirement:25 kWdimensions of the machine ca.:9 x 2 x 1,9 mfaceplate 2 steadiescoolant attachment taper turning attachment
faceplate diameter:1600 mmswing diameter:1800 mmturning height:1500 mmmax. ram stroke:1200 mmfaceplate turning speed range -stepless-:2,5 - 250 U/minworkpiece weight max.:10.000 kgram head dimension:240 x 240 mmfeed range:1 - 3000 mm/minpower capacity:45 kWweight of the machine ca.:20 tmodernized and overhauled in 2010 with CNC SIEMENS 840 D12 positions automatic toolchangertelescopic coverssplash guardingchip conveyorcoolant attachmentdiverse toolholders
faceplate diameter:5000 mmswing diameter:6100 mmturning height:2400 mmram stroke each side:1490 mmram head dimension:340 x 340 mmmax. workpiece weight:100.000 kgtotal power requirement:100 kWweight of the machine ca.:155 tfaceplate turning speed range:0,4 - 50 U/minwith 2 axes CNC SIEMENS 840 D
turning diameter over bed:500 mmturning diameter over slide rest:310 mmturning length:1500 mmspindle turning speed range:7 - 710 U/minfeed range:5,6 - 224 mm/mintotal power requirement:15 kWweight of the machine ca.:3,7 tdimensions of the machine ca.:2,9 x 1,4 x 1,6 mMachine with 2-axis digital readout- MULTIFIX quick tool change device- 3-jaw chuck
turning diameter over bed:3800 mmturning diameter over slide rest:3200 mmturning length:12000 mmfaceplate turning speed range -stepless-:2 - 200 U/minmax. workpiece weight:90.000 kgbed width:4000 mm2 steadies
turning diameter:1600 mmturning length:12000 mmcontrol:FAGOR 8050 Used CNC Lathe with FAGOR 8050 and extensive accessories.For further technical data and accessories, pls browse the Appendix.Parallellathe WMWmod. 4 GUIDE-WAYS¦ CNC: FAGOR 8050¦ bed: monolithic¦ centres height: 800 mm¦ centres distance: 12000 mm¦ swing over cross-slide: 1250 mm¦ turret: automatic 4 positions¦ tailstock: motorized¦ tailstock connection: hydraulic¦ platform: diam. 1000 mm¦ steady rests: nr.02¦ chip conveyorWarranty: noneTake advantage of the favorable leasing and hire-purchase terms from IKB Leasing. Ask us about it.
turning diameter:1390 mmturning length:14000 mmweight of the machine ca.:13 tMore information can be found in the Appendix.
turning diameter over bed:1450 mmturning diameter over slide rest:1000 mmturning length:8000 mmspindle bore:160 mmturning speed range:2,8 - 560 U/minbed width:850 mmfaceplate diameter max.:1400 mmturning diameter in the gap:1800 mmlength of gap:600 mmdimensions of the machine ca.:12 x 2 x 2,5 mwith Digital Readout2 fixed steadies dia 1070 mmchip conveyor
