usado
usado
Key data: 630 mm, 630 mm, 630 mm
Centro de mecanizado horizontal Heller MCI 16, Construido en 2006, Control Siemens 840 D, Recorrido X/Y/Z 630/630/630 mm, Cambiador de herramientas 80 veces, Portaherramientas HSK 63, Velocidad del husillo hasta 10.000 rpm, Palet de 2 pliegues 400 x 500 mm, Mesa giratoria 0,001°, IKZ 63 bar, Transportador Peso de la máquina 11.000 kg,
usado
Núm. Inv. : 7288 Tipo: FTC 1000 Productor: Heller Generado:- Parámetros: En buen estado técnico.
usado
Centro de fresado horizontal de 4 ejes HELLER MC16 Año 2000 Control de trayectoria CNC SIEMENS de 4 ejes, modelo SINUMERIC 840 D Eje X longitudinal 630 mm Eje Y vertical 630 mm Eje Z transversal 630 mm Mesa giratoria NC Eje B basculante 360.000 x 0,001 Tamaño del palet 400 x 500 mm Tamaño máx. de la pieza x altura 720 x 800 mm Peso máx. de la pieza 500 kg Tiempo de cambio de palet 9 seg. Velocidad de giro eje B 40 rpm/min Cono portaherramientas HSK 63 Tamaño de la herramienta x lg. x peso 150 x 227 x 12 mm/kg Velocidades de husillo, infinitamente variables 45 – 24.000 rpm Avances/avances rápidos XYZ: 1 – 60.000 mm/min Fuerza de avance 10.000 nm Par de giro 48/72 nm Accionamiento del husillo 30 kW Carga eléctrica total, aprox. 60 kW - 400 V - 50 Hz Peso total 12,5 toneladas Accesorios / Características especiales : -Almacén de herramientas tipo bastido ...
usado
Fabricante: HELLER Tipo MCA- U 150 Año de construcción 1996/2008 Control UniPro 90 Peso de la máquina aprox. 10.000 kg Portaherramientas SK 40 Carrera X 600 mm Carrera en Y 500 mm Carrera en Z 600 mm Rango de velocidad 8000 1/min Transportador de virutas: sí Tamaño de la mesa 500x400 mm Número de herramientas en el almacén 60 pl.
usado
Control uni-Pro CNC 90 Recorrido X/Y/Z 800/800/710 mm Velocidad 4500 1/min Almacén de herramientas para 52+120 herramientas SK 50 Mesa giratoria NC Cambiador de palets de 4 pliegues 500x630 mm Transportador
1 Sierra de metal duro de riel de segunda mano con unidad de perforación Mfc.: Tipo Heller: TEK001-73-37 Carro de sierra: 610 ? 710 mm Velocidad de corte ? 6 etapas: 63-200 m/min. Superficie de corte: altura del carril hasta: 200 mm de ancho del carril hasta: 200 mm Velocidad de alimentación: 50 ? 1250 mm/min. Potencia: 50 kW Unidad de perforación Qty. 3 Husillos de perforación Diámetro de perforación: 12 ? 40 mm carrera z: carrera z de 630 mm (adj.): 250 mm Carrera de cambio de herramienta (adj.): Diámetro del husillo del taladro de 380 mm: 60 mm Distancia mínima desde el extremo del carril: 33 mm Distancia del husillo del taladro - husillo 1-3: mín. 228 mm máx. 600 mm ¿Distancia del husillo de perforación? husillo 1-2: mín. 114 mm máx. 486 mm Velocidad de alimentación del taladro: 40 ? 200 mm/min. Potencia motor: 30 kW, 1420 RPM Rango de revolución: Qty. ...
DISTANCIA DE TRANSPORTE DE LA SIERRA: 610-710 MM, RANGO DE CORTE: ALTURA: 200 MM, ANCHO: 200 MM, DIA DE TALADRO: 12 - 40 MM; TRAZO: 630 MM;
usado
Travel X/Y/Z: 1250mm/560mm/630mm, max. milling head-table center distance: 445mm, spindle center-table top edge distance min./max.: 75mm/805mm, table dimensions X/Y: 1550mm/500mm, max. table load: 2500kg, table height: 800mm. Spindle holder: SK50, rated power: 15kW, speed: 3150rpm, feed: 10m/min, swivel: 90°, measuring system resolution: 1μm, position tolerance: 20μm, tool positions: 24, dimensions X/Y/Z: approx. 6200mm/3600mm/3100mm, weight: approx. 9000kg. Including removable NC dividing head Peiseler ATH630, 800mm/800mm, pitch: 1° and various tools. Documentation available.
usado
X-travel: 800mm, y-travel: 630mm, z-travel: 630mm, controls: uni-Pro NC 80-C, length: 5600mm, width: 4200mm, height: 3600mm, weight: 12t, operational hours counter: 88,356h, with documentation.
usado
X-travel: 630mm, y-travel: 630mm, z-travel: 630mm, B-travel: NC + 2 pallet changers, controls: Heller uni-Pro CNC 90, the machine needs to be overhauled, a power module is defective, therefore Z-axis does not move, reference point approach not possible, with documentation.
usado
Travel X/Y/Z: 1600mm/1500mm/1250mm, table dimensions X/Y: 800mm/1000mm, round pallet storage: 4+1 with clamping hydraulics, speed: 6000rpm, feed X/Y/Z: 40000mm/min, rapid traverse X/Y/Z: 40000mm/min, max. workpiece weight: 2500kg, tool magazine: 405 places/SK50/set-up station. Including 70bar high-pressure coolant system, emulsion mist extraction system. On-site inspection is possible. Available from January 2025.
usado
CONTROLS CNC controls SIEMENS 840 D WORKING RANGE -CUBIC- number of processing axes (excl parallel axes): 4 X-axis travel: 630 mm Y-axis travel: 630 mm Z-axis travel: 630 mm SPINDLE / HEAD spindle revolutions (min): 45 /min spindle revolutions (max): 10000 /min tool fixture: HSK A63 drive power S6 40%: 30 kW TOOL MAGAZINE magazin type: chain magazine number of positions: 80 AUTOMATIC WORKLOAD EQUIPMENT store type: table changer number of store positions: 2 number of pallets: 2 ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS space requirements -left/right-: 6200 mm space requirements -front/back-: 3400 mm total height ...
usado
X-travel: 1800mm, y-travel: 600mm, z-travel: 500mm, tool cone: SK50, with documentation, was maintained regularly, an inspection is possible.
usado
x-travel:1000 mm y-travel:800 mm z-travel:1100 mm weight of the machine ca.:15,2 t Tool bore:SK50 Tool taper:HSK-A 100 turning speed range:45-6.000 U/min size of pallet:630x800 mm change time of pallets:21 sec Mechanical processing of cylinder heads and cylinder crankcases Machines have been in single-shift operation since 2013 Service and maintenance intervals were adhered to
usado
x-travel:450 mm y-travel:450 mm z-travel:450 mm weight of the machine ca.:14 t size of pallet:320 x 320 mm Double spindle 4-axis machining center Horizontal 4 machine plates Renishaw probe Control Siemens Sinumerik 840D Working space (X / Y / Z): 450x450x450 mm Load pallet / table max .: 300 kg Acceleration: 10 m / s² Rapid traverse: 60 m / min Pallet size: 320 x 320 mm Chip-to-chip time: 2.6 s Workpiece height max .: 700 mm Tool holder: HSK 63 Tool places: 2x 60 Tool spindle: 10,000 rpm, 95 Nm Speed increase to 18,000 rpm Infrared receiver for probe, Make Renishaw Vaf72a0p Tool magazine with 60 places Control panel on the workstation Control panel on the tool installation site Workpiece positioning stations can be rotated manually with hydraulic workpiece clamping 60 bar Pneumatic support control on the workstation Automatic swing gate Extended coolant layer 70 bar / 1500I / VF 250 Coo ...
usado
Description: Automatic wave saw Saw blade 315mm max. shaft diameter 90mm Speeds 9 - 45 rpm Motor 3.0KW See pictures Approx. Onsite Dimension. (l x w x h): 2,900 x 1,300 x 1,500 mm, weight approx.: 1,600 kg
usado
- Number of axes : 5 Milling spindle - Tool holder type : SK50 - Spindle power : 60 [kW] - Spindle speeds : 50-8000 [rpm] - Gearbox - Speed ranges : 2 Linear axes - Travels on X/Y/Z axes : 1250 / 1200 / 1400 [mm] - Rapid traverses rates (X/Y/Z) : 50 [m/min] Rotary A-axis - Travel : +15 / -190 [°] - Indexing precision : 0.001 [°] Rotary B-axis - Travel : (+/-) 360 [°] - Indexing precision : 0.001 [°] - Cutting feed rate : 10 [rpm] Tool changer - Automatic Tool Changer type : Loading arm - Tool magazine capacity : 50 - Tool exchange time : 6.3 [sec] Table - Table dimensions : 1100 [mm] - Maximum weight upon table : 2000 kg - Maximum part dimensions (diameter x height) : 1810 x 1400 [mm] Power supply - Supply voltage : 400 [V] - Total installed power : 50 [kW] Weight & Dimensions - Machine floor space : 7400 X 5400 [mm] - Machine height : 48 ...
usado
Well maintained CNC machine. No maintenance backlog. needed CNC machining center, horizontal needed Manufacturer: HELLER Type: MC 25 Year of construction: 2002 Control: CNC - path control including color flat screen SIEMENS SINUMERIK 840 D Switch-on time: 1 – 1 ½ shift, exclusively aluminum processing TECHNICAL SPECIFICATIONS Working area x-axis (longitudinal) 800 mm y-axis (vertical) 800 mm z-axis (transverse) 800 mm rotary table Pitch (B axis) 360,000 x 0.001° Indexing accuracy Tp (VDI/DGQ 3441) 10 angle s Clamping weight max. 800 daN Tangential moment (clamped) max. 3500 N, Tilting moment max. 8000 Nm Swiveling time 180° 2.2 s Round milling torque max. 800 Nm pallet changing device Number of pallets 2 Pallet size 500 x 630 mm Pallet change time (at 500/800 daN) 13/15 sec. Pallet load max. 800 daN Workpiece dimensions ...
usado
2004 Heller MCi 16 Construction year: 09.2004 steering: Siemens 840D Tool management: MTV Motor spindle power 40% ED: 30 kW Spider: 45 – 10,000 1/min (Replaced May 2015) Tool holder: HSK-A 63 DIN 69893 my IKZ Magazine places: 80 chain Travel X, Y, Z: 630 x 630 x 630mm Workpiece interference circuit: Ø 720mm Tension: 400 V / 50Hz/100A (fuse 100A) coolant tank: 1200 Liter Tool breakage control: Yes (SBBK) High pressure system: 70 Bar (Knoll) Scraper belt conveyor: Yes (Knoll) Tool changer : Not like. 2014 Tool code chip: AND (Balluff) Tool breakage control: Yes (SBBK) Z-KGT + Z-guides: Repair 2018+2020 Find more here - / Contact us at -
usado
2007 Heller MCH250 Horizontal machining center available in CW20 2025 Machine center Control Siemens 840D Powerline Voltage 400V Frequency 50Hz Rated current 123 A Gear spindle with 2 stages Speed max. 6,000 min-1 Power max. 40 kW (100% ED) / 60 kW (40% ED) Torque max. 1146 Nm (100% ED) / 764 Nm (40% ED) Travel 800 / 800 / 800mm XYZ - B-axis pitch 1° Rapid traverse 50 m/min XYZ HSK A100 tool holder Tool magazine 405 places Tool dimensions ø280 / ø420 (bridge tool) / max. 25 kg / max. length 600 mm Pallet size 630 x 630mm Find more here - / Contact us at -
usado
The machine is particularly suitable for machining hard and tough materials, as it is very sturdily built. For this reason, it has been used for roughing titanium and steel components. For example, the FPU-3 has flat guides and a high max. permissible torque of 2,800 Nm can be used due to the gear spindle. Tools with a diameter of 315 mm and a length of max. 340 mm can be inserted into the tool magazine. The machine has always been maintained with TPM. A detailed machine documentation is available. Accessories / equipment: - Matching platform made of galvanized sheet steel with soft supports. - Chip conveyor - Tool magazine General brief description: The machine is particularly suitable for cutting hard and tough materials, as it has a very stable construction. For this reason, it has been used for roughing titanium and steel components. For example, the FPU-3 has flat guides and ...
usado
This 4-axis HELLER H2000 horizontal machining center was manufactured in 2014. Equipped with a Siemens 840D solution line control, it features a robust spindle capable of 10,000 rpm and 38 kW power. It includes an NC rotary table and a tool magazine with 80 slots for HSK 63 holders. Additional features include an infrared receiver with a Renishaw measuring probe and a scraper belt conveyor. For more information about this horizontal machining center, please reach out to us.
usado
This 4-axis HELLER MCH 350 was manufactured in 2006, featuring a Siemens 840D PL control system and a robust spindle capable of 7,000 rpm. It includes a HSK 100 tool clamping system and a large magazine with 234 slots. The machine offers a substantial working area of 1250 x 1000 x 1000 mm and a pallet size of 800 x 800 mm. For more information about this machining centre, please reach out to us.
usado
This 4-axis Heller MCi16 horizontal machining center, constructed in 2006, integrates advanced features for precision and efficiency. It boasts an HSK63 tool holder with 80 places, a high spindle speed of 10000, and a Siemens 840D control system that provides exacting operational command. The addition of an IKZ system at 63bar and a 2 compartment pallet changer significantly enhances productivity and reduces setup times. Consider the Heller MC16 machine we have for sale. For more information about this horizontal machining center, please reach out to us.
usado
This HELLER MC25 Uni-Pro Horizontal Machining center was manufactured in the year 1998 in Germany. It is equipped with an UniPro CNC 90 control unit.
usado
This HELLER MCP-H 250 Horizontal Machining Centre was manufactured in 1999 in Germany. It is equipped with a HELLER Unipro 90 control unit and a tool taper SK50. The pallet size is 630 x 500 mm and the spindle speed range 45-6000 rpm. It has a NC rotary table, a pallet changing device and a tool magazin (chain) with 52 places. As additional equipment it comes with measuring device for BLUM TC 50, linear scales Heidenhain, BKW cooling unit for spindle cooling, Knoll coolant system with vacuum rotary filter and sludge discharge, Knoll chip conveyor, BKW cooling unit for cooling lubricant system, work area flushing and 2 pallets. The machine is in good condition for its age. Annual maintenance has been carried out over the entire service life. In 2018, the machine was retrofitted with the latest interface/receiver for the Blum TC 50. It is still under production and can be inspected at any ...
usado
control: Siemens 840D Número de ejes: 4 St.: 2 torretas de peaje: 160 cono de la herramienta: HSK 63 Rango de velocidad de giro del husillo: 24.000 U/min
usado
La máquina de centrado de un solo lado hace Gebr. HELLEREspecificaciones técnicas:Diámetro del eje hasta: 150 mm:Altura central: 150 mmLongitud de la cama: 800 mmMotor de potencia de accionamiento: 1,1 kWDimensiones externas L x W x H: 1300 x 900 x 1200 mmPeso aprox: 200 kgutilizadoPrecio bajo petición. Entrega: ex almacén o ubicación libre de carga camión. Pago: neto en el momento de la adquisición o con cita previa. Los datos técnicos no son vinculantes. Errores exceptuados. Estaremos encantados, si le gusta nuestra oferta y siempre estamos disponibles para sus consultas. SaludosM. Máquinas herramienta WaldeckWAHO
usado
Máquina perforadora radial hacer HELLER tipo RB 50/1250Serial -No: 29551 construido en 1961Especificaciones técnicas:Capacidad de perforación en acero: 50 mmCapacidad de perforación en GG: 60 mm12 velocidades del husillo: 33 - 1500 rpm. Montaje del husillo: MK 512 alimentaciones automáticas: 0,08 - 1,5 mm/revCaptura de pluma: 301 mmProyección: 1250 mmDiámetro de la columna: 380 mmPotencia de accionamiento: 4 kWMedidas aprox.: 2200 x 2300 x 2780/3110 mmPeso aprox.: 4250 kgutilizado, en muy buen estadoPrecio bajo petición. Entrega: ex almacén o ubicación libre de carga camión. Pago: neto en el momento de la adquisición o con cita previa. Los datos técnicos no son vinculantes. Errores exceptuados. Estaremos encantados, si le gusta nuestra oferta y siempre estamos disponibles para sus consultas. SaludosM. Máquinas herramienta WaldeckWAHO
