CONTROLS PLC SIEMENS S7 PRESS DESIGN drive system: hydraulic PRESS FORCES total force (nominal): 300 toPRESS TABLE table surface (left-right): 2200 mm table surface (front-back): 1700 mmSLIDE stroke: 1600 mmTOOL ASSEMBLY DIMENSIONS shut height (stroke down, adjustment up), BDC: 1600 mmELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 HzDIMENSIONS / WEIGHTS space requirements -left/right-: 6536 mm space requirements -front/back-: 2923 mm total height: 6135 mm total weight approx.: 36000 kg
CONTROLS PLC SIEMENS PRESS DESIGN drive system: hydraulic SLIDE total force (nominal): 500 to stroke: 225 mm stroke rate (max.): 60 /minSLIDE (HYDR. PRESS) approximation velocity max.: 200 mm/s working velocity min.: 15 mm/s working velocity max.: 44 mm/s return velocity max.: 200 mm/sCOUNTER RAM nominal force: 100 to stroke: 30 mmV-RING nominal force: 200 toTOOL DIMENSIONS shut height max.: 420 mm ram adjustment: 100 mm distance between columns (H-frame): 880 mm passline opening (free passage in side columns): 470 mm range of transfer pins - in strip direction: 394 mmDECOILER design: cradle sheet width max.: 300 mmLEVELLER UNIT sheet thickness max.: 12 mmSTRIP-FEEDER feeder type: grip feeder CROP SHEAR cutting force: 500 kNELECTRICAL SPECIFICATIONS total power consumption: 100 kWPress is equipped with 4. forceStraight ...
CONTRÔLES PLC SIEMENS S7 SLIDE force totale (nominale) : 630 à TOOL DIMENSIONS table inférieure (gauche-droite) : 900 mm table inférieure (avant-arrière) : 900 mm hauteur de fermeture maximale : 900 mm
PRESS DESIGN drive system: hydraulic SLIDE total force (nominal): 40 to stroke: 45 mm stroke rate (max.): 110 /minTOOL DIMENSIONS lower table (left-right): 300 mm lower table (front-back): 280 mm shut height max.: 90 mmDIMENSIONS / WEIGHTS space requirements -left/right-: 1835 mm space requirements -front/back-: 1500 mm total height: 1800 mm total weight approx.: 2500 kg
CONTROLS SIEMENS SIMATIC PRESS DESIGN drive system: eccentric / crank PRESS FORCES total force (nominal): 160 toPRESS TABLE table surface (left-right): 1200 mm table surface (front-back): 970 mmSLIDE stroke rate (max.): 90 /minSLIDE (MECHAN. PRESS) slide adjustment: 120 mmELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 HzDIMENSIONS / WEIGHTS space requirements -left/right-: 3200 mm space requirements -front/back-: 1600 mm total height: 4400 mm total weight approx.: 32000 kg
GLISSIÈRE force totale (nominale) : 40 à la vitesse de course (max.) : 110 /minDIMENSIONS OUTIL Table inférieure (gauche-droite) : 300 mm Table inférieure (avant-arrière) : 280 mm hauteur de ferme max. : 180 mm DIMENSIONS / POIDS Exigences espace -gauche/droite - : 1835 mm Espace requises - avant/arrière - : 1500 mm hauteur totale : 1800 mm poids total environ : 2500 kg
SLIDE total force (nominal): 80 to stroke rate (max.): 120 /minV-RING stroke: 90 mmTOOL DIMENSIONS lower table (left-right): 420 mm lower table (front-back): 420 mm upper table (left-right): 420 mm upper table (front-back): 420 mmDIMENSIONS / WEIGHTS space requirements -left/right-: 2970 mm space requirements -front/back-: 1665 mm total height: 242 mm total weight approx.: 6000 kg
PRESSE DESIGN Système de changement rapide de puces : oui COULISSE force totale totale (nominale) : 100 à course : 20 mm course (max.) : 80/min DIMENSIONS OUTIL Table inférieure (gauche-droite) : 430 mm hauteur d’arrêt maximale : 220 mm Environ. 79 millions de coups de claque
COULISSE force totale (nominale) : 80 pour la course (max.) : 72 /minDIMENSIONS OUTIL Table inférieure (gauche-droite) : 470 mm Table inférieure (avant-arrière) : 420 mm Table supérieure (gauche-droite) : 400 mm Table supérieure (avant-arrière) : 400 mmDIMENSIONS / POIDS Besoins en espace -gauche/droite : 1600 mm Espace nécessaire -avant/arrière : 1400 mm hauteur totale : 2500 mm poids total environ : 6000 kg
CONTRÔLES PLC SIEMENS SIMATIC PRESS DESIGN coussin de table : oui FORCE DE PRESSION FORCE TOTALE (NOMINALE) : 630 SURFACE DE TABLE À PRESSE (GAUCHE-DROITE) : 2500 mm surface de table (avant-arrière) : 1300 mm COUSSIN DE DÉPRESSION (COUSSIN DE TABLE) FORCE DE COUSSIN : 250 à la course : 400 mm surface de la plaque de coussin (gauche-droite) : Surface de plaque de 2450 mm (avant-arrière) : 1250 mm
PRESS FORCES total force (nominal): 100 toPRESS TABLE table surface (left-right): 950 mm table surface (front-back): 660 mm thickness of bolster plate: 68 mmSLIDE table surface (left-right): 540 mm table surface (front-back): 450 mm spigot hole diameter: 60 mm stroke: 130 mm stroke rate (max.): 65 /minSLIDE (MECHAN. PRESS) slide adjustment: 100 mmTOOL ASSEMBLY DIMENSIONS shut height (stroke down, adjustment up), BDC: 370 mmDIMENSIONS / WEIGHTS total weight approx.: 7000 kgLocated in Barcelona - Spain2 identical units available
CONTROLS electronic controls SCHMIDT PRESS FORCES total force (nominal): 0.25 toPRESS TABLE table surface (left-right): 180 mm table surface (front-back): 150 mmSLIDE slide force: 0.25 to stroke: 100 mmELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 HzDIMENSIONS / WEIGHTS total weight approx.: 35 kgThis is an assembly press with force-displacement monitoring.• Operating hours: approx. 150• Condition: very good, almost like new• Features: Press force monitoring, two-hand operation• Stroke: 100 mm• Tool dimensions: 150 x 100 mm• Press force: 0.25 tons
PRESS DESIGN drive system: eccentric / crank PRESS FORCES total force (nominal): 55 toPRESS TABLE table surface (left-right): 750 mm table surface (front-back): 450 mmSLIDE table surface (left-right): 400 mm table surface (front-back): 300 mm spigot hole diameter: 45 mm stroke: 50 mm stroke rate (max.): 100 /minSLIDE (MECHAN. PRESS) slide adjustment: 70 mm stroke min.: 6 mm stroke max.: 50 mm stroke rate (min.): 50 /min stroke rate (max.): 100 /minTOOL ASSEMBLY DIMENSIONS shut height (stroke down, adjustment up), BDC: 310 mmELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 HzDIMENSIONS / WEIGHTS space requirements -left/right-: 1200 mm space requirements -front/back-: 1500 mm total height: 2500 mm total weight approx.: 3850 kgATTACHMENTS (PRESSES) strip feeder: optional feeder type: grip feeder saf ...
CONTROLS PLC SCHNEIDER PRESS DESIGN drive system: eccentric / crank number of slide actions: 11 feedstock transport direction: left to right PRESS FORCES total force (nominal): 66 toSLIDE slide force: 6 to stroke: 114 mmSLIDE (MECHAN. PRESS) variable speed: yes stroke rate (min.): 40 /min stroke rate (max.): 130 /min main drive power: 7.5 kWSTRIP-FEEDER feeder type: roll feeder TRANSFER SYSTEM distance between tools, stroke X fixed: 82 mmDIMENSIONS / WEIGHTS space requirements -left/right-: 2875 mm space requirements -front/back-: 1500 mm total height: 2900 mm total weight approx.: 7500 kgATTACHMENTS (PRESSES) safety guard / safety door: yes 2-hand engagement: yes noise protection cabin: yes acc. to actual accident protection regulation: yes Specifications:Number of stations: 12 (11+1)Capacity per ram: 6 tonsMaximum st ...
CONTROLS PC controller BECKHOFF PRESS DESIGN number of slide actions: 13 SLIDE slide force: 3 to stroke: 60 mm stroke rate (max.): 210 /minSLIDE (MECHAN. PRESS) slide adjustment: 6 mm variable speed: yes stroke rate (min.): 70 /min stroke rate (max.): 210 /min main drive power: 4 kWDIMENSIONS / WEIGHTS space requirements -left/right-: 2300 mm space requirements -front/back-: 1000 mm total height: 1900 mm total weight approx.: 4000 kg
CONTROLS PLC PRESS DESIGN drive system: hydraulic quick die change system: yes SLIDE total force (nominal): 450 to stroke: 230 mmSLIDE (HYDR. PRESS) working velocity min.: 5 mm/s working velocity max.: 70 mm/s return velocity max.: 200 mm/s return force: 200 toV-RING nominal force: 200 toTOOL DIMENSIONS lower table (left-right): 790 mm lower table (front-back): 760 mmOVERALL SPECIFICATIONS (COIL LINES) coil weight max.: 3 toCOIL CHAIR coil weight max.: 3 toSTRIP-FEEDER feeder type: roll feeder band lubrication system: yes ELECTRICAL SPECIFICATIONS total power consumption: 150 kW mains voltage: 400 V mains frequency: 50 HzDIMENSIONS / WEIGHTS total weight approx.: 28400 kgincluding Coil Line ARKU AH 3000/300 MSG
PRESS DESIGN drive system: hydraulic frame design: C-frame, single sided table cushion: yes opening in table: yes PRESS FORCES total force (nominal): 100 toPRESS TABLE table surface (left-right): 710 mm table surface (front-back): 560 mmSLIDE slide force: 100 to table surface (left-right): 560 mm table surface (front-back): 450 mm spigot hole diameter: 50 mm stroke: 320 mm thickness of bolster plate: 150 mmSLIDE (HYDR. PRESS) approximation velocity max.: 340 mm/s working velocity max.: 32 mm/s return velocity max.: 330 mm/sSLIDE EJECTOR / CUSHION nominal force: 2 to stroke: 40 mmDIE CUSHION (TABLE CUSHION) cushion force: 10 to stroke: 80 mmTOOL ASSEMBLY DIMENSIONS shut height (stroke down, adjustment up), BDC: 455 mmSTRIP-FEEDER feeder type: roll feeder sheet width max.: 300 mm sheet thickness max.: 20 mm spee ...
Key data: 40 t, 1030 mm
À vendre est un frein à pression automatisé avec un système robotisé de première main pour le formage de pièces en tôle en série. Frein à pression BYSTRONIC Xpert 40/1030 2019 Robot KUKA KR10R 1100 sixx 2019 Spécifications Frein à pression - Force de presse : 400 kN (40t) - Longueur de travail : 1030 mm - Contrôle : ByVision Robot - Capacité de charge maximale nominale : 11 kg - Portée : 1100mm - Essieux : 6 essieux - Répétabilité de position : 0,02 mm - Modules de sécurité certifiés CE Caractéristiques - Cellule de courbure entièrement automatisée avec robot industriel 6 axes intégré - à partir de la première main - Dimensions (LxLxH) : environ 3,25 m x 2,8 m x 2,5 m - Terminal de contrôle ByVision Bending avec écran tactile Full HD de 22 pouces État de la machine - Horaires d’ouverture : 7 724 h - Compteur de cycles ...
CONTROLS PC controller BECKHOFF Offer for servicesof complete Overhaul of a Customer-Owned Fineblanking Press FEINTOOL GKP 160Scope of Overhaul• Complete disassembly into individual components• Inspection of all parts, including crack testing of critical components• Overhaul of the drive system, new motors• Reworking and precise alignment of all guideways• Complete overhaul of the hydraulic cylinders• Overhaul of the clamping tables• Installation of a new hydraulic unit• Renewal of the pneumatic system• Renewal of the electrical systemModernisation / Retrofit• Combined table• Servo feed systems• Central lubrication system• RAZIOL band lubrication• New brake/clutch unit• BECKHOFF PC-based control system with touch panel• PILZ safety control system• Implementation of CE conformityNotes• Special options and customer-specific extensions can be integrate ...
CONTROLS electronic controls SIEMENS S7 300 PRESS DESIGN drive system: eccentric / crank openings in uprights: yes number of suspensions: 2 table cushion: no quick die change system: yes PRESS FORCES total force (nominal): 250 toPRESS TABLE table surface (left-right): 2000 mm table surface (front-back): 1100 mm height above floor level: 1105 mm opening in bed (left-right): 1700 mm opening in bed (front-back): 305 mmSLIDE table surface (left-right): 2080 mm table surface (front-back): 1000 mm stroke rate (max.): 120 /minSLIDE (MECHAN. PRESS) slide adjustment: 120 mm stroke adjustment: yes stroke min.: 20 mm stroke max.: 180 mmTOOL ASSEMBLY DIMENSIONS shut height (stroke down, adjustment up), BDC: 500 mm distance between columns (H-frame): 2055 mm passline opening (free passage in side columns): 810 mmDECOILER sheet ...
CONTROLS PC controller BECKHOFF PRESS DESIGN drive system: knuckle-joint SLIDE total force (nominal): 160 to stroke: 60 mm stroke rate (max.): 70 /minCOUNTER RAM nominal force: 40 to stroke: 14 mmV-RING nominal force: 50 to stroke: 10 mmTOOL DIMENSIONS lower table (left-right): 480 mm lower table (front-back): 520 mm upper table (left-right): 480 mm upper table (front-back): 520 mm shut height max.: 314 mm ram adjustment: 80 mm distance between columns (H-frame): 500 mm passline opening (free passage in side columns): 220 mmSTRIP-FEEDER feeder type: roll feeder sheet width max.: 210 mm sheet thickness max.: 6 mm feeding step max.: 999.9 mm sheet length min: 2000 mm pilot release system: yes band lubrication system: yes Complete refurbished fineblanking press: disassembly into individual parts findings of all compon ...
PRESS DESIGN drive system: eccentric / crank PRESS FORCES total force (nominal): 50 toPRESS TABLE table surface (left-right): 700 mm table surface (front-back): 450 mmSLIDE table surface (left-right): 440 mm table surface (front-back): 360 mm spigot hole diameter: 40 mm stroke: 90 mm stroke rate (max.): 70 /minSLIDE (MECHAN. PRESS) slide adjustment: 70 mm stroke min.: 0 mm stroke max.: 90 mm main drive power: 3 kWTOOL ASSEMBLY DIMENSIONS shut height (stroke down, adjustment up), BDC: 300 mmDIMENSIONS / WEIGHTS space requirements -left/right-: 700 mm space requirements -front/back-: 1295 mm total height: 2360 mm total weight approx.: 3000 kg
PRESS DESIGN drive system: eccentric / crank PRESS FORCES total force (nominal): 45 toPRESS TABLE table surface (left-right): 700 mm table surface (front-back): 440 mm opening in bed (diameter): 40 mmSLIDE table surface (left-right): 410 mm table surface (front-back): 280 mm stroke rate (max.): 110 /minSLIDE (MECHAN. PRESS) slide adjustment: 65 mm stroke min.: 0 mm stroke max.: 90 mm main drive power: 5.5 kWTOOL ASSEMBLY DIMENSIONS shut height (stroke down, adjustment up), BDC: 380 mm distance between columns (H-frame): 360 mmATTACHMENTS (PRESSES) 2-hand engagement: yes foot engagement: yes European CE standards: yes
CONTROLS conventional PRESS DESIGN drive system: eccentric / crank frame design: C-frame, single sided PRESS FORCES total force (nominal): 100 toSLIDE slide force: 100 to stroke rate (max.): 72 /minSLIDE (MECHAN. PRESS) slide adjustment: 80 mm stroke adjustment: yes stroke min.: 8 mm stroke max.: 112 mmTOOL ASSEMBLY DIMENSIONS shut height (stroke down, adjustment up), BDC: 407 mmATTACHMENTS (PRESSES) 2-hand engagement: yes for safe tools only
CONTROLS PLC SIEMENS S7 300 PRESS DESIGN drive system: hydraulic PRESS FORCES total force (nominal): 800 toPRESS TABLE table surface (left-right): 2600 mm table surface (front-back): 2000 mm height above floor level: 540 mmSLIDE stroke: 900 mmSLIDE (HYDR. PRESS) approximation velocity max.: 460 mm/s working velocity min.: 25 mm/s working velocity max.: 44 mm/s return velocity max.: 460 mm/sTOOL ASSEMBLY DIMENSIONS shut height (stroke down, adjustment up), BDC: 1700 mmELECTRICAL SPECIFICATIONS total power consumption: 180 kWDIMENSIONS / WEIGHTS total weight approx.: 95000 kgATTACHMENTS (PRESSES) press automation: yes gripper transfer system: yes acc. to actual accident protection regulation: yes European CE standards: yes Complete hot forming line consisting of: Hydraulic press NEFF 800 to. Ruhstrat furnace system:- Natural gas heat ...
Pression : 63 tDistance entre les colonnes : 360 mmCourse : 400 mmPoids de la machine env. : 4 tDimensions de la machine env. : 1,8x1,6x2,7 m
CONTROLS PLC SIEMENS S7 PRESS DESIGN drive system: link drive feedstock transport direction: left to right SLIDE total force (nominal): 80 to stroke: 50 mm stroke rate (max.): 80 /minCOUNTER RAM nominal force: 22 to stroke: 8 mmV-RING nominal force: 25 to stroke: 15 mmTOOL DIMENSIONS lower table (left-right): 420 mm lower table (front-back): 420 mm upper table (left-right): 420 mm upper table (front-back): 420 mm shut height max.: 220 mm ram adjustment: 80 mm distance between columns (H-frame): 450 mm passline opening (free passage in side columns): 200 mmOVERALL SPECIFICATIONS (COIL LINES) sheet width max.: 180 mm sheet thickness max.: 5 mm feed velocity max.: 999 m/minSTRIP-FEEDER feeder type: roll feeder sheet width max.: 180 mm sheet thickness max.: 5 mm feeding step max.: 999 mm sheet length min: 1350 mm ...
CONTROLS PC controller BECKHOFF C 6140 PRESS DESIGN drive system: hydraulic frame design: H-frame, monoblock quick die change system: yes feedstock transport direction: left to right SLIDE total force (nominal): 410 to stroke: 200 mmSLIDE (HYDR. PRESS) approximation velocity max.: 200 mm/s working velocity min.: 8 mm/s working velocity max.: 80 mm/s return velocity max.: 150 mm/sCOUNTER RAM nominal force: 120 to stroke: 40 mmV-RING nominal force: 250 to stroke: 40 mmTOOL DIMENSIONS lower table (left-right): 820 mm lower table (front-back): 1250 mm upper table (left-right): 820 mm upper table (front-back): 1250 mm shut height max.: 410 mmSTRIP-FEEDER feeder type: roll feeder sheet width max.: 450 mm sheet thickness max.: 16 mm feeding step min.: 1 mm feeding step max.: 999.9 mm speed max.: 48 m/min nomina ...
pression : X tTaille de la table : 550x390 mmGorge : 550 mmTaille de la plaque magnétique : 250x100 mmPoids de la machine env. : 0,25 tPlus de détails sur
CONTROLS PC controller BECKHOFF PRESS DESIGN drive system: knuckle-joint SLIDE total force (nominal): 250 to stroke: 61 mm stroke rate (max.): 60 /minCOUNTER RAM nominal force: 75 to stroke: 15 mmV-RING nominal force: 75 to stroke: 13 mmTOOL DIMENSIONS lower table (left-right): 540 mm lower table (front-back): 540 mm upper table (left-right): 540 mm upper table (front-back): 540 mm shut height max.: 320 mm ram adjustment: 145 mm distance between columns (H-frame): 560 mm passline opening (free passage in side columns): 270 mmSTRIP-FEEDER feeder type: roll feeder sheet width max.: 250 mm sheet thickness max.: 10 mm feeding step max.: 999.99 mm sheet length min: 1900 mm pilot release system: yes band lubrication system: yes Complete refurbished fineblanking press: disassembly into individual parts findings of all com ...
