pressure:20 tStroke:230 mmtable surface area:Ø600 mmdistance table - lower edge of ram:770 mmweight:595 kg
Pressure:063 tthroat:250 mmstroke:10 - 100 mmno. of strokes:120 /mindistance table/ram, max. stroke up, adjustment up:380 mmtable surface area:700 x 500 mmhole in the table:180 x 140 mmtable height over floor:700 mmram surface:360 x 275 mmram adjustment:60 mmpower requirement:5,5 kWweight:3,8 tDimensions (WxDxH):1,9 x 1,7 x 2,4 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:hydraulic overload protection in ram:mechanical
pressure:150 tthroat:400 mmstroke:30 - 150 mmno. of strokes:50 /mindistance table/ram, max. stroke up, adjustment up:620 mmtable surface area:1000 x 750 mmhole in the table:320 x 200 mmtable height over floor:800 mmram surface:800 x 600 mmram adjustment:85 mmweight:10,0 tDimensions (WxDxH):1,4 x 2,2 x 3,1 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic ram counterbalance:pneumatic
nominal force:2500 tstroke:600 mmcycle time:13 - 18 sdistance between columns:1720 mmDistance table/ram, max. stroke up, adjustment up:2600 mmtable surface area:1720 x 1800 mmallowed max. force:4000 tblow die to die:5000 tram surface:2100 x 1320 mmcapacity of ejector in table:40 tejector stroke in table:250 mmejector surface area in table:900 x 820 mmcapacity of ejector in ram:6 tejector stroke in ram:40 mmspindle diameter:425 mmpower requirement:900,0 kWweight:335,0 tDimensions (WxDxH):3,4 x 4,6 x 9,7 mheight over floor:8,3 mfully-automated forging line:to produce axle shaft
pressure:100 tthroat:380 mmstroke:650 mmdistance table/ram, max. stroke up, adjustment up:950 mmtable surface area:800 x 700 mmhole in the table:200 mmtable height over floor:920 mmram surface:630 x 600 mmspeed down:65 mm/sspeed up:375 mm/sworking speed:17 mm/soil volume:350 lpower requirement:18,5 kWweight:9,0 tDimensions (WxDxH):1,5 x 2,5 x 4,0 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 §20
: neu : ca. 10 Wochen ab Auftrags : Türkei : 91200 €: 1723.68 €: 100 to: 500 mm: 600 x 900 mm: 700 x 1100 mm: 750 mm: 320 mm: 100 mm/s: 8,5 mm/s: 165 mm/s: 11 kW: 2100 mm: 1900 mm: 3350 mm: 7300 kg: 240 bar: 30 to: 200 mm: 120 mm: 170 bar: 52 mm/sec.: 700 x 400 mm2-hand controlControl over SPSAdjustable die cushion strokeLubricant-free ram guidelight barriersUser Manual in Germanaccording to CE rulesThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure:250 tdistance between columns:1125 mmstroke:250 mmdistance table/ram, max. stroke up, adjustment up:800 mmtable surface area:1100 x 900 mmpressure of drawing cushion in table:63 tstroke of drawing cushion in table:100 mmdie cushion area:700 x 400 mmtable height over floor:960 mmside window:700 mmram surface:1080 x 900 mmoil volume:1000 lpower requirement:35,0 kWweight:23,0 tDimensions (WxDxH):2,5 x 2,3 x 4,5 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard:Sick foundation pit:not necessary
: neu : ca. 4 Monate ab Auftragse : Italien : 74800 €: 1413.72 €: 100 to: 500 mm: 1000x800 mm: 600 mm: 26 mm/s: 5 mm/s: 4 kW: 1260 mm: 1060 mm: 2400 mm4-pillar guideram guide roundtable and ram with T-slots2 hand operationSiemens PLCmanometerusers manual Light barrier € on RequestSiemens touchscreen-control, 50 programsstoreable, for programming: • Upstroke and downstroke quota• Break time in the bottom• time of Decompression• setting pressure of work• Pieces counter• prestop in upstroke and downstroke• setting for movement in manual and in automatic• management of alarms and anomalies € on Request Working hour counter € on Request Stroke counter € on Request Decompression valve € on Request Oil cooler with decompreission valve € on Request Pressur switch € on RequestThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure:250 tthroat:450 mmstroke:36 - 126 mmno. of strokes:40 /mindistance table/ram, max. stroke up, adjustment up:525 mmtable surface area:1000 x 750 mmhole in the table:400 x 360 mmtable height over floor:1000 mmram surface:600 x 500 mmram adjustment:111 mmpower requirement:19,0 kWweight:13,5 tDimensions (WxDxH):1,3 x 3,2 x 3,35 mclutch:pneumatic overload protection in ram:mechanical ram adjustment:motoric
: neu : ca. 4 Monate ab Auftragse : Italien : 117000 €: 2211.3 €: 125 to: 500 mm: 800 x 400 mm: 900 x 600 mm: 600 mm: 300 mm: 115 mm/s: 42 mm/s: 7 mm/s: 70 mm/s: 15 kW: 1400 mm: 1950 mm: 2600 mm4 guides for the slideT-slots in the tableRexroth hydraulic unitMonitored electrovalvesAir/oil heat exchangerPressure switchDouble pushbuttons controlStroke adjustment by limit switch micronsSiemens CPULateral fixed protrection gratesCE certification following ",IV enclosure",OPTIONS(prices on request):Blank holderPrismatic guidesFrontal light curtainCNC control Siemens with touchscreenHydraulic pump with variable flowProportional valvesLateral sliding guides with security micronsThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure:100 tdistance between columns:1230 mmstroke:20 - 200 mmno. of strokes:20 - 60 /mindistance table/ram, max. stroke up, adjustment up:650 mmtable surface area:1050 x 750 mmtable height over floor:760 mmside window:540 mmram surface:1000 x 750 mmram adjustment:100 mmpower requirement:18,0 kWweight:20,5 tDimensions (WxDxH):2,8 x 1,9 x 4,3 minfinitely variable drive:PIV clutch:pneumatic overload protection in ram:hydraulic ram counterbalance:pneumatic ram adjustment:motoric
pressure:160 tdistance between columns:880 mmstroke:150 mmdistance table/ram, max. stroke up, adjustment up:400 mmtable surface area:830 x 1000 mmhole in the table:265 x 365 mmtable height over floor:850 mmside window:610 mmram surface:860 x 1000 mmpower requirement:55,0 kWweight:14,7 tDimensions (WxDxH):2,2 x 2,0 x 4,3 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20 depth stop:motoric adjustable table:motoric foundation pit:not necessary
Pressure:250 tthroat:450 mmstroke:8 - 135 mmno. of strokes:50 /mindistance table/ram, max. stroke up, adjustment up:635 mmtable surface area:1250 x 850 mmhole in the table:355 mmtable height over floor:950 mmpassage to the back:660 mmram surface:790 x 610 mmram adjustment:120 mmpower requirement:18,5 kWweight:14,0 tDimensions (WxDxH):1,5 x 2,8 x 3,65 mGerman Safety: permitted for manual loading:CE-Norm - EN 692, BGR 500 clutch:pneumatisch overload protection in ram:mechanisch ram counterbalance:pneumatisch
pressure:500 tdistance between columns:2400 mmstroke:400 fix mmno. of strokes:13 - 23 /minDistance table/ram, max. stroke up, adjustment up:1600 mmtable surface area:2300 x 1800 mmcolumn travel -side:1600 mmram surface:2170 x 1800 mmram adjustment:300 mmtotal power requirement:110,0 kWWeight:135,0 tDimensions (WxDxH):3,35 x 4,85 x 7,0 mclutch:pneumatic overload protection in ram:hydraulic ram adjustment:motoric
: neu : ca. 6-8 Wochen ab Auftrag : Italien : 500 to: 500 mm: 5.000 x 2.550 mm: 700 mm: 18 mm/s: 3 mm/s: 5000 mm: 5000 mm: 3000 mm: 32000 kg: horizontal verschiebbar : 2550 mm: 1.700 mm: 3.600 mmhorizontal movable cylinderhydraulicaly movable standcontrol by levers as well as control panelaccording to CE regulations user manual in GERMAN and ENGLISHOPTIONS:Work table, welded to the base frame, with holes on the surfaceControl panel on the swivel arm (push buttons for press movement, solenoid valves, Siemens CPU)Radio control panel (push buttons for press movement, solenoid valves, Siemens CPU)Siemens control with touchscreenLifting cylinders in the table (6, 8 or 10 pcs.)No-rotation shaft for the piston2 speeds for stand movement and cylinderOil cooler and decompression valveThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure:300 tdistance between columns:2500 mmstroke:350 mmdistance table/ram, max. stroke up, adjustment up:1280 mmtable surface area:2500 x 1500 mmtable height over floor:850 mmside window:900 mmram surface:2500 x 1500 mmspeed down:300 mm/sspeed up:240 - 450 mm/sworking speed:23 - 44 mm/soil volume:3000 lpower requirement:132,0 kWweight:54,0 tDimensions (WxDxH):3,25 x 3,2 x 4,8 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 ram interlocking:SITEMA
nominal force:100 tstroke:320 mmno. of strokes:35 /mindistance between columns:360 / 250 mmDistance table/ram, max. stroke up, adjustment up:500 mmtable surface area:320 x 450 mmtable height over floor:660 mmram surface:250 x 280 mmspindle diameter:125 mmpower capacity:3,0 kWweight:4,5 tDimensions (WxDxH):2,0 x 1,6 x 3,1 m
Pressure:100 tdistance between columns:910 mmstroke:600 mmdistance table/ram, stroke up:1000 mmtable surface area:1340x680 / 910x1085 mmhole in the table:700 x 510 mmtable height over floor:800 mmside window:680 mmram surface:1230x680 / 910x1000 mmcapacity of ejector:7,5 tejector stroke:150 mmpower requirement:15,0 kWweight:9,5 tDimensions (WxDxH):2,3 x 1,9 x 3,6 mlight guard:Sick blank holder / ejector in ram:hydraulisch
pressure:150 tthroat:450 mmstroke:115 fix mmno. of strokes:45 /mindistance table/ram, max. stroke up, adjustment up:400 mmtable surface area:2250 x 1090 mmtable height over floor:900 mmpassage to the back:1900 mmram surface:1900 x 900 mmram adjustment:100 mmpower requirement:16,0 kWweight:19,5 tDimensions (WxDxH):3,0 x 2,3 x 3,9 m
: neu : ca. 4 Monate ab Auftragse : Italien : 31200 €: 595.92 €: 100 to: horizontal verschiebbar : 500 mm: 700 mm: 1550 mm: 25 mm/s: 2 mm/s: 2400 mm: 1200 mm: 2450 mm: 1960 kgHORIZONTAL MOVABLE CYLINDER 1.050 MM2 speedscontrol by handwheel and push button (2-hand)adjustable max. pressuremanometeraccording to CE regulations user manual in GERMAN and ENGLISH(sample photo)The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure:200 tdistance between columns:1800 mmstroke:710 mmDistance table/ram, max. stroke up, adjustment up:1100 mmtable surface area:1600 x 1300 mmpressure of drawing cushion in table:80 tstroke of drawing cushion in table:250 mmdie cushion area:1400 x 1080 mmtable height over floor:800 mmside window:1300 mmram surface:1660 x 1300 mmspeed down:400 mm/sspeed up:410 mm/sworking speed:14,3 - 49,7 mm/spower requirement:46,0 kWweight:25,0 tDimensions (WxDxH):3,65 x 3,3 x 5,4 mheight over floor:5,05 mheight beneath floor:0,4 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard at front and back:Sick drawing cushion in table:hydraulic ejector in ram:hydraulic depth stop:mechanical
pressure:50 tdistance between columns:1750 mmstroke:500 mmDistance table/ram, max. stroke up, adjustment up:800 mmtable surface area:1700 x 750 mmtable height over floor:800 mmside window:650 x 750 mmram surface:1700 x 750 mmpower requirement:11,0 kWweight:11,0 tDimensions (WxDxH):2,1 x 1,15 x 3,4 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 foundation pit:not necessary
pressure:015 tthroat:200 mmstroke:4 - 70 mmno. of strokes:140 /mindistance table/ram, max. stroke up, adjustment up:310 mmtable surface area:430 x 395 mmhole in the table:165 x 160 mmtable height over floor:560 - 735 mmtable adjustable:175 mmram surface:160 x 130 mmram adjustment:80 mmpower requirement:1,2 kWweight:0,9 tDimensions (WxDxH):1,0 x 1,25 x 1,8 mclutch:Drehkeil overload protection in ram:mechanical
pressure:030 tstroke:8 - 40 mmno. of strokes:100 - 600 /mindistance between columns:325 mmdistance table/ram, max. stroke up, adjustment up:250 mmtable surface area:540 x 300 / 325 x 395 mmhole in the table:315 x 110 mmtable height over floor:1000 mmcolumn travel -side:290 mmram surface:250 mmmaterial width of feeder:120 mmmaterial thickness of feeder:3,0 mmfeed length:60 mmpower requirement:5,5 kWweight:2,6 tDimensions (WxDxH):1,5 x 1,2 x 2,2 mclutch:pneumatic roll feed:mechanical, Bruderer BBV 120/60
pressure:100 tthroat:350 mmstroke:6 - 100 mmno. of strokes:60 /mindistance table/ram, max. stroke up, adjustment up:400 mmtable surface area:850 x 700 mmhole in the table:470 x 150 mmtable height over floor:855 mmram surface:450 x 300 mmram adjustment:80 mmpower requirement:7,5 kWweight:5,0 tdimensions (WxDxH):1,5 x 2,3 x 2,6 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:mechanical
pressure:500 tdistance between columns:2240 mmstroke:1180 mmdistance table/ram, max. stroke up, adjustment up:1800 mmtable surface area:2050 x 1800 mmpressure of drawing cushion in table:250 tstroke of drawing cushion in table:380 mmdrawing cushion surface in table:1800 x 1200 mmpressure of drawing cushion in ram:122 tstroke of drawing cushion in ram:200 mmdrawing cushion area in ram:1800 x 1200 mmram surface:2215 x 1800 mmtable height over floor:500 mmspeed down:400 mm/sspeed up:10 - 400 mm/sworking speed:10 - 100 mm/sdepth of the foundation:3,0 mpower requirement:122 + 75 + 64,5 kWweight:110,0 tDimensions (WxDxH):3,6 x 2,2 x 8,5 mheight over floor:6,8 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table and ram:hydraulic
pressure:500 tdistance between columns:3200 mmstroke:1250 mmdistance table/ram, max. stroke up, adjustment up:1810 mmtable surface area:3000 x 1900 mmpressure of drawing cushion in ram:150 tstroke of drawing cushion in ram:200 mmdrawing cushion area in ram:2400 x 1200 mmram surface:3160 x 1900 mmspeed down:400 mm/sspeed up:250 mm/sworking speed:18 - 58 mm/sheight over floor:6,5 mpower requirement:90,0 + 36,5 kWweight:110 tGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in ram:hydraulic
pressure:800 tdistance between columns:3010 mmstroke:300 mmdistance table/ram, max. stroke up, adjustment up:1350 mmtable surface area:3000 x 1800 mmtable height over floor:500 mmside window:1500 x 1400 mmram surface:3000 x 1800 mmspeed down:300 mm/soil volume:900 lheight over floor:5,4 mheight beneath floor:2,1 mpower requirement:200,0 kWweight:80,0 tDimensions (WxDxH):5,2 x 2,6 x 7,5 mram interlocking:in TDC depth stop:mechanical
nominal force:315 tstroke:300 mmno. of strokes:36 /mindistance between columns:540 mmdistance table/ram, max. stroke up, adjustment up:750 mmtable surface area:530 x 630 mmblow die to die:630 tAllowed max. force:500 tram surface:450 x 560 mmspindle diameter:180 mmpower capacity:18,0 kWweight:13,0 tDimensions (WxDxH):2,5 x 2,0 x 4,0 m
pressure:100 tdistance between columns:1060 mmstroke:700 mmdistance table/ram, max. stroke up, adjustment up:1250 mmtable surface area:1000 x 700 mmpressure of drawing cushion in table:40 tstroke of drawing cushion in table:200 mmdie cushion area:Ø 250 mmtable height over floor:950 mmside window:580 x 750 mmram surface:1000 x 700 mmoil volume:700 lpower requirement:47,0 kWweight:13,0 tDimensions (WxDxH):2,2 x 1,8 x 5,0 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 depth stop:mechanical; motoric adjustable ram interlocking:SITEMA
