mori seiki 车床 二手 出售

X-AXIS STROKE: 840 MM Y-AXIS STROKE: 860 MM Z-AXIS STROKE: 840 MM TABLE SIZE: 630 X 630 MM TABLE CAPACITY: 1,200 KG SPINDLE POWER: 30/25 KW ROTATION SPEED: 12,000 RPM ATTACHMENT: BT 50 NASOMANDRINO/PALLET DISTANCE: 50-810 MM SPINDLE-PLANK DISTANCE: 150-990 MM TOOL WAREHOUSE: 120 STATIONS MAX. WORKPIECE HEIGHT: 1000 MM CONTROL: MSG-502 YEAR OF BUILD: 2002

MORI SEIKI SH-500/40 Horizontal Machining Center was built in Japan in 1999 by MORI SEIKI CO., LTD. The machine is equipped with a numerical control type MORI SEIKI MSC-502. The milling machine has a table size of 500 x 500 mm and processes workpieces weighing up to 500 kg. The travel range of its X, Y, Z axes is 630 x 600 x 650 mm, respectively. The machine spindle rotates at 12,000 revolutions per minute. The milling machine is equipped with a magazine for forty tools with a maximum tool diameter of 150 mm, length 360 mm and a weight of 12 kg. The milling center is offered at a price with different types of holders. Technical parameters of the MORI SEIKI SH-500/40 CNC milling machine - CNC control: MORI SEIKI MSC-502 Travel range: - X axis (table travel length): 630 mm - Y axis (vertical movement of the spindle head): 600 mm - Z axis (cross table movement): 650 mm - distan ...

COURSE AXIS X: 840 MM COURSE ASSE Y: 860 MM COURSE ASSE Z: 840 MM TAVOLA SIZE: 630 X 630 MM TABLE RANGE: 1,200 KG TABLE INDEX: 1ST MANDRINO POWER: 30/25 KW ROTATION SPEED: 12,000 GIRI/MIN ATTACK: BT 50 NASOMANDRINO/PALLET: 50-810 MM MANDRINO - TAVOLA: 150-990 MM TOOL WAREHOUSE: 120 STATIONS MAXIMUM HEIGHT OF THE PIECE: 1000 MM CONTROL: MSG-502 BUILT: 2002

Machine Details Stock-No. 1105-03860 Type of machine CNC Lathe Make MORI SEIKI Type SL 150 Year of manufacture 1996 Type of control CNC Storage location Warehouse Country of origin Japan Delivery time immediately Freight basis ex Warehouse, free on truck Price Technical details turning diameter 420 mm centre distance 580 mm Turning length max. 500 mm Travel X / Y 230 / 520 mm spindle turning speed range 50 - 5000 rpm spindle nose JIS A2-5 bar diameter round max 42 mm spindle bearing diameter 90 mm tool turret - number of stations 12 (12) Tool Taper 20 x 20 tailstock adjustment 515 mm tailstock quill diameter 85 mm tailstock quill taper MT 4 tailstock travel 120 mm Rapid Travel - Longitudinal/Face 24 / 18 m/min Coolant Tank 160 L connected load 21 kVA Weight of the machine approx. 4.1 t dimensions of the machine approx. 7.5 x 2.5 x 1.8 m Additional infor ...

COURSE AXIS X: 840 MM COURSE ASSE Y: 860 MM COURSE ASSE Z: 840 MM TAVOLA SIZE: 630 X 630 MM TABLE RANGE: 1,200 KG TABLE INDEX: 1ST MANDRINO POWER: 30/25 KW ROTATION SPEED: 12,000 GIRI/MIN ATTACK: BT 50 NASOMANDRINO/PALLET: 50-810 MM MANDRINO - TAVOLA: 150-990 MM TOOL WAREHOUSE: 120 STATIONS MAXIMUM HEIGHT OF THE PIECE: 1000 MM CONTROL: MSG-502 BUILT: 2002

Machine Details Stock-No. 1105-03874 Type of machine CNC Lathe - Inclined Bed Type Make MORI SEIKI Type SL 15 Year of manufacture 1991 Type of control CNC Storage location FRANCE Country of origin Japan Delivery time by arrangement Freight basis ex stock HAGUENAU FRANCE Technical details Travel -X AXIS 230 mm turning diameter 450 mm turning length 525 mm control FANUC 15TF Spindle Bore: Ø 42 mm Number of Turrets: 1 piece no. of tools in turret 1 12 Stück power capacity 7,5 kW spindle nose A2-5 tailstock quill taper MT 4 feed range 1 - 15000 mm/min Rapid Traverse 15 m/min Additional information Machine in good condition CONTROL FANUC 15 TF CHIP CONVOYER TAILSTOCK NICE MACHINE

YEAR: 08/2004 LONGITUDINAL CORSA: X 800 MM TRANSVERSE COURSE: Y 700 MM VERTICAL COURSE: Z 700 MM ASSE B INDEXED 1st PALLET (2) 500X500 MM CNC MAPPS MSG-501 TOOL WAREHOUSES 60 LOCATIONS ATTACK MANDRINO BT40 MANDRINO MASSIMA VELOCITY 12000 RPM POWER OF MANDRINO'S POWER 26 KW

Mori Seiki NT 1000 multitasking lathe :::SPECIFICATIONS::: CNC Model: Mori Seiki - CNC Version: Mapp - Spindle Nose: ASA 5 - Spindle Power: 11Kw - Main Spindle Speed: 6000 Turning diameter: 370mm - Self-centering diameter: 210mm - Bar passage: 42mm - Turning length: 424mm - Number of tools: 90 Tool holder: CAPTO C4 Spindle speed: 12000 X-axis travel: 380mm Y-axis travel: +105 -105mm Z-axis travel: 460mm Swivel B-axis travel: +120° -120° degrees Rapid feeds linear axes X Y Z: X 40 Y 40 Z 50m/min High refrigerant pressure: yes Pressure value: 50bar External tank system with filter: yes Number of Tool Turrets: 1 Number of first turret tool slots: 10 Number of fixed tool positions in the first turret: 10 First Turret X-Axis Travel: 155mm First Turret Z-Axis Travel: 610mm Sub-spindle: yes Sub-spindle speed: 5000 Sub-spindle power: ...

CNC CONTROL: MSD 501 II, FANUC FEATURES: DIAMETER ADMITTED ON THE BED, MM 680 MAXIMUM TURNING DIAMETER 440 MM N1 MAXIMUM TREATMENT DIAMETER N2 322 MM MAXIMUM TURNING LENGTH, MM 471 THE STANDARD MACHINING DIAMETER MM170 MAIN SPINDLE: STEP PANEL 45 MM COUNTER SPINDLE: HOLE PITCH LINE 43 MM TURRET 1: POSITION N12 ALL MOTORIZED TOWER 2: POSITION N12 ALL MOTORIZED

MORI SEIKI SH-400 Horizontal Machining Center was manufactured in 2000 in Japan by Mori Seiki CO., LTD. The CNC milling machine is equipped with Mori Seiki MSC-501 numerical control. The price of the machine includes various types of frames. Technical data of the MORI SEIKI SH-400 CNC milling machine - CNC control: MORI SEIKI MSC-501 - machine weight: 10100 kg

4 pcs. rope pulleys for counter weight of a FB 225 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Deckel Maho DMG DMU 70eVolution 5Axis simultaneous Machining center CNC Hersteller [manufacturer]: DMG Deckel Maho Type [ type]: 70eVolution Control unit: Heidenhain iTNC 530 Incl. handwheel Baujahr[construction year]: 12/2006 - Renewed/renewed spindle - IKZ integrated cooling system for water 40bar and air (both possible) Travel X/Y/Z 750/600/520 mm B-axis 0 to 180° degrees C-axis n x +-360° degrees Table load up to 350kg Spindle speed range 20 to 18,000 1/min. Tool holder SK 40 DIN 69871 Weight [weight]: 10.000kg Full documentation is available. Inspection under power can be done at short notice. We will be happy to answer any further questions you may have. Tel. 017621834834Price, from stock here plus VAT Condition: good - ready for demonstration Delivery: from stock - as seen Payment: purely net - upon receipt of invoice Prior sale, errors excepted.  ...

Machine Details Warehouse number 1105-03545 Machine Type Machining Center - Vertical Mori SEIKI brand Type MV 40 B Year of construction 1991 Control type CNC Controller (FANUC 16M) MSG M 4 Storage location FRANCE Country of origin Japan Delivery time immediately Freight base from stock HAGUENAU FRANCE Price Technical details x-travel 800 mm y-travel 410 mm z-travel 510 mm Controller (FANUC 16M) MSG M 4 Rapid traverse X-axis 20 m/min Rapid traverse y - direction 20 m/min Rapid traverse Z-axis 15 m/min Table area 1150 x 450 mm Tool holder BT 40 Number of tool holders 30 tool diameter 80 mm tool length 250 mm tool weight 8 kg Speed range 10000 1/min Total power requirement 5.5 / 7.5 kW Machine weight approx. 6 t Information SUPER MACHINE CNC MORI MSG M 4 FANUC 16 WITH 4 AXIS NIKKEN

Mori seiki MT 2000 multitasking lathe :::TECHNICAL SPECIFICATIONS::: CNC model: Mori Seiki - CNC version: MSC 501 - Spindle nose: ASA 6 - Spindle power: 22Kw Number of main spindle speeds: 6000 - Turning diameter: 540mm - Bar passage: 65mm - Turning length: 1020mm Number of tools: 60 Tool holder: CAPTO C6 Spindle power: 18Kw Number of spindle speeds: 8000 X-axis travel: 565mm Y-axis travel: +-80mm Z-axis travel: 1077mm Swivel B-axis travel: + - 120 ° degrees Fast feeds for linear axes X Y Z: 24m/min High refrigerant pressure: yes Pressure value: 80bar External tank system with filter: yes Number of tool turrets: 1 Number of tool positions for the first turret: 12 Number of Motorized First Turret: 12 First turret X-axis travel: 155mm First turret Z-axis travel: 1067mm Sub-spindle: yes Spindle nose: ASA 5 Number of counter ...

MORI SEIKI NT6600 CNC INTEGRATED MILL TURN CENTER WITH LIVE MILLING MAXIMUM SWING OVER BED: 42" MAXIMUM WORK PIECE DIAMETER: 42" MAXIMUM WORK PIECE LENGTH: 239" MAXIMUM BAR DIAMETER: 6.4" SPINDLE BORE: 7" X AXIS TRAVEL: 41" Y AXIS TRAVEL: 26" Z AXIS TRAVEL: 242" B AXIS: +/- 120 DEG. MAIN SPINDLE SPEED: 1500 RPM MAIN SPINDLE MOTOR: 40 HP MILLING SPINDLE SPEED: 8000 RPM MILLING SPINDLE MOTOR: 40 HP ELECTRICS: 220V/3P/60Hz/216A OAD (APPROXIMATE): 490" X 182" X 169" HIGH WEIGHT (APPROXIMATE): 120,560 LBS. EQUIPPED WITH: C AXIS YAXIS B AXIS LIVE TOOLING/MILLING 20" CHUCK FS-31iA5 CNC CONTROL 140 POSITION AUTOMATIC TOOL CHANGER PROGRAMMABLE TAILSTOCK COOLANT THROUGH SPINDLE (HIGH PRESSURE) CHIP CONVEYOR Additional Control Options: Automatic Power Shut-Off MAPPS 4 System Part Program Storage: 8mb Stored Programs: 1000 Remote Communication Function ATA Flash M ...

Machine Details Stock-No. 1105-03607 Type of machine CNC Turning and Milling Center Make MORI SEIKI Type SL 150 SMC Year of manufacture 1997 Type of control CNC Storage location FRANCE Country of origin Japan Delivery time immediately Freight basis ex stock Technical details turning diameter 420 mm turning length 560 mm control fanuc 16 T swing dia. 455 mm rapid power traverse in X-and Z direction 18/24 m/min Travel x/z 220 / 520 mm bar material dia. 45 mm spindle drive 11 / 7.5 kW Spindle RPM 50 - 5000 U/min Spindle Torque 143 Nm spindle nose JIS A2-5 Turret positions 12 supspindel wiht 3 jaw chuck sup spindle Travel 450 mm total power requirement 25 kW Additional information WHIT FANUC 16 T CONTROL SUP SPINDLE C AXIS LIVE TOOLS X 5 PARTS CATCHER COLLECT CUCK OFF MAIN SPINDLE AND 3 JAW CHUCK OFF SUP SPINDLE - coolant equipment SHIP CONVEYOR

Machine Details Warehouse number 1105-03650 Machine Type Machining Center - Vertical Mori SEIKI brand Type MV 40 E Year of construction 2001 Control type CNC Control msc 500 (FANUC 16M) Storage location FRANCE Country of origin Japan Delivery time immediately Freight base EX WORK Technical details x-travel 560 mm y-travel 410 mm z-travel 460 mm Control msc 500 (FANUC 16M) Rapid traverses x/y/z 20/20/15 m/min Table area 900 x 450 mm Tool magazine: 30 BT 40 tool diameter 80 mm tool length 250 mm tool weight 8 kg Spindle speed 8000 1/min Spindle motor 7.5 kW Total power requirement 30 kW Machine weight approx. 5 t Space requirement approx. 2.48 x 2.25 x 2.8 m Information FANUC 16 M 2 SPAENEFOERDERER

Mori Seiki ZT 1500YB in operation, can be viewed during operation. 2002 yes Mori CL 2000 can be viewed under power. Currently not in operation 2004 yes Mori Seiki SL-204 can be viewed under power. Currently not in operation 2001 yes Mori Seiki SL-204 can be viewed under power. Currently not in operation 2003 yes

Machine Details Stock number 1105-03758 Machine type CNC lathe - inclined bed machine Brand MORI SEIKI Model SL 250 BMC Year of construction 1999 Control type CNC Control FANUC MSC 503 Storage location FRANCE Country of origin Japan Delivery time immediately Freight base EXW (Incoterms 2000) free Technical details Turning diameter 356 mm Turning length 500 mm Control FANUC MSC 503 Turning diameter over bed 520 mm Turning diameter above the paddling carriage 275 mm Center width 525 mm Travel - x 260 mm Travel - z 550 mm Spindle speeds 42 - 4000 rpm Spindle bore 85 mm Turret head (x-fold) 12-fold Shank cross-section 25 Shank diameter 50 mm Rapid traverse longitudinal 15000 mm/min Rapid traverse plan 12000 m/min tailstock stroke 491 mm Motor power 15 / 11 kW Total power requirement 30 kW Machine weight ca. 5.5 t Information VERY well maintained machine wit ...

Key data: 490 mm, 515 mm

tock-No. 1105-04043 Type of machine CNC Turning- and Milling Center Make MORI SEIKI Type NL1500SY/500 Year of manufacture 2006 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Japan Delivery time immediately Freight basis ex Warehouse Price Technical details turning diameter 490 mm turning length 515 mm control MSX-850 max. bar capacity 52 mm Travel -X Axis 280 mm Travel -Z AXIS 490 mm max. speed main spindle 6000 min-1 spindle taper 1 A2-6 C - Axis 0.001 ° Spindle bearing diameter 110/75 mm No. of tools in turret 1 12 Shaft Cross Cut 25 x 25 mm Shank diameter 50 / 32 mm Turret Change Time 0.25 s max. spindle speed driven tools 6000 min-1 rapid power traverse in X-and Z direction 30 m/min Rapids C - Axes 400 min -1 drive capacity - spindle motor 18.5 kW power capacity - driven tools 5.5 kW swing diameter over face slide 278 mm gre ...

Mori Seiki ZT 1500YB in operation, can be viewed during operation. 2002 yes Mori CL 2000 can be viewed under power. Currently not in operation 2004 yes Mori Seiki SL-204 can be viewed under power. Currently not in operation 2001 yes Mori Seiki SL-204 can be viewed under power. Currently not in operation 2003 yes Tsugami NP-32 can be viewed under power. Currently not in operation 1992 yes Riello in operation, can be viewed during operation. 2002 yes Muratec MW 120 GT 2012

Machine Details Stock number 1105-03760 Machine type machining center - vertical Brand MORI SEIKI Type MV 40 Year of construction 1999 Control type CNC Control msc 501 (FANUC 16M) Storage location FRANCE Country of origin Japan Delivery time immediately Freight Base EX WORK Price Technical details x-travel 560 mm y-travel 410 mm z-travel 460 mm Control msc 501 (FANUC 16M) Rapid traverse x/y/z 20/20/15 m/min Table surface 900 x 450 mm Tool magazine: 30 BT 40 tool diameter 80 mm tool length 250 mm tool weight 8 kg Spindle speed 8000 1/min Spindle motor 7.5 kW Total power requirement 30 kW Machine weight ca. 5 t Space requirement approx. 2.48 x 2.25 x 2.8 m Information The machine IS IN GOOD CONDITION CONTROL MSG 501

Machine Details Stock number 1105-03771 Machine type CNC lathe Brand MORI SEIKI Type SL 25 B/500 Year of construction 1992 Control type CNC Control mori Fanuc MF T6 T6 fanuc mori Storage location FRANCE Country of origin Japan Delivery time immediately Freight base from site Technical details Turning diameter 260 mm Turning length 625 mm Control mori Fanuc MF T6 T6 fanuc mori Circumferential diameter over bed 520 mm Orbital diameter via slide 350 mm Turning length 530 mm Travel - x 160 mm Travel - z 590 mm Speed 35-3500 rpm Spindle nose A2-6 Spindle bore 80 mm Bearing diameter 130 mm Turret head 10 pos. VDI Tool change time 0.7 sec Rapid traverse X-axis 12 m/min Rapid traverse Z-axis 15 m/min Quill diameter 110 mm Quill stroke 100 mm Tailstock displacement 491 mm Drive power - spindle motor 15/11 kW Total power requirement 40 kW Machine weight ca. 5 t  ...

Machine Details Stock number 1105-03807 Machine type CNC turning and milling center Brand Mori Seiki Type NL 2000 SY Year of construction 2005 Control type CNC Control MSX 850 Mapps 3 Storage location FRANCE Country of origin Japan Delivery time immediately Freight Base EX WORK Technical details turning diameter 356 mm Turning length 510 mm Control MSX 850 Mapps 3 Swing diameter 755 mm Standard turning diameter 275 Rod diameter 65 mm Travel - x 260 mm Travel - z 590 mm Spindle drive 15 kW Spindle speed 5000 1/min Turret stations / powered 12/12 Rapid traverse - longitudinal/flat 30 m/min Total power requirement 32 kW Machine weight ca. 5,8 t Space requirement approx. 2320 x 1783 x 1819 mm Accessories Conveyor High-pressure cooling 5 bar Workpiece counter Total counter Double foot switch Information High performance CNC lathe SUP SPINDLE + C AXIS + ...

turning diameter: max. 320 mm turning length: 810 mm control: MSX 701 MAPPS III standard turning dia.: 200 mm Main spindle:: Number of revolutions: max. 6.000 min/-1 power capacity - main spindel: 22 / 18,5 kW Bar feed: max. 52 mm spindle bore: 61 mm C-Axis: 0,001 ° Subspindel:: Number of revolutions: max. 6.000 min/-1 power capacity - Sub spindle: 22 / 18,5 kW Bar feed: max. 52 mm spindle bore: 61 mm C-Axis: 0,001 ° Turret 1 + 3:: number of toolpositions: je 16 pos. Number of driven toolspositions: je 16 pos. Spindle speed - driven tools: max. 6.000 min -1 power capacity - driven tools: 7,5 / 5,5 kW Y - Axis: 110 (+65 / -45) mm Turret 2:: number of toolpositions: 16 pos. Number of driven toolspositions: 16 pos. Spindle speed - driven tools: max. 6.000 min -1 power capacity - driven tools: 7,5 / 5,5 kW Y - Axis: 110 (+45 / -65) mm axis stroke:: x-travel: 1-3: 210 mm y-travel: 1-3: ...

Key data: 510 mm, 510 mm, 510 mm

Machine Details Stock-No. 1105-03907 Type of machine Machining Center - Vertical Make MORI SEIKI Type CV 500 Year of manufacture 1998 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Japan Delivery time CALL ME Freight basis EXW (Incoterms 2010) loaded on Technical details X-Travel 510 mm Y-Travel 510 mm Z-Travel 510 mm control MSC 803 number of spindle speeds 8000 spindle drive 7.5 kW Rapid Travel X/Y/Z 42/32 mm/min table-size 750 X 550 mm tool changing time 1.5 sec tool magazine: 25 BT 40 total power requirement 51 kW Weight of the machine approx. 4 t Accessories Memory 640 m Helical Interpolation Cylinder interpolation Additional information ROTARY DOUBLE TABLE CNC MSG 803 Technical details and information subject to amendments and errors.

MORI SEIKI MV 65-50 Year 1986 - STROKES (mm) X = 1270 Y = 650 Z = 650 -FANUC 11M CNC control -Tool holder -30 tool warehouse

Key data: 1050 mm, 560 mm, 560 mm

Machine Details Stock-No. 1105-03956 Type of machine Machining Center - Vertical Make MORI SEIKI Type MV 55 Year of manufacture 1991 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Japan Delivery time immediately Freight basis ex site Price Technical details x-travel 1050 mm y-travel 550 mm Z-Travel 560 mm control FANUC O M table-size 1,400 x 550 mm max. table load 1500 kg turning speed range - milling 6000 rpm tool taper BT 50 Tool changer 30 pos. max. tool diameter 80 mm max. tool-dia with free toolbox 125 mm max. tool length 250 mm max. tool weight 12 kg power capacity - milling spindle 7,5 / 11 kW rapid traverse X-axis 15 m/min rapid traverse Y-axis 15 m/min rapid traverse Z-axis 12 m/min Feed 0.001 ~ 5.000 mm/min spindle bearing diameter 100 mm total power requirement 35 kW weight of the machine approx. 10 t dimensions of t ...

Key data: 1020 mm, 510 mm, 460 mm

Machine Details Stock-No. 1105-04002 Type of machine Machining Center - Vertical Make MORI SEIKI Type MV 50 Year of manufacture 2001 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Japan Delivery immidiately Freight basis ex site Technical details x-travel 1020 mm y-travel 510 mm Z-Travel 460 mm control MSG 500 table-size 1350 X 550 mm max. table load 800 kg turning speed range - milling 8000 rpm tool taper BT 40 Tool changer 20 pos. max. tool diameter 80 mm max. tool-dia with free toolbox 125 mm max. tool length 250 mm max. tool weight 12 kg power capacity - milling spindle 7,5 / 11 kW rapid traverse X-axis 32 m/min rapid traverse Y-axis 32 m/min rapid traverse Z-axis 24 m/min Feed 0.001 ~ 10.000 mm/min spindle bearing diameter 100 mm total power requirement 35 kW weight of the machine approx. 5.7 t dimensions of the machine appr ...

Machine-Details Stock-No. 1105-04009 Type of machine Machining Center - Horizontal Make MORI SEIKI Type MH 50 Year of manufacture 1993 Type of control CNC Storage location FRANKREICH Country of origin Japan Delivery time stock Freight basis ex. location Technical details X-Travel 710 mm Y-Travel 600 mm Z-Travel 600/730 mm FANUC 16 M control power capacity - milling spindle 22 kW Spindle Turning Speed - Stepless 13000 1/min numbers of tools in magazin 120 BT 50 size of pallet 500 x 500 mm max. workpiece diameter on pallets 580 mm workpiece height max. 740 mm B-axis (table) 360000° X/Y/Z -STEPLESS feeds 24 mm/min Rapid Travel X/Y/Z 24000 mm/min total power requirement 35 kVA weight of the machine ca. 17 t dimensions of the machine ca. 3.9 x 3.4 x 2.6 m Accessories Chip conveyor Additional information NICE MACHINE - 2 pallets 500 X 500 360000° PALLET IND ...

DMG MORI SEIKI DMC 635 V Ecoline CNC machining center was built in 2013. The machine, designed for precision machining of workpieces, is distinguished by its extremely stable construction made of high-quality cast iron, which perfectly dampens any vibrations and oscillations. To achieve the highest precision and accuracy, reliable components in the form of cutting tools and a high-speed spindle are used in the machining process. Tools are changed in a very short time, so that the overall milling time is significantly reduced. The DMG DMC 635 V ECO CNC vertical machining center is offered with a modern touchscreen control panel and integrated chip conveyor. To this date, the machine has only worked for 9069 hours. The DMC 635 V ECOLINE milling center weighs 3900 kg. Technical specifications of the CNC milling machine DMC 635 V ECO - number of axes: 3 (X,Y,Z) - feed in the X/Y/Z ax ...

Key data: 1400 mm, 1200 mm, 1350 mm

A horizontal machining center from the manufacturer Mori Seiki NH 8000 DCG is offered here. The machine is in good condition and can be visited. Make: Mori Seiki Huzvdlw Type: NH 8000 DCG Year of Make: 2008 Control: Fanuc MSX-701III Specifications: Travel: X-axis 1400 mm Y-axis 1200 mm Z-axis 1350 mm B-axis rotary table 360x0.001° automaton. Tool changer with 60 tool positions Tool holder HSK 100 2-fold pallet changing system Pallet dimensions 800 mm x 800 mm max. tool length 800 mm max. tool weight 30 kg Spindle power 37 KW Max. spindle speed 8000rpm. IKZ cooling system

MSX-850 Controller Max. turning diameter: 386 mm Max. bar passage: 52 mm Travel X/Y/Z/B: 260/100/590/624 mm Main spindle max. speed: 6,000 rpm Sub-spindle max. speed: 6,000 rpm Beghs3a 12-speed tool turret 12 driven stations 5.5 kW, max. speed: 6,000 rpm Automatic Parts Catcher Conveyor

turning diameter: 390 mm turning length: 507 mm control: MSG 806 MAPPS max. turning diameter: 390 mm greates pass round over bed: 680 mm Swing dia. over traverse guideway: 510 mm centre distance: 618 mm Main spindle:: turning speed range - main spindle: 45 - 4.500 min/-1 power capacity - main spindel: 11 / 7,5 kW spindle bearing diameter: 110 mm spindle bore: 73 mm max. bar capacity: 51 mm spindle nose: JIS A2-6 chucking diameter: 210 mm C-Axis: 0,001 ° axis stroke:: x-axis: 235 (195+40) mm z-axis: 520 mm turret:: number of toolpositions: 12 pos. Number of driven toolspositions: 12 pos. Spindle speed - driven tool stations: max. 3.000 min -1 power capacity driven tool-stations: 5,9 / 4,5 kW Shank height for square tool: 25 mm Drill shank diameter: max. 50 mm turret change time: 0,2 sec. Tailstock:: tailstock adjustment: 490 mm dia. of quill: 85 mm taper of center: MT 4 quill stroke: ...

CNC controller: Fanuc FS31IA5 (MAPPS 4) Capacity Turning length mm: 800 Max. turning diameter mm: ø Ø430 Turn-mill spindle X-axis travel mm: 455 Y-axis travel mm: ±105 Z-axis travel mm: 800 B-axis degree: ±120 (0.001º) Speed spindle rpm: 12.000 Drive power kW: 9/5.5 Tool magazine Magazine places: 76 Tool holder: Capto C5 Tool length max. mm: 250 Tool diameter max. mm: 70/130 Tool weight max kg: 5 Lower turret X-axis travel mm: 160 Z-axis travel mm: 730 Number of tool slots St .: 10 Main spindle Speed spindle rpm: 6.000 Drive power spindle kW: 11/7.5 Spindle bore mm: 73 Chuck type: Hollow Chuck (8") Manufacturer: KITAGAWA Counter spindle Speed spindle rpm: 6.000 Drive power spindle kW: 7.5/5.5 Chuck type: Solid Chuck (8") Manufacturer: KITAGAWA Equipment Chip conveyor Signal lamp High pressure pump Chuck foot switch (double) for main and counter sp ...

Key data: 500 mm, 420 mm, 400 mm

Machine Details Stock-No. 1105-04021 Type of machine Machining Center - Universal Make LID MAHO DMG Type CMX 50 U 5-axis Year of manufacture 2020 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Germany Delivery time immediately Freight basis EX WORK Technical details X-Travel 500 mm Y-Travel 420 mm Z-Travel 380 mm control HEIDENHAIN TNC 620 tool adaptor SK 40 turning speeds 12000 1/min table surface area 500 X 380 MM mm tool change unit 30 pos. total power requirement 40 KVA 63 A Absich Additional information CONTROL HEIDENHAIN ITNC 620 NC round-swivelling table, coolant device,TOOLS PROBE PARTS PROBE COOULANT TROUGHT THE SPINDLE Cabin

Inv. Num. : 7736 Type: CL2000B Producer: MORI SEIKI Created: 2008 Parameters: Control system: Mitsubishi MAPPS III Switch-on hours: 37200 h Maximum turning length: 560 mm Max. turning diameter: 350 mm

CNC Machining Center Manufacturer: MORI SEIKI Type: Partner M300 A-1 Year of Make: 1990 Control: FANUC O-M Travels: X/Y/Z: 400 x 300 x 495 mm Distance between spindle center and pallet table (Y-axis) 25 – 325 mm Distance between spindle nose and pallet table (Z-axis) 125 – 620 mm Rapid traverse movement: 24 m/min Feed movement up to 5 m/min Spindle: Ball screw: 36 mm diameter Feed Actuators FANUC AC X/Y-Axis Model 5 Z-Axis Model 10 Main spindle revolutions: 100 – 6000 rpm Main spindle motor: AC 5.5 kW Main spindle taper: BT 40 Pallet: Pallet size: 315 x 315 mm Pallet Indexing Angle: 7.5 degrees Indexing accuracy: +/- 2 sec. Repeatability: +/- 1 sec. Clamping force of the pallet: 3,400 kg Max. workpiece weight: 150 kg Automatic Tool Changer: Number of Tools 30 Tool change 2.5 sec. Collets Clamping Time 7 sec. Tool diameter max.: 110 mm Too ...

Inv. Num. : 7790 Type: SL-4T Producer: MORI SEIKI Created: 1984 Parameters: Control system: FANUC 6T Maximum turning diameter over bed: 490 mm Maximum turning diameter over support: 320 mm Maximum spindle speed: 3000 1/min Length: 3100 mm Width: 1900 mm Height: 1900 mm Weight: 5500 kg Equipment: Conveyor

Mori Seiki NL 2500 SY / 700 Lathe :::TECHNICAL SPECIFICATIONS::: CNC Model: Mori Seiki CNC Version: MSX-850 III Main spindle nose: ASA 8 Main spindle power: 18.5Kw Main spindle bar pass: 80mm Turning diameter: 360mm Turning length: 705mm Main spindle speed: 4000 Number of tool turrets: 1 Number of tool positions for the first turret: 12 Number of Motorized First Turret: 12 First turret X-axis travel: 260mm Y-axis travel first turret: +- 50mm First turret Z-axis travel: 795mm Fast feeds for linear axes X Y Z: 30m/min Sub-spindle: yes Spindle nose: ASA 6 Number of counter-spindle speeds: 6000 Counter spindle power: 11Kw Bar loader model and brand: Iemca Master 880 Chip conveyor: belt Presetting: yes Machine equipment: Set of fixed and motorized tool holders :::D DIMENSIONS AND WEIGHT::: Length: 4420mm Width: 2 ...

Key data: 490 mm, 650 mm

Stock-No. 1105-04024 Type of machine CNC Turning- and Milling Center Make MORI SEIKI Type SL 2500 Y /650 Year of manufacture 2003 Type of control CNC Storage location FRANCE Country of origin Japan Delivery time immediately Freight basis ex Warehouse Price Technical details turning diameter 490 mm turning length 650 mm control MSX-805 max. bar capacity 65 mm Travel -X Axis 305 mm Travel -Z AXIS 690 mm Travel -Y Axis +50, -50 mm Max. Speed Main Spindle 4000 min-1 spindle taper 1 A2-6 C - Axis 0.001 ° Spindle bearing diameter 120/85 mm No. of tools in turret 1 10 Shaft Cross Cut 25 x 25 mm Shank diameter 50 / 32 mm Turret Change Time 0.25 s max. spindle speed driven tools 6000 min-1 rapid power traverse in X-and Z direction 30 m/min Rapids C - Axes 400 min -1 drive capacity - spindle motor 18.5 kW power capacity - driven tools 5.5 kW swing diameter ove ...

Mori Seiki NL 2000 SY 500 MOTORIZED LATHE :::TECHNICAL SPECIFICATIONS::: CNC Model: Mori Seiki CNC Version: MSX 850 Main spindle nose: ASA 6 Main spindle power: 15Kw Main spindle bar passage: 65mm Turning diameter: 275mm Turning length: 510mm Number of main spindle speeds: 5000 Number of tool turrets: 1 Number of tool positions for the first turret: 12 Number of Motorized First Turret: 12 First turret X-axis travel: 260mm Y-axis travel first turret: +- 50mm Z-axis travel first turret: 590mm Fast feeds linear axes X Y Z: X 30 / Y 10 / Z 30m/min Sub-spindle: yes Spindle nose: ASA 5 Number of counter-spindle speeds: 6000 Counter spindle power: 7.5Kw Bar Passage: 43mm Z stroke sub-spindle : 625mm Model and brand bar loader: Iemca Master 880 MP-E Chip conveyor: belt Presetting: yes Machine equipment: Extensive machi ...

x-travel: 635 mm y-travel: 510 mm z-travel: 460 mm Control: Siemens 840D total power requirement: kW weight of the machine ca.: 4 t dimensions of the machine ca.: 3,4 x 2,4 x 2,8 m Brand DMG Mori Seiki Machine no F666 Type DMC 635 V Ecoline Control Siemens 840D Year of make 2012 Table length 790 mm Table width 560 mm X 635 mm Y 510 mm Z 460 mm Spindle taper SK40 Speed maximum 12.000 RPM Chip transport Machine size 3.400 x 2.400 x 2.800 mm Machine weight 3.950 kg Tool magazine positions: 30 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 500 mm y-travel: 450 mm z-travel: 400 mm control: Siemens 840D total power requirement: 13/9 kW weight of the machine ca.: 4,7 t dimensions of the machine ca.: 3,4 x 2,5 x 2,2 m Brand DMG Mori Seiki Machine no F652 Type DMU 50 Ecoline Control Siemens 840D Year of make 2012 Table width 500 mm Table diameter 630 mm ø Table adjustable in degrees X 500 mm Y 450 mm Z 400 mm Spindle taper SK40 Speed minimum 20 RPM Speed maximum 10.000 RPM Maximum table load 200 kg Chip transport Machine size 3.400 x 2.500 x 2.200 mm Machine weight 4.700 kg Tool magazine positions: 30 B-as: -5/+110 ° C-as: 360 ° Engine power: 13/9 Kw The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

CNC-Steuerung: FANUC FS-31iA5 (MAPPS 4) Fähigkeiten Drehlänge mm: 424 Max. Drehdurchmesser mm: ø: 370 (270 with turret 2) Stangenarbeitskapazität mm: 52 DREH-FRÄSSPINDEL Indexierungsspezifikationen: yes Verfahrweg X-Achse mm: 380 Verfahrweg Y-Achse mm: ± 105 Verfahrweg Y-Achse mm: 460 + 155 (ATC) B-Achse Indizierung Gra.: ± 120º Max. Spindeldrehzahl U/min: 12.000 Spindelantriebssleistung kW: 9/5.5 Werkzeugmagazine Werkzeugeplätzen: 38 Werkzeugaufnahme: Capto C5 Max. Werkzeuglänge mm: 250 (210 for tools below Ø70mm) Max. Werkzeugdurchmesser mm: Ø70/Ø130 (with/without adjacent tools) Max. Werkzeuggewicht kg: 5 Untere Revolverturm Verfahrweg X-Achse mm: 155 Verfahrweg Y-Achse mm: 610 Anzahl Werkzeugplätze: 10 Drehzahl max. angetriebene Werkzeuge U/min: 6.000 Angetriebene Werkzeuge Leistung kW: 1,5/1,2 Hauptspindel Max. Spindeldrehzahl U/min: 6.000 Sp ...

CNC controller: Mitsubishi M-720BM (MAPPS 2) Capacity X-axis travel mm: 260 Z-axis travel mm: 590 Turning length mm: 510 Max. turning diameter mm: ø: Ø356 Upper turret Tool holder: 12 Main spindle Speed spindle rpm: 5000 Drive power spindle kW: 15/11 Spindle bore mm: 73 Manufacturer: KITAGAWA Equipment Chip conveyor Signal lamp Tool measuring arm High pressure pump Workarea light 4th axis Interface for Bar feeder Rated power kVA Working time hours Under power: 7456 Spnidle: 5423 Basic machine dimensions / weight Length mm: 3495 Width mm: 2050 Height mm: 2230 Weight kg: 5800

The Partner M300 is a versatile machine used for various metalworking and machining tasks. It is designed to handle complex operations such as drilling, milling, and turning, making it suitable for manufacturing and production environments. This machine is ideal for precise and efficient shaping of metal parts, catering to industries requiring high accuracy and repeatability. Technical Specifications: - Dimensions: 1,900 x 2,300 mm - Weight: Approximately 4,500 kg - Electrical System: AC 380V, 50 Hz - Machine Color: RAL 6011 green - Cooling System: Included - Work Area Lighting: Included Pallet Details: - Pallet Size: 315 x 315 mm - Pallet Indexing Angle: 7.5 degrees - Indexing Accuracy: +/- 2 seconds - Repeat Accuracy: +/- 1 second - Clamping Force: 3,400 kg - Maximum Workpiece Weight: 150 kg Travel Paths: - X-Axis: 400 mm - Y-Axis: 300 mm - Z-Axis: 495 mm - Distance Between Spind ...

CNC controller: Mitsubishi M-720BM (MAPPS 2) Capacity X-axis travel mm: 260 Z-axis travel mm: 520 C-axis: 360º (0.001°) Turning length mm: 515 Max. turning diameter mm: ø: Ø356 Upper turret Tool holder: 12 Main spindle Speed spindle rpm: 5000 Drive power spindle kW: 15/11 Spindle bore mm: 73 Manufacturer: KITAGAWA Counter spindle Counter spindle travel mm: 525 Equipment Chip conveyor Signal lamp Tool measuring arm Workarea light Working time hours Under power: 7.456 Cutting Time: 5.423 Basic machine dimensions / weight Length mm: 3.495 Width mm: 2.050 Height mm: 2.230 Weight kg: 5.800

Key data: 730 , 730 , 850

CNC controller: FS-31IA (MSX-701 III) Axes X-axis travel mm: 730 Y-axis travel mm: 730 Z-axis travel mm: 850 Rapid traverse m/min: 50 Distance spindle nose - table surface mm: 100 – 830 Acceleration in the axes m/s2: 9.8 (X), 10.8 (Y), 6.9 (Z) Worktable Number of pallets: 2 Table dimensions mm: 500X500 Maximum workpiece size (D x H) mm: 800 X 1000 Max. workpiece weight kg: 500 APC time s: 7 División estandar Grados: 0.001º Maximum workpiece rotation diameter mm.: 800 Spindle Spindle speed rpm: 14.000 Spindle drive power kW: 22/18.5 Tool holder: HSK A63 Bearing Inner Diameter mm.: 40 Spindle torque Nm: 220 Tool system Tool magazine slots: 120 With free neighboring places mm: 140 With occupied neighboring places mm: 70 Max. Tool Length mm: 500 Max tool weight kg: 12 Tool-to-tool time s: 0,9 Chip-to-chip time s: 3,3 Tool Shanks : BT-40 NUMBER OF TOOL OFFSE ...

x-travel: 600 mm y-travel: 400 mm z-travel: 400 mm control: MSX 501 Mori Seiki work table:: table surface area: 700 x 450 mm max. table load: 350 kg number of T-slots: 4 T-slot - width: 18 mm T-slot - distance: 100 mm Main spindle: Number of revolutions: 12.000 U/min power capacity - main spindel: 18,5 / 15 / 11 kW tool taper: BT 40 max. Torque: 110,5 Nm diameter of forward milling spindle bearing: 70 feeds: rapid travel x/y/z: 20.000 mm/min feed speeds: 1 - 20.000 mm/min Tipp feed: 15 Steps / 0 - 1.260 mm/min Tool-Presetter:: Number of Toolpositions in magazine: 40 Pos. Max. mould width: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 250 mm max. tool weight: 8 kg change-time chip to chip: 2,8 sec change-time tool to tool: 1,0 sec total power requirement: 34 kVA weight of the machine ca.: 7,2 t dimensions of the machine ca.: 2,8 x 3,0 x 2,9 m Documents: Chip conveyo ...

CNC controller: MITSUBISHI MSX-853 IV Axes X-axis travel mm: 560 Y-axis travel mm: 560 Z-axis travel mm: 660 Distance spindle nose - table surface mm: 80-640 Feed rates m/min: 0-60 Worktable Number of pallets: 2 Table dimensions mm: 400 x 400 Maximum workpiece size (D x H) mm: 630x900 Max. workpiece weight kg: 400 APC time s: 9 División estandar Grados: 360 - 0.001º Spindle Spindle speed rpm: 12.000 Spindle drive power kW: 15/11 Spindle torque Nm: 110 Bearing Inner Diameter mm.: 80 Tipo: SJ-2B4351TK Tool system Tool magazine slots: 40 Max. Tool Diameter: 70 With free neighboring places mm: 170 Max. Tool Length mm: 450 Max tool weight kg: 8 Tool Shanks : MAS-BT40 Equipment Chip conveyor Workarea light 4th axis Cooling Tank capacity: 170L High-pressure bar: 15 Machine running times Under power: 64.734 Rated power kVA: ...

Key data: 190 mm

Stock No: 3764 CNC LATHE Manufacturer: Mori Seiki, Type: ZT 1000Y Machine NO.: ZT101CB0056, Year of manufacture: 2003 Specifications: Max. circumferential diameter 190 mm dia. Max. turn. About BED 250 mm DIA. Main motor power 22/18.5 kw Main spindle speed range 6000 rpm Hole through drawing tube 46 mm dia. C axles 0.001 Y axis 40+/- mm Z Aksen Rapid Traverse 1/2 - 24 m/min Tool turret 1 with 16 stations Motor power driven tools 5.5 / 3.7 / 2.2 kW Kw Tool turret 2 with 16 stations Powered tools. 6000 rpm Sub-spindle Sub-spindle speeds 6000 rpm Control MSX-501 Fabr. Power on 15088 hours Operating hours spindle 5080 hours Controlled in 5+2 axes Accessories: Load and Unload device Hydr. Chuck main spindle 169 mm dia Hydr. Chuck Subspindle 169 mm dia Tool setter Weight: 5000 kg

x-travel:800 mm y-travel:460 mm z-travel:510 mm total power requirement:20 kW weight of the machine ca.:8 t Vertical Processing Centre 20kW is the nominal value. The spindle only needs 7.5kW. It looks like 15kW will be enough.

YOM: 2003 CNC controller: MSX-501 Axes X-axis travel mm: 630 Y-axis travel mm: 600 Z-axis travel mm: 670 Rapid traverse m/min: 50 B-axis degrees: 360º (0.001º index) Rapid traverse m/min: 50 Worktable Number of pallets: 2 Table dimensions mm: 500x500 Maximum workpiece size (D x H) mm: ø800x1.000 Max. workpiece weight kg: 500 Spindle Spindle speed rpm: 14000 Spindle drive power kW: 18.5/22 Tool system Tool holder: ISO-40 Tool magazine slots: 60 Equipment Chip conveyor Signal lamp High pressure pump Internal coolant supply

GENERAL Project No.: 905722 Quantity: 1 pcs. Manufacturer: MORI SEIKI Type: SL 2500 Y/650 Control: MSG-805 L MAPPS Year of Make: 2003 Condition: Used machine DESCRIPTION TURN Max. turning diameter 356 mm Max. turning length 655 mm Max. circumferential diameter over bed 520 mm Max. rotation diameter over face slide 250 mm Max. circumferential diameter over bed cover 755 mm Max. speed main spindle 4500 1/min Max. power main spindle at ED 10-40/100% 18 kW Spindle passage main spindle 75 mm Spindle Flange Size Main Spindle A2-8 Axes on the main spindle unit C Hollow clamping cylinder on the main spindle Tailstock NC-controlled 1 turret on top Number of stations/powered by 12/12 Speed tool drive 6000 1/min Axles in the turret X/Y/Z Travel in X/Y/Z 160/120/590 mm Max. rapid traverse speed in X/Y/Z 18/-/24 m/min OTHER EQUIPMENT Tool life monitoring Spla ...

5-axis machining center Mori Seiki NHX 5000 Year of construction 2011 (bought new in 2013) Hours10768 Processing time 7172 hours Electricity one hour 29288 With few operating hours, used only for single part to small series production, mainly for special mechanical engineering The specifications are as follows: Travels: Cylinder Ø 500 x 700 Control M730BM (Mapps2) Speed 10,0000 rpm. Tool holder SK40 DIN 69871 Tool changer 60-fold Pallet changer 2-fold Accessories: Documentation Internal cooling Knoll 50 bar Conveyor Activation to 400 tool positions Pine pallet with long zero point clamping system Lang tensioning tower approx. 100 pieces of tool holders SK40 An on-site inspection is possible at any time by appointment.

x-travel: 560 mm y-travel: 560 mm z-travel: 630 mm Control: MSX 701 III MAPPS Main spindle:: Max. rpm: 14.000 min/-1 power capacity - main spindel: 18,5 / 11 kW max. Torque: 120 Nm tool taper: MAS BT 40 distance spindle center to table: 80 - 640 mm distance Spindlenose and center of table: 100 - 730 mm pallet changer:: numbers of pallets: 2 size of pallet: 400 x 400 mm max. workpiece weight: 400 kg max. workpiecediameter: 630 mm max. workpiece height: 900 mm change time of pallets: 6,0 sec b - axis: 0,001 ° Tool-Presetter:: number of toolpositions: 60 pos. tool taper: MAS BT 40 max. tool diameter: 70 / (140) mm max. tool length: 400 mm max. tool weight: 8,0 kg feeds:: rapid traverse ( X / Y / Z ): 50 m/min feed speeds: 0 - 50.000 mm/min Tipp feed: 0 - 1.260 mm/min total power requirement: 35 kVA weight of the machine ca.: 9,8 t dimensions of the machine ca.: 5,5 x 3,5 x 2,8 m Docume ...

x-travel: 800 mm y-travel: 530 mm z-travel: 510 mm Control: MSC 504 Mori Seiki Main spindle:: turning speeds: max. 10.000 min/-1 power capacity - main spindel: 15 / 11 kW tool taper: SK 40 spindle bearing diameter: 70 mm distance spindle /table: 150 - 660 mm work table:: table surface area: 1.100 x 600 mm max. table load: 800 kg T-slots: 6x 18 mm table height over floor: 900 mm turret:: number of toolpositions: 30 pos. tool taper: SK 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 300 mm max. tool weight: 8,0 kg change-time tool to tool: 1,3 sec change-time chip to chip: 4,1 - max. 9,2 sec feeds:: rapid traverse ( X / Y / Z ): 36 / 36 / 20 m/min feed speeds: max. 6.000 mm/min Tipp feed: 1 - 5.000 mm/min total power requirement: 27 kVA weight of the machine ca.: 6,1 t dimensions of the machine ca.: 3,5 x 3,0 x 2,8 m Documents: Chip conveyor: Co ...

x-travel: 800 mm y-travel: 530 mm z-travel: 510 mm Control: MSC 504 Mori Seiki Main spindle:: turning speeds: max. 10.000 min/-1 power capacity - main spindel: 15 / 11 kW tool taper: SK 40 spindle bearing diameter: 70 mm distance spindle /table: 150 - 660 mm work table:: table surface area: 1.100 x 600 mm max. table load: 800 kg T-slots: 6x 18 mm table height over floor: 900 mm turret:: number of toolpositions: 30 pos. tool taper: SK 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 300 mm max. tool weight: 8,0 kg change-time tool to tool: 1,3 sec change-time chip to chip: 4,1 - max. 9,2 sec feeds:: rapid traverse ( X / Y / Z ): 36 / 36 / 20 m/min feed speeds: max. 6.000 mm/min Tipp feed: 1 - 5.000 mm/min total power requirement: 27 kVA weight of the machine ca.: 6,1 t dimensions of the machine ca.: 3,5 x 3,0 x 2,8 m Documents: Chip conveyor: Co ...

Key data: 275 mm, 4000 1/min

Mori Seiki NL 2500 SY / 1250 CNC lathe with Y-axis, driven tools and 2nd spindle CNC control MSX-850-lll (mitsubishi 720 BM) Turning diameter 275 /366 mm Spindle bore diameter 80 mm Spindle speed 4000 rpm Spindle motor 18.5/15 Kw X-axis travel 260 mm Y-axis travel +50 / -50 mm Travel Z-axis: 1345 mm Travel of the W-axis (sub-spindle to main spindle) 1275 mm Min. indexing C-axis main spindle 0.001° Number of tools on the turret 12x Number of driven tools 12 x Tool cone BMT Bar Feeder LNS Quick Load Servo lll Spindle-motor-driven tools 6000 U/ If you have any questions about the machine, as well as an appointment for a viewing, please contact us by phone or e-mail. Feel free to check out our other ads for a full overview of our stock.

x-travel: 510 mm y-travel: 510 mm z-travel: 510 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m CNC control MSC 803 25-fold automatic tool changer coolant device Technische Daten / technical details: Verfahrweg X / X-Travel 510 mm Verfahrweg Y / Y-Travel 510 mm Verfahrweg Z / Z-Travel 510 mm Tischgröße / table size 750x548 mm Drehzahlbereich / spindle speed 8000 UpM /rpm Anzahl der Werkzeugplätze / tool places in changer 25 fach Antriebsleistung Spindel / drive capacity spindle 11 kW Gewicht der Maschine ca. / weight 4500 Kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 500 mm, 450 mm, 400 mm

Brand DMG Mori Seiki Machine No: F652 Type DMU 50 Ecoline Control Siemens 840D Year of construction 2012 Table width 500 mm Table diameter 630 mm ø Table adjustable in degrees X 500 mm Y 450 mm Z 400 mm Spindle Taper SK40 Minimum speed 20 RPM Maximum speed 10,000 RPM Maximum table load 200 kg Chip transport Machine size 3,400 x 2,500 x 2,200 mm Machine weight 4,700 kg Magazine slots: 30 B-axis: +110/-5° C-axis: 360° Engine power: 13/9 Kw

Key data: 635 mm, 510 mm, 460 mm

Brand DMG Mori Seiki Machine No: F666 Type DMC 635 V Ecoline Control Siemens 840D Year of construction 2012 Table length 790 mm Table width 560 mm X 635 mm Y 510 mm Z 460 mm Spindle Taper SK40 Maximum speed 12,000 RPM Chip transport Machine size 3,400 x 2,400 x 2,800 mm Machine weight 3,950 kg Magazine slots: 30

Travel X/Y/Z: 400mm/300mm/495mm, spindle center table distance: 25mm-325mm, spindle nose table distance: 125mm-620mm, rapid traverse: 24m/min, feed rate: 5m/min, spindle type: ball screw, spindle diameter: 36mm, speed: 6000rpm, spindle power: 5.5kW, spindle mount: BT40. Tool slots: 30, tool change time: 2.5s, clamping time: 7s, max. tool diameter/length: 110mm/250mm, max. tool weight: 8kg. Table dimensions X/Y: 315mm/315mm, table angle: 7.5°, table clamping force: 3400kg, max. workpiece weight: 150kg. Dimensions X/Y: approx. 1900mm/2300mm, weight: approx. 4500kg, control: Fanuc 0-M, operating hours: 732h, piece counter: 172776. Including cooling lubricant system and tool magazine with 30 places. Documentation available. On-site inspection is possible.

Turning diameter: 420mm, turning length: 820mm, spindle bore: 105mm, speed: 3000rpm, spindle power: 22kW, travel X/Z: 280mm/820mm, tool positions: 10, drive tool speed: 6000rpm. Machine dimensions X/Y/Z: approx. 4400mm/2100mm/2300mm, weight: approx. 6000kg, control: Mitsubishi M-720BM (MAPPS 2), operating hours: 10000h. Including various accessories. The driven tools have never been used, only the Y-axis has run. Measuring arm and ball screw of the Y-axis are as good as new. Documentation available. On-site inspection is possible.

CNC controller: FANUC FS-31iA5 (MAPPS 4) Capacity X-axis travel mm: 685 Y-axis travel mm: 125 Z-axis travel mm: 1075 Turning length mm: 1045 Max. turning diameter mm: ø: 600 Bar work capacity mm: 65 Turn-mill spindle Full indexing specifications: YES B-axis degree: 120º FULL INDEXING SPECIFICATION Speed spindle rpm: 12000 Drive power kW: 18.5/11 Tool magazine Magazine places: 80 Tool holder: CAPTO C5 Tool length max. mm: 250 Tool diameter max. mm: 70/130 Tool weight max kg: 5 Lower turret Number of tool slots St .: 12 Drive power driven tools kW: 5.5/3.7 Main spindle Speed spindle rpm: 5000 Drive power spindle kW: 25/22 (100%/40%ED) Spindle bore mm: 73 Chuck type: HOLLOW CHUCK (8") Manufacturer: KITAGAWA Counter spindle Speed spindle rpm: 5000 Drive power spindle kW: 25/22 (100%/40%ED) Spindle bore mm: 73 Chuck type: HOLLO ...

X-axis travel mm: 260 Z-axis travel mm: 590 B-axis travel mm: 624 Turning length mm: 515 Max. turning diameter mm: ø: 366 Swing over bed mm: ø: 923.8 Swing over cross-slide mm: 755 Bar work capacity mm: 52 Upper turret Number of tool slots St .: 16 Speed driven tools RPM: 6.000 Drive power driven tools kW: 5.5/5.5/3.7 (3min/5min/cont) Indexing time s: 0.25 Main spindle Speed spindle rpm: 6.000 Drive power spindle kW: 11/7.5 Spindle bore mm: 61 Chuck type: Hollow Chuck (6") Manufacturer: KITAGAWA Spindle nose: JIS A2-5 Counter spindle Speed spindle rpm: 6.000 Drive power spindle kW: 11/7.5 Spindle bore mm: 43 Chuck type: Hollow Chuck (6") Manufacturer: KITAGAWA Coolant system Tank capacity liter: 235 Equipment Chip conveyor Signal lamp High pressure pump Chuck foot switch (double) for main and counter spindle Interface for ...

Key data: 560 , 560 , 630

CNC controller: FS-18IMB (MAPPS 2) Axes X-axis travel mm: 560 Y-axis travel mm: 560 Z-axis travel mm: 630 Rapid traverse m/min: 50 Rotary Worktable (4th axis): FULL 4TH AXIS ROTARY TABLE Worktable Number of pallets: 3 Table dimensions mm: 400 Maximum workpiece size (D x H) mm: 560 x 800 Max. workpiece weight kg: 300 APC time s: 6 Spindle Spindle speed rpm: 14.000 Spindle drive power kW: 18.5/11 KW Spindle torque Nm: 120 Nm (10%ED) Tool system Tool holder: BT-40 Tool magazine slots: 120 With free neighboring places mm: 140 With occupied neighboring places mm: 70 Max. Tool Length mm: 400 Max tool weight kg: 8 Tool-to-tool time s: 0,9 Chip-to-chip time s: 2,8 Equipment Chip conveyor Signal lamp 4th axis Ready for internal cooling (40/80 bar) RENISHAW OMP60 CE Round pallet storage Measuring system (worktable) Cooling Tank ...

swing dia.: 680 mm max. turning diameter: 429 mm turning length: 440 mm control: Fanuc turning speeds: 5.000 U/min max. bar material dia.: 56 mm travel -x axis: 233 mm travel -z axis: 510 mm number of tapers in turret head: 2x12 CNC Turning- and Milling Center | MORI SEIKI - ZL-150SMC equipped with main/counter spindle, c- axis, 2x turret for driven tools, bar feeder and chip conveyor. The machine is in a well-maintained condition. Please note that the technical details were added from comparable machines. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: ZL 150SMC | ZL150SMC | ZL-150 SMC | ZL 150 SMC The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 800 mm

Technical details are on picture. Parts shown by hand not come.

Technical data shown on picture. Parts shown by hand not come.

MAchine is in good working condition.

- C-Axis rapid traverve 400 Min - Turret indecing time 0,2 sec for 1 station - Heavy duty cutting (depth cut 6mm) 162.7 mL/Min - LNS Bar feeder new 2017 - Large package tooling driven / live tools - 8 axis controlled with 2 spindles and turrets

x-travel: 600 mm y-travel: 530 mm z-travel: 510 mm Control: M 730 BM MAPPS IV Main spindle:: max. spindle speed: 10.000 min/-1 power capacity - main spindel: 15 / 11 kW tool taper: SK 40 transmission ratio: 1 spindle diameter in front bearing: 80 mm work table:: table surface area: 900 x 600 mm max. table load: 800 kg T-slots: 6x 18 x 100 mm distance spindle /table: 150 - 660 mm Tool-Presetter:: number of toolpositions: 30 pos. tool taper: SK 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 150 mm max. tool length: 300 mm max. tool weight: 8,0 kg change-time tool to tool: ca. 1,3 sec change-time chip to chip: ca. 3,45 sec feeds:: rapid traverse ( X / Y / Z ): 30 m/min feed speeds: 1 - 30.000 mm/min Tipp feed: 0 - 5.000 : 20 mm/min total power requirement: 30 kVA weight of the machine ca.: 6,0 t dimensions of the machine ca.: 4,5 x 3,5 x 2,7 m Documents: Chip conveyor:  ...

Key data: 430 mm, 1260 mm

Control MORI SEIKI ... MSX-850 MAPS II Turning diameter ... 430mm Turning length ... 1260mm Inclined bed Axis Y ... +- 60mm Spindle bore ... 105mm powered tools ... 10 Axis X ... 280mm Axis Z ... 1370mm Circumferential diameter over bed ... 995mm Circumferential diameter via support ... 825mm Spindle speed ... 1-3000 rpm Axis C ... 0,001° Motor power of driven tools ... 5.5kW Main engine power ... 25/30kW Max. spindle torque ... 1000/1300Nm Machine weight... 8100kg L x W x H ... 4532x2291x2390mm The machine is in good condition, possible to test under power.

Mori Seiki SL250 b 500 High-performance CNC lathe with bar feed (Kupa 2 m) Collet chuck Passage 65 mm Year of construction 1998 Control Fanuc 16l Block Recording Switch-on hours approx. 88875 Spindle hours 19,000 Miscellaneous accessories:

Key data: 610 mm, 1540 mm

Stock number: 3998 CNC LATHE Manufacturer: MORI SEIKI , Type: NTX 2000 / 1500 SZ MAPPS-IV CNC Year of Make: 2013 Specifications: Max. circumferential diameter 610 mm dia. Turning length 1540 mm Main spindle 4000 RPM - 26 kw Hole through drawing pipe 80 mm dia. Spindle bore 91 mm dia. C axis - head spindle movement 0.001 degrees X axis movement 675 mm Z ash movement 1562 mm Y axis +/- 125 mm mm B axis movement 120 degree - 0.0001 degree B axis spindle speed 12000 rpm B axis spindle effect 18.5 Sub-spindle 5000 RPM - 22 Kw Control MAPPS IV (MX711 ) 5 axis Fabr. Accessories: ATC Tool magazine with 76 stations Hydr. Chuck main spindle Kitagawa BB-210 - 250 mm/dia mm dia Hydr. Chuck Subspindle Kitagawa BB-208 - 200 mm/dia mm dia Car Door Chip conveyance. High pressure coolant pump 70 bar Measuring System Renishaw S ...

Two identical CNC lathes Mori Seiki are available. Turning diameter: 356mm, max. machining length: 705mm, travel X/Z: 260mm/795mm, speed: 4000rpm, spindle bore: 91mm, spindle power: 18.5kW, tool positions: 12. Machine dimensions X/Y/Z: approx. 2800mm/1900mm/2150mm, weight: approx. 6000kg, control: Mitsubishi/Fanuc. The operating hours have a maximum display value of 9999h, therefore the exact runtime cannot be determined. Documentation available. An on-site inspection is possible.

CNC Control: Mitsubishi M-720BM(MAPPS 3) Upper turret Tool holder: 12 Main spindle Max. spindle speed rpm: 4000 Spindle drive power kW: 18.5/15 Spindle bore mm: 91 Manufacturer: KITAGAWA Sub-spindle Spindle motor: 6000 Spindle drive power kW: 11/7.5 Spindle bore mm: 43 Manufacturer: KITAGAWA Equipment Conveyor Signal lamp Tool measuring arm High Pressure Pump Workspace light Common Variables for Custom Macros (100) Year of construction: 2011

For sale Mori Seiki CNC lathe type DL-15 in good condition. Equipped with 2 x 12 positions turret and left and right spindle. Maximum speed 6,000 rpm of both spindles. Fanuc MSC-516 control. Chip conveyors and bar feeders. Still in good condition and still under power, subject to prior sale

turning diameter: 460 mm turning length: 795 mm control: MORI SEIKI M730 BM Swing diameter face slide: 590/360 mm spindle passage: 80 mm Traverse X/Z:: 260/795 mm Number of working hours: 19.552 h Cutting time: 10.704 h spindle drive: 18,5 kW total power requirement: 40 kVA weight of the machine ca.: 6,4 t dimensions of the machine ca.: 3.994 x 3.056 x 2.187 m Chip chuck Ø250 mm. Chuck sub-spindle Ø170 mm. Holder HAINBUCH chip conveyor suction Bar feeder Hydrafeed Multiservo mod MSV max. bar length 1,600 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
