Modelo
(Fabricante: WMW)
Máquina mandrinadora WMW BKoE 450 x 800 Recorrido X: 560 mm Recorrido Y: 400 mm Recorrido Z: 470 mm Husillo: Ø 90 mm Cono: CM4 Salida del husillo: 150 mm Velocidad del husillo: de 50 a 1600 RPM Tamaño de la mesa: 450 x 800 mm Capacidad de carga máxima sobre mesa: 400 kg Escala3 ejes HEIDENHAIN Descenso automático Voltaje: 380 V Ancho con mesa de extremos: 2900 mm / sin extremos de mesa: 1500 mm Profundidad:2500 mm Altura total: 2600 mm Peso: 4,5 T
Key data: 105 mm, 2500 mm, 1850 mm
CNC Heidenhein TNC 124 Tabla 1750 mm x 2000 mm diámetro del husillo 105 mm x - 2500 mm, y - 1850 mm, z - 1400 mm, ancho - 700 mm
CAPACIDAD MÁX. 63 T, DIÁMETRO DE LAMINACIÓN 110
DIÁMETRO MÁXIMO 250 LONGITUD MÁXIMA 800
Rectificadoras de engranajes WMW Modul ZStTK 1250x24
Key data: 460 mm, 10
GENERADOR EN ESPIRAL DE ENGRANAJES BISELADOS
Max diam 250 , max longitud 2000, 3 x cabezas , cambio de marcha
Máquina cilíndrica de rectificar WMW SA 6Ux3000 con accesorios
Máquina de engranajes cónicos en espiral ZFTKK 500/3V. Algunos de los cambios de marcha faltan
Prensa excéntrica PEE I 250, en condiciones de trabajo.
usado
Longitud de molienda 6000 mm Diámetro de molienda 1050 mm
bore capacity in steel (diameter):40 mm arm length:1250 mm workpiece height max.:1390 mm Dist. spindle nose & working surface base:350 - 1260 Spindle travel:315 max. boring diameter:40 mm Distance between spindle axis and column:350 - 1260 spindle taper:4 MK Range of spindle speeds:22,4 - 2800 Number of spindle speeds:16 Number of spindle feeds:16 Table:500 x 630 Travel of spindle head:900 mm total power requirement:3,5 kW dimensions of the machine ca.:2150x1070x2840 m feed:0,09 - 1,5 m/min weight of the machine ca.:3 t
turning diameter:1600 mm turning length:12000 mm control:FAGOR 8050 Used CNC Lathe with FAGOR 8050 and extensive accessories. For further technical data and accessories, pls browse the Appendix. Parallellathe WMW mod. 4 GUIDE-WAYS ¦ CNC: FAGOR 8050 ¦ bed: monolithic ¦ centres height: 800 mm ¦ centres distance: 12000 mm ¦ swing over cross-slide: 1250 mm ¦ turret: automatic 4 positions ¦ tailstock: motorized ¦ tailstock connection: hydraulic ¦ platform: diam. 1000 mm ¦ steady rests: nr.02 ¦ chip conveyor Warranty: none Take advantage of the favorable leasing and hire-purchase terms from IKB Leasing. Ask us about it.
bore capacity in steel (diameter):10 mm throat:210 mm bore stroke:100 mm total power requirement:0,7 kW weight of the machine ca.:302 kg dimensions of the machine ca.: 620 x 800 x 1950 mm Table dimensions:350 x 250 mm spindle speeds::250, 355, 710, 1000, 1400, 2000, 2500 U/min
bore capacity in steel (diameter):10 mm throat:210 mm bore stroke:80 mm total power requirement:1,1 kW weight of the machine ca.:195 kg dimensions of the machine ca.:530 x 650 x 1850 mm spindle speeds::355, 710, 1400, 2800 U/min Table dimensions:340 x 280 mm
x-travel:850 mm y-travel:280 mm z-travel:355 mm total power requirement:8 kW weight of the machine ca.:4 t dimensions of the machine ca.:2 x 2 x2.40 m revolutions per minute: 28-1.400 U/min table-size:1.200 x 370 mm surface area:1.060 x 260 mm spindle taper:SK 50
pressure:10 t stroke:400 mm total power requirement:1,6 kW weight of the machine ca.:1,1 t dimensions of the machine ca.:1100 x650 x 2050 mm dayligth:500 mm table-size:400 x 450 mm Documents:vorhanden
grinding length:1000 mm grinding width:250 mm workpiece height:400 mm total power requirement:12 kW weight of the machine ca.:3,8 t dimensions of the machine ca.:3.300 x 1.800 x 2.300 mm hydraulic power unit:400 x1000 x 1500 mm control cabinet:2 Stück, 1000 x 1400 x 1500 mm
