Sprzedaję Fensterbau Profil Umfälzautomat Zentrum Weinig Univar 10. Rok budowy 1998. Głowice frezarsko-hutnicze OERTLI. Dostępne to samo. Cena jednostkowa 5.500 euro. Dostępne 4 szt. Stan bardzo dobry !
Składa się z: Frezarek do łączenia na mikrowczepy ProfiJoint, Ręczna stacja transferowa i prasa jednokanałowa Długość dosuwu 150-700 mm Szerokość drewna 40-150 mm grubość drewna 20-50 mm
Tenoning spindle: 1 St. Number of milling agregates: 4 St. Spindle diameter: 50 mm Control: Weinig PC-Nexus Weinig Unicontrol 6 with NC spindles ----------------------------------------- Machine available for inspection while still in operation until September 2026 Summary of technical data (please inquire about any additional accessories included) Item 1: Cross-cut saw ---------------------------- > Electronic cross-cut saw, horizontally continuously adjustable > Number of tools: 1 unit > Spindle speed: 2,800 rpm > Spindle diameter: 40 mm > Max. tool diameter: 400 mm > Motor power: 3.0 kW > Laser alignment light for identifying the cut position > NC length stop mounted on the slotting table included, positioning of the cross-cut saw integrated into the control system. > Length 3500 mm Item 2: Tenoning and slotting spindle ---------------------------- > Number of tools: variable, infinit ...
Number of spindles: 5 St. Working width: 230 mm Working height: 120 mm Length of the planing table: 2500 mm Feed motor: 4 kW Feed speed: 5-30 m/min. control: Memory-Funktion Weinig Powermat 500 with grooved table ---------------------------------- The machine arrives at the warehouse and is cleaned and fully inspected. Brief Summary: ---------------------------------- - 5 Spindles - 8,000 rpm - Grooved table for short or difficult-to-guide workpieces, coated with Marathon PowerCoating - One driven roller in the outfeed table, hardened: 210 mm wide - Left and top spindles controlled for width and height - Quick-release spindle nut Detailed Description: ---------------------------------------------------------------------- - Technical Data: Working width: 20-230 mm Working height: 8-120 mm Number of spindles: 5 1st Spindle - bottom ----------------------------------------------- Motor with ...
Number of spindles: 6 St. Working width: 230 mm Working height: 120 mm Length of the planing table: 2500 mm Feed motor: 3 kW Feed speed: 5-24 m/min. total power requirement: 27 kw Dimensions (L/W/H): 3900 x 2200 x 2000 mm weight of the machine ca.: 2500 kg Weinig four-side planer Profimat 23 window version with glazing bead removal, ATS control and program control ------------------------------------- Machine will be renovated and functionally checked! Technical data summary (please inquire about any additional accessories included) ------------------------------------- Generally ------------------------------------- > Working width: 230 mm > Working height: 120 mm > Number of spindles: 6 pieces. > Dressing table length: 2500 mm > Feed speed: 5-24 m/min > Total power requirement: 27 kW > Dimensions: 3900 x 2200 x 2000 mm > Machine weight, approx.: 2500 kg Spindle arrangement ------------ ...
Tenoning spindle: 2 St. Number of milling agregates: 7 St. Spindle diameter: 50 mm control: Weinig, PC-Nexus Weinig Unicontrol 12 with radial and axial CNC spindles as well as VARIO table and milling carriage Machine dismantled professionally and in our warehouse in 73447 Oberkochen. Video and pictures were taken before dismantling. Technical data summary (please inquire about any additional accessories included) crosscut saw > Electronic crosscut saw, horizontally infinitely adjustable > Number of tools: 1 piece. > Spindle speed: 2,800 rpm > Spindle diameter: 40 mm > Tool diameter max.: 400 mm > Motor power: 3.7 kW > Laser directional light to detect the saw section > Axial adjustment path 150 mm NC axis, electronically infinitely variable > Radial pneumatic adjustment path 8 positions for e.g. edge rounding from above Rounding aggregate > Position: horizontally below > Motor power ...
Number of spindles: 6 St. Working width: 230 mm Working height: 120 mm Length of the planing table: 2500 mm Feed motor: 3 kW Feed speed: 5-30 m/min. control: Powercom Weinig Powermat 500 (Window Version for window producers) -------------------------------------------------------- The machine will be a partial renovated at our warehouse prior to delivery. The interior view photos of a similar machine from our archive serve to illustrate how the machine will be renovated. Technical Summary: -------------------------------------------------------- - 6 spindles, 5 of which are PowerLock - 8,000 rpm - Large PowerCom control system - Spindles 2, 3, and 4: CNC-controlled axial adjustment - Spindles 2, 3, 4, and 5: CNC-controlled radial adjustment - Window package for glazing bead separation: pneumatic cycling for right and top spindles for bead separation Detailed Description: ---------------- ...
Number of spindles: 5 St. Working width: 230 mm Working height: 120 mm Length of the planing table: 2500 mm Feed motor: 4 kW Feed speed: 5-30 m/min. Control: Memory-Funktion Weinig Powermat 400 with HSK/Powerlock, axial/radial CNC controlled ---------------------------------------------------------------------- This machine is currently being refurbished at our facility! Pictures taken before dismantling and currently during the processing phase! Brief Summary: ---------------------------------------------------------------------- - 5 spindles with 8,000 rpm - 4 x HSK/Powerlock - Axially and radial CNC adjustments of the spindles via control - CNC-controlled adjustment and positioning of the feed - Table tops with guide blades at spindles 2 and 3. - Includes Weinig/Neumann RF 15 return conveyor system Detailed Description: ----------------------------------------------------------------- ...
max. workpiece length: 4500,6000 mm profile spindle: 4 Stück main drive: 30 kW Weinig Conturex C226 Machining Center ---------------------------------------------- For sale on behalf of a client, includes software (Klaes) and tooling (Oertli) for IV68/IV78/IV92 and Wood/Alu 68–92 systems. Machine still is electrically connected. Technical specifications and window cross-sections available upon request! ---------------------------------------- Price of the above-mentioned machine available upon request! ---------------------------------------- Dismantling and reinstallation available upon request! (Technical specifications provided by the manufacturer – subject to change/no liability assumed!) All prices are net, plus statutory VAT. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Number of spindles: 6 St. Working width: 230 mm Working height: 120 mm Length of the planing table: 2500 mm Feed motor: 4 kW Feed speed: 5-30 m/min. control: Memory-Funktion Weinig Powermat 400 with HSK/Powerlock, axial/radial CNC controlled ---------------------------------------------------------------------- - The machine renovated and functionally checked ! Short summary: ---------------------------------------------------------------------- - 6 spindles with 8,000 rpm 5 x HSK/Powerlock Axial and radial CNC adjustment of the spindles via control CNC - controlled adjustment and positioning of the feed Detailed description: ---------------------------------------------------------------------- - Technical specifications: Working width: 20-230 mm Working height: 8-120 mm Number of spindles: 6 1. Tool holder - below ------------------------------------------------ Motor with brake: 5.5 ...
Number of spindles: 4 St. Number of tools: 11 St. Spindle diameter: 50 mm Spindle length: 285,125 mm length: 4000 mm width: 2000 mm height: 2200 mm Weinig Univar 10/3 folding machine --------------------------------- For milling around windows, doors and the like with uneven circumferential profiles. Machine suitable for wood thickness 68 to 92 mm Time required per frame milling, medium size 1.20 x 1.20 m - approx. 2 minutes. The available tool positions are selected using a selector switch on the control panel retrieved. Machine with 3 hydraulically controlled right precision Lifting spindles for holding 3 tool sets, 2 x 95 mm spindle stroke per spindle The spindle stroke takes place in a U-movement, so that the opening is possible for short parts The milling stop remains as small as possible. Spindle stroke horizontally fine Adjustable for both tool positions from the operator side. Ce ...
Tenoning spindle: 2 St. Number of milling agregates: 7 St. Spindle diameter: 50 mm control: Weinig PC-Nexus Weinig Uncontrol 12 with radial and axial CNC spindles and VARIO table .. The machine has already been professionally dismantled and stored in 73447 Oberkochen Specifications summary (please inquire about any additional accessories included) .. crosscut saw .. > Crosscut saw electronically, horizontally infinitely adjustable > Number of tools: 1 pc. > Spindle speed: 3000-6000 rpm > Spindle diameter: 40 mm > Tool diameter max.: 400 mm > Motor power: 3.7 kW > Laser guide light for detecting the sawing section > Axial adjustment path 150 mm NC axis, electronically stepless > Adjustment path, radial, pneumatic, 8 positions, e.g. for edge rounding from above rounding aggregate .. > Position: horizontally below > Axial adjustment path together with the crosscut saw. electronic length s ...
Number of spindles: 6 St. Working width: 230 mm Working height: 120 mm Length of the planing table: 2500 mm Feed motor: 3 kW Feed speed: 5-24 m/min. Dimensions (L/W/H): 3900 x 2200 x 2000 mm weight of the machine ca.: 2500 kg Weinig Profimat 23 Four-Sided Planer – Window Version (With glazing bead separation feature, or usable as a grooving spindle) ATS Control and Program Control ------------------------------------- Technical Specifications Summary (Please inquire regarding any additional accessories that may be included) ------------------------------------- General ------------------------------------ > Working width: 230 mm > Working height: 120 mm > Number of spindles: 6 > Infeed table length: 2500 mm > Feed motor: 3 kW > Feed speed: 5–24 m/min > Total power requirement: 27 kW > Dimensions: 3900 x 2200 x 2000 mm > Machine weight (approx.): 2500 kg Spindle Arrangement ---------- ...
Number of spindles: 6 St. Working width: 230 mm Working height: 120 mm Length of the planing table: 2000 mm Feed motor: 4 kW Feed speed: 5-24 m/min. WEINIG Unimat 23 E Planer and moulder ------------------------------------------ 6 spindles (with 2 rigth spindles, reinforced motors, 8,000 rpm, ATS control Machine will be cleaned and functionally checked before delivery Working width 20 - 230 mm Working height 8 - 120 mm 1st spindle (bottom) 5.5 kW (motor replaced) ------------------------- Diameter 40 mm Speed 6,000 rpm Tool swing diameter 125 - 180 mm Rebating unit including tool Hardened table insert in front of 1st (bottom) spindle 2nd spindle (right) 12.1 kW (motor replaced) ------------------------- Shared motor with left vertical spindle Diameter 40 mm Speed 8,000 rpm Tool swing diameter 112-250 mm Max. Tool diameter behind stop plane 203 mm Max. groove depth 35 mm Axially travel 8 ...
Tenoning spindle: 1 St. Number of milling agregates: 4 St. Spindle diameter: 40/50 mm Weinig Unicontrol 6 -------------------------------------------- Machine will be checked in our factory before delivery! Technical Data Summary (Please inquire about any additional accessories included) Item 1: Cut-off saw -------------------------------------------- > Number of tools: 1 pc. > Spindle speed: 2,800 rpm > Spindle diameter: 40 mm > Maximum tool diameter: 400 mm > Motor power: 3.0 kW > Laser guide light for identifying the saw cut CNC-controlled length stop ------------------------------------------- > Length: 3,600 mm > Electronic length stop including positioned cut-off saw Item 2: Tenoning spindle -------------------------------------------- > Number of tools: 3 (stroke 2 x 100 mm) or 4 (Stroke 3 x 80 mm) > Tool clamping length: 320 mm > Pneumatic vertical spindle stroke: 240 mm for wood ...
working length: 3600 mm Working width: 1500 mm Working height: ca. 900 mm WEINIG Return Conveyor System RF15 ----------------------------------- Can be used after moulders, planers, and milling machines with a maximum feed speed of approx. 22 m/min. Technical Description: Workpiece length: 250 - 3,600 mm Workpiece width: 30-230 mm Longitudinal-transverse conveyor with two integrated, driven roller conveyors: Transverse conveyor path 1,500 mm Constant conveyor speed: 30 m/min Roller conveyor length 2,200 mm Return roller conveyor (non-driven) to the operator (Technical specifications according to the manufacturer - without guarantee!) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Working width: 230 mm Working height: 15-120 mm Number of spindles: 2 St. Weinig Hydro Planer Type Uniplan 23 -------------------------------------------------------------------- Machine was factory overhauled by Weinig in 2024. Description: For two-sided horizontal woodworking with two working spindles. Spindle arrangement: horizontal, bottom and top. The two horizontal spindles are equipped with hydraulically tensioned counterbearings without axial adjustment. Built-in straight jointers on both spindles with automatic stone feed, remotely controlled with the hood closed. Machine with continuous, chainless feed, equipped with rubber rollers. Electric up/down adjustment of the spindles according to a mechanical digital display (SIKO). On/off switch for limiting the up/down adjustment. Feed roller pressure pneumatic. Stops and table tops are not adjustable. Machine with steel table tops. ...
Number of spindles: 6 St. Working width: 230 mm Working height: 120 mm Length of the planing table: 2500 mm Feed motor: 3 kW Feed speed: 5-24 m/min. total power requirement: 27 kw Dimensions (L/W/H): 3900 x 2200 x 2000 mm weight of the machine ca.: 2500 kg Weinig Profimat 23 four-side planer, window version with glazing bead removal or can be used as a grooving spindle ATS control and program control ------------------------------------ Machine was factory overhauled by Weinig in 2024. Technical Specifications Summary (Please inquire about any additional accessories included) -------------------------------------------------------- General ------------------------------------ > Working width: 230 mm > Working height: 120 mm > Number of spindles: 6 > Planer table length: 2500 mm > Feed motor: 3 kW > Feed speed: 5-24 m/min > Total power requirement: 27 kW > Dimensions: 3900 x 2200 x 2000 m ...
Tenoning spindle: 1 St Number of milling agregates: 4 St. Spindle diameter: 50 mm Control: Weinig, PC-Nexus Weinig Unicontrol 10 CNC - Spindles radially and axially CNC-controlled -------------------------------------------------------------- The machine was factory overhauled by Weinig in 2024. The control panel was also upgraded to a Siemens S 7 677 C, with a new membrane panel Touch. With the following machining units: Crosscut saw -------------------------------------------------------------- with laser alignment light, motor power 3 kW, spindle diameter 40 mm, spindle speed 3,000 Axially adjustable via NC axis Radial pneumatic adjustment to 8 positions for edge rounding from above Unit from below for edge rounding ------------------------------------------------------------- Axially adjustable with crosscut saw Tenon and slotting spindle --------------------------------------------- ...
Number of spindles: 5 St. Working width: 230 mm Working height: 120 mm Length of the planing table: 2500 mm Feed motor: 4 kW Feed speed: 5-30 m/min. Control: Memory-Funktion Weinig Powermat 600 Compact ---------------------------------------------------------------------- The machine has been cleaned and fully inspected. Brief Summary: ---------------------------------- - 5 Spindles - Powerful Motors - Left and top spindles controlled for width and height Detailed Description: ---------------------------------------------------------------------- - Technical Data: Working Width: 20-230 mm Working Height: 10-120 mm Number of Spindles: 5 1st Spindle - Bottom ----------------------------------------------- Motor with brake: 7.5 kW Spindle diameter: 40 mm Speed: 6,000 rpm Tool Circle: 125-145 mm Tool Circle for Rebating Cutter: 130-160 mm Axially Travel: 5 mm Rebating Device MarathonCoatine ...
Number of spindles: 5 St. Working width: 20 - 230 mm Working height: 8 - 120 mm Length of the planing table: 2000 mm Feed motor: 1,1 kW Feed speed: stufenlos regelbar 2 - 12 m/min. Control: Memory Funktion 1 WEINIG VARIOMAT planer and moulder including multifunction / slotting table ---------------------------------------------------------------------- -------- Machine will be cleaned and functionally tested before delivery ! Technical manufacturers description: -------------------------------------- Working width: 20 - 230 mm Working height: 8 - 120 mm 1st spindle horizontal, bottom --------------------------------------- Motor with brake: 5.5 kW Diameter 40 mm Speed 6000 rpm Tool radius 125 - 145 mm Axis adjustment range 5 mm Folding device including rebate cutter MarathonCoating for table insert before and after the 1st lower spindle 2nd spindle vertical, right ----------------------- ...
Tenoning spindle: 1 St. Number of milling agregates: 5 St. Spindle diameter: 50 mm Control: Weinig, PC-Nexus Weinig Unicontrol 6 with NC spindles Machine will be cleaned and completely checked before delivery -------------------------------------------- Technical data summary (please enquire about any additional accessories included) Item 1: Cross-cut saw ------------------------------------------- > Number of tools: 1 pc. > Spindle speed: 2,800 rpm > Spindle diameter: 40 mm > Max. tool diameter: 400 mm > Motor power: 3 kW > Radial adjustment path pneumatically controlled to 8 positions, e.g. for edge rounding from above > Laser aiming light for detecting the saw section Item 2: Rounding unit horizontal below ------------------------------------------- > Position: horizontal below > Motor power: 1.5 kW > Spindle diameter: 20 mm > Clamping length 25 mm > Spindle speed: 9,000 rpm > Max. to ...
Number of spindles: 6 St. Working width: 230 mm Working height: 160 mm Length of the planing table: 1050 mm Feed motor: 7 kW Feed speed: 6-40 m/min. control: MemoryPlus Weinig Powermat 1200 ---------------------------------------------------------------------- - with infeed automation Weinig wheel magazine EM 100 and linked with outfeed automation Weinig High-Mech A 1 The machine will be completely overhauled at our warehouse before delivery ! Detailed description: ---------------------------------------------------------------------- - 1. Weinig planer and moulder Powermat 1200 ---------------------------------------------------------------------- - Technical data: ------------------------ Working width 20 - 230 mm (with tool flight circle 93 - 163 mm) Working height 10 - 160 mm (with tool flight circle 93 - 163 mm) 1. Spindle ----------------------------- First lower horizontal spindle ...
Tenoning spindle: 1 St. Number of milling agregates: 4 St. Spindle diameter: 50 mm control: Weinig, PC-Nexus Weinig Unicontrol 6 with NC spindles ----------------------------------------- Machine will be cleaned and completely checked before delivery Technical data summary (please enquire about any additional accessories included) Item 1: Cross-cut saw --------------------------- > Electronic cross-cut saw, infinitely adjustable horizontally > Number of tools: 1 piece > Spindle speed: 2,800 rpm > Spindle diameter: 40 mm > Max. tool diameter: 400 mm > Motor power: 3.0 kW > Laser aiming light for detecting the saw section > NC length stop, mounted on slot table included Positioning of the cross-cut saw integrated in the control system. > Length 3500 mm Item 2: tenoning spindle ---------------------------- > Number of tools: variable, infinitely variable adjustment NC axis > Tool clamping l ...
Tenoning spindle: 1 St. Number of milling agregates: 5 St. Spindle diameter: 50 mm Control: Weinig PC-Nexus Weinig Unicontrol 11 Window System with Extensive Tooling ----------------------------------------- Optionally available (at additional cost): - Weinig Univar 6 Rebating Machine (Price upon request!) - Götzinger PowerDrill Drilling and Milling Center for Windows and Doors (Price upon request) Manufacturers Technical Description: ----------------------------------------- Item 1: Weinig Unicontrol 11 Window System ----------------------------------------- Includes existing tooling sets: - IV 67 (Wood and Wood-Aluminum) - IV 77 (Wood and Wood-Aluminum) - IV 90 (Wood) Cross-cut Saw -------------------------------------------------------------- With laser alignment light, motor power: 3 kW, spindle diameter: 40 mm, electronically variable spindle speed with brake: 3,000–6,000 rpm. Ma ...
Tenoning spindle: 2 Stk. Number of milling agregates: 5 St. Spindle diameter: 50 mm Control: Weinig, PC-Nexus Weinig Unicontrol 10 NC Window System — Optional: Extensive Tooling Set ----------------------------------------- Optionally available (at an additional cost): IV 68 Wood, Wood/Aluminum IV 78 Wood, Wood/Aluminum IV 68 Entrance Doors Manufacturers Technical Description: ----------------------------------------- Item 1: Weinig Unicontrol 10 NC Window System ----------------------------------------- Cross-cut Saw -------------------------------------------------------------- with laser alignment light, motor power: 3 kW, spindle diameter: 40 mm, spindle speed: electronically variable (with brake) from 3,000 to 6,000 rpm. Max. tool cutting circle: 400 mm Axial adjustment: 150 mm via NC axis Radial adjustment: pneumatic, to 8 positions for top edge rounding Horizontal bottom roundin ...
Number of spindles: 5 St. Working width: 20 - 230 mm Working height: 8 - 120 mm Length of the planing table: 2500 mm Feed motor: 1,1 kW Feed speed: stufenlos regelbar 2-12 m/min. weight of the machine ca.: 2500 kg 1 WEINIG VARIOMAT Planing and Moulding Machine --------------------------------------- Brief Summary: --------------------------------------- - 5 spindles - Powerful motors - Cycle-controlled jointing - MemoryPlus control system - Option: Stähle-Hess Saturn single-piece sanding machine Technical Manufacturers Description: --------------------------------------- Working width: 20 – 230 mm Working height: 8 – 120 mm 1st Spindle: Horizontal Bottom --------------------------------------- Motor with brake: 7.5 kW Diameter: 40 mm Speed: 6000 rpm Tool cutting circle: 125 – 145 mm Axial adjustment range: 5 mm Rebating device incl. rebating cutters 2nd Spindle: Vertical Right --- ...
Tenoning spindle: 2 St. Number of milling agregates: 7 St. Spindle diameter: 50 mm # 6726 Weinig Unicontrol 12 CNC -------------------------------------------------------- Sale on behalf of a customer. Machine connected and ready for demonstration. crosscut saw -------------------------------------------------------- Crosscut saw electronically, horizontally infinitely adjustable Number of tools: 1 pc. Spindle speed: 3000-6000 rpm Spindle diameter: 40mm Tool diameter max.: 400 mm Motor power: 3 kW Laser guide light to identify the saw section rounding aggregate -------------------------------------------------------- Position: horizontally below Motor power: 1 kW Spindle diameter: 20mm Spindle speed: 9000 rpm Tool flight circle max.: 130 mm electronic length stop, length: 3500 mm -------------------------------------------------------- 1. tenoning Spindle ---------------------- ...
Manufacturer: Weinig Unicontrol, Type: Unicontrol 10, Year: 1999, Control: Weinig/Siemens, Controlled lenght stopper: yes, Trimming saw: yes, Studioeinrichtung Winkel: no, Automatisierungspaket: yes, Doppelteilpaket: yes, Elektrischer Längenanschlag bis mm: 3600, Crosscut saw controlled: yes, Diameter of the spindle mm: 50, Werkzeugdurchmesser max.: mm: 400/320, Length of tenoning spindle mm: 640, Tool travel range tenoning spindle: für 8 Werkzeuge, Schlitzspindel Motorleistung kW: 7,5, Moulding spindles: 3, Länge Profilspindel mm: 320 X 50, 1 length of profile spindle in mm: 320, 1Engine power kW: 5,5, 2 length of profile spindle in mm: 320 X 50, 2 spindle lift in mm: 320, 2 Engine power kW: 5,5, 3 Länge Profilspindel mm: Profilfräsaggregat vertikal, 3 Engine power kW: 2,2, Diameter of the spindle mm: 50, Fly circle moulding tool mm: 320, Fly circle tenoning tool: 400, Constant str ...
Manufacturer: Weinig , Type: Unimat 30 EL, Year: 1999, Control: Siemens, Planing widht mm: 300, Planing hight mm: 120, Number of spindles: 6, Elektronische Achsverstellung: no, Work piece width min-max mm: 300, Min.-max. workpiece length in mm: 300, Min.-max. workpiece height in mm: 120, Saw unit kW: no, Table rollers: no, Rotations of spindles max. rpm: 6000, Spindle arrangement: U/R/L/R/O/U, Separate engine per spindle: yes, Fully suspended drive feeding: yes, Feeding - kW: 5,5, Feeding speed min-max m/min: 5-36, Feeding speed continous adjustable: yes, Pneumatical top pressure: yes, Jointer Stück: no, 1.Bottom spindle kW: 7,5, 2nd spindle on right kW: 5,5, 3.Left spindle kW: 5,5, 4th spindle on right kW: 5,5, 5.Top spindle kW: 7,5, 5th spindle at bottom kW: 7,5, Noise enclosure: Kabine, FREE TEXT: inkl.3 Hebebühnen und und eine Apstapelanlage/, Year :1999
