usado
Seiger SLZ 570 E Año de construcción: 2004 Control: Heidenhain Manual Plus 4110 Ø de circulación sobre la cama 570 mm Ø de circulación a través de la corredera frontal 340 mm Ancho de la cama 350 mm Distancia máxima 2000 Contrapunto Ø 90 mm contrapunto cono Morse MK 5 Diámetro del husillo 93 mm Cabezal de husillo según DIN 55027 Gr. 8 Ø del husillo en el cojinete delantero 130 mm L/W/H 3.990/2.200/1.970 Accionamiento principal 25 KW Guías y escala de vidrio en el eje X Acoplamiento de seguridad en los ejes Z y X Deslizador facial largo y continuo con tira de cuña ajustable
usado
Key data: 380 mm, 1000 mm
torno de ciclo usado Seiger SLZ360 Construido en 1999 Horas de conexión aprox. 20000 h Diámetro circunferencial sobre la cama 380 mm Anchura central 1000 mm Rango de velocidad 1-4000 1/min incl. control Heidenhain manual Plus M Titular de Parat Sistema de refrigeración Manual
usado
Key data: 490 mm, 1000 mm
Control Sinumerik 810 D Diámetro de circulación sobre el lecho 490 mm Diámetro de circulación sobre el carro frontal 280 mm Longitud de torneado 1.000 mm Diámetro del husillo 93 mm Rangos de velocidad 1-625 / 1-3.000 rpm Potencia de accionamiento 16 kW Dimensiones aprox. 3,0 m / 1,8 m / 2,0 m Peso de la máquina 3,6 t Carrera del contrapunto 180 mm
usado
- Diámetro del columpio sobre la cama: 490 mm - Distancia entre centros: 1000 mm - Diámetro de oscilación sobre la diapositiva frontal: 280 mm - Rango de velocidad: 1 - 625 / 1 - 3.000 rpm - Etapas de transmisión: ZF - 2 - Paso del husillo: 93 mm - Diámetro del cojinete del husillo: tamaño 8 - 130 mm - Montaje en contrapunto: MK5 - carrera 160 mm - Control: Siemens Manualturn - Potencia total: 17 kW - Peso de la máquina: 3.600 kg - Dimensiones (An x Pr x Al): 3,0 x 1,8 x 2,0 m - Horas de funcionamiento: 31556 h Detalles sin mandril de mandíbula, opción de cálculo de contorno y volante de contorno, montaje multifijo, cabezal de husillo según DIN 55027 Accesorios Documentación, succión, ningún otro accesorio
usado
turning diameter:380 mm turning length:750 mm control:Manual Plus Heidenhain spindle bore diameter:45 mm power main drive with:11 / 9 kW main spindle speeds::3800 1/min machine weight ab.:1900 kg dimensions of machine:2400 x 1600 x 1900 mm teach-in lathe incl. electronic handwheels incl. collet system 173 E static steady moving steady cooling system accessories toolholder system PARAT 25 x 25 manuals steady moved steady rest 3-chaw-chuck SCHUNK Rota S plus D = 250 mm Under power in our showroom main spindle with new bearings ( 0 hours working ) approx. 28.600 h "machine on"
usado
turning length:2000 mm control:- total power requirement:25 kW weight of the machine ca.:3 t dimensions of the machine ca.:3800 x 1800 x 1850 mm swing over bed:500 mm swing diameter over face slide:280 mm control:Zyklen-Steuerung Heidenhain bed width:350 mm Documents:vorhanden
usado
turning diameter: 500 mm centre distance: 1000 mm control: Siemens 840D swing diameter over face slide: 280 mm spindle head: Gr 8 spindle bore: 93 mm spindle diameter in front bearing: 130 mm main drive motor: 25 kW turning speed range: 1 - 3000 U/min tailstock quill taper MT: 5 tailstock quill diameter: 90 mm tailstock travel: 180 mm total power requirement: 34 kVA weight of the machine ca.: 3,2 t dimensions of the machine ca.: 4,4 x 2,2 x 1,97 m - Control unit Siemens 840D - 3-jaw chuck - Support with 2 tool holders ( - steady rest - Tailstock ( air pressure supported ) - chip conveyor - Coolant system only 5720h operating hours very good condition The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
usado
Description: x-way 725 mm z-way 400 mm ManualPlus 620 control unit Speed - level 1 5 - 250 rpm Speed - level 2 5 - 710 rpm Description: 4-fold steel holder PARAT 'manual' Manually operated face plate RÖHM 4 jaws Ø 1000 mm turning diameter over slide: 1,400 mm, faceplate diameter: 1,000 mm, total power requirement: 55 kW, weight approx.: 6,500 kg, Approx. Onsite Dimension. (l x w x h): 4,800 x 2,500 x 2,100 mm
usado
turning diameter: ca. 850 mm turning length: 6000 mm control: Heidenhain 620 centre distance: 6000 mm swing diameter over bed slide: 1250 mm swing diameter max. over cross slide: 850 mm radial face slide adjustment: 680 mm spindle bore: 130 mm main drive AC:: spindle capacity 100% / 60% ED: 37 / 52 kW max. torque: ca. 9000 Nm turning speed range: 5 - 710 U/min feed motor AC:: rapid traverse X-axis: 6 m/min rapid travel Y-axis: 3 m/min tailstock:: diameter of quill: 160 mm quill stroke: 315 mm quill holder (inner taper): MK 6 steady, closed: passage: 450 mm total power requirement: 52 kW weight of the machine ca.: 16,5 t Overall size: 9000 x 2200 x 2300 mm dimensions of the machine ca.: 12 x 4 x 2 m Equipment/accessories: - face plate diameter 1200 mm - various fixators - documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
usado
turning diameter: 660 mm centre distance: 3000 mm control: Sinumerik 840D SL total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m turning length: mm Sinumerik 840D SL control 3-jaw chuck diameter 315mm 4-fold Parat tool holder device steady rest 12mm – 150mm steady rest 120mm – 270mm tail stock chip conveyor coolant device Technische Daten / technical details: Spitzenweite / center to center 3000 mm Umlufdurchmesser über Bett / rotary diameter over bed 660 mm Umlaufdurchmesser über Schlitten / rotary diameter over sledge 435 mm Spindelbohrung / spindle hole 93 mm Drehzahlbereich (2-stufig) / spindle speed (2-steps) 1-2500 UpM /rpm Eilgang X, Z / rapid feed X, Z 8/10 m/min Reitstockaufnahme / tail stock taper MK6 Antriebsleistung Spindel 100/60%ED / drive capacity spindle 100/60%ED 22/30 kW Gewicht der Maschine ca. / weight ca. ...
usado
turning diameter: 800 mm turning length: 1500 mm control: SIEMENS SINUMERIK 810 Dpl workpiece weight flying clamped: 750 workpiece weight with one steady: 2200 kg swing diameter over face slide: 540 mm power capacity: 20/28 kW spindle bore: 83 mm weight of the machine ca.: 6 t dimensions of the machine ca.: 3,5x2,8x2 m gearbox must be checked machine without tailstock! -without tools -without jaws The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
usado
diámetro de torneado: 1250 mm longitud de torneado: 6000 mm control: Heidenhain diámetro del husillo: 130 mm 0: 5-710 U/min relación de transmisión: 2 peso de la pieza de trabajo: 7000 kg potencia total requerida: 37/52 kW peso de la máquina aprox.: 16 t dimensiones de la máquina aprox.: 12x4x2 m
