turning diameter:250 mm swing diameter:250 mm turning height:200 mm total power requirement:37,7 kW chuck diameter:315 mm spindle speed max.:5500 1/min travel -x axis:625 mm travel -y axis:+100/-80 mm travel -z axis:250 mm worktool system:VDI 30+40 weight of the machine ca.:8 t The synchronous spindle is powered with 37.7 kW of power, a torque of 300 Nm and a maximum speed of 5,500 rpm. Typical components are ball cages, ball hubs, gear wheels, sliding sleeves, pump wheels, flanges, synchronizer rings, bearing rings and pivot pins. The machine bed is made of Hydropol, a mixture of special concrete and steel, which ensures the greatest smoothness and precision even with larger components and powerful machining.
Altura central 110 mm Anchura central 160 mm Diámetro del husillo 23 mm Potencia del motor 1,7 kW . Velocidades : 700 - 1400 - 2800 rpm .
Características técnicas: Longitud máxima de torneado 90 mm Diámetro de circulación sobre el lecho 220 mm Diámetro de circulación sobre el soporte 110 mm Anchura central 160 mm Diámetro 23 mm 3 velocidades 350 / 700 / 1400 rpm
Características técnicas: Altura central 110 mm Anchura central 160 mm Diámetro del husillo 23 mm Potencia del motor 1,7 kW en cada caso, velocidad de rotación a través de potenciómetro A ajustar a partir de aprox. 100 – 2.300 rpm 3 velocidades preestablecidas o 3 etapas de conmutación
turning diameter: 235 mm turning length: 200 mm turning speeds: 6500 U/min control: Siemens 840D swing diameter: mm turning height: mm workpiece height max.: 100 mm spindle bearing diameter: 90 mm spindle head: A5 total power requirement: 41 kW weight of the machine ca.: 6500 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
