Model
(Producent: SALVAMAC)
cutting width: max 610 mm Cutting height: max 200 mm Saw blade diameter: 650 mm Motor output: 11 kW The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
cutting width: max. 310 mm Cutting height: max. 125 mm Saw blade diameter: 500 mm Motor output: 5,5 kW SALVAMAC LEGEND 500 – The semi-automatic under-table cross-cut saw -------------------------------------------------- ----------- Maximum cutting area: 220x125/ 260x100/ 285x80/ 310x50 mm. When sawing stacked boards h max. 100 mm. The structure is made entirely of thick-walled and reinforced throughout painted steel. Solid floor mounting system with flanged steel feet for the mounting hole. Bimanual safety cutting control in ergonomic position. Engine power of the saw motor 5.5 kW. Adjustable cutting speed via a pneumatic controller. Maximum system for weight balance and longevity. Shock absorbing system. Independent pneumatic adjustment options to adapt to different Types of processing. Durable and easily replaceable saw blade adjustment bar. HM circular saw blade, diameter 500 mm, Z ...
cutting width: max. 250 mm Cutting height: max. 80 mm Saw blade diameter: 400 mm Motor output: 3,0 kW turning speeds: 2800 U/min Required air-pressure: 6-8 bar work height max.: 900 +-20 mm mm Dimensions (L/W/H): 530x869x1217 mm SALVAMAC Legend 400 – The semi-automatic chop saw -------------------------------------------------- - Maximum cutting area: 220x80/ 250x50 mm. (When sawing stacked boards, note: rear stop height 100 mm) The structure is made entirely of sturdy, thick-walled steel, which is painted throughout and reinforced. A solid one Floor mounting system is equipped with flanged steel feet, to ensure secure attachment. The two-hand control is ergonomically positioned for comfort and efficient operation. Motor power of the saw motor 3.0 kW. The cutting speed is adjustable via a pneumatic controller, to enable precise adjustment. The system also has a Shock-absorbing system t ...
cutting width: max. 310 mm Cutting height: max. 125 mm Saw blade diameter: 500 mm Motor output: 5,5 kW Speed: 2.800 U/min. Required air-pressure: 6-8 bar Working height: 900 +/- 20 mm Dimensions (L/W/H): 10645x1000x1300 mm SALVAMAC CLASSIC 50 – The semi-automatic miter saw with SALVASTOP 100 - electronic length stop/slider -------------------------------------------------- - New machine from our demonstration room, Bj. 2022 Pos. 1: Classic 50 under table miter saw -------------------------------------------------- - Maximum cutting area: 220x125/ 260x100/285x80/310x50 mm. When cutting boards that are on top of each other, h max. 100 mm. The structure is made entirely of thick-walled and reinforced full-surface painted steel. Solid floor mounting system with flanged steel feet for the mounting hole. Bimanual safety cut control in ergonomic position. Motor power of the saw motor 5.5 kW. ...
cutting width: max. 330 mm Cutting height: max. 150 mm Saw blade diameter: 550 mm Motor output: 7,5 kW turning speeds: 2800 U/min Required air-pressure: 6-8 bar work height max.: 900 +- 20 mm Dimensions (L/W/H): 530x869x1217 mm SALVAMAC Legend 550 the semi-automatic chop saw -------------------------------------------------- - Maximum cutting area 220x150/330x50 mm (When sawing stacked boards, note: rear stop height 100 mm) The structure is made entirely of sturdy, thick-walled steel, which is painted throughout and reinforced. A solid one Floor mounting system is equipped with flanged steel feet, to ensure secure attachment. The two-hand control is ergonomically positioned for comfort and efficient operation. Engine power of the saw motor 7.5 kW. The cutting speed is adjustable via a pneumatic controller, to enable precise adjustment. The system also has a Shock-absorbing system to mini ...
cutting width: max. 610 mm Cutting height: max. 150 mm Saw blade diameter: 600 mm Motor output: 9,2 kW turning speeds: 2750 U/min Required air-pressure: 7 bar work height max.: 900 +- 20 mm Dimensions (L/W/H): 770x1385x1370 mm SALVAMAC Legend 600 the semi-automatic chop saw -------------------------------------------------- - Maximum cutting area 420x150/520x100/610x30 mm (When sawing stacked boards, note: rear stop height 100 mm) The structure is made entirely of sturdy, thick-walled steel, which is painted throughout and reinforced. A solid one Floor mounting system is equipped with flanged steel feet, to ensure secure attachment. The two-hand control is ergonomically positioned for comfort and efficient operation. Engine power of the saw motor 9.2 kW. The cutting speed is adjustable via a pneumatic controller, to enable precise adjustment. The system also has a Shock-absorbing system ...
cutting width: max. 375 mm Cutting height: max. 125 mm Saw blade diameter: 500 mm Motor output: 5,5 kW turning speeds: 2800 U/min Required air-pressure: 6-8 bar Dimensions (L/W/H): 530x869x1217 mm SALVAMAC Legend 500 fast semi-automatic chop saw -------------------------------------------------- - Maximum cutting area Option A: 220x125/310x50mm Option B: 350x80/375x50mm (When sawing stacked boards, note: rear stop height 100 mm) The structure is made entirely of sturdy, thick-walled steel, which is painted throughout and reinforced. A solid one Floor mounting system is equipped with flanged steel feet, to ensure secure attachment. The two-hand control is ergonomically positioned for comfort and efficient operation. Engine power of the saw motor 5.5 kW. The cutting speed is adjustable via a pneumatic controller, to enable precise adjustment. The system also has a Shock-absorbing system to ...
Key data: 600 mm, 150 mm
Piła ukośna z brzeszczotem D 600 Przenośniki rolkowe przy wejściu materiału Przenośniki rolkowe przy wylocie materiału z ogranicznikiem składania W 250 mm Możliwość rozbudowy przenośników rolkowych na metr
Maksymalny obszar cięcia: 220x125/ 260x100/285x80/310x50 mm. Podczas krojenia desek jeden na drugim, h max. 100 mm. Konstrukcja wykonana jest w całości z grubościennej i wzmocnionej w pełni malowanej stali. Solidny system montażu podłogowego z kołnierzowymi stalowymi nóżkami do otworu montażowego. Dwuręczna bezpieczna kontrola cięcia w ergonomicznej pozycji. Moc silnika brzeszczotu 5,5 kW. Regulowana prędkość cięcia za pomocą regulatora pneumatycznego. Maksymalny system równoważenia masy i trwałości. System amortyzujący. Niezależne opcje regulacji pneumatycznej w celu dostosowania do różnych rodzajów obróbki. Trwała i łatwo wymienialna listwa regulacji brzeszczotu. Piła tarczowa z węglików spiekanych, średnica 500 mm, Z=108. Pneumatyczna prasa mocująca górny przedmiot obrabiany ze sterowaniem elektropneumatycznym. System ruchu docisk ...
