The package includes: (1) Gear Pump STEIMEL T3-80G-GKM: power: 2.2kW, feed pressure: 8bar, pump speed: 930/min, output: 3m³/h, year of construction: 2008 (2) Two Volute Casing Pumps WILLY WANDRACH 32/160 M1S: power: 4kW, output: 6-10m³/h, total dynamic head: 2.8-3bar, temperature: 20°C, density: 1kg/m³, viscosity: 100mm²/s.
Suitable for emulsions separation, type: 3-chamber system, material: polypropylene, capacity: 8m³, capacity: 1m³, pump output: 3m³/h, including 3 dispersing pumps, 3 sludge rakes and flotation tailings tank with pump.
The following three reservoirs are available: (1) Volumetric capacity: 2500l, built 1996, fluid: acid sulfur, operating temperature: 25°C, flow rate: 30000l/h max., connections top / side: DN32, 2xDN40, DN80, DN100 / DN25, DN32, DN80, DN500, material: PVC-EN/GF-UP. The tank has never been filled. (2) Volumetric capacity: 2850l, built 1996, fluid: sulphuric acid solution, operating temperature: 80°C, flow rate: 30000l/h max., material: GF-VE. (3) Volumetric capacity: 33250l, built 1998, fluid: caustic soda, operating temperature: 30°C, flow rate: 30000l/h max., connections top / side: DN60, DN80, DN100 / 2xDN50, 3xDN80, DN600, inner coating: PVC liner 3mm, material: PVC-CAW/GF-UP. In 2001 the tank was repaired and TÜV-checked.
Mechanical-physical seperation method: Number of modules: 2, material: Al²O³ / ZrO², median pore diameter: 0.05µm, membrane length: 1200mm, membrane diameter: 25.4mm, canal diameter: 3.3mm, filtration area: 14.8m².
Air Handling System includes: (1) Ventilation Module Fischbach VN104: Volume flow: 1900m³/h, external compression: 168-200Pa, rotational speed ventilator: 0-1400/min, voltage: 230V, nominal current: 5.5A, number of machines: 2 (2) Air Heater Fischbach PWW LW 1: Heat output: 9kW, air inlet temperature: 11°C, air outlet temperature: 25°C, water comsumption: 0.39m³/h (3) Plate Heat Exchanger Fischer APD N1: Exhaust air volume flow: 1900m³/h, fresh air volume flow: 1900m³/h, exhaust air inlet temperature/humidity: 20°C/50%, fresh air inlet temperature/humidity: -12°C/80% (4) Filter KFS 195-EU4: Initial resistance: 30Pa, number of filters: 2 (5) Multi-Leaf Damper JKA: Number of multi-leaf dampers: 2, including three distance cloth nozzles DSTA.
Volume flow: 2000m³/h, pressure supply air/exhaust air: 766/752Pa, operating rotational speed supply air/exhaust air: 3296/3277/min, rotational speed supply air/exhaust air: 5350/min max., rated power supply air/exhaust air: 5/0.75kW, nominal rotational speed: 2890/min, filter class filter 1/filter 2: G3/F7, seperation efficiency: 87/99%, filter medium: Aluminium wire mesh/micro glass fibre, filter surface: 0.0/4.0m², filter length: 48/534mm, filter size: 592x490mm.
Medium: Egg, conveying volume: 40-450l/h/ 0.005l/cycle, specific weight: 1.050kg/dm³, differential pressure: 0.2-2bar, temperature: 1-4°C, viscosity: 20-50mPas, pump rotational speed: 84-471/min, conveying pressure: 6bar max., design temperature: 150°C, number of pumps: 4.
There are two identical machines available, intake volume flow: 29.05m³/min, volume flow: 1980m³/h, mass flux: 1939kg/h, suction density: 1.112kg/m³, pressure gradient: 600mbar, inlet temperature: 40°C, exit temperature: 102°C, blower rotational speed: 4170/min, motor power: 45kW, length: 1800mm, width: 1500mm, height: 1978mm, weight: 1.33t, including Sea Container SC 40: inner dimensions: 11.900x2330x2350mm, total load: 26.98t, empty weight: 3.5t, Fassungsvermögen: 64m³, length: 12.192mm, width: 2438mm, Höhe: 2591mm, including blower control and control cabinets.
