Second-hand Weinig Profimat 23 automatic planing and moulding machine for four-sided planing and profiling of timber, with a long dressing table. Technical data: Spindle 1: Bottom / 4 kW / 40 mm Spindle 2: Right / 40 mm Spindle 3: Left / shared motor with #2 / 40 mm Spindle 4: Top / 5.5 kW / 40 mm Spindle 5: Bottom / 4 kW / 40 mm Spindles: 5 Working width: 230 mm Working height: 120 mm Feed: 2.2 kW Planing table length: 2,500 mm Condition: Gebraucht Location: Tauberbischofsheim, Germany
ATUALMENTE posso oferecer-te esta plaina HM 4 Industry da Hundegger. GRÁTIS 26 de dezembro O avião de alto desempenho da Hundegger! Uma máquina de plaina HM 4 usada da HUNDEGGER HM-400 2008 com toda a mecanização à esquerda e à direita da máquina de plaina HM4 para 16 m de comprimentos de madeira, como mostrado nas fotografias. 4 motores de plaina de 11KW. 4 x unidade biselada. Medição totalmente automática da secção transversal Venda vista do local, em estado de montagem, sem garantia e garantia, sem desmontagem. Preço líquido 69.000 euros
Offered is a combined Weinig/Alfred Harbs planing and profiling line for woodworking. 1) Weinig Unimat 23 E planer/moulder, year of manufacture: 1996, operating voltage: 3x380V/50Hz, control voltage: 230V/50Hz and 24V DC, rated current: 78A, main fuse: 80A, power: 34kW. 2) Weinig Uniplan fine finish/hydro planer, year of manufacture: 1996, operating voltage: 3x380V/50Hz, control voltage: 230V/50Hz and 24V DC, rated current: 42A, main fuse: 50A, power: 17kW. 3) Weinig UC 10, year of manufacture: 1996. 4) Alfred Harbs K6V, year of manufacture: 1992. Including additional associated components and transport equipment. An on-site inspection is possible.
Second-hand Weinig high-performance planer, model Hydromat 17BL, for professional woodworking. The machine has ten spindles and is suitable for industrial planing and profiling of timber. With a working width of 170 mm, a working height of 120 mm and a feed rate of 60 m/min, it is designed for high-performance continuous processing. Technical data: Spindles: 10 Spindle 1: Bottom / 7.5 kW / 50 mm Spindle 2: Right / 7.5 kW / 50 mm Spindle 3: Left / 7.5 kW / 50 mm Spindle 4: Right / 7.5 kW / 50 mm Spindle 5: Left / 7.5 kW / 50 mm Spindle 6: Top / 11 kW / 50 mm Spindle 7: Bottom / 7.5 kW / 50 mm Spindle 8: Top / 7.5 kW / 50 mm Spindle 9: Bottom / 7.5 kW / 50 mm Spindle 10: Universal / 7.5 kW / 50 mm Working width: 170 mm Working height: 120 mm Feed rate: 60 m/min Feed motor: 15 kW Table: Hard-chromed Condition: Gebraucht Location: Tauberbischofsheim, Germany
Planing width: 410mm, working height: 3mm-240mm, max. stock removal: 5mm, feed speed: 12m/min, thicknessing table X/Y: 775mm/423mm, extraction port diameter: 120mm, operating hours: approx. 350h, weight: approx. 361kg. Equipped with 4-knife TERSA cutterblock for quick knife changes without adjustment or screws, solid gray cast iron thicknessing table with 4-column guide on four large spindles, integrated lifting device for a stable table position without additional locking, manual thicknessing table adjustment with numerical readout and reading accuracy of 1/10mm, helical-toothed steel infeed roller for gentle stock removal from 0.2mm and satin-finished steel outfeed roller. The machine is currently in storage.
Key data: 630 mm, 230 mm, 5 kW
À venda está uma plainadora industrial pesada, robusta e precisa de espessura de cómoda, do tipo tradicional Kölle HK 63, comprimento da penteadeira 2100 mm, largura da plaina 630 mm, altura 230 mm, 4 facas, 5,5 KW, puxador de aço e rolos extratórios. Teste e ajuda com o carregamento possível, apenas levantamento, pré-pagamento ou pagamento em dinheiro na recolha, Sem garantia ou garantia. Preço mais IVA
Ano de fabricação: 1980 Largura de trabalho: 860 mm Altura de trabalho: 250 mm Altura de trabalho 4 lados: 230 mm Número de fusos: 4 Disposição do fuso: u-o-r+l Diâmetro do fuso: X-X-50-50 mm Rolamentos de contagem: 1-2 Potências dos motores: 11-15-5,5-5,5 kW Ajuste da largura de trabalho: manual Ajuste da altura de trabalho: motorizado Alimentação: 4 Rolos acionados na mesa: 3 Rolos superiores de alimentação: 3 Constante de altura da mesa: aprox. 800 mm Peso: 4850 kg Voltagem/Frequência: 380V 50Hz 3Ph
Key data: 4 , 230 mm, 150 mm
Plaina de quatro lados Weinig Tipo: Q 22 Quattromat Ano de Fabricação: 1990 Largura de plaina 230 mm Altura de planeamento 150 mm Comprimento da penteadeira: 1960 mm 4 eixos: 1 4 kW inferiores 2 à direita e 3 à esquerda acionados por 1 motor 5,5 kW 4 acima de 5,5 kW Velocidade de avanço 6 - 22 m/min. Cardão de alimentação, motor de alimentação 2,2 kW Manual da bomba de lubrificante Com capuz insonorizado Incluindo as cabeças de plaina 2 peças de comprimento 230 mm 2 peças de comprimento 150 mm Peso com subestrutura 1.620 kg Dimensões 3350 mm x 1450 mm x H 1600 mm
usava
usava
Weinig Unimat 23 SP automatic planing and splitting machine for the precise planing (or pre-planing) and splitting of solid timber in a single operation. The machine delivers a high standard of finish and is ideal for efficient mass production in the timber industry. Technical data: Spindles: 4 Working width: 230 mm Working height: 120 mm Spindle 1: Bottom (5.5 kW) Spindle 2: Top (5.5 kW) Spindle 3: Right (11 kW) Spindle 4: Left (11 kW) Feed: 5.5 kW Condition: Gebraucht Location: Tauberbischofsheim, Germany
Kölle planer, or planer for short, for smoothing and levelling (planing) timber. Includes an adjustable angle stop and accessories Technical data: Working width: 600 mm Blade system: Z2 strip planing blades Condition: Gebraucht Location: Tauberbischofsheim, Germany
Kölle HA 51 planer, or planer for short, for smoothing and levelling (planing) timber. Includes Hemag jointing unit. Technical data: Working width: 450 mm Working height: 100 mm (joining) Condition: Gebraucht Location: Tauberbischofsheim, Germany
Weinig Unimat 23E automatic planing and profiling machine for four-sided planing and profiling of timber, featuring a mobile spindle for automatic adjustment and a grooving bed (optionally available without the grooving bed) for short and curved workpieces, as well as a long dressing table. Technical data: Optional: Conversion to a conventional smooth table, on request. Spindles: 5 Spindle 1: Bottom / 40 mm / 5.5 kW Spindle 2: Right / 40 mm / 7.5 kW Spindle 3: Left / 40 mm / Shared motor with spindle 2 Spindle 4: Top / 40 mm / 7.5 kW Spindle 5: Bottom / 40 mm / 5.5 kW Working width: 230 mm Working height: 160 mm Feed: 4 kW / 524 m/min Condition: Gebraucht Location: Tauberbischofsheim, Germany
Bäuerle Type 125/02 heavy-duty thickness planer for the precise sizing (thickness planing) of solid timber and wood-based materials. The robust construction and powerful drive ensure consistent planing results and a long service life. Accessories included. Technical data: Planing width: 610 mm Planing height: 200 mm Planing shaft: Z4 strip planing blades Feed speed: 714 m/min Motor power: 4.4 kW Weight: approx. 1,150 kg Condition: Gebraucht Location: Tauberbischofsheim, Germany
