pressure:250 tthroat:450 mmstroke:36 - 126 mmno. of strokes:40 /mindistance table/ram, max. stroke up, adjustment up:525 mmtable surface area:1000 x 750 mmhole in the table:400 x 360 mmtable height over floor:1000 mmram surface:600 x 500 mmram adjustment:111 mmpower requirement:19,0 kWweight:13,5 tDimensions (WxDxH):1,3 x 3,2 x 3,35 mclutch:pneumatic overload protection in ram:mechanical ram adjustment:motoric
: neu : ca. 12 Wochen ab Auftrags : Türkei : 59800 €: 1130.22 €: 100 to: 400 mm: 800 x 500 mm: 500 mm: 110 mm/s: 10 mm/s: 160 mm/s: 11 kW: 1900 mm: 1700 mm: 2930 mm: 5500 kg: 250 barWelded monoblock frameCylinders hardened and chrome-plated2 auxiliary cylinders and 2 round guidesT-slots can be configured according to customer requirementsPump, valves, and filters from Bosch RextrothHydraulic overload valveHydraulic proportional valveCoolerSiemens electrical components8 additional signal inputs and outputs7-inch touchscreenSiemens S7 PLCStroke, pressure, speed, and dwell time adjustable via the PLCRemote maintenance accessSick light guardsSafety coversSafety PLC from Siemens or SickCategory 4 sensors and photoelectric switchTwo-hand control panelReset and emergency stop buttonsEquipped according to CE regulationsThe data for this ad was created with ModulMWS - the software solution o ...
pressure:100 tdistance between columns:1230 mmstroke:20 - 200 mmno. of strokes:20 - 60 /mindistance table/ram, max. stroke up, adjustment up:650 mmtable surface area:1050 x 750 mmtable height over floor:760 mmside window:540 mmram surface:1000 x 750 mmram adjustment:100 mmpower requirement:18,0 kWweight:20,5 tDimensions (WxDxH):2,8 x 1,9 x 4,3 minfinitely variable drive:PIV clutch:pneumatic overload protection in ram:hydraulic ram counterbalance:pneumatic ram adjustment:motoric
: neu : ca. 4 Monate ab Auftragse : Italien : 74800 €: 1413.72 €: 100 to: 500 mm: 1000x800 mm: 600 mm: 26 mm/s: 5 mm/s: 4 kW: 1260 mm: 1060 mm: 2400 mm4-pillar guideram guide roundtable and ram with T-slots2 hand operationSiemens PLCmanometerusers manual Light barrier € on RequestSiemens touchscreen-control, 50 programsstoreable, for programming: • Upstroke and downstroke quota• Break time in the bottom• time of Decompression• setting pressure of work• Pieces counter• prestop in upstroke and downstroke• setting for movement in manual and in automatic• management of alarms and anomalies € on Request Working hour counter € on Request Stroke counter € on Request Decompression valve € on Request Oil cooler with decompreission valve € on Request Pressur switch € on RequestThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
: neu : ca. 8 Wochen ab Auftragse : Türkei : 111800 €: 2113.02 €: 125 to: 5.5 mm: 1100 mm: 630 mm: 180 mm: 15 - 150 mm: 42 - 65 1/min: 700x400 mm: 8 : 90 mm: 320 mm: 610 mm: 15 kW: 1400 mm: 2200 mm: 3120 mm: 12500 kgtouch screen controlsemi automatic stroke adjustmentdie space adjustment with mechanical display decimal resolutionadjustable motor speedoverload protectorautomatic cams resetdouble bolster plateoil circular lubricationdynamic brakesafety light guard KeyenceAutomation and control of press parameters by PLC, alarms and informations displayd on human machine interface touch screen.Standard monitoring:- press speed view and adjustment- programmable piece counter and maintenance piece counter- die space adjustment with brake motor- Semi automatic or automatic stroke adjustment- die safety control- alarms view- overload protectorThe data for this ad was created with ModulMWS ...
pressure:160 tdistance between columns:880 mmstroke:150 mmdistance table/ram, max. stroke up, adjustment up:400 mmtable surface area:830 x 1000 mmhole in the table:265 x 365 mmtable height over floor:850 mmside window:610 mmram surface:860 x 1000 mmpower requirement:55,0 kWweight:14,7 tDimensions (WxDxH):2,2 x 2,0 x 4,3 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20 depth stop:motoric adjustable table:motoric foundation pit:not necessary
: neu : ca. 14 - 16 Wochen ab Auf : Türkei : 197600 €: 3734.64 €: 400 to: 6050 mm: 3 : 365 mm: 5100 mm: 510 mm: 630 mm: hydraulisch : 120 mm/s: 8 mm/s: 100 mm/s: 750 mm: 350 mm/s: 300 mm/s: 250 mm: 1220 mm: 154 mm: 500 l: 37 kW: 7500 mm: 2110 mm: 3810 mm: 34660 kg3 axes (Y1, Y2, X)CNC control DT-15- 2D grafic display 15",- intuitive touch-screen control (simple drawing of the bending outline with your finger)- user friendly programming in dialogue form- automatic calculation of the bending sequence- automatic calculation of the blank sheet size- graphic product and tool memory- correction possibility- USB interfaces for backup and programm transportation- PC software, generating programms on the PC and transfer to the machine by USBservo motorized back gauge on linear guides and ball screwsback gauge finger blocks on double linear guidesCNC crowning tableupper tool 1010 / A / 75 ...
Pressure:250 tthroat:450 mmstroke:8 - 135 mmno. of strokes:50 /mindistance table/ram, max. stroke up, adjustment up:635 mmtable surface area:1250 x 850 mmhole in the table:355 mmtable height over floor:950 mmpassage to the back:660 mmram surface:790 x 610 mmram adjustment:120 mmpower requirement:18,5 kWweight:14,0 tDimensions (WxDxH):1,5 x 2,8 x 3,65 mGerman Safety: permitted for manual loading:CE-Norm - EN 692, BGR 500 clutch:pneumatisch overload protection in ram:mechanisch ram counterbalance:pneumatisch
pressure:500 tdistance between columns:2400 mmstroke:400 fix mmno. of strokes:13 - 23 /minDistance table/ram, max. stroke up, adjustment up:1600 mmtable surface area:2300 x 1800 mmcolumn travel -side:1600 mmram surface:2170 x 1800 mmram adjustment:300 mmtotal power requirement:110,0 kWWeight:135,0 tDimensions (WxDxH):3,35 x 4,85 x 7,0 mclutch:pneumatic overload protection in ram:hydraulic ram adjustment:motoric
pressure:300 tdistance between columns:2500 mmstroke:350 mmdistance table/ram, max. stroke up, adjustment up:1280 mmtable surface area:2500 x 1500 mmtable height over floor:850 mmside window:900 mmram surface:2500 x 1500 mmspeed down:300 mm/sspeed up:240 - 450 mm/sworking speed:23 - 44 mm/soil volume:3000 lpower requirement:132,0 kWweight:54,0 tDimensions (WxDxH):3,25 x 3,2 x 4,8 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 ram interlocking:SITEMA
: neu : ca. 14 - 16 Wochen ab Auf : Türkei : 33700 €: 643.67 €: 30 to: 2 mm: 400 mm: 600 mm: 150 mm: 1 - 60 mm: 140 1/min: 4 : 60 mm: 40 mm: 200 mm: 300 mm: 3 kW: 1300 mm: 1150 mm: 2050 mm: 1670 kgWelded steel frame construction4-fold ram guidePneumatic clutch-brake combinationProtective enclosure with light barriers and side doorsMechanical overload protectionTwo-hand and foot pedal operationManual stroke adjustmentManual ram adjustmentVariable stroke rate via frequency converterOperating modes: Adjustment mode Two-hand release Foot release 2-stroke operation via light barriers Continuous operationTouchscreen for Stroke counter with preselection for continuous operation Stroke rate adjustment Lubrication intervals and duration Alarm messages Motor direction of rotation Monitoring of inputs and outputs2 free cams for connecting peripheralsAutomatic central lubricationEqui ...
nominal force:100 tstroke:320 mmno. of strokes:35 /mindistance between columns:360 / 250 mmDistance table/ram, max. stroke up, adjustment up:500 mmtable surface area:320 x 450 mmtable height over floor:660 mmram surface:250 x 280 mmspindle diameter:125 mmpower capacity:3,0 kWweight:4,5 tDimensions (WxDxH):2,0 x 1,6 x 3,1 m
Pressure:100 tdistance between columns:910 mmstroke:600 mmdistance table/ram, stroke up:1000 mmtable surface area:1340x680 / 910x1085 mmhole in the table:700 x 510 mmtable height over floor:800 mmside window:680 mmram surface:1230x680 / 910x1000 mmcapacity of ejector:7,5 tejector stroke:150 mmpower requirement:15,0 kWweight:9,5 tDimensions (WxDxH):2,3 x 1,9 x 3,6 mlight guard:Sick blank holder / ejector in ram:hydraulisch
pressure:150 tthroat:450 mmstroke:115 fix mmno. of strokes:45 /mindistance table/ram, max. stroke up, adjustment up:400 mmtable surface area:2250 x 1090 mmtable height over floor:900 mmpassage to the back:1900 mmram surface:1900 x 900 mmram adjustment:100 mmpower requirement:16,0 kWweight:19,5 tDimensions (WxDxH):3,0 x 2,3 x 3,9 m
pressure:200 tdistance between columns:1800 mmstroke:710 mmDistance table/ram, max. stroke up, adjustment up:1100 mmtable surface area:1600 x 1300 mmpressure of drawing cushion in table:80 tstroke of drawing cushion in table:250 mmdie cushion area:1400 x 1080 mmtable height over floor:800 mmside window:1300 mmram surface:1660 x 1300 mmspeed down:400 mm/sspeed up:410 mm/sworking speed:14,3 - 49,7 mm/spower requirement:46,0 kWweight:25,0 tDimensions (WxDxH):3,65 x 3,3 x 5,4 mheight over floor:5,05 mheight beneath floor:0,4 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard at front and back:Sick drawing cushion in table:hydraulic ejector in ram:hydraulic depth stop:mechanical
pressure:50 tdistance between columns:1750 mmstroke:500 mmDistance table/ram, max. stroke up, adjustment up:800 mmtable surface area:1700 x 750 mmtable height over floor:800 mmside window:650 x 750 mmram surface:1700 x 750 mmpower requirement:11,0 kWweight:11,0 tDimensions (WxDxH):2,1 x 1,15 x 3,4 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 foundation pit:not necessary
pressure:015 tthroat:200 mmstroke:4 - 70 mmno. of strokes:140 /mindistance table/ram, max. stroke up, adjustment up:310 mmtable surface area:430 x 395 mmhole in the table:165 x 160 mmtable height over floor:560 - 735 mmtable adjustable:175 mmram surface:160 x 130 mmram adjustment:80 mmpower requirement:1,2 kWweight:0,9 tDimensions (WxDxH):1,0 x 1,25 x 1,8 mclutch:Drehkeil overload protection in ram:mechanical
pressure:030 tstroke:8 - 40 mmno. of strokes:100 - 600 /mindistance between columns:325 mmdistance table/ram, max. stroke up, adjustment up:250 mmtable surface area:540 x 300 / 325 x 395 mmhole in the table:315 x 110 mmtable height over floor:1000 mmcolumn travel -side:290 mmram surface:250 mmmaterial width of feeder:120 mmmaterial thickness of feeder:3,0 mmfeed length:60 mmpower requirement:5,5 kWweight:2,6 tDimensions (WxDxH):1,5 x 1,2 x 2,2 mclutch:pneumatic roll feed:mechanical, Bruderer BBV 120/60
pressure:100 tthroat:350 mmstroke:6 - 100 mmno. of strokes:60 /mindistance table/ram, max. stroke up, adjustment up:400 mmtable surface area:850 x 700 mmhole in the table:470 x 150 mmtable height over floor:855 mmram surface:450 x 300 mmram adjustment:80 mmpower requirement:7,5 kWweight:5,0 tdimensions (WxDxH):1,5 x 2,3 x 2,6 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:mechanical
pressure:500 tdistance between columns:2240 mmstroke:1180 mmdistance table/ram, max. stroke up, adjustment up:1800 mmtable surface area:2050 x 1800 mmpressure of drawing cushion in table:250 tstroke of drawing cushion in table:380 mmdrawing cushion surface in table:1800 x 1200 mmpressure of drawing cushion in ram:122 tstroke of drawing cushion in ram:200 mmdrawing cushion area in ram:1800 x 1200 mmram surface:2215 x 1800 mmtable height over floor:500 mmspeed down:400 mm/sspeed up:10 - 400 mm/sworking speed:10 - 100 mm/sdepth of the foundation:3,0 mpower requirement:122 + 75 + 64,5 kWweight:110,0 tDimensions (WxDxH):3,6 x 2,2 x 8,5 mheight over floor:6,8 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table and ram:hydraulic
pressure:6 tstroke:1020 mmtotal power requirement:3,5 kWCan only adjust between tips Texte, Bilder, Grafiken, Layout, Strukturen und Algorithmen etc. unterliegen weltweitem Urheberrecht.Unerlaubte Verwendung der Daten, werden sowohl strafrechtlich als auch zivilrechtlich verfolgt.Das ausschließliche Urheber- / Nutzungsrecht dieser Daten wurde nachfolgender Person eingeräumt.Copyright © 2005-2026, Josef Weber. All rights reserved.
pressure:500 tdistance between columns:3200 mmstroke:1250 mmdistance table/ram, max. stroke up, adjustment up:1810 mmtable surface area:3000 x 1900 mmpressure of drawing cushion in ram:150 tstroke of drawing cushion in ram:200 mmdrawing cushion area in ram:2400 x 1200 mmram surface:3160 x 1900 mmspeed down:400 mm/sspeed up:250 mm/sworking speed:18 - 58 mm/sheight over floor:6,5 mpower requirement:90,0 + 36,5 kWweight:110 tGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in ram:hydraulic
: neu : ca. 12 Wochen ab Auftrags : Türkei : 13200 €: 253.44 €: 100 to: horizontal verschiebbar : 300 mm: 1570 mm: 220x160 mm: 5 mm/s: 10 mm/s: 2560 mm: 1000 mm: 2480 mm: 1755 kghorizontal movable cylinder by handwheelsteel welded framestop at any positionpressure manometersafety valve against overloading2 V-blockstable height adjustabletable up-down movement attachmentcontrol by operating leveraccording to CE regulations user manual in GERMAN and ENGLISHThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure:800 tdistance between columns:3010 mmstroke:300 mmdistance table/ram, max. stroke up, adjustment up:1350 mmtable surface area:3000 x 1800 mmtable height over floor:500 mmside window:1500 x 1400 mmram surface:3000 x 1800 mmspeed down:300 mm/soil volume:900 lheight over floor:5,4 mheight beneath floor:2,1 mpower requirement:200,0 kWweight:80,0 tDimensions (WxDxH):5,2 x 2,6 x 7,5 mram interlocking:in TDC depth stop:mechanical
nominal force:315 tstroke:300 mmno. of strokes:36 /mindistance between columns:540 mmdistance table/ram, max. stroke up, adjustment up:750 mmtable surface area:530 x 630 mmblow die to die:630 tAllowed max. force:500 tram surface:450 x 560 mmspindle diameter:180 mmpower capacity:18,0 kWweight:13,0 tDimensions (WxDxH):2,5 x 2,0 x 4,0 m
pressure:100 tdistance between columns:1060 mmstroke:700 mmdistance table/ram, max. stroke up, adjustment up:1250 mmtable surface area:1000 x 700 mmpressure of drawing cushion in table:40 tstroke of drawing cushion in table:200 mmdie cushion area:Ø 250 mmtable height over floor:950 mmside window:580 x 750 mmram surface:1000 x 700 mmoil volume:700 lpower requirement:47,0 kWweight:13,0 tDimensions (WxDxH):2,2 x 1,8 x 5,0 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 depth stop:mechanical; motoric adjustable ram interlocking:SITEMA
: neu : ca. 6-8 Wochen ab Auftrag : Italien : 500 to: 500 mm: 5.000 x 2.550 mm: 700 mm: 18 mm/s: 3 mm/s: 5000 mm: 5000 mm: 3000 mm: 32000 kg: horizontal verschiebbar : 2550 mm: 1.700 mm: 3.600 mmhorizontal movable cylinderhydraulicaly movable standcontrol by levers as well as control panelaccording to CE regulations user manual in GERMAN and ENGLISHOPTIONS:Work table, welded to the base frame, with holes on the surfaceControl panel on the swivel arm (push buttons for press movement, solenoid valves, Siemens CPU)Radio control panel (push buttons for press movement, solenoid valves, Siemens CPU)Siemens control with touchscreenLifting cylinders in the table (6, 8 or 10 pcs.)No-rotation shaft for the piston2 speeds for stand movement and cylinderOil cooler and decompression valveThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure:160 tdistance between columns:2050/1900 mmstroke:15 - 170 mmno. of strokes:15 - 40 /mindistance table/ram, max. stroke up, adjustment up:690 mmtable surface area:1600 x 800 mmside window:800 mmram surface:1620 x 700 mmram adjustment:140 mmpower requirement:15,0 kWweight:24,0 tDimensions (WxDxH):3,3 x 2,3 x 5,3 mheight over floor:4,8 mheight beneath floor:0,5 mclutch:pneumatic ram adjustment:motoric ram counterbalance:pneumatic
pressure:500 tstroke:40 - 160 mmno. of strokes:32 / 48 /mindistance between columns:1620 mmdistance table/ram, max. stroke up, adjustment up:660 mmtable surface area:1600 x 1300 mmtable height over floor:750 mmcolumn travel -side:400 x 430 mmram surface:1400 x 1200 mmram adjustment:120 mmpressure of drawing cushion in table:60 tstroke of drawing cushion in table:100 mmdrawing cushion surface in table:1300 x 810 mmmaterial width of feeder:1000 mmmaterial thickness of feeder:- 6,0 mmfeed length:350 mmheight beneath floor:0,3 mpower requirement:44,0 / 66,0 kWweight:56,0 tDimensions (WxDxH):3,55 x 2,55 x 5,1/5,8 mheight beneath floor without drawing cushion:0,3 mheight beneath floor with drawing cushion:1,0 mclutch-/ brake combination:pneumatic; Desch overload protection in ram:mechanical ram counterbalance:pneumatic ram adjustment:motoric drawing cushion in table:pneumatic Mechanical pincer ...
