pressure: 100 t throat: 620 mm stroke: 0-100 mm hole diameter in sheet thickness: 40 in 20 mm no. of strokes: 49 Hub/min Control: total power requirement: 15 kW weight of the machine ca.: 3.500 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 40 t throat: 175 mm work height max.: 1055 mm stroke: 30 mm sheet thickness - max.: 8 mm total power requirement: 4 kW weight of the machine ca.: 1020 kg dimensions: 910 x 670 x 1930 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 50 t throat: 610 mm total power requirement: 7,5 kW machine weight ab.: 1700 kg dimensions: 1500 x 650 x 1700 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Pressing force: 100 t diameter: 40 mm throat: 760 mm total power requirement: 8,5 kW weight: 3.600 kg Accessories / equipment: - punching table The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 100 t punching cross-cut in cmm: 40.0 in 22.0 mm ST stroke: 120 mm column arm: 760 mm total power requirement: 8.5 kW weight of the machine ca.: ca. 3.800 kg dimensions of the machine ca.: ca. 2500 x 1700 x 2000 mm Original price, including stop system: approx. 45.000 euros Special price available upon request Features: - Robust / heavy-duty hydraulic hole punch - Punch stroke continuously adjustable - NC stop system MUBEA MATIC 82 Travel range in X and Y axes With FAGOR control unit Includes large support table Separate control cabinet - Various (custom) punching tools (see Figure 9) - Front safety guard, including sheet metal scraper - 1 freely movable foot switch - Operating instructions for machine and stop system The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
sheet width: 170 mm plate thickness: 0 mm number of rolls: 0 weight of the machine ca.: 0,1 t Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
round bar steel: 33 mm square edge steel: 30 mm L-beam: 60 x 8 mm hole diameter in sheet thickness: 20 in 13 mm hole punhing press: pressure: 35 t hole punching press: throat: 320 mm hole punching press: max. length of stroke: 24 mm hole punching press: capacity (dia. x thick.): 30 x 9 mm hole punching press: capacity (dia. x thick.): 20 x 13 mm total power requirement: 1,5 kW weight of the machine ca.: 1,7 t dimensions of the machine ca.: 1,5 x 0,7 x 1,8 m Profile steel shear with: - Hole punch - Notcher - Foot switch - Machine light - Mounted on a trolley The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
9 gavetas Peso: 293 kg Dimensões CxLxA: 720x725x1000mm Conteúdo incluído: Anúncio ver foto
Especificações Tipo: KBLH 700 Dimensões (CxLxA): 1850 x 680 x 2050 mm Altura de trabalho: 700 mm Comprimento de corte: 510 mm Comprimento da faca: 520 mm Secção transversal máxima de cisalhamento: 3500 mm Curso da tesoura, infinitamente variável: 0 – 45 Número máximo de tesouras no curso: 11 Faca PMG para: L-steel 90°+45°/ T-steel 90° Potência necessária: 8,5 kW Peso aprox.: 2950kg
Separating tool, punching tool, punch, punch die, punch stamp, -Stamping tool: Die holder with fine adjustment -Bore: Ø 25 mm -Dimensions: see photos -Dimensions: 300/250/H210 mm -Weight: 32.1 kg
Separating tool, punching tool, punch, punch die, punch stamp, -Punch tool: for holding dies -Hole: Ø 100/43 mm -Dimensions: see photos -Dimensions: 345/280/H245 mm -Weight: 55.9 kg
Separating tool, punching tool, punch, punch die, punch stamp, -Punch tool: Intermediate block -Bore: Diameter 65 mm -Dimensions: see photos -Dimensions: 370/250/H125 mm -Weight: 46.7 kg
Profile steel knife, shearing tool, cutting tool, separating tool, punching tool, punch, punch die, punch stamp -Manufacturer: Mubea, shearing tool for square steel / round steel -Item No.: 0502805202 -Square steel: 27x27 mm / 50x50 mm -Round steel: Ø 31/56 mm -Number: 2x shearing tools available -Price: per piece -Dimensions: 185/185/H40 mm -Weight: 8.8 kg/pc.
Separating tool, punching tool, punch, punch die, punch stamp, stripper -Manufacturer: Mubea, scraper 4 pieces -Size: 10/15/30/40 mm -Dimensions: see photos -Submission/Price: complete -Transport dimensions: 150/110/H60 mm -Weight: 6.1 kg
Triangular notching tool, notching side knife, die holder, separating tool, punching tool, punch, punch die, punching die -Punch tool: Angle notching tool, notching unit -Dimensions: see photos -Dimensions: 150/130/H80 mm -Weight: 4.4 kg
Triangular notching tool, notching side knife, die holder, separating tool, punching tool, punch, punch die, punching die -Punch tool: Angle notching tool, counter blade only, without notching unit -Hole spacing: 200/150 x Ø 18 mm -Dimensions: 255/200/H100 mm -Weight: 14 kg
Separating tool, punching tool, punch, punch die, punch stamp, -Manufacturer: Mubea, die-cutting tool intermediate block -Dimensions: see photos -Dimensions: 310/17/H110 mm -Weight: 22.6 kg
Separating tool, punching tool, punch, punch die, punch stamp, -Manufacturer: Mubea, die-cutting tool for holding dies -Bore: Ø 73 mm / Mounting Ø 90 mm / Hole spacing 90/75 mm M10 -Dimensions: see photos -Dimensions: 200/100/H120 mm -Weight: 6.8 kg
Separating tool, punching tool, punch, punch die, punch stamp, gill forming tool -Manufacturer: Mubea, die-cutting tool for holding dies -Hole: Ø 35 mm -Dimensions: see photos -Dimensions: 235/105/H130 mm -Weight: 11.1 kg
Punching tool, punch, stripper, hold-down -Scraper: Hold-down device for dies -Hole: Ø27/33 x 257 mm -Dimensions: 360/105/H135 mm -Weight: 5.0 kg
Punching tool, punch, stripper, hold-down -Scraper: Hold-down device for dies -Hole: Ø30 x 258 mm -Dimensions: 310/100/H125 mm -Weight: 4.6 kg
Oferta 23145 Dados técnicos: - Tesouras de aço planas - comprimento da lâmina 420 mm - Para material plano 400 x 15 mm - Tesouras de aço com perfil - não existem facas disponíveis - Aço em L a 90 110 x 10 mm - com 45 65 x 8 mm - Aço em T a 90 90 x 10 mm - Tesouras de barra de aço - não existem facas disponíveis - Aço redondo / aço quadrado 35 / 32 mm - Dispositivo de entalhe - para material até 12 mm - Entalhe triangular T 60 mm - Furador - força de perfuração aproximada. 500 KN - - Curso infinitamente variável 0 - 40 mm - Punções em aço até 30 mm em 15 mm - Projeção 410 mm - Acionamento hidráulico 400 V / 7,5 kW - Requisito de espaço aproximado. L 1400 x D 1800 x D 700 mm - Peso aproximado. 1800 kg - com: - vários punções + matrizes - Tabela de paragens de suporte - Dispositivo de entalhe tri ...
Oferta 23145 Dados técnicos: - Tesouras de aço planas - comprimento da lâmina 420 mm - Para material plano 400 x 15 mm - Tesouras de aço com perfil - não existem facas disponíveis - Aço em L a 90 110 x 10 mm - com 45 65 x 8 mm - Aço em T a 90 90 x 10 mm - Tesouras de barra de aço - não existem facas disponíveis - Aço redondo / aço quadrado 35 / 32 mm - Dispositivo de entalhe - para material até 12 mm - Entalhe triangular T 60 mm - Furador - força de perfuração aproximada. 500 KN - - Curso infinitamente variável 0 - 40 mm - Punções em aço até 30 mm em 15 mm - Projeção 410 mm - Acionamento hidráulico 400 V / 7,5 kW - Requisito de espaço aproximado. L 1400 x D 1800 x D 700 mm - Peso aproximado. 1800 kg - com: - vários punções + matrizes - Tabela de paragens de suporte - Dispositivo de entalhe tri ...
Die holder, notching tool, punching tool, punch, punching die, punching punch, -Manufacturer: Mubea, punching tool Ø 60 mm -Type: Mubea 60 holder Ø 50 mm -Die: Ø 150 mm -Total dimensions: Ø 150 x 120 mm -Weight: 6.6 kg
Hand lever shears, long-blade sheet metal and round steel shears, lever shears -Manufacturer: Mubea, sheet metal and round steel shears -Cutting insert length: 200 mm -Steel sheet: up to 7 mm -Flat/strip iron: up to 100x9 mm -Round steel: up to 20 mm -Rectangular profile: up to 18x18 mm -Lever arm: with rack and pinion transmission -Overall dimensions: 540/180/H1570 mm -Transport dimensions: 1250/180/H490 mm -Weight: 44 kg
Die holder, notching tool, punching tool, punch, punch die, punch stamp, -Manufacturer: Mubea, punching tool Ø 60 mm -Type: Mubea 60 5-12 Mount Ø 50 mm -Matrix: Ø 150 mm -Overall dimensions: Ø 150 x 120 mm -Weight: 6.7 kg
Die holder, notching tool, punching tool, punch, punching die, punching punch, -Manufacturer: Mubea, punching tool square Ø 70 mm -Type: Mubea 70 5-10 holder Ø 50 mm -Die: Ø 150 mm -Total dimensions: Ø 150 x 120 mm -Weight: 6.6 kg
Die holder, notching tool, punching tool, punch, punching die, punching punch, -Manufacturer: Mubea, punching tool square Ø 70 mm -Type: Mubea 70 2 holder Ø 50 mm -Die: Ø 150 mm -Total dimensions: Ø 150 x 120 mm -Weight: 5,9 kg
Hand lever shears, long knife, sheet metal and round steel shears, lever shears -Mubea: sheet metal and round steel shears -Cutting insert length: 200 mm -Dimensions: 380/160/H1240 mm -Weight: 22 kg
Long-blade sheet metal and round steel shears -Sheet metal shears: sturdy -Material: Flat steel -Round: up to 15 mm -Square: up to 15 mm
