Modelo
(Fabricante: MORI SEIKI)
Centro de mecanizado vertical MORI SEIKI, Modelo/Tipo: GV-503/5ax X-recorrido 610 mm Y-travel 765 mm Z-recorrido 460 mm Tamaño de mesa de palé 550 x 550 mm BT 40 estrecha
Centro de mecanizado Mori Seiki M25 – FH 2/35
MORI SEIKI NT6600 CNC CENTRO DE TORNEADO DE MOLINO INTEGRADO CON FRESADO EN VIVO SWING MÁXIMO SOBRE LA CAMA: 42 pulgadas DIÁMETRO MÁXIMO DE LA PIEZA DE TRABAJO: 42 pulgadas LONGITUD MÁXIMA DE LA PIEZA DE TRABAJO: 239 pulgadas DIÁMETRO MÁXIMO DE LA BARRA: 6.4inch DIÁMETRO DEL HUSILLO: 7 pulgadas X AXIS TRAVEL: 41 pulgadas RECORRIDO DEL EJE Y: 26 pulgadas RECORRIDO DEL EJE Z: 242 pulgadas EJE B: +/- 120 GRADOS. VELOCIDAD DEL HUSILLO PRINCIPAL: 1500 RPM MOTOR DEL HUSILLO PRINCIPAL: 40 HP VELOCIDAD DEL HUSILLO DE FRESADO: 8000 RPM MOTOR DEL HUSILLO DE FRESADO: 40 HP ELECTRICIDAD: 220V / 3P / 60Hz / 216A OAD (APROXIMADO): 490inch X 182inch X 169inch HIGH PESO (APROXIMADO): 120,560 LBS. EQUIPADO CON: EJE C YAXIS EJE B HERRAMIENTAS/FRESADO EN VIVO CHUCK de 20 pulgadas FS-31iA5 CNC CONTROL CAMBIADOR AUTOMÁTICO DE HERRAMIENTAS DE 140 POSICIONES CULATA PROGRAMABLE ...
x-travel:800 mm y-travel:460 mm z-travel:510 mm total power requirement:20 kW weight of the machine ca.:8 t Vertical Processing Centre 20kW is the nominal value. The spindle only needs 7.5kW. It looks like 15kW will be enough.
standard turning dia.:200 turning length:max. 810 mm control:MSX-701 MAPPS IV greates pass round over bed:800 mm Max. distance between centres:1130 mm max. turning diameter:320 mm max. workpiecediameter:300 mm bar material dia.:65 mm Traverse X-Axis 1:210 Traverse X-Axis 2:210 mm Traverse X-Axis 3:210 mm Traverse Y-Axis 1:110 (+65/-45) mm Traverse Y-Axis 2:110 (+45,/-65) mm Traverse Z-Axis 1:300 mm Traverse Z-Axis 3:300 mm Traverse Z-Axis 2:810 mm Traverse B-Axis:870 mm turning speed range - spindle:5.000 1/min Number of spindle speed ranges:2 . spindle nose:JIS A2-6 spindle bore:73 mm spindle bearing diameter:120 mm C-Axis:0,001 ° turning speed range - spindle:5.000 1/min spindle nose:JIS A2-6 spindle bore:73 mm bar material dia. max:65/52 mm spindle bearing diameter:120 mm C-Axis:0,001 ° Number of Turrets:3 . Number of tool stations:16 x 3=48 pos Schank height for square tool:20 mm D ...
standard turning dia.:200 turning length:max. 810 mm control:MSX-701 MAPPS III greates pass round over bed:800 mm Max. distance between centres:1130 mm max. turning diameter:320 mm max. workpiecediameter:300 mm bar material dia.:65 mm Traverse X-Axis 1:210 Traverse X-Axis 2:210 mm Traverse X-Axis 3:210 mm Traverse Y-Axis 1:110 (+65/-45) mm Traverse Y-Axis 2:110 (+45,/-65) mm Traverse Z-Axis 1:300 mm Traverse Z-Axis 3:300 mm Traverse Z-Axis 2:810 mm Traverse B-Axis:870 mm turning speed range - spindle:5.000 1/min Number of spindle speed ranges:2 . spindle nose:JIS A2-6 spindle bore:73 mm spindle bearing diameter:120 mm C-Axis:0,001 ° turning speed range - spindle:5.000 1/min spindle nose:JIS A2-6 spindle bore:73 mm bar material dia. max:65/52 mm spindle bearing diameter:120 mm C-Axis:0,001 ° Number of Turrets:3 . Number of tool stations:16 x 3=48 pos Schank height for square tool:20 mm ...
x-travel:800 mm y-travel:410 mm z-travel:510 mm control:Fanuc 10 MA rapid travel x/y/z:20/20/15 mm/min table surface area:1100 x 450 mm tool taper:BT 40 tool magazin::30 BT 40 max. tool length:250 mm max. tool weight:8 kg power requirement:7,5/5,5 kW turning speed range:6000 1/min weight of the machine ca.:6,3 t Under offer is a complete CNC tool shop, which will be given up due to old age of owner. The Mori Seiki is still highly accurate. All existing tool holders, tools, drills, vices etc. come with the machine. All measuring devices also come with the machine. Upon request orders for parts to be made can be passed on to new owner. This is a low cost all inclusive opportunity for a "Startup"
x-travel:1400 mm y-travel:1200 mm z-travel:1350 mm control:MSX- 701 Mapps III table surface area:800 x 800 mm rapid traverse:50 m/min table rotating:360.000 x 0,001 B-Achse ° table load:2,0 t numbers of pallets:2 turning speed range:8000 1/min power capacity - milling spindle:37 kW no. of tools in the magazine:60 Stück tool taper:HSK-A 100 weight:31 t dimensions:5,9 x 3,48 x 3,68 m Equipment: - Thru-the-spindel coolant system Mayfran Consep 2000 70 bar with chipconveyor - Helical cutting + Synchronized tapping - Parts program memory 1 MB - Knoll 70 bar high pressure and filter system - Electrostatic oil dust collector LTA - elect. hand wheel - renishaw probe - abso- scale i X/Y/Z- axis - 5 free m- funktions - 48 extra off sets - dual ballscrews on X/Y/Z- axis
x-travel:630 mm y-travel:600 mm z-travel:650 mm control:MSC 502 (Fanuc 16) Spindle RPM:12000 1/min spindle drive:22 / 18,5 kW rapid travel x/y/z:32 m/min Pallet dimension:500x500 mm numbers of pallets:2 table load:0,5 t working diameter:max. 610 mm Number of tool station:60 BT40 max. tool length:360 mm max. tool weight:12 kg tool changing time:1,3 sec B-axis positioning (non continuous):1 total power requirement:50 kVA weight of the machine ca.:14 t dimensions of the machine ca.:3,3 x 5,8 x 3,2 m spindle load monitor:Typ C This horizontal machining center comes with a pallet changer with 2 pallets, and has the following options: ATC 60 tool stations, High pressure coolant trough spindle interface,
turning diameter: 176 mm turning length: 570 mm swing diameter: 510 mm working diameter: 420 mm travel -z axis: 570 mm travel -x axis: 245 mm spindle bore: 43 mm diameter of quill: 85 mm quill stroke: 120 mm Spindle Speed: 60-6.000 U/min. rapid power traverse in X-and Z direction: 24 m/min total power requirement: 5,5 kW control: MSG-805 V weight of the machine ca.: 3.400 kg dimensions of the machine ca.: 2000x1700x1800 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 800 mm y-travel: 530 mm z-travel: 510 mm Control: MSC 504 Mori Seiki Main spindle:: turning speeds: max. 10.000 min/-1 power capacity - main spindel: 15 / 11 kW tool taper: SK 40 spindle bearing diameter: 70 mm distance spindle /table: 150 - 660 mm work table:: table surface area: 1.100 x 600 mm max. table load: 800 kg T-slots: 6x 18 mm table height over floor: 900 mm turret:: number of toolpositions: 30 pos. tool taper: SK 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 300 mm max. tool weight: 8,0 kg change-time tool to tool: 1,3 sec change-time chip to chip: 4,1 - max. 9,2 sec feeds:: rapid traverse ( X / Y / Z ): 36 / 36 / 20 m/min feed speeds: max. 6.000 mm/min Tipp feed: 1 - 5.000 mm/min total power requirement: 27 kVA weight of the machine ca.: 6,1 t dimensions of the machine ca.: 3,5 x 3,0 x 2,8 m Documents: Chip conveyor: Co ...
x-travel: 800 mm y-travel: 530 mm z-travel: 510 mm Control: MSC 504 Mori Seiki Main spindle:: turning speeds: max. 10.000 min/-1 power capacity - main spindel: 15 / 11 kW tool taper: SK 40 spindle bearing diameter: 70 mm distance spindle /table: 150 - 660 mm work table:: table surface area: 1.100 x 600 mm max. table load: 800 kg T-slots: 6x 18 mm table height over floor: 900 mm turret:: number of toolpositions: 30 pos. tool taper: SK 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 300 mm max. tool weight: 8,0 kg change-time tool to tool: 1,3 sec change-time chip to chip: 4,1 - max. 9,2 sec feeds:: rapid traverse ( X / Y / Z ): 36 / 36 / 20 m/min feed speeds: max. 6.000 mm/min Tipp feed: 1 - 5.000 mm/min total power requirement: 27 kVA weight of the machine ca.: 6,1 t dimensions of the machine ca.: 3,5 x 3,0 x 2,8 m Documents: Chip conveyor: Co ...
turning diameter: 370 mm turning length: 424 mm control: MSX-711-IV Mori Seiki swing diameter: 370 mm X1- Axis: 380 mm X2- Axis: 155 mm Z1- Axis: 460+155 mm Z2- Axis: 610 mm y-axis: +/- 105 mm B - axis: +/- 120 ° bar material dia.: 65 mm speed spindle max.: S1 5.000 / S2 6.000 U/min. spindle bore: S1/S2 65/38 mm : 12000 1/min tool taper: Capto C5 toolpiece magazine: chain magazine: 76 Stück tool turret with 10 work positions: total power requirement: 45 kW weight of the machine ca.: 10,5 t dimensions of the machine ca.: 2,71 x 2,43 x 2,40 m MAPPS control system Renishaw HPRA (manual tool presetter) Blum Laser Control Direct measuring system X,Y,Z,B Collet chuck SMW Autoblok KSZ-MB-040-Z140 Workpiece conveyor belt Bar feeder Breuning Irco ILS-RBK-10012 Knoll band filter KF10/500 / IKZ with milling spindle 7 stages up to 70 bar Chip conveyor ConSep 2000 The data for this ad was create ...
turning diameter: 200 mm turning length: 393 mm control: MSX 853 weight of the machine ca.: 3,5 t total power requirement: kW dimensions of the machine ca.: m MSX 853 cnc control 3-jaw chuck diameter 210mm 12-fold revolver C-axis driven tools tail stock coolant device chip conveyor Technische Daten: / technical details Drehdurchmesser / turning diameter 200 mm Drehlänge / turning lenght 393 mm X-Weg / X-travel 160 mm Z-Weg / Z-travel 450 mm max. Drehzahl Spindel / max. spindle speed 50-3000 UpM /rpm Eilgang X/Z / rapid feed X/Z 24/30 Anzahl der Revolverplätze / number of tool places 12 max. Stangendurchmesser / max. bar diameter 51 mm Antriebsleistung Spindel / drive capacity spindle 13,5 kW Gewicht ca. / weight ca. 3500 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are n ...
turning diameter: max. 356 mm turning length: 705 mm control: MSX 850 III MAPPS Mitsubishi greates pass round over bed: 923,8 mm Swing dia. over traverse guideway: 755 mm standard turning dia.: 275 mm Main spindle:: max. spindle speed: 4.000 min/-1 power capacity - main spindel: 18,5 / 15 kW spindle nose: JIS A2-8 spindle bearing diameter: 140 mm spindle bore: 91 mm max. bar capacity: 80 mm chucking diameter: 305 mm C-Axis: 0,001 ° Subspindle:: Spindle speed range subspindle: max. 6.000 min/-1 power capacity - Sub spindle: 11 / 7,5 kW spindle nose: JIS A2-5 spindle bearing diameter: 85 mm spindle bore: 43 mm chucking diameter: 210 mm C-Axis: 0,001 ° turret:: number of toolpositions: 12 pos. Number of driven toolspositions: 12 pos. Shank diameter: 26 mm Drill shank diameter: 50 mm Spindle speed - driven tool stations: max. 6.000 min -1 turret change time: 0,25 sec. axis stroke:: x-a ...
x-travel: 560 mm y-travel: 510 mm z-travel: 510 mm Control: MSC 502 distance spindle center to table: 50 - 650 mm distance Spindlenose and center of table: 100 - 610 mm Main spindle:: turning speed range - main spindle: max. 12.000 min/-1 power capacity - main spindel: 22 / 18,5 kW tool taper: MAS BT-40 spindle bearing diameter: 70 mm pallet changer:: numbers of pallets: 2 size of pallet: 400 x 400 mm max. workpiecediameter: 580 mm max. workpiece height: 650 mm b - axis: switching time: 90°: 2,5 sec change time of pallets: 6,0 sec Tool-Presetter:: number of toolpositions: 60 pos. tool taper: MAS BT-40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 300 mm max. tool weight: 8 kg change-time tool to tool: 1,5 sec change-time chip to chip: 3,7 sec feeds:: rapid traverse ( X / Y / Z ): 32 m/min feed speeds: 1 - 24.000 mm/min Tipp feed: 0 - 1.260 mm/m ...
diámetro de torneado: 430 mm, longitud de giro: 519-525 mm. control: Mori seiki MSX-805 eje x: 230 mmz. Eje: 520 mm, consumo total de potencia: kWpeso de la máquina, aprox. 4100 kg. Dimensiones de la máquina, aprox. m. Los datos de este anuncio se crearon con ModulMWS, la solución de software de LogoTech oHG.
x-travel: 1.020 mm y-travel: 510 mm z-travel: 510 mm control: MSC 501 Fanuc table surface area: (APC) 1.200 x 480 mm max. table load: (APC) 550 kg Main spindle:: turning speed range - milling: 10.000 U/min power capacity - milling spindle: 22 / 18,5 kW tool taper: BT 40 Tool-Presetter:: number of toolpositions: 30 pos. tool taper: BT 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 300 mm max. tool weight: 8 kg rapid traverse: 32 m/min feed: 1 ~ 16.000 mm/min Tipp feed: 0 ~ 1.260 mm/min spindle bearing diameter: 85 mm total power requirement: 59,5 kVA weight of the machine ca.: 6,9 t dimensions of the machine ca.: 3,9 x 2,7 x 2,9 m Documents: Chip conveyor: 2x Coolantsystem: high pressure coolant: through spindle coolant: Signal-Light: pallet changer: 2 pos. CNC - Machining Center - Vertical MORI SEIKI - SV 500 B/40 - Clamping devices are NOT ...
Modelo: Mori Seiki MV-653/50 (Año 2000) Recorridos (X/Y/Z): 1530 x 660 x 650 mm (60 pulgadas x 26 pulgadas x 25,6 pulgadas) Tamaño de la mesa: 1700 x 660 mm (67 pulgadas x 26 pulgadas) Estrecha del husillo: CAT 50 / BT 50 Velocidad del husillo: 6.000 RPM (Alto par) Potencia del motor: 22 kW (30 CV) Capacidad ATC: 30 estaciones Peso de la máquina: 16.000 kg (35.270 lbs) Encuentra más aquí - / Contacta con nosotros en -
diámetro de torneado: 370 mm. Longitud de tornado: 424 mm. control: Fanuc consumo total de potencia: kWpeso de la máquina, aprox. dimensiones de la máquina aprox. m. Los datos de este anuncio se crearon con ModulMWS, la solución de software de LogoTech oHG.
Diámetro de giro: 190 mm Longitud de giro: 235 mm Control: FANUC/Mori MSX 501 Rango de velocidad de giro del eje: 50-5000 U/cabeza de torreta: 2x 16 peso de la máquina aprox: 7,5 ejes TY y B- Varios. accesoriosmás detalles sobre www.marcels-maschinen.ch Los datos de este anuncio se crearon con ModulMWS, la solución de software de LogoTech oHG.
Diámetro de giro: 190 mm Longitud de giro: 235 mm Control: FANUC/Mori MSX 501 Rango de velocidad de giro del eje: 50-5000 U/cabeza de torreta: 2x 16 peso de la máquina aprox: 7,5 ejes TY y B- Varios. accesoriosmás detalles sobre www.marcels-maschinen.ch Los datos de este anuncio se crearon con ModulMWS, la solución de software de LogoTech oHG.
diámetro de torneado: - mmLongitud de tornado: - mmcontrol: - : ohne Gewähr requisito total de potencia: - kWweight de la máquina aprox.: 4 tdimensiones de la máquina ca.: - m Los datos de este anuncio se crearon con ModulMWS, la solución de software de LogoTech oHG.
turning diameter: 660/275 mm turning length: 1498 mm control: Fanuc/Mori Seiki MSX 701 total power requirement: 90 kVA weight of the machine ca.: 26,6 t dimensions of the machine ca.: 5301 x 2997 x 2788 mm 9-axis CNC turning and milling centre Fanuc MSX-701 CNC control Milling spindle at top (B axis), as full 4th axis, positioning 0.0001 deg. 40-position tool magazine 10-position turret at bottom, all positions driven 2 x 3-jaw quick-change chuck KNCS-N 315/91 KNOLL high-pressure coolant system, pressure setting 12/25/35/45/55/62 and 72 bar, with maintenance-free rotary filter system Chip conveyor Drain system for main spindle chuck (controlled via M function) Drain system for tool cutting edge (controlled via M function) Coolant gun incl. accessories Oil mist extraction Direct measuring system X1, X2, Y-axis Bar loader interface Double foot switch for both spindles Island ...
turning diameter: 460 mm turning length: 795 mm control: MORI SEIKI M730 BM Swing diameter face slide: 590/360 mm spindle passage: 80 mm Traverse X/Z:: 260/795 mm Number of working hours: 19.552 h Cutting time: 10.704 h spindle drive: 18,5 kW total power requirement: 40 kVA weight of the machine ca.: 6,4 t dimensions of the machine ca.: 3.994 x 3.056 x 2.187 m Chip chuck Ø250 mm. Chuck sub-spindle Ø170 mm. Holder HAINBUCH chip conveyor suction Bar feeder Hydrafeed Multiservo mod MSV max. bar length 1,600 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 600 mm y-travel: 530 mm z-travel: 510 mm Control: M 730 BM MAPPS IV Main spindle:: max. spindle speed: 10.000 min/-1 power capacity - main spindel: 15 / 11 kW tool taper: SK 40 transmission ratio: 1 spindle diameter in front bearing: 80 mm work table:: table surface area: 900 x 600 mm max. table load: 800 kg T-slots: 6x 18 x 100 mm distance spindle /table: 150 - 660 mm Tool-Presetter:: number of toolpositions: 30 pos. tool taper: SK 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 150 mm max. tool length: 300 mm max. tool weight: 8,0 kg change-time tool to tool: ca. 1,3 sec change-time chip to chip: ca. 3,45 sec feeds:: rapid traverse ( X / Y / Z ): 30 m/min feed speeds: 1 - 30.000 mm/min Tipp feed: 0 - 5.000 : 20 mm/min total power requirement: 30 kVA weight of the machine ca.: 6,0 t dimensions of the machine ca.: 4,5 x 3,5 x 2,7 m Documents: Chip conveyor: ...
This 5-axis MORI SEIKI ZT1500YB was manufactured in 2005. It features a maximum turning diameter of 190 mm and a maximum turning length of 235 mm. The machine includes a robust turret with 12 stations and a rapid traverse speed of up to 24,000 mm/min. If you are looking to get high-quality turning capabilities, consider the MORI SEIKI ZT1500YB horizontal turning machine we have for sale. Contact us for further details.
Este MORI SEIKI RL2500 de 4 ejes fue fabricado en 2003. Cuenta con un diámetro máximo de giro de 400 mm e incluye dos torretas con 12 estaciones cada una, proporcionando capacidades de mecanizado eficientes. La máquina está equipada con un control Mori Seiki MAPPS MSX-501 y tiene una velocidad de eje de 3500 rpm. Si buscas capacidades de torneado de alta calidad, considera la máquina de torneado multihusillo MORI SEIKI RL2500 que tenemos a la venta. Contáctanos para más detalles.
CONTROLS CNC controls MORI SEIKI MSG-501 WORKING RANGE -CUBIC- number of processing axes (excl parallel axes): 4 X-axis travel: 1300 mm Y-axis travel: 1200 mm Z-axis travel: 1100 mm TABLE table surface (left-right): 800 mm table surface (front-back): 800 mm workpiece load (max): 2000 kg SPINDLE / HEAD spindle revolutions (max): 0 /min spindle revolutions (max): 6000 /min tool fixture: ISO BT 50 AXIS DRIVES rapid traverse: 42000 mm/min TOOL MAGAZINE number of positions: 60 ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS space requirements -left/right-: 7400 mm space requirements -front/back-: 4300 mm total height: 3750 mm total weight approx.: 23500 kg ATTACHMENTS chip conveyor: yes coolant unit: yes band filtration unit: yes through spindle coolant att ...
CONTROLS CNC controls MITSUBISHI M720BM BASIC FUNCTIONS number of spindles: 2 number of turrets: 1 live positions: yes number of c-axes: 2 WORKING RANGE TURNING swing diameter (max): 700 mm turning diameter (max): 350 mm MAIN SPINDLE spindle revolutions (max): 4000 /min spindle bore diameter: 90 mm c-axis: yes X/Z SLIDE - rotation speeds (max): 6000 /min TOOL MAGAZINE number of positions: 24 ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS total weight approx.: 7500 kg ATTACHMENTS (TURNING) chip conveyor: yes coolant unit: yes hydraulic system: yes European CE standards: yes Machine in a good condition The spindle guides need to be replaced. Machine equipment (1500.- CHF (below)): - 1x double face and longitudinal turning tool holder - 3x face and longitudinal turnin ...
