MAYER maquina usada para la venta

Veneer vio a Fabr. Mayer con longitud de corte de 3500 mm, con unidad de planificación para re-enforeconclusión con parada de ancho trasero

1 Sierra de placa de segunda mano Mfc.: Modelo Mayer: PS3 E Construido: 1989 – nuevo panel eléctrico en 2010 Dimensiones de la placa: Longitud: 3100 mm Espesor: 70 mm Potencia del motor de sierra: 11 kW, 2890 RPM Dia.de la hoja: 350 mm Tensión de la hoja: Hidráulica Huella: 5700 x 7500 mm –W x L Lubricación: Micro-spray ACCU-LUBE

<br>8-30 mm<br><br>Still in operation: Yes<br>Available: immediately

8-30 mm Aún está en funcionamiento: Sí Disponible: inmediatamente

CONTROLS   CNC controls

Yarn machine Manufacturer Mayer Model 32-20 3 İPLİK Year 2003

Description: - Horizontal panel saw with lifting table - Serial number 0159-00-5823 - Total installed power 30 KW - Cutting width 5200 mm - Cutting height approx. 120 mm - 8 grippers (for panel bundles and thin panels), 3 pushers - Main saw blade: max. diameter 450 mm and motor 18 KW - Scoring saw blade: max. diameter 150 mm and motor 2.20 KW - Feed speed of the saw carriage: 5 - 50 m/min - Return speed of the saw carriage: 70 m/min - Feed speed of the pushers: 30 m/min - Return speed of the pushers: 60 m/min - Front air tables: one with the dimensions 2500 x 600 mm and 4 with the dimensions 2000 x 600 mm - Max. Dimensions of the panels on the platform approx. 5200 x 2400 mm - Max. Weight carried by the lift table 6000 kg - Loading rollers for the lift table are included in the scope of delivery - MAYER PC 5400 control system - ARDIS cutting optimizer - Label printer Approx. Onsite Dimen ...

Year of construction 1999 96 systems No. uiglenia 28 2592 needles Cylinder diameter 30 Single-bearing computerized machine. SFE yarn feeding and MPF positive feeders. Equipped with MER type feeders - for lycra feeding . Additional machine computer equipment : - Power supply board - Several Mag 68k boards for controlling selector selection in individual systems. Additional locks - possibility of acquiring on needles - can be a 3-way machine. Possibility to produce MESZ knitted fabrics. Additional shapers. Operating instructions. Price with loading.

Description: Machine number: 19805 Table diameter: 450 mm Approx. Onsite Dimension. (l x w x h): 450 x 450 x 1,200 mm, weight approx.: 90 kg

10gg 34 2008 year Mayer Relanit 1.6 R (Long Stripe Machine) Price for both machines!

MAYER large area saw Motor of the main saw unit 9 kW Max size of cut board 3200 x 2400 mm Cut materials: all types of difficult-to-machine plastics and all types of wood and chipboard. With heavy and solid saws, Mayer relies on consistently high quality and advanced machine design. The overall concept is also convincing: The heavy construction with pressure rails and the steel material shifter, the simple operation in one-handed operation guarantee high performance and accuracy in a rational blank of board material. The saw carriage with the main and pre-cutting unit with a cutting height of up to 100 mm moves on a hardened and ground system guided along circular profiles. The automatic adjustment of the cutting height guarantees the optimal cutting angle of the blade into the material. The pressure beam opens depending on the height of the material, which reduces the time requi ...
