프레스 사용 판매를 위해 (1,807)

수용량, 톤: 800 스트로크, mm : 320 스트로크/분: 20 폐쇄 높이, mm : 900 침대에서 램 조정 스트로크, mm : 320 침대 크기, mm: 2500x1600 주요 드라이브 모터 힘, kW: 75 전체 치수, mm : 4220x3500x8356 무게, 톤: 96,6

(측면 전면 이동 테이블) 명목상 힘: 1000 톤 슬라이드 스트로크: 400 mm 1분당 연속 슬라이드 스트로크: 20 1분당 단일 슬라이드 스트로크: 16 폐쇄 높이: 1060 mm 슬라이드 조정: 320 mm 테이블 치수: 3150x1800 mm 슬라이드 어두움, 앞뒤: 1700 mm 창 H 1500 x W 1900 mm 테이블에 있는 수력 공압 쿠션 P = 0.42 MPa에서의 클램핑력 (P = 4.2 kg / cm2), kN 2000 토출력 P = 0.45 MPa (P = 4.5 kg / cm2), kN 200 메인 드라이브 전기 모터 출력: 132kW 치수: 5150x4700x11400 H 바닥7830 mm 무게: 193 �

장비 설명 사용된 간접 압출 프레스 • 브랜드 / 모델: SMS Hasenclever 28 / 31.5 MN "McKechinstrang" • 타입: 비철 빌렛을 위한 수평 간접 압출 시스템 • 드라이브: 유압 보조 장치가 있는 기계식 본체 • 원산지: 독일 • 현재 상태: 해체 및 배송 가능 • 일련 번호 / 제조 연도: [확정 예정] 2. 중요한 기술 명세 매개 변수 값 메인 피스톤 힘 25.07 MN 커플링을 사용한 총 가압력 31.23 MN 최대 스트로크 3,070mm 작동 스트로크 2,825 mm 램 속도: 28MN, 0–64mm/sec 램 속도: 31.5MN, 0–57mm/sec 빌릿 직경 범위 230–355 mm 빌릿 길이 (추위) 320–1,320 mm 수신기 난방 시스템 저항; 최대 63 kW / 375 C 전단력 0.64 MN 프로파일 이젝터 힘 0.31 MN 작동 차동 실린더 280/200 3. 포함된 구성 요소 • 통합 가열 기능 ...

6500ton Open Die Forging Press HJ / 서남 (한국) 디자인: 동유럽 기업 설치: 2006/2008 프레스 유형 : 4 열 푸시 다운 오일 유압 시스템 공칭 하중 (320 bar의 정적 작동 압력) : 5,000 톤 업셋 포스 (420 bar의 정적 작동 압력) : 6500 톤 일광: 5,200 mm 움직일 수 있는 크로스 헤드의 스트로크: 2,700 mm 메인 램 직경 (중앙 실린더) : 1 세트 - ¢ 950 mm 사이드 램 직경 (사이드 실린더) : 2 세트 - ¢ 750 mm 리턴 실린더 램 직경: 2세트 - ¢300 mm 이동대 폭 2,600×길이 6,600 mm 이동 테이블 스트로크 (중앙에서 양측까지 2,750mm) : 5,500 mm 접근 속도: 300mm/초 메인 실린더 단조 속도 (2,200 tons/ 320 bar) : 163 mm/sec 전실린더 단조속도 (5,000 tons/ 320 bar) : 73 mm/sec 업셋팅 단조 속도 (6,500 tons/ 420 bar): 10 mm/sec 복귀 � ...

VORONEZH K8544 열간 단조 프레스 연도 : 1980 / 2008 정밀 검사 및 설치 힘 : 2500ton 램 스트로크 : 350 mm 램 크기 : 1120X1070 mm 테이블 전체 크기 : 1400X1200 mm 연속 모드에서 스트로크 수 : 60 수동 모드에서 스트로크 수 : 26 짊어진 높이 : 890 mm 상부 녹아웃 스트로크 : 60 mm 하부 녹아웃의 스토로크 : 70 mm 주모터 : 132KW (HYUDAI HEAVY Y2012로 변경) 프레스 전체 치수 : 5380X4680X6400 mm 2007년에 새로운 유압 받침대 조건 : 아주 좋은 근무 조건 트리밍 프레스 사용 가능

2000 톤 스미토모 열간 단조 프레스 라인 연도 2006 스트로크 350mm(13.78인치) 분당 스트로크 수 75 닫힌 높이 850mm(33.47인치) 슬라이드 애드j. 7mm(.27인치) 램 크기 1200 mm LR X 1300 mm FB 침대 크기: 1320 mm LR X 1300 mm FB 4 단계 이송 시스템 슬라이드 녹아웃 하단 녹아웃 스크랩 시스템 듀얼 다이 체인저 엑스트라 다이 슈즈 빌렛 히터 및 빌렛 톱도 사용 가능 이 라인은 HONDA에서 변속기 기어를 만드는 데 사용되었으며, 빌릿을 사용하여 크기로 자르고 1300C로 가열한 다음 프레스가 4번 칩니다. 불량 부품과 불량 부품을 결정할 수 있고, 불량 부품은 담금질 탱크로 보내지고, 좋은 부품은 냉각 컨베이어로 보내져 마지막에 손으로 부품을 픽업할 수 있습니다. 전체 시스템은 한 명의 운� ...

(2) 아사히 THP500-6 수평 단조 프레스 (표제 기계) 년도 : 2008 첫 번째 스트로크: 24 mm 두 번째 스트로크: 50mm 킥아웃 파워: 150 kN 개방 높이: 625 mm 닫힌 높이: 425 mm 다이 (가로xL): 500x490 mm 펀치 (가로xL): 250x350 mm 램 스트로크: 200 mm 단조력: 5000 kN 사이클링 시간 : 6.5 초 크랭크 속도: 60 RPM 기계 무게: 28 t

pressure:160 tdistance between columns:1360 mmstroke:300 mmDistance table/ram, max. stroke up, adjustment up:620 mmtable surface area:1300 x 900 mmtable height over floor:950 mmside window:640 mmram surface:1300 x 900 mmpower requirement:45,0 kWweight:16,0 tDimensions (WxDxH):2,5 x 2,1 x 4,1 mcutting impact cushioning:hydraulic

pressure:600 tdistance between columns:3640 mmstroke:350 mmno. of strokes:11 - 44 /minDistance table/ram, max. stroke up, adjustment up:1550 mmtable surface area:3600 x 2500 mmsliding table:3600 x 2500 mmram surface:3600 x 2500 mmSide window:2200 mmram adjustment:400 mmmaterial width coil line:500 - 1950 mmMaterial thickness at 1200 mm material width:0,6 - 2,5 mmMaterial thickness at 1850 mm material width:0,6 - 2,0 mmMaterial thickness at 1950 mm material width:0,6 - 1,75 mmCoil weight:35,0 tcoil internal diameter:610 mmcoil external diameter:900 - 1900 mmno. of straightening rolls:13 straightening roll diameter:50 mmStack height:400 mmstacking dimensions - station 1+2 (L x W):150-2000 x 250-2000 mmstations:2 power requirement:112,0 + 35,0 kWWeight:390,0 tDimensions (WxDxH):7,3 x 5,1 x 15,0 mHeight above floor:9,1 mHeight below floor:5,9 mclutch-/ brake combination:pneumatic overload pr ...

pressure:315 tdistance between columns:1290 mmstroke:700 mmdistance table/ram, max. stroke up, adjustment up:950 mmtable surface area:1250 x 1100 mmpressure of drawing cushion in table:125 tstroke of drawing cushion in table:300 mmdie cushion area:900 x 900 mmCapacity of ejector in ram:20 tStroke of ejector in ram:250 mmtable height over floor:800 mmram surface:1250 x 1100 mmoil volume:1200 lpower requirement:40,0 kWweight:22,0 tdimensions (WxDxH):2,6 x 1,6 x 5,2 mheight over floor:4,05 mdrawing cushion in table:hydraulic ejector in ram:hydraulic cutting impact cushioning:hydraulic

Pressure:40 tthroat:330 mmstroke:250 mmdistance table/ram, max. stroke up, adjustment up:450 mmtable surface area:800 x 500 mmhole in the table:100 mmtable height over floor:900 mmram surface:100 mmSpeed down:406 mm/sSpeed up:393 mm/sWorking speed:14 mm/soil volume:350 lpower requirement:7,5 kWweight:4,6 tdimensions (WxDxH):1,3 x 2,3 x 3,4 mGerman Safety: permitted for manual loading:CE-sign depth stop:mechanical

Max plate thickness: 2.5mm. Max working width: 1020mm. In working order. Auction-ID: A3-46156-6141

pressure:40 tthroat:300 mmstroke:630 mmDistance table/ram, stroke up:900 mmTable surface area:620 x 520 mmHole in the table:150 mmtable height over floor:600 mmRam surface:150 mmPower capacity:15,0 kWWeight:4,5 tDimensions (WxDxH):1,0 x 1,9 x 3,0 mGerman Safety: permitted for manual loading:CE-sign

pressure:400 tdistance between columns:1060 mmstroke:450 mmno. of strokes:15 - 30 /mindistance table/ram, max. stroke up, adjustment up:1160 mmtable surface area:1000 x 700 mmcapacity of ejector in table:2 x 16 tejector stroke of ejector in table:125 mmDie cushion pressure in table:120 tDie cushion stroke in table:2 mmcapacity of ejector in ram:2 x 4 tstroke of ejector in ram:100 mmram surface:1000 x 700 mmcolumn travel -side:630 mmpower capacity:55,0 kWweight:50,0 tdie cushion in table:2. station

no. of strokes:150 /minimpact energy:420 kJdistance lower die block / ram gudeway:435 mmThroat:425 mmsteel forging - rectangular up to:110 mmsteel forging - diameter up to:125 mmpower requirement:22,0 kWweight of hammer:3,9 tweight of anvil:3,0 tram hammer weight:200 kgweight:6,9 tdimensions (WxDxH):1,1 x 2,3 x 2,4 m

Pressure:080 tthroat:345 mmstroke:20 - 160 mmno. of strokes:65 /mindistance table/ram, max. stroke up, adjustment up:495 mmtable surface area:920 x 610 mmtable height over floor:800 mmHole in the table:280 mmpassage to the back:670 mmram surface:650 x 400 mmram adjustment:50 mmpower capacity:10,0 kWweight:7,7 tDimensions (WxDxH):1,5 x 2,2 x 3,15 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:hydraulic ram adjustment:motoric

pressure:800 tdistance between columns:1050 mmstroke:200 mmno. of strokes:8 - 25 /mindistance table/ram, max. stroke up, adjustment up:1300 mmSide window:550 mmtable surface area:1030 x 900 mmCapacity of ejector in table:15 tStroke of ejector in table:85 mmram surface:1040 x 800 mmram adjustment:120 mmCapacity of ejector in ram:12 tejector stroke in ram :80 mmpower requirement:36,0 - 112,6 kWweight:65,0 tDimensions (WxDxH):3,0 x 3,1 x 6,07 mejector in table:hydraulic ejector in ram:hydraulic

pressure:315 tdistance between columns:2350 mmdistance table/ram, max. stroke up, adjustment up:1200 mmdistance between cutting impact cushioning:1600 mmDistance table/ram, stroke up:1200 mmstroke:800 mmtable surface area:2060 x 1260 mmtable height over floor:750 mmDie cushion pressure in table:100 tDie cushion stroke in table:400 mmdie cushion area:1250 x 1000 mmside window:780 mmram surface:2200 x 1500 mmCapacity of ejector in ram:63 tspeed down:500 mm/sspeed up:310 / 410 mm/sworking speed:20 - 73 mm/squantity of oil:3900 lpower requirement:80,0 + 45,0 kWweight:55,0 tDimensions (WxDxH):4,6 x 2,7 x 7,2 mHeight above floor:6,0 mHeight below floor:1,2 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 die cushion in table:hydraulic ejector in ram:hydraulic ram interlocking:hydraulic cutting impact absorption:hydraulic

pressure:160 tthroat:450 mmstroke:300 mmdistance table/ram, max. stroke up, adjustment up:580 mmtable surface area:1000 x 1000 mmdie cushion capacity:20 tdie cushion stroke:300 mmram surface:700 x 750 mmfeed down:400 mm/sfeed up:400 mm/stable height over floor:1350 mmdie cushion area:Ø 350 mmpower capacity:55 + 11 kWweight:19,5 tDimensions (WxDxH):1,5 x 3,5 x 4,6 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulisch depth stop:mechanisch

equipped with adjustable shape stamp Auction-ID: A1-49836-9

Lot of bending tools, incl. metal shelf, different sizes and lengths for more details see photos Auction-ID: A7-49942-1059

Hand Pesse (Schmidt) + Screw Feeder NJR-23 (OHTAKE) and Accessories , Dimensions: 250x80x70 , 130x80x50 , 280x130x140 , for more details see photos of the nameplates Auction-ID: A7-49942-1101

pressure:063 tthroat:250 mmstroke:8 - 100 mmno. of strokes:56 / 84 /mindistance table/ram, max. stroke up, adjustment up:415 mmtable surface area:710 x 500 mmhole in the table:320 mmtable height over floor:800 mmpassage to the back:320 mmram surface:450 x 280 mmram adjustment:63 mmweight:4,1 tdimensions (W x D x H):1,35 x 2,0 x 2,6 moverload protection in ram:mechanical

pressure:200 tdistance between columns:2100 mmstroke:550 mmDistance table/ram, stroke up:1800 mmtable surface area:2000 x 2800 mmtable height over floor:760 mmram surface:2000 x 2000 mmSide window:2000 mmfeed down:400 mm/spower requirement:51,0 kWweight:33,0 tdimensions (WxDxH):3,25 x 3,5 x 5,4 mHeight above floor:5,4 mfoundation pit:not necessary

pressure:200 tdistance between columns:2100 mmstroke:550 mmDistance table/ram, stroke up:1800 mmtable surface area:2000 x 2800 mmtable height over floor:760 mmram surface:2000 x 2000 mmSide window:2000 mmfeed down:400 mm/spower requirement:52,0 kWweight:33,0 tDimensions (WxDxH):3,25 x 3,5 x 5,4 mHeight above floor:5,4 mfoundation pit:not necessary

pressure:400 tdistance between columns:3250 mmdistance table/ram, max. stroke up, adjustment up:1000 mmstroke:800 mmtable surface area:3250 x 1400 mmtable height over floor:1250 mmdie cushion capacity:170 tdie cushion stroke:200 mmdie cushion area:1800 x 1000 mmdistance between cutting impact cushioning:2610 mmside window:800 mmram surface:3250 x 1400 mmreturn capacity:51 tspeed down:300 mm/sspeed up:300 mm/sworking speed:16 - 33 mm/squantity of oil:2900 lpower requirement:100,0 kWweight:70,0 tDimensions (WxDxH):4,9 x 3,1 x 7,6 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 cutting impact absorption:hydraulic

pressure:400 tdistance between columns:1250 mmstroke:250 fix mmno. of strokes:45 /mindistance table/ram, max. stroke up, adjustment up:825 mmtable surface area:1000 x 900 mmcolumn travel -side:400 x 700 mmram surface:1000 x 900 mmram adjustment:100 mmcapacity of ejector in table:40 tejector stroke:160 mmpower capacity:270,0 kWweight:44,0 tDimensions (WxDxH):2,4 x 3,6 x 7,2 mheight over floor:6,4 m

pressure:125 tstroke:25 fix mmno. of strokes:70 - 700 /mindistance between columns:1150 mmdistance table/ram, max. stroke up, adjustment up:400 mmtable surface area:1150 x 1000 mmhole in the table:900 x 220 mmside window:650 mmram surface:990 x 850 mmram adjustment:60 mmmaterial width:250 mmmaterial thickness:2,5 mmpower requirement:46,5 kWweight:29,5 troll feed:mechanical, Schuler, WK 8-250

pressure:250 ttable length:4000 mmtable width:3000 mmControls:SIEMENS SIMATIC C7 PRESS DESIGN:. - frame design : 4 column :. - moving bolster : yes :. PRESS FORCES:. - total force (nominal):250 toPRESS TABLE:. - clamping surface (left-right):4000 mm - clamping surface (front-back):3000 mm - tool weight max.:100000 kg - number of T-slots:12 - distance between T-slots:375 mm - height above floor level:390 mmRAM:. - clamping surface (left-right):4000 mm - clamping surface (front-back):3000 mm - number of T-slots:12 - distance between T-slots:375 mm - stroke:2900 mm - tool weight max.:50000 kgRAM (HYDR. PRESS):. - number of main-cylinders:1 - approximation velocity max.:180 mm/s - working velocity max.:50 mm/s - restoring force of ram:95 toTOOL ASSEMBLY DIMENSIONS:. - distance table - ram max.:2750 mm - distance between columns (H-frame):4100 mm - Free passage ...

Pressure:080 tthroat:380 mmstroke:8 - 112 mmno. of strokes:60 /mindistance table/ram, max. stroke up, adjustment up:472 mmtable surface area:840 x 610 mmtable height over floor:800 mmpassage to the back:520 mmram surface:650 x 400 mmram adjustment:70 mmpower capacity:7,5 kWweight:6,9 tDimensions (WxDxH):1,1 x 2,15 x 3,2 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:mechanical ram counterbalance:pneumatic clutch-/ brake combination:pneumatic
