KONDIA maquina usada para la venta

Detalles de la máquina Número de stock 1105-03741 Centro de mecanizado tipo máquina - vertical Hacer KONDIA Tipo B 1050 Año de construcción 1999 Tipo de control CNC Ubicación de almacenamiento HAGUENAU País de origen españa Plazo de entrega INMEDIATAMENTE Base de carga EX WORK Técnicas Recorrido - x 1000 mm Recorrido - y 600 mm Recorrido - z 520 mm Información Control: Heidenhain TNC 410 CA Dimensiones de la mesa: 1.120 x 600 mm Portaherramientas: SK 40 (DIN69871) Revista de herramientas: 22 herramientas Potencia motriz: 7,5 kW Equipamiento: , Chip conveyor, M, Handwheel HR 410,

3-axis milling machine Kondia B-1050 Manufacturer: Kondia Model: B-1050 Type of Machine: Milling Machine Total Power Installed: 19 kW Year of Manufacture: 2000 Weight: 5100 kg Voltage: 380 V / 50 Hz Air Pressure Requirement: 6 BAR Travel 500 x 1000 Control : Heidenhain TNC 410 Find more here - / Contact us at -

This 3-axis KONDIA B-1050 vertical machining centre was manufactured in 2000. It features a robust table with dimensions of 1200 x 500 mm and can handle a maximum weight of 450 kgs. Equipped with a high-speed spindle up to 6,000 r.p.m. and a 22-tool automatic changer, it ensures efficient operation. Rapid feeds reach up to 25,000 mm/min on X-Y axes. Ideal for precision machining, buy this KONDia B-1050 vertical machining centre. Contact us for further details regarding this vertical machining centre.

Used Kondia b - 1050 Machining center - vertical with Selca S4045DH in excellent condition. Machinery with chip evacuator, working, 12,000 rpm spindle, 22 position tool changer. Table size 1000x500x610

CNC: Heidenhnain TNC 426 X-axis travel: 2000 mm Y-axis travel: 1000 mm Z-axis travel: 510 mm Table / pallet dimensions: 2000 x 1000 mm x mm Number of tools: 40 Spindle taper: ISO 40 Power: 7.5 kW Cooling through the spindle Chip conveyor - Distance between spindle nose and table top mm. 800 - Load capacity on the table Kg. 2000 - High pressure system through the spindle 20 bar - RPM 4000 - Rapid X / Y axes mt / min. 24 - Rapid Z axis mt / min. 20 - Remote handwheel HR 410 overall dimensions: 5130x3570 Net weight 12.000 kg

SEASKA S-600 5-axis machining center. Year 2004 Axis X 660,0 Axis Y 400,0 Axis Z 510,0

Used machining center Make: KONDIA Model: B700 CNC: Fagor 8025 Table dimensions: 860x400mm Travels (X, Y, Z): 700, 410, 510mm Cone: BT40/ISO Spindle Rpm: 8.000 Umbrella type tool changer - 20 Tools Includes 4th spindle.

It has 4th axis controlled by TSUDAKOMA model RN-200B cnc. Table dimensions: 1200x400mm Travels X, Y, Z: 600x400x510mm Rapid traverse in XY axes: 36.000mm/min. Rapid traverse in Z axis: 30.000 mm/min. Working feed rate: 5.000 mm / min. Head: ISO 40 Speed range: 15.000 rpm Maximum distance from spindle to table: 660 mm Automatic tool changer: No. of tools: 20 Type of selection: RANDOM Maximum tool length: 225 mm Maximum tool weight: 6 kg. Accuracy: - Positioning accuracy: 0.01 mm. - Repeatability accuracy: 0.005mm - Resolution: 0.001mm Has chip extractor. Includes vice. Includes ISO 40 tooling.

Table dimensions: 1200x500 mm Travel (X, Y, Z): 1000x500x510mm Maximum weight on the table: 500 kg Fast feed in XY axis: 25,000 mm / min. Fast feed in Z axis: 20,000 mm / min. Working feed: 5,000 mm/min. Head: ISO 40 Speed ​​range: 100-6,000 rpm Maximum distance from shaft to table: 650 mm Automatic tool changer: 18 Selection type: sequential Maximum tool diameter: 85mm (between adjacent tools) Maximum tool diameter: 135 mm (among alternative tools) Maximum tool length: 250mm Maximum tool weight: 6 kg Tool change time: 6 sec.

x-travel: 600 mm y-travel: 350 mm z-travel: 140 mm table surface area: 700 x 300 mm spindle taper ISO: 40 spindle turning speed range: 100 - 4000 U/min distance spindle center to column: 395 mm distance spindle nose and table: min. 170 -max. 550 mm control: TNC 407 milling feeds: 3 + 2000 mm/min rapid traverse: 5000 mm/min spindle drive: 5,5 kW total power requirement: 9 kW weight of the machine ca.: 1,9 t dimensions of the machine ca.: 2,5 x 1,8 x 2,2 m • control HEIDENHAIN TNC 407, The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
