旋盤 中古 販売のため (3,052)

2×2×2m 650 C と 1200 C PLC

CNCフラットベッド旋盤Optimumも利用可能です。ベッド /スライド上のスイング直径:280mm/170mm、中心距離:700mm 、スピンドルボア:27mm、速度:4000rpm、伸び幅×/Z:165mm/6 60mm、送り×/z:2m/分/3m/分、工具ステーション数:4、ク� ��ルストローク:85mm。機械寸法 X/Y/Z:約2000mm/750mm/1550mm、重量:約450kg、制御:シーメン� �・シヌメリック。資料はご用意しています。現地で の検査も可能です�

Chuck flange, flange mount, lathe chuck flange, driving flange-Chuck flange: for three-jaw chucks, four-jaw chucks, face plates-Outer: Ø 193 mm-Inside: Ø 80 mm-Hole circle: Ø 105 mm-Dimension: Ø 193 x 75 mm-Weight: 4.1 kg

Change gear, change gears, gear-Number of teeth: 152 pieces-Module: 1.25 mm-for splined shaft: Ø 25 mm

Heavy lathe, turning machine, lathe, center and feed screw lathe, center and feed screw lathe -Manufacturer: Weisser, lead screw lathe type PF200 -Turning length: 1340 mm -Turning Ø over bed: 420 mm -Turning Ø over support: 240 mm -Spindle bore: Ø 41 mm -Spindle speeds: 31.5 - 1400 rpm -Three-jaw chuck: Röhm Ø 250 mm -Accessories: incl., see photos -Tailstock mount: MK4 -Drive motor: 2.5/3.5 kW -Dimensions: 2670/1000/H1230 mm -Weight: 1450 kg

Change gear, change gears, gear-Number of teeth: 141 pieces-Module: 1.25 mm-for splined shaft: Ø 25 mm

Grinding wheel holder, standard flanges, special flanges, grinding wheel flange-Grinding wheel holder: Holder: Ø mm-Mounting: Hole shaft cone Ø 40-48 mm-Type designation: not available-Dimensions total Ø 180 x 85 mm-Weight: 6.8 kg

Grinding wheel holder, standard flanges, special flanges, grinding wheel flange-Grinding wheel holder: Holder: Ø mm-Mounting: Hole shaft cone Ø 38-48 mm-Type designation: not available-Dimensions total Ø 180 x 85 mm-Weight: 7,3 kg

Lathe, turning machine, lead screw lathe, lead screw lathe -Handover: in the current condition as viewed -Condition: Gearbox makes noise (video) -Manufacturer: Colchester, Leadscrew and Feedscrew Lathe Type Triumph 2000 -Turning length: 1300 mm -Turning Ø over bed: 390 mm -Turning Ø over support: 240 mm -Spindle bore: Ø 55 mm -Spindle speeds: 22 - 2000 rpm -Three-jaw chuck: Ø 250 mm -Accessories: Tool holder/tools see photos -Tailstock mount: MK4 -Dimensions: 960/2435/H1640 mm -Weight: 1327 kg

Three-jaw chucks, three-jaw lathe chucks, power chucks-Chuck size: Ø 200 mm-Short taper: 6-Weight: 25 kg

Grinding wheel holder, standard flanges, special flanges, grinding wheel flange-Grinding wheel holder: Holder: Ø 127 mm-Mounting: Hole shaft cone Ø 45-59 mm-Type name: 508x10-100x127 / 508x10-80x127-Dimensions total Ø 190 x 100 mm-Weight: 7.7 kg

Chuck flange, flange holder, lathe chuck flange, driving flange, intermediate flange, lathe chuck face plate, mounting flange -Feed flange: mounting flange -Outside: Ø 160 mm -Recess: Ø 130 mm -Hole: Ø 25 mm -Bolt circle: Ø 139 x 10 mm -Dimensions: Ø 160 x 40 mm -Weight: 2.6 kg

Upper support, upper slide, dovetail guide, tool slide, cross table, spindle drive for upper support -Spindle drive: for upper support -Trapezoidal spindle: Ø 20 mm -Dimensions: see photos -Dimensions total: 450/155/H110 mm -Weight: 5.4 kg

Grinding wheel holder, standard flanges, special flanges, grinding wheel flange-Grinding wheel holder: Holder: Ø mm-Mounting: Hole shaft cone Ø 38-49 mm-Type designation: not available-Dimensions total Ø 180 x 85 mm-Weight: 6.6 kg

Grinding wheel holder, standard flanges, special flanges, grinding wheel flange-Grinding wheel holder: Holder: Ø mm-Mounting: Hole shaft cone Ø 34-43 mm / M50-Type designation: not available-Dimensions total Ø 180 x 80 mm-Weight: 7 kg

Chuck flange, flange mount, chuck flange, drive flange, intermediate flange, chuck faceplate, mounting flange -Muck flange: Mounting flange for three-jaw chucks, four-jaw chucks, faceplates -Outer diameter: 162 mm -Socket: Short cone 5, cone Ø 79 - 82 mm -Bolt circle: Ø 105 x 10 mm -Dimensions: Ø 162 x 25 mm -Weight: 2.4 kg

Chuck flange, flange holder, lathe chuck flange, driving flange, intermediate flange, lathe chuck face plate, mounting flange -Chuck flange for: driving heart, three-jaw chuck, four-jaw chuck, face plate -Outside: Ø 250 mm -Adapter: short cone size 8 (Ø135-139 mm) -Bolt circle: Ø 170 mm -Dimensions: Ø 250 x 175 mm -Weight: 14.1 kg

Heavy-duty lathe, cycle-controlled lathe, lathe, center- and feed-screw lathe, center- and feed-screw lathe, CNC lathe -Control: Monforts Control System MTC K -Machine bed: hardened -Turning length: 1100 mm -Turning Ø over bed: 560 mm -Turning Ø over support: 300 mm -Spindle bore: Ø 60 mm -Spindle speeds: 2 - 2800 rpm -Key bar chuck: Schunk Ø 250 mm -Tailstock mount: MK5 -Drive: 16 kW -Accessories: Multifix tool holder, tools see photos -Dimensions: 1600/2860/H1830 mm -Weight: 3300 kg

Grinding wheel holder, standard flanges, special flanges, grinding wheel flange-Grinding wheel holder: Holder: Ø mm-Mounting: Hole shaft cone Ø 46-59 mm / M50-Type designation: not available-Dimensions total Ø 180 x 80 mm-Weight: 7,1 kg

Bezel, setting stick, lynette -Intermediate plate for: bezel -Prism size: 33/38 mm -Height: 71 mm -Drawings: with the photos -Dimensions: 345/175/H71 mm -Weight: 32 kg

Change gear, change gears, gear-for: heavy-duty lathe Braun Zerbst-Number: 23 pieces change gears-Module: mm-Dimensions: 530/530/H735 mm-Weight: 144 kg

Centering device, centering unit for bending machine, straightening machine, sheet metal straightening machine, strip straightening machine, strip straightening device, sheet metal straightening system, for eccentric press, hydraulic press -Manufacturer: Schied: centering device -Hole distance: 300/90 mm O 13 mm -Dimensions: see photos -Total dimensions: 460/160/H160 mm -Weight: 17.5kg

Grinding wheel holder, standard flanges, special flanges, grinding wheel flange-Grinding wheel holder: Holder: Ø 127 mm-Mounting: Hole shaft cone Ø 45-58 mm-Type designation: 407x10-100x127 015 322 0020-Number: 5x mounting flange available-Price: per piece-Dimensions total Ø 180 x 100 mm Weight: 7.1 kg/piece

Grinding wheel mount, standard flanges, special flanges, grinding wheel flange -Grinding wheel mount: Mounting diameter: Ø 76 mm -Shaft: Perforated shaft cone Ø 45-58 mm -Number: 3x mounting flanges available -Price: per piece -Dimensions: Ø 148 x 55 mm -Weight: 3.9 kg/pc.

Grinding wheel holder, standard flanges, special flanges, grinding wheel flange-Grinding wheel holder: Holder: Ø 127 mm-Mounting: Hole shaft cone Ø 45-58 mm-Type designation: 407x10-100x127 015 322 0020-Quantity: 1x mounting flange available-Dimensions total Ø 180 x 105 mm-Weight: 6.5 kg

Counterholder, counter bearing, bearing block, pillow block, holder for draw and lead screw, draw and lead screw holder, spindle holder-Holder: for pull and lead screw-Dimensions: see photos-Transport dimensions: 160/120/H400 mm-Weight: 14.7 kg

Counterholder, counter bearing, bearing block, pillow block, holder for draw and lead screw, draw and lead screw holder, spindle holder-Holder: for pull and lead screw-Dimensions: see photos-Transport dimensions: 105/155/H450 mm-Weight: 11.3 kg

Upper support, upper slide, dovetail guide, cross table-Tool slide: from automatic lathe SUGA type STS-2-Measurements: see photos-Dimensions: 830/610/H300 mm-Weight: 119 kg

Stop, depth stop, length stop for lathe -Groove opening: 22 mm -Number: 1x keystrokes available -Price: per piece -Dimensions: 130/110/H50 mm -Weight: 2.4 kg

Wedge bar chuck, three-jaw chuck, three-jaw lathe chuck, power chuck -Mouth size: Ø 250 mm -Recess: Ø 230 mm -Bolt circle: Ø 200 mm -Quantity: 2 available -Price: per piece -Weight: 35 kg
