x-travel:630 mm y-travel:630 mm z-travel:500 mm number of spindle speeds:0 - 15000 spindle motor:32 kW size of pallet:500 x 500 mm b-axis:36000 x 0,001 ° no. of workpieces in the magazine:61 Stück tool taper:HSK 63 weight of the machine ca.:15 t Single-Spindle Mechanical processing cylinder head VR6
spindle speed::max. 12000 tool taper:HSK 80 . b-axis:360 x 0,001 ° worktool support (A-axis):+40 / -95 ° weight of the machine ca.:25 500 Kgs. x-travel:800 mm y-travel:700 mm z-travel:630 mm dimensions of the machine ca.:6200 x 3000 x 3200 mm pallet size::500 x 500 mm no. of tools in the magazine:61 Nos. Weight approx.:23,5 t Horizontal Machining Center with CNC Control System SIEMENS 840 C in well maintained condition. Single spindle
x-travel:800 mm y-travel:950 mm z-travel:1020 mm weight of the machine ca.:17 t dimensions of the machine ca.:6 x 3 x 3,2 m Diameter of the table:770 mm max. table load:800 kg tool taper:HSK-A63 max. tool length:465 mm no. of tools in magazin:60 spindle turning speed range:12.000 U/min feed power:8 kN kp power capacity:25/35 kW 5 axis G550-1024 HSK A-63 Grob (Bezeichnung G550-1024) 1 spindle
x-travel:800 mm y-travel:950 mm z-travel:1020 mm control:HEIDENHAIN iTNC 530 table load capacity:800 kg tool taper:HSK 63 turning speeds:16.000 1/min spindle:35 / 25 kW table-size:770 mm max. torque on the spindle:160 / 223 Nm tool change unit:120 (2x60) Pos. weight of the machine ca.:20 t dimensions of the machine ca.:3,3 x 6,15 x 3,2 m 5-axis simultaneously machining center with controlled swivel-rotary table (A/B-axis), milling head horizontal, internal coolant device (10-80bar), oilmist-suction, electromech. tool-length measuring device GROB, chipconveyor, 3D touch probe, KINEMATICOPT, BLUM laser, el. handwheel, hour meter: approx. 82.000 h "machine on", approx. 48.800 h "spindle on"
x-travel:800 mm y-travel:950 mm z-travel:1020 mm control:Sinumerik 840D sl MDynamics Operate turning speeds:10.000 1/min Spindle power:26/20 kW max. torque on the spindle:340/262 Nm tool taper:HSK-A 100 tool change unit:120 (2x60) Pos. Pallet changer 2x:630 x 630 mm table load capacity:800 kg weight of the machine ca.:20 t dimensions of the machine ca.:3,3 x 6,15 x 3,2 m 6-axis simultaneous horizontal machining center with controlled swivel-rotary table (A/B-axis), Swivel table can swing overhead (180°), that means the part is hanging down overhead and chips don?t accumulate on pallet, they can fall free into the chip conveyor CNC controlled U-axis enables radial movement of tool for variable spindling diamenter. twin pallet changer 630 x 630 mm 6 hydraulic couplings for pallet fixture clamping with rotary joint in A and B-axis special hydraulic pump for fixture coolant through spindle ...
x-travel:800 mm y-travel:690 mm z-travel:630 mm total power requirement:76 kW weight of the machine ca.:25,5 t b-axis:630 Rundeinheit control:Siemens 840 D workpiece weight:max . 1.100 kg spindle turning speed range:15000 U/min Boring power:30 mm plate size:630 x 630 mm Dimension:6000 x 2900 x 2400 mm spindle taper::HSK 63 Documents:vorhanden
x-travel:600 mm y-travel:770 mm z-travel:675 mm total power requirement:47 kW weight of the machine ca.:13 t Tool bore:HSK-A63 numbers of tools in magazin:40 including additional tool magazine ZM 182 1 spindle , 5 axes
usado
rolling capacity max.: t workpiece diameter: 470 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Key data: 600 mm, 770 mm, 805 mm
Siemens Sinumerik 840D sl 2 palets, cambiador de palets de 2 pliegues Tamaño del palet: 400 x 400 mm Viajar: X: 600 mm Y: 770 mm Z: 805 mm Mesa giratoria eje A Mesa giratoria con sistema de sujeción de palets grueso (eje B, PW) Husillo de fresado HSK-A63 Potencia de accionamiento del husillo de fresado: 32/25Kw Par máximo: 206 Nm Velocidad máxima del husillo: 16.000 rpm Diagnóstico de husillo Grob GSD Almacén de herramientas con 90 posiciones de herramientas Dispositivo de limpieza de herramientas Medición de la longitud de la herramienta Medición de piezas de Renishaw, RMP60 Luz de estado de la máquina Estación de preparación de palets, se puede girar a mano Puerta de configuración, panel de control adicional Preparación del sistema hidráulico de sujeción de la pieza Calibración del eje giratorio GSC Paquete de Eficiencia Energética EED Auricular ...
