turning length:800 mmtotal power requirement:380 Vweight of the machine ca.:1400 kgdimensions of the machine ca.:2200 x 1200 x 1300 mcentre height:160 mmchucking diameter:150 mm
turning diameter over bed:240 mmturning length:450 mmtotal power requirement:0,5 kWweight of the machine ca.:120 kgdimensions of the machine ca.:1500 x 600 x 1200 mmcentre height:120 mmspindle bore:21 mmrevolutions per minute: 75 - 2980 U/min
turning diameter:480 mmturning length:1250 mmcontrol:H 645 weight of the machine ca.:8 tdimensions of the machine ca.:5 x 2 x 2 mcentre distance:1580 mmswing over bed:495 mmswing diameter:üb.Querschlitten ca.350 mmworking area:1600 mmcontrol:H645 connected load:50 kW
control: Numeriksteuerung CNC 700 K total power requirement:28 KVAweight of the machine ca.:7,8 tdimensions of the machine ca.:6610 x 2280 x 2235 mmwork height max.:1060 mmgreates pass round over bed:305 mmspindle bore:82 mmDocuments:vorhanden
turning length:630 mmtotal power requirement:16 kWweight of the machine ca.:5 tdimensions of the machine ca.:3400 x 1500 x 1600 mmswing diameter over slide rest:Hinterdrehschlitten 250 mmcentre height:über Hinterdrehschlitten 150 mmcenter height over bed:300 mmturning spindle:Kopf DIN 55021 Gr. 8 centre distance:1000 mmaccessories::2 Schränke Wechselräder
turning diameter:500 mmturning length:1000 mmcontrol:MANUAL PLUS Grundig total power requirement:24 kVAweight of the machine ca.:2650 kgdimensions of the machine ca.:2500 x 1750 x 1850 mmswing diameter over face slide:290 mmchuck:Ø max. 260 mmcross movement:260 mmspindle head:DIN 55027 Größe 8 spindle bore diameter:70 mmrapid travel - longitudinal/face:8 /6 m/minspindle speeds::8 - 2800 tailstock travel:180 mmtailstock quill taper MT:5
turning length:2000 mmcontrol:- total power requirement:25 kWweight of the machine ca.:3 tdimensions of the machine ca.:3800 x 1800 x 1850 mmswing over bed:500 mmswing diameter over face slide:280 mmcontrol:Zyklen-Steuerung Heidenhain bed width:350 mmDocuments:vorhanden
turning diameter over slide rest:280 mmturning length:4000 mmtotal power requirement:7,8 kWweight of the machine ca.:6 tdimensions of the machine ca.:5,9 x 1,9 x 1,40 m
turning diameter:200 mmswing diameter:260 mmturning height:200 mmTool table:1054 x 400 mmDimensions (L/W/H):2200 x 2300 x 2300 mmweight:3300 kgslide travel radial ( X-axis ):520 mmslide travel axial ( Z-axis ):200 mmno pallet circulating belt, no C-axis, no driven tools
Un tour central conventionnel Cazeneuve HBX 360 de précision avec mandrin, tige d’outils et crosse arrière. Tour d’atelier bien connu ; condition d’usage avec usure visible. Spécifications complètes à confirmer. Auction-ID: A1-51509-12
turning diameter:570 mmturning length:1000 mmdimensions of the machine ca.:3,25 x 2,03 x 1,95 mTool disc turret for 8 tools with VDI 30.Not for power toolsmachine manual, technical documentation;Accessories: 3-jaw chuck, various tool holdersVideo is available
swing diameter:200 mmweight of the machine ca.:15 tDistance between tips:832,5 mmturning length:380 mmwith chip conveyor and belt filter press, infeed and outfeed belt 2 x 12-position revolvers
number of spindles:6 spindle passage:22 mm?Bar feeder complete is 4.70 meters - for 3 meters of material ?The machine is still on ?Materail to be processed on the machine: Steel ?Production with OIL Machine has only Single-NCU without PCU.The complete energy supply of all 6 main spindles was replaced in April 25.No socket for powered tools!
weight of the machine ca.:18 tcentre distance:700 mmmax. swing diameter:200 mmLathe with 4 tools only for 3-cylinder crank shaft
max. workpiece diameter:29 mmmin. workpiece diameter:26 mmworkpiece length:66 mmthe system was originally delivered for the following workpiece sizes: diameter 26mm - 29mm length 65mm - 66mmChanging parts in the clamping device, handling, etc. would probably result in diameters of up to approx. Ø50mmTotal length will probably be almost 400 mm possible with a few conversions.Also dependent on tool lengths, machining lengths on the component, etc.Workpiece: Piston pin Drawing number: WHT 000 718, WHT 000 718 A Workpiece dimensions (Ø, WxH): Ø26 x 66; Ø29 x 65 Length: 66 or 65 mm Material: 17Cr3Quantity: xxx parts / year Cycle time: 5 sec. However, workpiece lengths up to 600mm are manageable. The machining diameter can be adjusted if the appropriate tools are available. The clamping station can currently only accommodate this product. However, this can be adapted by changing the clampi ...
turning diameter:250 mmswing diameter:250 mmturning height:200 mmtotal power requirement:37,7 kWchuck diameter:315 mmspindle speed max.:5500 1/mintravel -x axis:625 mmtravel -y axis:+100/-80 mmtravel -z axis:250 mmworktool system:VDI 30+40 weight of the machine ca.:8 tThe synchronous spindle is powered with 37.7 kW of power, a torque of 300 Nm and a maximum speed of 5,500 rpm.Typical components are ball cages, ball hubs, gear wheels, sliding sleeves,pump wheels, flanges, synchronizer rings, bearing rings and pivot pins.The machine bed is made of Hydropol, a mixture of special concrete and steel, which ensures the greatest smoothness and precision even with larger components and powerful machining.
number of spindles:6 spindle passage:18 mmturning length:63/50 mmweight of the machine ca.:8,6 tspindle drive motor:11 kW
turning diameter:200 mmturning height:120 mmweight of the machine ca.:18 tAvailable from 01.08.2024
turning diameter:1000 mmswing diameter:1000 mmMachine type: Vertical latheManufacturer: HessappType: DV 62Serial no.: 14.2308Working range of the spindleLargest diameter 1000 mmLargest swing diameter 1000 mmCross slide travelStroke of the vertical slide 900 mmStroke of the horizontal slide 1810 mmTotal travel 2315 mmTurning spindleSpindle head with centering cone according to DIN 55021 A15Spindle diameter in the front bearing 203 mmMain driveVia a controlled asynchronous motor and gear transmissionwith range switching.Spindle speedsSpeed range I: 5 - 350 rpm.Speed range II: 30 - 1000 rpm.Travel speedX/Z axis: 10 m/min.W1 axis: 8 rpmNo C-Axis
faceplate diameter:800 mmpower requirement:110 kWweight of the machine ca.:37.000 / total 52.000 ttransport measurements machine:5,07 x 2,98 x 3,90 mclamping diameter:800 mm:Ø 800 x 720 mmTool bore:Capto C6 tools in tool magazin:2 x 80 With C-Axis
Équipé d’un affichage numérique Heidenhain à 3 axes ; Hauteur centrale 180 mm, largeur centrale 1000 mm, passage de broche en D 56 mm, vitesses de broche 2000 tr/min ; Auction-ID: A1-51062-12
largeur centrale 750 mm ; diamètre de circulation sur le plateau 330 mm ; diamètre de ventilation culasse face 160 mm ; déplacement culasse face 180 mm ; largeur du plateau 240 mm ; section transversale du ciseau 20x20 mm ; tête de broche selon la norme DIN 55027 Gr.5 ; diamètre de broche sur le roulement avant 70 mm ; alésage 40,5 mm Auction-ID: A1-51062-13
Un tour de précision conventionnel de haute qualité avec une précision du fabricant d’outils selon DIN 8605. La machine dispose de deux plages de vitesses commutables mécaniquement (V : 30—750 limin I W : 150—3000 Ilmin) pour un réglage fin sans gradons ainsi qu’une plaque d’alimentation de table transparente pour Fils métriques et fils de modules. Tension secteur : 3phasé / 400 V (50 Hz), fusible secteur 25 A. Équipements et outils de broche haut de gamme : 1 x ND de type indicateur de position numérique multi-axes (DRO) Heidenhain sur bras de moniteur réglable. 1 mandrin de tour à trois mâchoires de précision Röhm monté sur la broche principale (y compris la clé à mandri). 1 x tête d’outil à changement rapide PARAT d’origine (taille 2 / type RD) incluant chapeau ciseau à tour monté sur la luge supérieure. 1 x couvercle pivotant en polycarbonat ...
TOUR CNC MORI SEIKI ZL 200 SMC d’occasionN° de série : ZL200AE0279Année : 2001Alimentation : 200 V – 50 Hz – 51 kVAPoids de la machine : 5 850 kgBroche principaleDiamètre en barre : 65 mmDiamètre maxi de tournage : 390 mmPuissance de broche : 11/7,5 kWVitesse de broche : 40 - 4 000 tr/minNez de broche : JIS A2-6Axe C : 360° incrément d’indexage 0,001°Contre brocheDiamètre en barre : 51 mmPuissance de broche : 7,5/5,5 kWVitesse de broche : 60 - 6 000 tr/minNez de broche : JIS A2-5Axe C : 360° incrément d’indexage 0,001°Tourelle supérieureNombre de positions : 12Nombre de positions motorisées : 6Course des axes : X=235 mm - Z=520 mmTourelle inférieureNombre de positions : 8Nombre de positions motorisées : 4Course des axes : X=175 mm - Z=500 mmÉquipé de1 CN FANUC MSC 5011 Bras mesureur d’outils1 Récupérateur de pièces1 Convoyeur à copeaux1 Embarreur LNS QUI ...
turning diameter: 330 mmturning length: 669 mmcontrol: Siemens 828D total power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: 300 mmturning length: 500 mmcontrol: Fanuc total power requirement: kWweight of the machine ca.: 3300 kgdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: 210 mmturning length: 580 mmcontrol: 840 D Siemenscentre height: 190 mmturning diameter over bed: 330 mmturning dia. over face-slide: 260 mmMain spindle:: turning speed range - main spindle: max. 4.000 min/-1power capacity - main spindel: 10 / 7,5 kWmax. Torque: 115 / 86 Nmspindle bore: 68,5 mmmax. usable bar diameter: 51 mmC - Axis: 0,001 °axis stroke:: travel -x axis: 185 mmtravel -z axis: 455 mmturret:: number of toolpositions: 12 pos.tool taper: VDI 30 Driven Tool Stations:: 6 pos.Tailstock:: tailstock adjustment: 400 mmintake pressure max.: 4.000 Nfeeds:: rapid traverse: X: 20 / Z: 30 m/minFeed force ( X / Y / Z ): 4,5 kNtotal power requirement: 21 kWweight of the machine ca.: 3,2 tdimensions of the machine ca.: 8,0 x 2,2 x 2,0 mDocuments: Chip conveyor: Tailstock: Coolantsystem: C-axis: parts catcher: driven tool stations: Signal-Light: bar feeder: I ...
