Estuchadoras

• Estuchadora vertical, intermitente, semiautomática • Profundidad de la caja plegable del área de formiato 15 - 70, ancho 20 - 115, altura 50 - 190 mm, extracción de la caja con ventosa • Producción máx. 15-70 cajas/min, la velocidad máxima depende del formato y del producto • Dispositivo de estampado • Bomba de vacío • Carcasa completa con puertas segmentadas • Móvil con chasis desmontable • Armario eléctrico móvil • PLC Telemecanique TSX 17 • Electr. conexión 400V/50Hz

equipped with a LAETUS system flask tilter Was previously used on a syrup line, Elec: 380V 50Hz, A + B (mm): 140mm max, A (mm): 15 - 90mm, B (mm): 12 - 70mm, C (mm): 50 - 200mm, Dimensions (mm): 2280 x 1570 mm, Height (mm): 1755 mm, Documentation: X in Spanish

Machine: Automatic horizontal cartoner with reciprocating movements. Product: Blisters, strips, trays, rigid or flexible tubes, bottles, sachets, soaps and other products food or cosmetics. Usable material: cases with opposite or alternating legs in compact cardboard with a weight ranging from 220 to 400 g/m², pre-broken and pre-glued. Closing: By retracting legs or by hot glue distributed by commercially available nozzles., Cadence / min: 20 to 140 cycles/min , Elec: 400 V / 50 Hz / 8.6 A , A + B (mm): max 140 , A (mm): min 15 / max 90, B (mm): min 12 / max 70 , C (mm): min 50 / max 200

• Format range folding box (5 inch) w 15-90, h 12-70, l 50-200 mm • Output 20-120 folding boxes/min, clocked motion, the maximum speed depends on the format and product • Product infeed conveyor CAM 502 H for cylindrical products (diam. 18-67 mm, h 45-150 mm) and rectangular products (w 15-117, h 15-67, l 45-150 mm), equipped for bottles with bottle-transfer chicane and pusher in product chain • Centrally adjustable product chain • Closure double-sided offset or equilateral tuck-in flaps • Leaflet folding and inserting machine from magazine GUK FA21/4, Cartonac 91 • Code reading Argus 6012 (1x brochure, 1x folding box, 1x brochure presence in folding box) • 1 KBA-Metronic hot-stamping unit (without embossing stick), for flap insert side, retrofitted 2018 • Bad ejection • Vacuum generator • HMI/IPC touch panel Siemens Simatic TP700 Comfort, Windows CE 6.0,  ...

• Format range folding box (5 inch) width 15-90, height 12-70, length 50-200 mm • Product length max. 155 mm • Output 20-120 cartons/min, clocked motion, the maximum speed depends on the format and product • Centrally adjustable product chain • Closure double-sided offset or equilateral tuck-in flaps • Leaflet folding and inserting machine from magazine GUK FA21/4, Cartonac 81 • Code reading Laetus Argus 4 (2x brochure, 1x folding box) • Colour embossing unit on both sides • Bad ejection with ejection counter control • Vacuum pump • Electronic cam gear retrofitted • SPS CAM • Various format parts (insertion hopper) • Various spare parts • Electr. connection 400V/50 Hz

• Intermittent motion • Formate area folding box W 15-90 mm, H 12-90 mm, L 55-170 mm • Output 80-150 boxes/min, the maximum speed depends on the format and product • Jar/bottle feeding device with feeding conveyor and change parts for jar diam. 23 mm, height 30 mm • Embossing device with 5 lines for front flap • Bad discharge • Leaflet folder/inserter GUK FA21/4 Cartonac 91 for overlong leaflets L max. 650 mm, W max. 215 mm • Code reader Laetus Argus 6012 for 2x leaflet, 1x box • Suitable for bothside tuck-in closure with alternate or equal flaps • Touchscreen BFB IMA with terminal PC Polaris V40, controller Parker 1x Twin, 3x SPD • Vacuum ejector • Electr. connection 400V/50Hz/26A

• Automatic operation, product feed horizontal, box feed vertical • Folding box format range w 15-140 x h 10-70 x l 45-160 mm depending on format inserts (data not binding, exact statement after receipt of customers folding box sample) • for both sides flap closure by hot glue with hot melt device Nordson ProBlue 4 • Output max. 55 cycles/min • Product infeed conveyor with grouping and stacking station for small carton in infeed direction w 22 x h 9 x l 70 mm, other product infeeds possible at extra cost • Embossing unit for flap opposite insertion side with 2-line embossing stick • Outfeed conveyor with stacking chute for filled folding cartons • Available format sets for folding box sizes w 75+70, h 21+12 mm (depth adjustable without format) • Teachbox for checking the function of the closing tools • PLC Siemens S7-300 CPU 314 with operator terminal Siemens ...

• Fully automatic horizontal cartoner for both side moved plug-in closure • Operation direction from right to left • Adjusted for feeding of single and double 4-edge sealed bags • 600 mm format wheel and 6 stations • Format area folding box width 15 -125 mm x height 15 - 110 mm x depth 45 - 150 mm according to format parts • Output max. 60 cycles/min, the maximum speed depends on the format and product • Product stacking device • Leaflet folding and inserting device GUK FA21/4 Cartonac 2000 from magazin with separate GUK operating panel • Code reader SysTec TE 2000 with 2x leaflet, 1x folding box, 1x leaflet presence with bad discharge for folding box and leaflet • Without printing device • Available format parts (format cartridges) for folding box dimensions width x height x depth: 87 x 27 x 127 mm 91 x 70 x 127 mm 91 x 110 x 127 mm • Teach ...

máquina de cartón continua, rango de formato de cartón plegable mín. 30x15x65 mm (AxWxH), máx. 80x90x155 mm (AxWxH), rango de formato blíster mín. 30x3.5x60 mm (LxWxH), máx. 75x12x150 mm (LxWxH), alimentador de inserción/libro (las inserciones se retiran automáticamente de las cajas de almacenamiento/bandejas y se proporcionan al alimentador de plaquitas), preparados para el reacondicionamiento de una carpeta de folletos GUK, chorro de tinta avanzado cloud m600 para la aplicación de los datos variables y el cierre de código como plug-in Cierre de pegamento por medio de Nordson PROblue 4 dispositivo de pegamento caliente como protección Tamper-Evident, salida de cartón plegable en el sistema de etiquetado Pago Pagomat 6/2 para aplicar etiquetas en la parte superior de la caja plegable (viñeta, Bollino), tensión de conexión 400 V/230 V/50 Hz, fusible eléctrico 20 A, valor ...
