ERMAKSAN máquina utilizada para venda

3100 x 6 milímetros Cibelec CNC com pneum. Fixação em chapa metálica aprox. 8000 kg

O cortador a laser ERMAKSAN LASERMAK 6000 6X2 foi produzido em 2014. Parâmetros técnicos: – fonte laser: 6000 W CO2-laser GE Fanuc C6000i-Model C – RF-excitação: 2 MHz – estabilidade de energia: ± 2% (monitor de energia) – comprimento da onda laser: 10,6 μM – modo de feixe: Modo Fanuc Low Order – obturador a laser: obturador mecânico de segurança – composição a gás laser: CO2 / He / N2 – consumo de gás por laser: 20 l/h – arrefecimento do caudal da água: 250 l/min – capacidade máxima de corte: aço suave 25 mm (durante os ensaios o máximo alcançado: 30 mm), aço inoxidável 15 mm, alumínio 12 mm – requisito total de energia: 100-120 kW – corte do comprimento focal da cabeça: 5 "-7" -10 "polegadas" – tamanho máximo da folha de cálculo: 6150 x 2000 mm – capacidade máxima de carga: 4000 kg – eixos da máquina: 5 eixos [X,  ...

Área de trabalho: 1,5 x 3 m ou 2 x 4 m Equipamento standard: unidade de arrefecimento a laser 2 kW, sistema de ar adstringente e purificante, segurança, mesa de transferência automática dupla, unidade de comando CAD/CAM (Metalix, Lantek, Almacam) com ecrã tátil de 15 polegadas, correia transportadora, luz de aviso, conjunto de bocal Todos/CAD programas como Lantek, Metalix e Almacam são nós . Opções: Tecnologia de acionamento linear, fonte de luz laser opcionalmente disponível com dispositivo de amostragem de 3, 4 ou 6 KW, barreira de luz de segurança, ar condicionado para automação Painel. 24 meses de garantia O preço refere-se a uma facilidade de 1,5 x 3 m com 2 KW

Gama de trabalho: 1,5 x 3m, ou 2 x 4m Equipamento standard: auto-focalização da cabeça de corte laser 2kW, unidade de arrefecimento, sistema de limpeza e secagem de ar,gabinete de segurança, mesa de transferência automática, software CAD/CAM (Lantek, Metalix, Almacam)Dispositivo de controlo com 15 ecrãtátil,foerderband,luz de aviso,duesenset Opções:tecnologia de acionamento linear , fonte de luz laser opcional com dispositivo de remoção 3, 4 ou 6 KW, barreira de luz de segurança,ar condicionado para painel de automação. 24 meses de garantia do fabricante O preço refere-se a um sistema de 1,5 x 3m com 2 KW; pronto a ser utilizado

linha de soldadura para tubos galvanizados e pretos.

Description: Total strokes (13-03-2024): 61.872 See PDF for more technical information List of tools supplied with the machine: Tool length >,4000 mm Dies: 3209 ,  ,V12 3215 ,  ,V24 3234 ,  ,V50 3223 ,  ,V100 3040 ,  ,V12 ,  ,26 gr. ,  ,  ,R3 Hemming die BMR 55.16.30 ,  ,  ,  ,  ,  , V16 30 gr. Top tool: 1310 ,  ,  ,  ,  ,  ,  ,  ,  ,  , 85 gr. ,  ,  ,R0.8 H115 1030 ,  ,  ,  ,  ,  ,  ,  ,  ,  , 88 gr. ,  ,  ,R0.8 H145 TOP.175.26. ,  ,  ,  , 26 gr. ,  ,  ,R0.8 H145 Note! Loading costs are calculated for the complete machine loaded on a flatbed trailer. If the machine has to be dismantled, adition costs will be charged serial number: 00025469-ERH, throat: 510 mm, Read  ...

sheet width:3100 mm plate thickness:6 mm table length:3400 mm table width:490 mm table height:800 mm stroke:18 pro Min. quantity of oil:150 l Numbers of downholders:14 cutting angle:1,2 ° total power requirement:11 kW weight of the machine ca.:5,5 t mot.digital controlled backgauge, workspace:1000 mm :1000 mm front support arms with T-slot and flip cams:1000 mm

The machine is in good technical condition. Forming force: 80t Max. sheet length: 2600mm Weight: 5500kg Dimensions LxWxH: 2900 x 2150 x 2700mm Upon prior agreement, the possibility of a tour in progress.

Capacity: 1270 x 35 tons Elgo NC control for X and Y axis 1 set of tools

Capacity: 3100 x 8 mm (steel) Cybelec NC backgauge Rear entry protection

Capacity 4100 x 175 tons Stroke 700mm ESA S640 CNC DSP laser on the front Y1, Y2, X, R, Z1 and Z2 CNC controlled Double touch fingers Walk-in protection at the rear Wila New Standard clamping Includes 1 set of tools

Laser: IPG 1kW Snowboard: 3000 x 1500mm Including exclusion Auto focus Auto calibration Nozzle cleaning Precitec Procutter kick Including new Metalix software with AutoNest

Capacity 4100 x 175 tons Stroke 700mm ESA S640 CNC DSP laser on the front Y1, Y2, X, R, Z1 and Z2 CNC controlled Double touch fingers Walk-in security at the rear More photos to follow soon

Used Ermaksan press brake Type CNCAP EVO 3100 135 CNC Bombering Y1, Y2, X, R, Z1 and Z2 CNC controlled Hydraulic Wila NS top clamp Sealing mold at the bottom

This ERMAKSAN RPP 12730 Punching machine was manufactured in the year 2009 in Turkey. It has 2 axis. The machine has a punching force of 300 kN.

This ERMAKSAN AP 2100-35 Bending machine was manufactured in the year 2005 in Turkey. The machine has a pressing force of 350 kN.

This ERMAKSAN POWER BEND PRO 3100-175 Bending machines machine was manufactured in 2018 in Turkey. The machine has a Cybelec cybtouch 12 PS 2D control panel with touch screen. It is equiped with a high-quality hydraulics HOERBIGER and a hydraulic cylinders are made of high-strength hardened steel and chrome plated, which guarantees their durability and longevity.

This Ermaksan AP 3100-120 Bending machine was made in 2002 in Turkey. The machine has a pressing force of 1200 kN.

Hydraulic guillotine shear Manufacturer: Ermaksan -wear resistant blades upper knife: two sides; lower knife: four sides - Control unit: CYBTOUCH 6 - 1.000mm rear guide with drive, precision 0.1mm - 1.000mm side ruler and front supports - metric scales - ball screws on the front supports to facilitate the positioning of the sheets - CE approved front, back and side protection plates -light curtains on the back (labor protection) Delivery time: about 4 weeks -Sheet guide system -Automatic hydraulic adjustment of the cutting distance - Silent high pressure pump - Holding springs -adjustable pedal - emergency stop button - shadow line - retractable finger guard - CE certified regulation and conformity Technical data: Cutting width: 2600 Cutting thickness: 6mm Strokes per minute: 24 Number of fasteners: 12 pieces Pressure: 10 to. Main drive: 11 kw backgauge ...

Capacity: 40 t Folding length: 1000 mm CNC Brand: Delem Max. bending length:        1000mm Distance between column:    800mm Max. pressing force:        40T Beam stroke:                100mm Table Width:                90mm Troth beam:                 250mm Approch speed:              110mm/min. Working speed:              11mm/min. Return speed:               105mm/min. Adjustment X-Axis back gauge:1000mm Number of controlled axis:  4 Power:                      4,8kW Length:                  ...
