Máquina injetora
Ano de construção: 2011 Controlo CC200 Força de bloqueio 400 toneladas incluindo vários acessórios (unidade de arrefecimento Piovan, unidade de arrefecimento Tooltemp, bomba de vácuo) A máquina vem diretamente da produção
This Engel Duo 3550/550 Tech was manufactured in 1998. It features a clamping force of 5500 kN, a maximum injection volume of 1960 cm³, and a screw diameter of 80 mm. The machine dimensions are 8840 x 2520 x 2230 mm, and it weighs 20,000 kg. If you are looking to get high-quality injection moulding capabilities, consider the Engel Duo 3550/550 Tech machine we have for sale. Contact us for more information.
This Engel VICTORY 1350/260 tech was manufactured in 2012. It features a clamping force of 260 tons, a maximum injection volume of 735 cm³, and a screw diameter of 60 mm. The machine dimensions are 5,861 × 1,923 × 2,300 mm, and it weighs 19,400 kg. Currently in production with excellent condition and 73,164 operating hours. Contact us for more information about this machine.
This Engel DUO 3550/400 pico was manufactured in 2013. It features a clamping force of 4,000 kN, a screw diameter of 80 mm, and a maximum injection volume of 1,960 cm³. The machine dimensions are 7,420 × 2,360 × 2,360 mm, and it weighs 11,000 kg. It is equipped with a robot interface Euromap 67. Contact us for more information about this machine.
This Engel DUO 7050/650 pico was manufactured in 2013. It features a clamping force of 6500 kN, a maximum injection volume of 4160 cm³, and a screw diameter of 105 mm. The machine includes a robot interface (Euromap 67) and is still in production with excellent condition. If you are looking to get high-quality injection molding capabilities, consider the Engel DUO 7050/650 pico machine we have for sale. Contact us for more information about this machine.
This Engel DUO 4550/500 pico was manufactured in 2013. It features a clamping force of 5,000 kN, a screw diameter of 90 mm, and a maximum injection volume of 2,480 cm³. The machine dimensions are 7,800 x 2,405 x 2,355 mm, and it weighs 14,000 kg. Currently in production with approximately 65,000 operating hours, it remains in excellent condition. Contact us for more information about this machine.
Engel E-Victory 170H/50V/120 combi (2015) 2k machine CC300 controll Clamping force: 1200 kN Mould min-max: 300mm Total tool max height: 800 mm plate size : 740 x 680mm Opening stroke: 505 mm Ejector stroke: 130 mm Ejector force: 39.8 kN Pump drive power: 15 kW Injection unit 1 Screw diameter: 25 mm Max. swept volume: 59 cm³ Screw speed max: 400 r/min Screw speed max (current): 400 r/min Injection rate: 109 cm³/s Injection rate (increased): 109 cm³/s Specific injection pressure: 2400 bar Specific injection pressure (increased): 2400 bar Injection unit 2 Screw diameter: 20 mm Max. swept volume: 25 cm³ Screw speed max: 450 r/min Injection rate: 104 cm³/s Specific injection pressure: 2400 bar Machine with conveyor. Working hours : 41.427 h Possible to buy robot Engel VIPER 20 Linear (Z=3320mm)
Engel victory 200/50 spex (2010) CC200 Clamping force: 50 t Screw diameter: 35 mm Type: Horizontal Drive: Hydraulic Hours: 56000
Engel INSERT 330H/90 Controll: CC100 Condition: funtional Vertical machine with Horizontal injection Rotary table diameter: 1100mm Clamping force: 90 ton Opening max. : 570 Opening min. : 270 Platen size: 590x340 Screw: 40 mm Screw length: 160 mm Injection volume: 201 cm3 Injection pressure: 1230 bar Motor: 15 kw Weight: 5600 kg Height 2800 mm
Clamping Force: 60 tons (600 kN) Injection Unit Orientation: Vertical Rotary Table: Included Screw Diameter: 25 mm Shot Size: Around 4.4 oz (125 g) Injection Pressure: Up to 210 bar Injection Speed: Approximately 139 mm/s Mould Opening Stroke: 305 mm Ejector Stroke: 106 mm
Engel ES200/45VTHL-PRO-ELAST (2002) Clamping force: 45 t Type: Vertical Drive: Hydraulic Machine for Rubber.
Key data: 1200 kN, 186 g/PS, 35 mm
À espera de renovação na nossa sede em Northamptonshire está esta máquina de moldagem por injeção Engel VC500/120 com duplo núcleo pneumático e um núcleo hidráulico simples. Qualquer máquina que esteja à espera de renovação (ou em recondicionamento) connosco pode ser reservada com um depósito de 10% e depois damos prioridade à renovação, procurando que a máquina esteja disponível para inspeção no prazo de 8 semanas após a encomenda. As máquinas recondicionadas da STV Machinery passam por um procedimento de teste abrangente, durante o qual todas as funções da máquina são testadas e, se necessário, reparadas. Uma produção de pelo menos 5000 ciclos sem falhas antes da aprovação garante uma operação sem problemas após a entrega. As máquinas são ultra limpas e, esteticamente, tão boas quanto conseguimos arranjar. Garantimos que os nossos recondici ...
Máquina de injeção Engel Tipo ES 1500T/160 V – ELAST Placa deslizante de curso 300mm Ejetor central de curso para placa deslizante 100mm Ejetor central de força para placa deslizante 30kN Ejetor mecânico lateral do curso 250mm Ejetor hidráulico lateral do curso 250mm Ejetor hidráulico lateral de força 80kN Ejetor central do curso 120mm Ejetor central de força 20kN Potência de acionamento da bomba 15kW Enchimento de óleo 1 225 Pressão de funcionamento do sistema hidráulico 250bar Unidade de controlo de temperatura de capacidade 2x3 kW Carga total ligada 48kW Escurecimento: 2675mm de comprimento x 1350mm de largura x 3310mm de altura Peso: 6900 Com manual de instruções
Fazer: Engel Tipo: Injeção vertical de borracha Modelo: ES 280V/40VT-ELAST Número de série: 41938, Ano de fabrico: 2000 Força de aperto 400kN Volume de injeção 280cm3 Tamanho da placa: 860x400mm Em bom estado de conservação.
screw size:60 mm closing pressure:3500 kN weight of the machine ca.:25,5 t
clamping force: 450 kN injection volume: 135 cm³ screw diameter: 35 mm platen size: 550 x 430 mm Condition: second-hand, Specification: Horizontal injection moulding machine Injection unit: - Screw diameter: 35 mm - Screw length L/D: 17.3D - Dosing stroke: 140 mm - Screw speed: 20 – 480 rpm - Moulding volume: 135 cm³ - Injection pressure: 1,065 bar - Increased injection pressure: 1,620 bar - Heating power: 6.8 kW - Number of heating zones (including nozzle): 4 Clamping unit: - Maximum clamping force: 450 kN - Platen dimensions: 550 x 330 mm - Extended clamping plates: 550 x 430 mm - Minimum mould installation height: 180 mm - Maximum plate spacing: 530 mm - Opening stroke: 350 mm - Control system: EC 100 Drive: - Pump drive power: 11 kW - Approx. weight: 3,300 kg - Dimensions: 3,300 x 1,200 x 1,800 mm Current oper ...
clamping force: 4.000 kN injection volume: 2480 cm³ screw diameter: 90 mm platen size: 1.300 x 1.080 mm Condition: second-hand, Specification: Horizontal injection moulding machine Injection unit: - Screw diameter: 90 mm - Injection volume: 2,480 cm³ - Maximum shot weight: 2,232 g - Injection pressure: 1,360 bar - Increased injection pressure: 1,600 bar - Heating capacity: 64 kW Clamping unit: - Max. clamping force: 4,000 kN - Clamping plates: 1,300 x 740 mm - Extended clamping plates: 1,300 x 1,080 mm - Minimum mould installation height: 350 mm - Maximum platen spacing: 1,300 mm - Opening stroke: 950 mm - Core pull unit: 2-stage on BAP - Control system: EC 100 Drive: - Pump drive power: 55 kW - Weight (clamping side) approx.: 25,000 kg - Weight on injection side (approx.): 8,000 kg Discharge ...
Engel ES 2550/500 HL - V Hours - 114924 Injection unit Screw diameter mm 70 Screw peripheral speed m/s 0.894 Maximum shot volume cm3/g 1193 Injection pressure maximum hydr/spec bar 2140 Nozzle radius mm R35 Maximum barrel temperature °C 350 Clamping unit Clamping force kN 5000 Maximum opening stroke (distance between the platens) mm 1700 Minimum installation height mm 500 Distance between tie bars Horizontal mm not applicable Distance between tie bars Vertical mm not applicable Centering ring Diameter nozzle side mm 200 Centering ring Diameter ejector side mm 200 Ejector Ejector available Yes/No Yes Ejector stroke Maximum mm 250 Core pulls Core pulls AS pcs. 2 Core pulls DS pcs. 1 Air valves Pneum. Valve gate nozzles - 4 Cumsa - No Air valves - 1 Robot-Linear Engel A-axis - No B-axis - Yes C-axis - Yes 5- /6-axis Yes/No No Machine data Year of manufactur ...
Engel ES 2550/500 HL Hours - 119209 Injection unit Screw diameter mm 70 Screw peripheral speed m/s 0.894 Maximum shot volume cm3/g 1193 Injection pressure maximum hydr/spec bar 2140 Nozzle radius mm R35 Maximum barrel temperature °C 350 Clamping unit Clamping force kN 5000 Maximum opening stroke (distance between the platens) mm 1700 Minimum installation height mm 500 Distance between tie bars Horizontal mm not applicable Distance between tie bars Vertical mm not applicable Centering ring Diameter nozzle side mm 200 Centering ring Diameter ejector side mm 200 Ejector Ejector available Yes/No Yes Ejector stroke Maximum mm 250 Core pulls Core pulls AS pcs. 2 Core pulls DS pcs. 1 Air valves Pneum. Valve gate nozzles - 4 Cumsa - No Air valves - 1 Robot-Linear Engel A-axis - No B-axis - Yes C-axis - Yes 5- /6-axis Yes/No No Machine data Year of manufacture - ...
Engel Victory 350/1800 Hours - 73686 Injection unit Screw diameter mm 70 Screw peripheral speed m/s 0.828 Maximum shot volume cm3/g 1039 Injection pressure maximum hydr/spec bar 2199 Nozzle radius mm R35 Maximum barrel temperature °C 350 Clamping unit Clamping force kN 3500 Maximum opening stroke (distance between the platens) mm 1358 Minimum installation height mm 450 Distance between tie bars Horizontal mm not applicable Distance between tie bars vertical mm not applicable Centering ring Diameter nozzle side mm 160 Centering ring Diameter ejector side mm 160 Ejector Ejector available Yes/No Yes Ejector stroke Maximum mm 250 Core pulls Core pulls AS pcs. 1 Core pulls DS Pcs. 1 Air valves Pneum. Valve gate nozzles - 4 Cumsa - No Air valves - 1 Robot-Linear Engel A-axis - No B-axis - Yes (servo) C-axis - Yes 5- /6-axis Yes/No No Machine data Year of manuf ...
Engel ES 1350/350 HL Hours - 122266 Injection unit Screw diameter mm 55 Screw peripheral speed m/s 0.733 Maximum shot volume cm3/g 618 Injection pressure maximum hydr/spec bar 2183 Nozzle radius mm R35 Maximum barrel temperature °C 350 Clamping unit Clamping force kN 3500 Maximum opening stroke (distance between the platens) mm 1305 Minimum installation height mm 350 Horizontal tie bar spacing mm not applicable Distance between tie bars vertical mm not applicable Centering ring Diameter nozzle side mm 160 Centering ring Diameter ejector side mm 160 Ejector Ejector available Yes/No Yes Ejector stroke Maximum mm 250 Core pulls Core pulls AS pcs. 2 Core pulls DS pcs. 0 Air valves Pneum. Valve gate nozzles - 4 Cumsa - No Air valves - 1 Robot-Linear Engel A-axis - No B-axis - Yes C-axis - Yes 5- /6-axis Yes/No No Machine data Year of manufacture - 2005 Perip ...
clamping force: 250 kN injection volume: 134 cm³ screw diameter: 35 mm platen size: 300 x 300 mm Condition: second-hand, Specification: C-frame injection moulding machine - second-hand Clamping unit: - Clamping force: 250 kN - Heating plate dimensions: 300 x 300 mm - Heating power of the plates: 5.3 kW - Clamping/opening stroke: 330 mm - Platen distance with heating plates at maximum: 380 mm - Clamping direction: from below - Side ejector: yes - Stroke of side hydraulic ejector: 100 mm - Ejector stroke/force: 70 mm / 24 kN Injection unit: - Increased injection pressure: 1,580 bar - Maximum injection volume: 134 cm³ - Screw diameter: 35 mm - Screw length: 17.1D - Maximum screw speed: 20–480 rpm - Metering stroke: 140 mm - Injection: from above - Voltage: 3x 400 V, 50 Hz, N, PE Pump drive power: ...
clamping force: 800 kN injection volume: 154 cm³ screw diameter: 35 mm platen size: 430 x 660 mm Condition: second-hand, Specification: C-frame injection moulding machine - second-hand Clamping unit: - Clamping force: 800 kN - Mould mounting area: 430 x 660 mm - Clamping/opening stroke: 450 mm - Maximum mould installation height without heating plates: 300 mm - Maximum plate spacing without heating plates: 750 mm - Clamping direction: from below - Ejector stroke: 130 mm - Ejector force: 40 kN Injection unit: - Increased injection pressure: 2,180 bar - Maximum injection volume: 154 cm³ - Screw diameter: 35 mm - Screw length: 20D - Maximum screw speed: 20–400 rpm - Metering stroke: 160 mm - Injection: from above - Nozzle stroke: 250 mm - Voltage: 3 × 400 V, 50 Hz, N, PE - Pump drive power: ...
clamping force: 250 kN injection volume: 134 cm³ screw diameter: 35 mm platen size: 300 x 300 mm Condition: second-hand, Specification: C-frame injection moulding machine - second-hand Clamping unit: - Clamping force: 250 kN - Heating plate dimensions: 300 x 300 mm - Heating power of the plates: 5.3 kW - Clamping/opening stroke: 330 mm - Platen distance with heating plates at maximum: 380 mm - Clamping direction: from below - Side ejector: yes - Stroke of side hydraulic ejector: 100 mm - Ejector stroke/force: 70 mm / 24 kN Injection unit: - Increased injection pressure: 1,580 bar - Maximum injection volume: 134 cm³ - Screw diameter: 35 mm - Screw length: 17.1D - Maximum screw speed: 20–480 rpm - Metering stroke: 140 mm - Injection: from above - Voltage: 3x 400 V, 50 Hz, N, PE Pump drive power: ...
Manufacturer: Engel Model: Victory 330H/80L/110 Year of Manufacture: 2008 Type of Machine : Injection Molding Machine.Combi machine for 2-component injection molding (main cylinder is Ø 18mm thermoplastic and L-unit is a Ø 12mm LSR cylinder) Operating hours: 35995h Find more here - / Contact us at -
Manufacturer: Engel Model: 330/75 HL Year of Manufacture: 2002 Type of Machine : Injection Moulding Machine Machine Weight: 5,850 kg Find more here - / Contact us at -
Manufacturer: Engel Model: ES 200/90 HL Year of Manufacture: 1999 Type of Machine : Injection Moulding Machine Machine Weight: 5,900 kg Find more here - / Contact us at -
Manufacturer: Engel Model: e victory 50/50 Year of Manufacture: 2019 Operating Hours: 18,660 Hours Condition: Very good technical condition Technical Details Safety Standard: CE Type Injection Unit: Horizontal Injection Unit: 50 Material Injection Unit: Thermoplastics Screw Diameter: 18 mm Drive Injection Unit: Electric Construction: Holmlos Clamping Plate: 450 x 500mm Closing Force: 50to Platen Spacing: 600 mm Drive: Hydraulisch/ Hybrid Tool Weight Max: 600 Kg
