Krauss Maffei 175-1000 C2 Injection molding machines

Germany2005ID 169283910

Germany2005ID 169283910

usedVerified seller
Request price Directly to the seller
Krauss Maffei 175-1000 C2 Injection molding machines
1 / 1

Technical data

· ID 169283910
Source: seller information

Injection molding machines

Condition
used
Year of manufacture
2005
Location
52070 Aachen

Identifikation

ManufacturerKrauss Maffei
Model175-1000 C2

Technik

Quantity1
Technical parameter 11750kN
Technical parameter 2393g/PS
Technical parameter 350mm

Description

Clamping force: 175t
Year of Make: 2005
Injection weight in hp: 393g

Injection Unit .../1000
Screw diameter
50 mm
Spec. Spray pressure
2304 bar
Injection volume
432 cc
Injection weight in hp
393 g
L/D Screw Ratio
22
Clamping unit 175/...
Clamping force
175 t
Size of the clamping plates
915 x 910 mm
Lights spar spacing
560 x 560 mm
Tool installation height
350 mm
Opening way
700 mm
Max. panel spacing
1050 mm
Ejector path
200 mm
Weight
9000 kg
Dimensions(m) LxWxH
5.2 x 1.75 x 2.2 m
Year of construction
2005
Control type
MC4
