Eurolux Tank 1000 Litres ROUND Stackable AISI 304

For transport and storage of all types of beverages ex: bier, wine, juice, liquor, whiskey.
For yoghurt, mustard, honey, cream for hands, etc. Also for pharma and chemical purpose.

Material:
Cone: 1.4301 IIID
Jacket: 1.4301 IIID
All other parts: 1.4301 IIIC

Volume: 1000 litre
Test pressure:+ 3,4 bar
Max. allowable: Operating pressure:+2,0/-0,15 bar
Operating temperature:130°C

Dimensions:
Height over all:1845 mm +/- 10 mm
Diameter of container:1000 mm
Diameter of reinforcing ring:1012 mm
Weight: 126 kg

Thickness:
Top Bottom:2 mm
Lid:3 mm
Jacket:1,5 mm
Cone:2 mm
Outlet Tube:2mm
Forklift Tunnel:3 mm

Design and Equipment:
stacking device - consisting of a stacking crown which is welded directly on the top bottom;
Top Bottom:
with a DN 400 cover system which is welded in the center of the top bottom; Cover System
with a DN 400 lid which is fixed by a clamp with a screw spindle;

Connections -
following connections are welded into the lid:
Screw connection DN 50 ( DIN 11851 ) with plastic screw cap pressure relief valve

Cylindrical tank:
with reinforcing rings for better under pressure and pressure resistance.
With sample valve DN 15 (on extra charge)
Cone
with 120° with a centrical welded outlet tube DN 65.

Upper bottom:
with a butterfly valve DN 50 G/S with plastic cap.
with hygienic clear outlet with thread connection DN 50 with pipe connection thread with butterfly valve DN 32 (on extra charge)
Feet Frame
Consisting of round tubes which are welded directly on the cone with 2 forklift tunnel for stackable operatings.

Operating Conditions
stackable:1 + 1 filled, 1 + 2 empty

Only corrections on internal welding seams are grinded.
Container fully pickled, passivated and neutralised.
Tightness inspection carried out by water pressure test.
