Vertical Bandsaws BEHRINGER LPS 40-4

Behringer LPS 40-4 - Vertical Metal Band Saw

- Hydraulic belt tensioning
- Servo-controlled feed
- Solid C-frame
- Year of construction 2014

Technical data

- Working area (LxWxH): 4000 x 680 x 400 mm
- Smallest section height: 10 mm
- Minimum section width: 15 mm
- Inner table support surface: approx. 680 x 4000 mm
- Indoor table max. load: 7500 kg
- Outdoor table support surface: approx. 680 x 4000 mm
- Outdoor table max. load: 9500 kg
- Material support height: approx. 1385 mm
- Cutting speed: 17 - 120 m/min
- Saw blade dimensions: 5400 x 54 x 1.6 mm
- System or belt tensioning pressure: 85 bar
- Quantity of cooling lubricant: approx. 250 l
- Motor power - saw drive: 5.5 kW
- Motor power - hydraulic pump: 2.2 kW
- Motor power - chip conveyor: approx. 0.26 kW
- Connected load: approx. 11 kW
- Voltage: 400 V, 50 Hz
- Control voltage / hydraulic valve voltage: 24 V= (DC)
- Current consumption: approx. 25 A
- Fuse: 35 A
- Cable cross-section: min. 10 mm2
- Machine dimensions WxHxD: 6450 x 2870 x 2350 mm
- Weight (net): approx. 10000 kg
seller offer No. resale 200133
