pressure: 225 t pressing length: 3050 mm distance between columns: 2550 mm : Cybelec Visitouch stroke of ram: 700 mm column arm: 405 mm distance between table / ram: min. 320 / max. 1020 mm total power requirement: 29,5 kW weight of the machine ca.: 15.500 kg Accessories/equipment: Rear stop Stop support adjustment: - Stop range X-axis (from bending line): 5-1000 mm - Adjustment speed X-axis: max. 500 mm/sec Height adjustment - Adjustment range R-axis (from table surface): 85-235 mm - Adjustment speed R-axis: max. 150 mm/sec Stop finger adjustment: - Adjustment range Z1-axis (from left table front): 520-2365 mm - Adjustment speed Z1-axis: max. 1000 mm/sec - Adjustment range Z2-axis (from left table front): 690-2535 mm - Adjustment speed Z2-axis: max. 1000 mm/sec - Adjustment range X1-axis (from center position): ± 125 mm - Adjustment speed X1 axis: max. 250 mm/sec Die displacement - adj ...
pressure: 135 t chamfer lenght: 3050 mm distance between columns: 2550 mm stroke: 400 mm quantity of oil: 300 l Control: Cybelec Visitouch total power requirement: 15 kW weight of the machine ca.: 10.700 Kg range L-W-H: 4200x2200x3200 mm Equipment: - Controlled axes: Y1, Y2, X, R, - SICK” light barrier in front of the machine - Side safety guards - Protective grille behind the machine - foot switch - incl. tools The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
sheet width:3050 mm plate thickness:4 mm total power requirement:9 kW weight of the machine ca.:6 t dimensions of the machine ca.:3900 x H 1850 x T 2100 mm
sheet width: 3050 mm plate thickness: 10 mm control: Elgo 87 P2 : 11 - 31 Hub/min cutting angle adjustment: 1 - 4 ° Number of hold downs: 16 Stück : 900 kg : 11 kW table width: 700 mm table height: 800 mm range L-W-H: 4000 x 2220 x 1830 mm weight: 6300 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 225 t chamfer lenght: 4050 mm distance between columns: 3550 mm control: CYBELEC DNC 86 PS total power requirement: 18,5 kW weight of the machine ca.: 18.000 kg dimensions of the machine ca.: 5180x2400x3200 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 110 t chamfer lenght: 2550 mm Control: Cybelec DNC 70 weight: 9000 kg dimensions: 3000 x 2100 x 3000 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
sheet width: 4050 mm plate thickness: 8 mm distance between columns: mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
sheet width: 3050 mm plate thickness: 10.0 mm thickness at Niro-steel: 6.0 - 8.0 mm down holder: 13 Stück distance between columns: 3070 mm cutting angle: 1.0 - 4.0 ° no. of strokes: ~ 22 Hub/min Control: ELGO P8511 oil volume: 240 l voltage: 400 V total power requirement: 15.0 kW weight: 8000 kg range L-W-H: 3550 x 2350 x 1900 mm good condition () from a maintenance workshop Equipment: - NC electro-hydraulic guillotine shears - heavy / stable welded construction (machine body) - NC ELGO digital control unit P8511 - NC electro-motorized backgauge on ball screws - electro-hydraulic cutting angle adjustment Front analog cutting angle display - 1x stable side fence, with T-slot and mm scale - 3x stable support arms, with T-slot and mm scale - Ball castors in the work table incl. recessed grips - Front finger guard - can be folded up at the front - 1x freely movable foot switch - 2x fro ...
pressure: 135 t chamfer lenght: 2550 mm distance between columns: 2050 mm control: CYBELEC ModEva 10 S total power requirement: 25 kW weight of the machine ca.: 11.000 kg dimensions of the machine ca.: m Machine: - Sturdy machine frame constructed as a fully welded all-steel structure - Pressure beam with high bending strength - Electrohydraulic top drive via proportional valves - Modern block hydraulic system Optional equipment: - Increase in installation height and stroke by 150 mm each - Backgauge system 2 - 2 axes, R-axis adjustment 150 mm - 2 x additional stop fingers 2/4-axes, however, offset by 20 mm - CNC holding device - Distance from the bending line to the holding device approx. 240 mm - EHT quick-clamping device for EHT upper tools, pneumatic, head width 26 mm, horizontally self-centering - EHT lower tool clamping, mounting width 55 mm, pneumatic - Hardened insert strip for E ...
pressure: 50 t chamfer lenght: 1550 mm distance between columns: 1150 mm Control: CYBELEC DNC 1200 PS Eco column arm: 405 mm table height: 900 mm stroke of ram: 400 mm distance between table / ram: 720 mm total power requirement: 9,5 kW weight of the machine ca.: 5.200 kg dimensions of the machine ca.: 2000x1900x2920 mm Accessories/Equipment: - CYBELEC DNC 1200 PS Eco controller - 2 support arms - 4 stop fingers - Lasersafe - Foot switch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 170 t chamfer lenght: 3050 mm distance between columns: 2550 mm stroke: 400 mm weight of the machine ca.: 15.300 kg dimensions of the machine ca.: m Machine: - Sturdy machine frame - Press beam - Spherical bearing for the press beam with press beam tilt - Electro-hydraulic top drive - Block hydraulic system - Length measuring system (Y-axis) with dynamic spring compensation - Control cabinet air conditioning unit - Adapter strip for tool mounting - 2 stop fingers Optional equipment: - 2-axis backgauge (XM/XS, R) - 1 sheet metal holding device 200 daN CNC - 2 x additional stop fingers 2/4-axis - 1 x pneumatic upper tool clamping 26 mm - 1 x pneumatic lower tool clamping 55 mm - 1 x lower tool shift EHT pneumatic - 1 x CNC crowning device 3000 kN/m - 1 x Operator Safety Guard PILZ PSENvip Productive - 2 x Bending aid 1500 N - 1 x Support strips for bending aid - 1 x Parking posit ...
sheet width: 3050 mm plate thickness: 10 mm control: Elgo 87 P2 : 11 - 31 Hub/min cutting angle adjustment: 1 - 4 ° Number of hold downs: 16 Stück : 900 kg : 11 kW table width: 700 mm table height: 800 mm range L-W-H: 4000 x 2220 x 1830 mm weight: 6300 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 125 t chamfer lenght: 3550 mm distance between columns: 3050 mm column arm: 300 mm stroke of ram: 240 mm quantity of oil: 200 l control: CYBELEC Cybtouch 15 range L-W-H: 4500x2200x3000 mm Equipment/accessories: - manual crowning - 3 x manual stop fingers - die displacement - pneum. upper tool clamping - foot switch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
plate thickness: 16 mm cutting length: 4075 mm weight: 23 t output: 45 kw The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 225 t chamfer lenght: 2050 mm distance between columns: 1550 mm control: CYBELEC DNC 1200 PS Eco stroke: 550 mm table height: 700 mm throat: 405 mm distance between table / ram: 320-870 mm column arm: 405 mm weight of the machine ca.: 14.000 kg Accessories / equipment: - controlled axes: Y1 - Y2 - X - R - Z1 and Z2 can be moved manually - Lasersafe angle measurement - Pneumatically adjustable support table - pneumatic upper and lower tool clamping - 2-hand foot control - manual crowning The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 135 t chamfer lenght: 3050 mm distance between columns: 2550 mm dayligth: 320 - 560 mm stroke: 240 mm working feed: 10.0 mm/sec return speed: 150 mm/sec column arm: 400 mm work height max.: 1050 mm control: DNC 1200 PS/B operating pressure: max. 297 bar compressed air: 4.5 - 6.0 bar connected load: 15.0 kW oil volume: 250 ltr. weight: 11500 kg range L-W-H: 5240 x 2400 x 2900 mm good/well-Maintained conditions used in Aluminum processing - in checked conditions - machine Video - https://www.youtube.com/watch?v=z-Bxibk_8uE Features: - CNC Electro-Hydraulic Press Brake - CYBELEC CNC Control Model DNC 1200 PS/B Swiveling Control Panel, Front Right Numerical Programming Tool & Program Library - CNC Controlled Axes: Y1 + Y2 + X + R + CNC Crowning - CNC Electro-Motorized Backgauge (X-Axis) with 3x Manually Adjustable Backgauge Fingers (Z-Axis) Maximum Travel Speed: 250 mm/sec - ...
sheet width: 3100 mm plate thickness: 4.0 mm thickness at Niro-steel: 2.5 mm cutting angle adjustment: 1.0 ° back stop - adjustable: 10 - 1000 mm adjustment speed: 180 mm/s down holder: 21 Stück strokes per minute: 18 - 31 oil volume: 160 L Control: ELGO P8511 column arm: 200 mm distance between columns: 3050 mm 0: max. 300 bar voltage: 400 V main drive: 9.0 kW weight of the machine ca.: 4800 kg. dimensions of the machine ca.: 3660 x 2070 x 2140 mm from a maintenance workshop Equipment: - electro-hydraulic sheet metal shear swing cut - machine frame = all-steel welded construction - ELGO NC control model P8511, control panel at the front left for positioning the electro-motoric rear stop target/actual position value input possible adjustment by three-phase motor via toothed belt - support table with ball rollers there are recessed grips between the table plates - front finger guar ...
pressure: 150 t chamfer lenght: 4050 mm distance between columns: 3550 mm Control: CYBELEC ModEva Pac throat: 350 mm distance between table / ram: 430 mm table width: 250 mm stroke: 250 mm total power requirement: 18,5 kW weight of the machine ca.: 16500 kg dimensions of the machine ca.: 4400x2100x3200 mm Equipment/accessories: - Control conversion at the end of 2018 - Electric backgauge 1250 mm - 10-stage die displacement - crowning - EHT 26 mm tool holder - Axes controlled: Y1,Y2,X,R - Sheet metal holding table - 4x manually adjustable stop fingers - pneum. Upper tool clamping - Safety light curtain - 3x height-adjustable support arms - Oil cooler - 2-hand foot switch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Número : 8740 Tipo: VR 13-31 Produtor: EHT Gerado: Parâmetros: Comprimento máximo de corte: 3100 mm Espessura máxima de corte: 13 mm
Hydraulic CNC press brake EHT for sale. Press force: 1100kN, bending length: 3050mm, min./max. table-ram distance: 280mm/600mm, rapid approach speed: 100mm/s, working speed: 2mm/s-8mm/s, return speed: 100mm/s, backgauge adjustment range: 5-1000mm, backgauge adjustment speed: 200mm/s, backgauge vertical adjustment: +/-10mm, safety distance between tooling and operating elements: 120mm, stopping time: 75ms, stopping distance: 11mm, Control system: DAK 90. Machine weight: 8500kg. Documentation available. Inspection by appointment possible.
This 4-axis EHT EHPS 20-35 press brake was manufactured in 1995. It features a pressing force of 2,000 kN and a bending length of 3,550 mm, providing robust capabilities for metal forming. The machine includes a distance between columns of 3,050 mm and a throat depth of 350 mm. If you are looking to get high-quality bending capabilities, consider the EHT EHPS 20-35 press brake we have for sale. Contact us for further details.
Sheet metal shears, tin scissors, sheet metal scissors, hydraulic shears -Sheet shear: hydraulic -Cutting width: 2000 mm -Max. cutting thickness: steel 6 mm -Features: Back gauge, cutting gap adjustment -Space requirement: 3280/2700/H2060 mm -Transport dimensions: 2280/2700/H2060 mm -Weight: 5980 kg
Hydraulic cylinders, support cylinders, hydraulic pistons, pressure pistons, hydraulic buffers, pressure boosting cylinders -Hydraulic cylinder: from press brake EHT type EHP 11-40 -Piston rod: Ø 155 mm -Stroke: 250 mm -Number: 2 cylinders available, 1 left / 1 right -Price: per piece -Dimensions: 855/285/380 mm -Weight: 311 kg/unit
Stop for press brake, bending machine, guillotine shear, drive shaft -Drive shafts: for stop, from press brake EHT type EHP 11-40, 2 pieces -Length: 515 mm -Hole: Ø 25 mm -Price: complete -Dimensions: Ø 50 x 515 mm -Weight 5.1 kg/pc.
Bending tool, die, upper knife, upper tool, straight tool, die tool, seam closing tool -Tool: from press brake EHT type EHP 11-40 -Measures: see drawing in the photos -Dimension: 4050/45 / H130 mm -Weight: 147 kg
pressure: 225 t chamfer lenght: 3050 mm distance between columns: 2550 mm column arm: 300 mm ajustment speed: 110 mm/sec work speed: 9.0 mm/sec return speed: 130 mm/sec work stroke: 240 mm dayligth: 320 - 560 mm table height: 1000 mm table width: 200 mm oil volume: 350 ltr. operating pressure: max. 296 bar air pressure: 4.5 - 6.0 bar voltage: 400 Volt total power requirement: 18.5 kW weight: 14900 kg range L-W-H: 5180 x 2400 x 3100 mm - in checked condition - machine video - https://www.youtube.com/watch?v=ebbbzSYMxKw Furnishing: - electro-hydraulic CNC die bending/press brake - CYBELEC CNC control ModEva 12S, swiveling at the front right High-resolution graphic color screen 14 inches Representation as a line, area or volume drawing of the product Clear, concise menus in the operators language Large tools and products library - CNC-controlled back gauge adjustment (X-axis) Stop rang ...
pressure: 85.0 t chamfer lenght: 2050 mm distance between columns: 1650 mm column arm: 400 mm stroke: 240 mm dayligth: 320 - 560 mm ajustment speed: 150 mm/sec working feed: 15.0 mm/sec return speed: 150 mm/sec back stop - adjustable: 5.0 - 1000 mm table width: 110 mm work height max.: 1050 mm operating pressure: max. 297 bar compressed air: 4.5 - 6.0 bar oil volume: 200 l operating pressure: 340 bar total power requirement: 7.5 kW weight of the machine ca.: 5900 kg range L-W-H: 4100 x 2100 x 2750 mm with increased installation height / piston stroke well-maintained condition () - in checked condition - machine video - https://www.youtube.com/watch?v=ikl6RNZWeiU Equipment: - CNC electro-hydraulic press brake - including CYBELEC CNC control swiveling control panel at the front right external screen - CNC axis adjustment: Y1 - Y2 - X - R - Z1 - Z2 - I + CNC crowning - CNC electro-motor ...
sheet width: 3200 mm plate thickness: 4.0 mm ST distance between columns: 3300 mm upper clamping bar adjustment: 400 mm Adjustment folding beam: 80.0 mm pivoting angle: 180 Grad clamping capacity max.: 200 KN rear stop: 10.0 - 1600 mm oil volume: 160 Liter total power requirement: 9.8 kW weight: 8500 kg range L-W-H: ~ 4900 x 2000 x 2300 mm From a maintenance workshop Good / well-maintained condition () - in checked conditions - machinevideo - https://www.youtube.com/watch?v=RY-amZooeX4 Equipment: - Robust CNC folding machine - CNC control unit - CYBELEC DNC 80 PP Swiveling control panel, front right 2D graphic display for display and multiple simulation 2D graphic programming Easy handling - CNC electro-motorized backgauge Travel range 10.0 - 1,600 mm Pneumatic / lowerable stop fingers Adjustment speed max. 250 mm/sec. Rear sheet support table with brushes - Electro-motorized l ...
An EHT hydraulic guillotine shear refurbished in 2023 is available. Cutting length: 3000mm, max. sheet thickness steel/VA: 4mm/2mm, backgauge: 10mm-1000mm, adjustment speed: 180mm/s, stroke rate: 18-31 strokes/min, oil volume: 160l. Machine dimensions X/Y/Z: approx. 3700mm/2100mm/2150mm, weight: approx. 4800kg, operating hours: 44024h. The cylinders, blades and hoses were overhauled in 2023. On-site inspection is possible.
sheet width: 3000 mm plate thickness: 4 mm distance between columns: 3050 mm total power requirement: 8 kW weight of the machine ca.: 4.8 t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
