309 DMG MORI 販売のための中古機

CNC立形マシニングセンタ タイプ:MCX 600 V メーカー:DMG森精機 年式:2017年 X:600ミリメートル Y:560ミリメートル Z:510ミリメートル 最大スピンドル速度:12000 rpm 最大ワーク高さ:630 mm ワークの最大長さ:900 mm 最大ワーク幅:560 mm 最大ワーク重量:600 kg 機械重量:4700キロ 非常に良好な状態で、数時間、電力の下で働いた 詳細はこちら - / お問い合わせ先 -

1. CNC旋盤 - DMG MORI SPRINT 20/5 (スイスタイプ): - モデル:SPRINT 20/5 - 製造年:2016 - 最大スピンドル速度:10,000 RPM - 最大バー径:25 mm - 最大トルク:100Nm - 重量:2,150キロ - メーカー:DMG森精機 - 状態:優れた、手入れの行き届いた機械。 2.バーフィーダー - IEMCA SMART 320: - モデル:SMART - タイプ:32 LL - 製造年:2016 - 最大圧力:6バール - 重さ:440キロ - 電圧:200V、三相 - 電流:5A - 周波数:50 Hz - メーカー:IEMCA - 状態:完全に動作し、優れた作業状態にあります。 詳細はこちら - / お問い合わせ先 -

この4軸のDMG MORI NHX 5000は2017年に製造されました。最大回転数は15,000rpm� �、X軸とY軸の移動距離は730mm、Z軸の移動距離は880mm� �す。この機械は500×500mmの堅牢なパレットサイズと40 工具の工具容量を備えています。高品質な加工能力� ��お求めの場合は、当社で販売中のDMG MORI NHX 5000水平機械加工センターを検討してください。詳細 についてはお問い合わせください�

DMG DMU 40 eVo ist ein vertikales Bearbeitungszentrum mit hoher Präzision, Genauigkeit und Zuverlässigkeit. Arbeitsfähigkeiten: Tisch 480x400 mm, 5 T-Nuten (63 mm Abstand, 14H7), Zentrierbohrung 30H6, max. Tischlast 250 kg; Wege X400 Y400 Z375 mm, B -5/+110°, C 360°, Tischdrehzahl 60 t/min. Technische Hauptdaten: Leistung 50 kW, Spindel HSK-A63 bis 24000 min-¹ (stufenlos), Drehmoment 130/86 Nm, Spindelleistung 35/25 kW, Vorschub 0-80000 mm/min, Druckluft 6 bar, 3x400V 50Hz, Abmessungen L2960xB2620xH2530 mm, Gewicht ~7150 kg. Zubehör: FANUC Lade-Roboter, Kühlmittel/IKZ 40/80 bar, TRS2 Werkzeugbruchkontrolle, Laser-Werkzeugvermessung, Späneförderer, Nebelabsaugung, Spülpistole, rotierendes Sichtfenster, Schaltschrank-Klimagerät. Erreicht enge Toleranzen; typische Branchen: Automotive, Luftfahrt, Medizintechnik, Uhrmacherei, Werkzeugbau. Technische Daten ohne Gewähr

NZX 1500/800SY ist ein CNC Dreh-Fräs-Bohrcenter mit hoher Präzision, großer Genauigkeit und Zuverlässigkeit. Kapazitäten: 2 Drehspindeln, 2 Revolver, Schwingdurchmesser 800 mm, max. Drehdurchmesser 320 mm, Stangendurchmesser max. 52 mm; Verfahrwege Z 810 mm, X 210 mm, Y 110 mm (je Schlitten). Technische Daten: Drehzahlen 0–6000 t/min, Spindelleistung 22/18.5 kW, Leistung angetriebene Werkzeuge 7.5/5.5 kW, Spindelnase JIS A2-5, Spindelbohrung 61 mm; Eilgänge X 30 m/min, Z 50 m/min, Y 20 m/min; Maschinengewicht ~8100 kg; Abmessungen L4396×B2835×H2320 mm. Zubehör: direktes Messsystem X-Achse, Beleuchtung, Kühlmitteleinrichtung, Kühlmittel durch die Gegenspindel, Lader-Schnittstelle, Teilefänger, Teileförderband, Späneförderer. Erreicht enge Toleranzen; geeignet für Automotive, Luftfahrt, Medizintechnik, Uhrmacherei und Maschinenbau. Technische Daten ohne Gewähr

DMG MORI EcoTurn 310 ist eine CNC-Drehmaschine hoher Präzision, ausgelegt für hohe Genauigkeit und Zuverlässigkeit. Arbeitsumfang: 3 Achsen; Schwingdurchmesser über Bett 330 mm, über Kreuzschlitten 260 mm; max. Drehdurchmesser 200 mm; Stangendurchlass 51 mm; Verfahrwege Z 455 mm, X 182,5 mm; Eilgang X/Z 30 m/min. Technische Daten: Revolver 12 Positionen mit 12 angetriebenen Werkzeugen; Drehzahl 4.500 min-¹ (stufenlos bis 5.000 min-¹); Spindelaufnahme VDI 30; Morsekonus 4 CM; Gesamtleistung 21 kVA; Gewicht ~3.400 kg; Abmessungen L4400×B2400×H2100 mm. Zubehör: 3-Backenfutter, Satz Spannzangen REGO-FIX ER25, Lampe, Kühlmitteleinrichtung. Eignet sich für enge Toleranzen in Automotive, Luftfahrt, Medizintechnik, Uhrenindustrie und Maschinenbau. Technische Daten ohne Gewähr

control: SIEMENS 840D SL ShopTurn turning diameter: 700 mm swing over bed: 900 mm turning length: 3065 mm c-axis: indexing: 0.001 ° turning speeds: -2500 U/min tool taper: VDI 50 Top turret tool hodler:: 12 tailstock quill taper MT: 5 y-travel: 160 mm rapid traverse X-axis: 40 m/min rapid traverse Z-axis: 30 m/min Overall size: 4450x2100x2350 mm rapid traverse Z-axis: m/min weight of the machine ca.: 7200 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

制御: 製造: SIEMENS 840D x-travel: 600 mm y-travel: 560 mm z-travel: 510 mm テーブルサイズ: 900 x 560 mm スピンドル回転速度範囲: 12000 U/min ツールマガジン::30 機械重量 ca.: 5 t HEIDENHAIN TNC-426 4 軸 用に準備

機械は技術的に良好な状態であり、事前の合意があ� ��ばテストが可能です。シーメンスのショップター� �システム(フィーダーを含む)により、機械は完全に� ��備されています。基本パラメータ 最大作業空間 回転数:≈ 410–500 mm 最大長さ:800 mm 軸間距離:約1020 mm ベッド上方のスイング直径:~700 mm 現実的:シャフト、フランジ、ボディに理想的で最大 ~800 mm 移動軸 X:~480 mm Y:100 mm Z: ~800–845 mm B軸: 110(5軸加工)C軸:360度(インデックス+補間)これにより� �完全な旋盤ミル(クラシック旋盤ではありません)と� ��ります。スピンドル メインスピンドル回転数:~5000rpm 出力:~25–34kW 通過速度:約76–87mm カウンタースピンドル回転数:~6000rpm ミリングスピンドル(クラシック旋盤との主な違 ...

GeneralTraveling column machine; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical50000/50000/50000 mm/minRapid traverse longitudinal/transverse/vertical50/50/50 m/minWorking area 1Longitudinal2000 mmCross800 mmVertical850 mmTool changerType of magazineChain Number of tools40 Max. tool weight8 KgMax. tool length400 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmSwivelhead, B-axisControlled NC swivel milling head 15,000 rpm (B-axis) with clamping in position Continuously positioning NC- swivel milling head with integrated motor spindle for 4/5 axes positioning and simultaneous machining. Swivel speed: 50 rpm Swivel range: ±12 Drive power (100% DC) 16 kWDrive power (40% DC) 21 kWTorque (100% DC) 85 NmTorque (40% DC) 111 NmSpeed range 20 - 15000 rpmSpindle taper SK40 Tool holder D ...

GeneralUniversal Milling Machine Stealth Design; Control: CELOS X with HEIDENHAIN TNC7 Working area 1Longitudinal550 mmCross450 mmVertical420 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/mininlineMASTER® spindlespeed range 20 - 15.000 min-1 SK40 suitable for BIG-PLUS® tools Drive power (100% DC) 14,5 kWDrive power (40% DC) 20,3 kWTorque (100% DC) 84 NmTorque (40% DC) 121 NmSpeed range 20 - 15000 rpmSpindle taper SK40 Tool holder DIN ISO 7388-1-A Clamping System DIN ISO 7388-3-A, AD Tool clamping for HSK-A63Tool clamping HSK-A63 according DIN 69893 (incl. adaptation working spindle and tool magazine) NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 505 x 500mm / 19.9 x 19.6 in swivel range -35 to +110°, rotary axis 360° including direct measuring sys ...

GeneralUniversal Milling Machine Stealth Design; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal550 mmCross450 mmVertical420 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/mininlineMASTER® spindlespeed range 20 - 15.000 min-1 SK40 suitable for BIG-PLUS® tools Drive power (100% DC) 14,5 kWDrive power (40% DC) 20,3 kWTorque (100% DC) 84 NmTorque (40% DC) 121 NmSpeed range 20 - 15000 rpmSpindle taper HSK-A 63 Clamping System HSK-A 63 Toolchanger with set up station for tool loadingNumber of tools 30

GeneralHigh dynamic Vertical Drill-Tap centre with best milling performance; Control: 3D-control Siemens 840D sl Operate Working area 1Longitudinal350 mmCross420 mmVertical380 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minIntegrated swivel rotary table simultaneousIntegated swivel rotary table DMP 35 version 5-Axis simultaneous mode! Torque drives incl. direct measuring in A- and C-Axis Swivel range A-Axis -120 / + 100 degrees Max. load C-axis 100kg Table diameter C-Axis d290mm Rotary joint, 6-channels Inclusive So Tool magazine 25 placesTool magazine 25 places (suitable for inclusion in the tool spindle) Max. tool length 150 mm Chip-to-chip time 1.6 sec Note: machine width increases to 1410 mm! Spindle speed 24,000 rpmSpindle 24,000rpm with tool taper ISO 7388-2 - J30 BT30 / BBT 30 (BIG PLUS ...

GeneralCNC Turning Centre with C axis and tool drive; Control: M730BM with MAPPS IV CharacteristicsMax machining diameter356 mmMax. Turning Length510 mmSwing- Ø, max.755 mmBar diameter max.65 mmSpeed max.-5000 rpmNumber of tool stations20 Rotary tool spindle speed10000 rpmMovements X / Z260/590 mmInput precision of C-axis on Mainspindle0,001 degreeRapid feed X / Z30/30 m/minDrive power main spindle15/15/11 kWDrive power tool spindle5,5/5,5/3,7 kWDimensions (L x W x H)2,82 x 2,09 x 2,15 mWeight approx.5000 KgCELOS - ERGOline TouchCELOS - ERGOline Touch to facilitate machine operation incl. 21.5 " ERGOline Touch ® control with multi touch screens Uniform management, documentation and visualization of order, process - and machine data Networkable with CAD / CAM User friendly and p (Spindle 1) Standard spindle 15 / 11 kW, 5,000min-1(Spindle 1) Standard Spindle 15/11 kW (20/15 HP), 5,0 ...

GeneralCNC Turning Centre with C and Y axis and tool drive; Control: Control M730UM with CELOS CharacteristicsMax machining diameter356 mmMax. Turning Length510 mmSwing- Ø, max.755 mmBar diameter max.65 mmSpeed max.-5000 rpmNumber of tool stations12 Rotary tool spindle speed10000 rpmMovements X / Z260/590 mmInput precision of C-axis on Mainspindle0,001 degreeRapid feed X / Z30/30 m/minDrive power main spindle15/15/11 kWDrive power tool spindle5,5/5,5/3,7 kWDimensions (L x W x H)2,82 x 2,09 x 2,15 mWeight approx.5000 KgCELOS - ERGOline TouchCELOS - ERGOline Touch to facilitate machine operation incl. 21.5 " ERGOline Touch ® control with multi touch screens Uniform management, documentation and visualization of order, process - and machine data Networkable with CAD / CAM User friendly and p (Spindle 1) Standard spindle 15 / 11 kW, 5,000min-1(Spindle 1) Standard Spindle 15/11 kW (20/ ...

General2 spindles automatic lathe - 2 cross slides - Main and counter spindle - Y axis on slide 1 - Y axis on slide 2 - C axis on main spindle - C axis on counter spindle - Chip tank with coolant system and coolant pump - Part unloading chute; Control: Numeric control Fanuc 32i Working areaBar diameter max.20 mmConveyor belt for finished workpiecesConveyor belt for finished workpieces outside the machine Special equipmentEmulsion kit Special equipment980-liter emulsion tank. 8/20 bar + cooler

This 5-axis DMG MORI DMU 95 Monoblock was manufactured in 2016. It features a tool capacity of 60 tools and is equipped with a Heidenhain TNC640 control unit. The machine includes an internal coolant supply of 40 bar and a Blum laser tool measurement system. If you are looking to get high-quality machining capabilities, consider the DMG MORI DMU 95 Monoblock vertical machining centre we have for sale. Contact us for further details.

GeneralUniversal Milling Machine Stealth Design; Control: CELOS X with HEIDENHAIN TNC7 Working area 1Longitudinal550 mmCross450 mmVertical420 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/mininlineMASTER® spindlespeed range 20 - 15.000 min-1 SK40 suitable for BIG-PLUS® tools Drive power (100% DC) 14,5 kWDrive power (40% DC) 20,3 kWTorque (100% DC) 84 NmTorque (40% DC) 121 NmSpeed range 20 - 15000 rpmSpindle taper HSK-A 63 Clamping System HSK-A 63 Toolchanger with set up station for tool loadingNumber of tools 30 IoTconnectorIoTconnector The IoTconnector allows the use of online services of DMG MORI (e.g. NETservice) NETserviceNETservice Qualified support by Internet-based remote diagnostics Messenger V4Messenger V4 Clear presentation of the machine live status. Service AgentService Agent Overv ...

GeneralUniversal Milling Machine Stealth Design; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal550 mmCross450 mmVertical420 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/mininlineMASTER® spindlespeed range 20 - 15.000 min-1 Drive power (100% DC) 14,5 kWDrive power (40% DC) 20,3 kWTorque (100% DC) 84 NmTorque (40% DC) 121 NmSpeed range 20 - 15000 rpmSpindle taper HSK-A 63 Clamping System HSK-A 63 Tool clamping for HSK-A63Tool clamping HSK-A63 according DIN 69893 (incl. adaptation working spindle and tool magazine) NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 505 x 500mm / 19.9 x 19.6 in swivel range -35 to +110°, rotary axis 360° including direct measuring system for B- and C-axis and working plane transformation Tool magazi ...

GeneralUniversal machining centre New DMG MORI Design; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical50000/50000/50000 mm/minRapid traverse longitudinal/transverse/vertical50/50/50 m/minWorking area 1Longitudinal400 mmCross400 mmVertical375 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight6 KgMax. tool length300 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmFloor space/WeightDimensions (L x W x H)6,21 x 6,58 x 2,69 (6,21 x 7,38 x 2,69) mWeight approx.7200 KgPackage Mill / TurnPackage Mill / Turn NC-Mill-turn table 450x450 mm / 17.7x17.7 in rounded down to d460 mm / 18.1 in C-axis direct drive, speed max.1,200 rpm Integrated balancing system Motorspindle 20-20,000 rpm power 35/25 kW (40/100% ED) tool taper HSK-A63 according D ...

GeneralUniversal Milling Machine Stealth Design; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal550 mmCross450 mmVertical420 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/mininlineMASTER® spindlespeed range 20 - 15.000 min-1 SK40 suitable for BIG-PLUS® tools Drive power (100% DC) 14,5 kWDrive power (40% DC) 20,3 kWTorque (100% DC) 84 NmTorque (40% DC) 121 NmSpeed range 20 - 15000 rpmSpindle taper HSK-A 63 Clamping System HSK-A 63 Tool clamping for HSK-A63Tool clamping HSK-A63 according DIN 69893 (incl. adaptation working spindle and tool magazine) NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 505 x 500mm / 19.9 x 19.6 in swivel range -35 to +110°, rotary axis 360° including direct measuring system for B- and C-axis and worki ...

GeneralVertical Machining Centres; Control: Control F0iMF CharacteristicsTable surface1400 x 560 mmMaximum load (table centre)1000 KgSpeed max.12000 rpmDrive power (100% DC)11 kWDrive power (25% DC)15 kWTool Magazine with60 PositionsSpindle taperBT 40 Movement X / Y / Z1100/560/510 mmRapid feed X / Y / Z36/36/30 m/minDimensions (L x W x H)3,19 x 2,76 x 2,94 (3,82 x 3,58 x 3,01) mWeight approx.5500 KgStandard spindle 12,000 min-1, 15/ 11 kWStandard Spindle 12,000 min-1, 15/ 11 kW Spindle speed: 12,000 min-1 Output: 15/13/11 kW (20/17.33/15 HP) (25%ED/30min/cont) Torque: 119/70/57 Nm (87.76/51.62/42.04 ft·lbf) (25%ED/30min/cont) Spindle Taper 7/24 Taper #40/ Grip MAS <BT40>Spindle Taper 7/24 Taper #40/ Grip MAS <BT40> This specification uses the spindle No. 40 7/24 taper / Grip MAS tool holder. The grip type and retention knob type of ATC are specified separately. Retention Kn ...

GeneralHigh dynamic Vertical Drill-Tap centre with best milling performance; Control: 3D-control Siemens 840D sl Operate Working area 1Longitudinal350 mmCross420 mmVertical380 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minMain driveDrive power (100% DC) 6 kWDrive power (40% DC) 8,5 kWTorque (100% DC) 41 NmTorque (40% DC) 48 NmSpeed range 20 - 15000 rpmSpindle taper BT 30 Clamping System ISO 7388-3 - JD30 Toolchangertoolchanger Type of magazine Wheel Number of tools 15 TableTable surface 740 x 420 mmMaximum load (table centre) 400 KgPreparation NC-Devider EA510 indirectPreparation 4.th axis Lehmann EA 510.L indirect measuring System Attention: Customer specific optimisations and adjustments are not part of delivery! Chip removal package with chip conveyorChip removal package with chip conveyor ...

GeneralVertical Machining Centre; Control: 3D control Heidenhain iTNC 530 Technical DataFeed rate longitudinal/transverse/vertical1-90000/1-90000/1-90000 mm/minRapid traverse longitudinal/transverse/vertical90/90/90 m/minWorking area 1Longitudinal885 mmCross600 mmVertical600 mmMiscellaneousClamping SystemHSK-A 63 Colour Floor space/WeightDimensions (L x W x H)4,9 x 4,3 x 3,2 mWeight approx.12000 KgCabineFull protection cabin DMC 75 V linear in 5-axes-versionAdditional price DMC 75V linear in 5-axes-version - motion in X=885mm und Z=600mm - spindle speed up to 18.000rpm, - tool-taper HSK-A 63, - swiveling range B-axis +10° to -110°, - swiveling speed B-axis 50rpm, - max. torque 750Nm / 553ft/lbs - clampi Tool magazine 150 pocketsTool magazine 150 pockets Tower type magazine Only available for HSK Tool holders. (differently from standard) Number of tools 150 Preparation measuring probe T ...

GeneralVertical-Machining centre Stealth Design; Control: CELOS with Heidenhain TNC 640 Technical DataFeed rate longitudinal/transverse/vertical1-42000/1-42000/1-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minWorking area 1Longitudinal1450 mmCross700 mmVertical550 mmIntegrated motor spindle speedMASTER®Integrated motor spindle speedMASTER® At speeds > 18.000 min-1, the use of tools with dual contact system (BIG-PLUS®) is stipulated. Drive power (100% DC) 25 kWDrive power (40% DC) 35 kWTorque (100% DC) 86 NmTorque (40% DC) 130 NmSpeed range - 20000 rpmSpindle taper SK40 Tool holder DIN ISO 7388-1-A Clamping System DIN ISO 7388-3-AD TableTable surface 1760 x 750 mmMaximum load (table centre) 1500 KgSlot width 14 mmNumber of Slots 7 Distance between T-Slots 100 mmCabin roofCabin roof In sheet steel design Open and close via front door Special equipmentClampin ...

GeneralVertical-Machining centre Stealth Design; Control: CELOS X with Siemens 840D SL Operate CharacteristicsTable surface1460 x 750 mmMaximum load (table centre)1500 KgTool Magazine with40 PositionsMovement X / Y / Z1150/700/550 mmRapid feed X / Y / Z42/42/42 m/minWeight approx.12900 KgSpindle speed 20 - 12,000 rpm SK50, 288NmSpindle speed 20 - 12.000 rpm SK50 for tool taper according to DIN ISO 7388-1-A50 with power 44/32 kW // 59.0/42.9 hp with torque 288/187 Nm (40/100% DC) (differently from standard) Tool magazine 40 pocketsTool magazine 40 pockets SK50 chain magazine with pockets and double gripper, incl. manually direct loading into the tool magazine Coolant-air blast change-overCoolant - Air-blast changeover external switchable via M-Function Air blast through spindle centreAir blast through spindle centre activated by M function, maintained air with low oil rate Internal coolan ...

GeneralVertical machining center in C-frame-design New DMG MORI Design Direct Measuring system X,Y,Z; Control: CELOS with Heidenhain TNC 640 Technical DataFeed rate longitudinal/transverse/vertical1-42000/1-42000/1-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minWorking area 1Longitudinal650 mmCross520 mmVertical475 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools30 TableTable surface 960 x 570 mmMaximum load (table centre) 800 KgSlot width 14 mmNumber of Slots 5 Distance between T-Slots 100 mmSpindle speed 15,000 rpm, 200 NmMotor spindle speedMASTER® SK 40 Spindle speed 20 - 15,000 min-1 Output 46 kW / 30 kW (62 hp / 40 hp) Torque 200 Nm / 130 Nm (148 ft lbs / 96 ft lbs) (40 / 100 % duty cycle) BIG-PLUS® tools possible Tool magazine 30 pockets SK40Tool magazine 30 pockets SK40 Chain magazine with pockets and with double gripper ...

GeneralVertical machining center in C-frame-design New DMG MORI Design Direct Measuring system X,Y,Z; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical1-42000/1-42000/1-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minWorking area 1Longitudinal650 mmCross520 mmVertical475 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 TableTable surface 960 x 570 mmMaximum load (table centre) 800 KgSlot width 14 mmNumber of Slots 5 Distance between T-Slots 100 mmSpindle speed 20.000 rpmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63 ft lbs) (40 / 100 % duty cycle) Tool magazine 60 pockets HSK-A63Tool magazine 60 pockets HSK-A63 Chain magazine with pockets and with double gripper, incl. manually direct ...

GeneralVertical-Machining centre Stealth Design; Control: CELOS X with Siemens 840D SL Operate CharacteristicsTable surface1460 x 750 mmMaximum load (table centre)1500 KgTool Magazine with30 PositionsMovement X / Y / Z1150/700/550 mmRapid feed X / Y / Z42/42/42 m/minWeight approx.12900 KgSpindle speed 15,000 rpm, 200 NmMotor spindle speedMASTER® SK 40 Spindle speed 20 - 15,000 min-1 Output 46 kW / 30 kW (62 hp / 40 hp) Torque 200 Nm / 130 Nm (148 ft lbs / 96 ft lbs) (40 / 100 % duty cycle) BIG-PLUS® tools possible Tool magazine 30 pockets SK40Tool magazine 30 pockets SK40 Chain magazine with pockets and with double gripper, incl. manually direct loading into the tool magazine Coolant-air blast change-overCoolant - Air-blast changeover external switchable via M-Function Air blast through spindle centreAir blast through spindle centre activated by M function, maintained air with low oil  ...

GeneralVertical Machining Center; Control: Control SIEMENS SINUMERIK ONE CharacteristicsTable surface850 x 650 mmSpeed max.12000 rpmDrive power (100% DC)9 kWDrive power (40% DC)13 kWTorque (100% DC)57 NmMax. torque83 NmTool Magazine with24 PositionsSpindle taperSK 40 DIN 69871 Movement X / Y / Z550/550/510 mmRapid feed X / Y / Z24/24/24 m/minDimensions (L x W x H)3,07 x 2,67 x 2,84 mWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D200 mm) Tropical PackageTropical Package Option includes: - Active cooling unit for electrical cabinet - Additional ventilator for control panel Recommended from 35°C to max. 45°C environmental temperature SK40 interfaceTool clamping SK 40 for pull-studs DIN 69872 Signal lamp with 4 colours standardSignal lamp with 4 colours Red: General error Yellow: Intervention nec ...
