Model
(Producent: DECKEL MAHO)
To trójosiowe pionowe centrum obróbki DECKEL MAHO DMC 63V zostało wyprodukowane w 1997 roku. Posiada skok osi X 630 mm, 500 mm w osi Y oraz 500 mm w osi Z. Maszyna wyposażona jest w magazyn narzędziowy o pojemności 24 narzędzi oraz maksymalną prędkość obrotową 8000 obr./min. Jeśli zależy Ci na wysokiej jakości obróbce, rozważ DECKEL MAHO DMC 63V, którą mamy na sprzedaż. Skontaktuj się z nami po więcej informacji.
Pionowe centrum obróbcze CNC DECKEL MAHO DMC 63 V zostało zbudowane w Niemczech w 2005 roku. Maszyna wykorzystywana w produkcji seryjnej i jednostkowej, charakteryzuje się dużą wydajnością obróbczą oraz stabilną konstrukcją ze wzmocnionym stołem roboczym, co zapewnia najwyższą możliwą precyzję frezowania. Zainstalowany sterownik CNC FANUC 180i-MB dodatkowo gwarantuje bezawaryjną pracę maszyny oraz wykorzystanie jej pełnego potencjału i możliwości. Centrum obróbcze CNC DECKEL MAHO GILDEMEISTER jest serwisowane na bieżąco i do tej pory przepracowało 26040 godzin. Dane techniczne centrum frezarskiego DECKEL MAHO DMC 63 V - wymiary stołu roboczego (dł. x szer.): 800 x 500 mm - posuwy w osi X/Y/Z: 630/500/500 mm - dokładność pozycjonowania osi X,Y,Z: 0,010 mm - maksymalna prędkość obrotowa wrzeciona: 10000 obr/min - stożek wrzeciona: SK 40 - 24-poz ...
Ten trzyosiowy DECKEL MAHO DC 100V został wyprodukowany w 1995 roku. Posiada sterowanie Siemens 840D, stół maszynowy o wymiarach 1250 x 800 mm oraz skoki 970 x 755 x 490 mm w osiach X, Y i Z. Z maksymalną prędkością 18 000 obr./min i 24 pozycjami narzędziowymi, to pionowe centrum obróbki jest nadal produkowane. Rozważ możliwość zakupu tego pionowego centrum obróbki DECKEL MAHO DC 100V. Skontaktuj się z nami, aby uzyskać więcej informacji.
To 4-osiowe poziome centrum obróbki DECKEL MAHO DMC 50 H zostało wyprodukowane w 2001 roku. Idealny do precyzyjnej obróbki, oferuje solidną konstrukcję i niezawodne osiągi. Skontaktuj się z nami, aby uzyskać więcej informacji o tej maszynie.
Podwójna paleta Jednostka sterująca: Siemens 840D Ruch :X: 560 mmY: 510 mmZ: 560 mm B: 360° Prędkość obrotowa: 18.000 obr./min Wymiary stołu: 400 mm x 400 mm Zmieniacz narzędzi: 60 pozycji Przenośnik wiórów, jednostka pomiarowa narzędzi, jednostka płynu wysokiego ciśnienia Można go kontrolować pod wpływem zasilania
x-travel:630 mm y-travel:560 mm z-travel:560 mm weight of the machine ca.:6,5 t Number of axles:5 St. spindle turning speed range:18.000 U/min numbers of tools in magazin:24 tool taper:SK 40 Round Table B-Axis
x-travel:700 mm y-travel:550 mm z-travel:500 mm tool taper:SK40 spindle speed max.:12.000 U/min Tool changer:30 fach electronic handwheel chip conveyor
x-travel:630 mm y-travel:560 mm z-travel:560 mm total power requirement:10 /15 kW weight of the machine ca.:6500 kg dimensions of the machine ca.: 4,4 x 5,4 x 2,9 m Table dimensions:1000 x 610 mm Loading:400 kg rapid traverse::X 26, Y 26, Z 20 m/min speeds::20 - 12.000 min -1 tool taper:SK 40 Number of tools:20 ( 2 x 10 ) St. control:CNC MillPlus/TNC430 Documents:vorhanden
2005Siemens 840D Powerline ShopMillØ630 x 500 mm200 kg115° (-5°/+110°)500 mm450 mm400 mm20-10,000 rpm9 kW13 kW82 Nm0.010 mm0.01 mm24 m/min20 m/minChain magazine with double gripper, 30 positions SK40 (DIN 69871)80-130 mm (speed dependent)290 mm6 kg80 l17 kW4,860 x 4,350 x 2,424 mm2,210 x 2,120 x 2,150 mm4.05 t35,880 h9,609 h400 V / 50 HzDirect linear encoders (X/Y/Z)Heidenhain TS641 (infrared)
x-travel: 500 mm y-travel: 400 mm z-travel: 400 mm Control: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 1040 mm y-travel: 600 mm z-travel: 500 mm Control: Heidenhain iTNC 530 table surface area: 1250 x 600 mm table load: 600 kg tool taper: SK 40 spindle turning speed range: 1 - 8000 U/min max. torque on the spindle: (S1/S6) 140/200 Nm feed range: 40000 mm/min rapid power traverse in X-and Z direction: 70 m/min rapid motion - y-axis: 40 m/min spindle drive: (100/40 % ED) 13/19 kW total power requirement: 39 kVA weight of the machine ca.: 8,9 t dimensions of the machine ca.: m Operating hours 70294 Spindle hours 23335 Please note the enclosed geometry measurement report with the tool pull-in force measurement. Equipment: CNC control Heidenhain iTNC 530 Electronic handwheel Heidenhain HR 410 Motor spindle with increased torque Direct path measuring system in Y-Z axis Preparation for measuring probe 30-station tool changer, tool diameter 100/140 mm, length 300, weight 7 kg ROTOCLEAR ...
x-travel: 730 mm y-travel: 560 mm z-travel: 560 mm control: iTNC 530 Heidenhain NC-Swivle milling head:: turning speed range - main spindle: max. 18.000 min/-1 power capacity - main spindel: 10 / 15 kW max. Torque: 130 / 87 Nm tool taper: HSK-A63 swivellable: NC: +30 / -120 ° work table:: table surface area: 1.000 x 600 mm T-slots: 9x 14 x 63 mm NC-Rotary table:: table diameter: 600 mm rotatable: C: 360 ° max. table load: 500 kg tool magazin:: number of toolpositions: 60 pos. tool taper: HSK-A63 total power requirement: 40 kVA weight of the machine ca.: ca. 11,0 t dimensions of the machine ca.: 4,5 x 4,5 x 3,5 m Documents: Chip conveyor: Coolantsystem: high pressure coolant: 20 bar Coolant through spindle: AD turning milling head: NC NC-rotary table: elektr. hand wheel: test probe: TS 640 Heidenhain elektr. hand wheel: iTWC 530 tool setting: BLUM Laser 3D quickSET: Signal lam ...
x-travel: 1.000 mm y-travel: 1.000 mm z-travel: 1.000 mm Control: 840 D Siemens Main spindle:: turning speed range - main spindle: 20 - 18.000 min/-1 power capacity - main spindel: 28 / 19 kW max. Torque: 121 Nm tool taper: HSK-A63 NC-Swivle milling head:: swivellable: B: -30 / +180 ° swivle time: 1,2 s pallet changer:: numbers of pallets: 2 size of pallet: 1.000 x 800 mm max. workpiece weight: 1.500 kg rotatable: C: 360 ° tool magazin:: number of toolpositions: 180 pos. tool taper: HSK-A63 total power requirement: 78 kVA weight of the machine ca.: 27,0 t dimensions of the machine ca.: 8,0 x 7,0 x 3,4 m Documents: Chip conveyor: Coolantsystem: through spindle coolant: pallet changer: Automatic Tool Changer: full splash guard: Rotary screen: elektr. hand wheel: 5 Axis - CNC Machining Center Universal DECKEL MAHO - DMC 100 U duoBLOCK - Swivel-Milling-Head (B-Achse) - NC-Rota ...
x-travel: 2.600 mm y-travel: 700 mm z-travel: 700 mm control: iTNC 530 Heidenhain Main spindle:: turning speed range - main spindle: 20 - 18.000 min/-1 power capacity - main spindel: 35 / 25 kW tool taper: SK 40 work table:: table surface area: 2.900 x 700 mm max. table load: 2.150 kg tool magazin:: number of toolpositions: 30 pos. tool taper: SK 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 130 mm max. tool length: 300 mm max. tool weight: 6,0 kg feeds:: rapid traverse ( X / Y / Z ): 40 m/min feed speeds: max. 40.000 mm/min feed power: max. 8 kN total power requirement: 54 kVA weight of the machine ca.: 14,4 t dimensions of the machine ca.: 8,0 x 5,6 x 2,8 m Chip conveyor: Coolantsystem: high pressure coolant: 40 bar through spindle coolant: Rotary screen: 2x Signal-Light: paper band filter: interface 4. axis: indexing attachment: Hofmann - RWNC-220L tool setti ...
x-travel: 630 mm y-travel: 560 mm z-travel: 560 mm control: iTNC 530 Heidenhain Main spindle:: turning speed range - main spindle: 20 - 12.000 min/-1 power capacity - main spindel: 15 / 10 kW max. Torque: 125 Nm tool taper: MAS BT 40 swivellable: B: 103 ° feed:: feed speeds: 20 - 10.000 mm/min rapid traverse X-axis: 26 m/min rapid traverse Y-axis: 26 m/min rapid traverse Z-axis: 20 m/min Resolution: 0,001 mm input unit: 0,001 mm work table:: surface area: 1.000 x 600 mm rotary table dia.: 600 mm number of T-slots: 8 / 1 T-slot - width: 14 H12 / 14 H7 T-slot - distance: 63 mm max. table loading capacity: 350 kg rotatable: C: 360 ° Tool-Presetter:: number of toolpositions: 24 pos. max. tool diameter: 80 mm max. tool-dia with free toolbox: 130 mm max. tool length: 315 mm max. tool weight: 8 kg total wight: max. 100 kg total power requirement: 26 kVA weight of the machine ca.: 6,7 t di ...
x-travel: 630 mm y-travel: 560 mm z-travel: 560 mm control: iTNC 530 Heidenhain NC-Swivle milling head:: turning speed range - main spindle: max. 18.000 min/-1 power capacity - main spindel: 10 / 15 kW max. Torque: 130 / 87 Nm tool taper: HSK-A63 swivellable: NC: +30 / -120 ° work table:: table surface area: 1.000 x 600 mm T-slots: 9x 14 x H7 max. table load: 700 kg tool magazin:: number of toolpositions: 60 pos. tool taper: HSK-A63 total power requirement: 49,7 kVA weight of the machine ca.: ca. 11,0 t dimensions of the machine ca.: 4,5 x 4,5 x 3,5 m Documents: Chip conveyor: Coolantsystem: high pressure coolant: turning milling head: elektr. hand wheel: Rotary screen: paper band filter: Spray gun: exhaust fan: indexing attachment: EA-733.20 Tailstock: CNC - MachiningCenter Universal DECKEL MAHO - DMU 60 monoBLOCK - 4 axes (+ NC dividing head) - Swivel-Millinghead - Spind ...
x-travel: 800 mm y-travel: 800 mm z-travel: 800 mm Control: iTNC 530 Heidenhain Main spindle:: Max. rpm: 18.000 min/-1 power capacity - main spindel: 28 / 19 kW max. Torque: 121 / 82 Nm tool taper: HSK-A63 swivellable: B: 0 - 190 ° swivle time: 1,2 s NC-Rotary table:: table diameter: 900 x 700 mm max. table load: 1.400 kg rotatable: C: 360 ° tool magazin:: number of toolpositions: 40 pos. tool taper: HSK-A63 change-time chip to chip: ca. 5,0 sec feeds:: rapid traverse ( X / Y / Z ): 60 m/min rapid traverse: B: 30 m/min rapid traverse: C: 30 m/min feed speeds: max. 60.000 mm/min total power requirement: 64 kVA weight of the machine ca.: 14,0 t dimensions of the machine ca.: 6,5 x 6,5 x 3,5 m Documents: Coolantsystem: high pressure coolant: through spindle coolant: 40 bar turning milling head: NC-rotary table: Tool Magazine: Chip conveyor: tool monitoring: BLUM Laser elektr. h ...
x-travel: 750 mm y-travel: 600 mm z-travel: 520 mm control: iTNC 530 Heidenhain Main spindle:: turning speed range - main spindle: 20 - 18.000 min/-1 power capacity - main spindel: 35 / 25 kW max. Torque: 130 / 87 Nm tool taper: HSK-A63 NC-Tilting round table:: table surface area: 700 x 500 mm Swivel range B-Axis: 0 - 180 ° Swivel range C-Axis: 0,001 ° max. table load: 350 kg center hole: 30 H6 mm T-slots: 7x 14H7 x 63 mm table turning speeds: 21,5 rpm tool magazin:: number of toolpositions: 32 pos. max. tool length: 315 mm max. tool diameter: 105 mm max. tool-dia with free toolbox: 130 mm max. tool weight: 6,0 kg feeds:: rapid traverse ( X / Y / Z ): 50 / 50 / 50 m/min feed speeds: 20.000 mm/min Feed force: X / Y / Z: 8 / 8 / 7 kN total power requirement: 50 kVA weight of the machine ca.: 8,5 t dimensions of the machine ca.: 6,5 x 3,5 x 3,5 m Documents: Chip-Tray: Coolantsystem: ...
x-travel: 885 mm y-travel: 600 mm z-travel: 600 mm control: iTNC 530 Heidenhain Main spindle:: Max. rpm: 1 - 28.000 min/-1 power capacity - main spindel: 35 / 25 kW max. Torque: 119 / 85 Nm tool taper: HSK A63 Swivel range milling spindle: B: -10° / +110° ° spindle bearing diameter: 80 mm rotary table:: table diameter: 750 mm rotation range: C: 360 ° rotary speed: max. 100 min/-1 max. table load: 600 kg feeds:: feed speeds: 1 - 90.000 mm/min rapid traverse: 90 m/min Feed force: X/Y: 13,8 kN Feed force: Z: 10,35 kN tool magazin:: number of toolpositions: 30 pos. max. tool diameter: 80 mm max. tool-dia with free toolbox: 140 mm max. tool length: 300 mm max. tool weight: 10 kg Workpiece dimension: max. workpiece height: 460 mm Max. Workpiece Area: ca. 750 x 600 mm passage: max. 600 mm total power requirement: 60 kVA weight of the machine ca.: 12 t dimensions of the machine ca.: 4,5 ...
x-travel: 2.200 mm y-travel: 560 mm z-travel: 720 mm control: iTNC 530 Heidenhain turning speed range - milling: 20 ~ 12.000 U/min power capacity - milling spindle: 35 / 25 kW tool taper: SK 40 tool piece magazine with: 100 pos. table surface area: 2.600 x 600 mm rapid traverse X-axis: 100 m/min rapid traverse Y-axis: 50 m/min rapid traverse Z-axis: 50 m/min max. tool diameter: 80 mm max. tool-dia with free toolbox: 130 mm max. tool length: 300 mm max. tool weight: 6 kg max. table load: 2.200 kg total power requirement: kW weight of the machine ca.: 12 t dimensions of the machine ca.: 7,0 x 4,2 x 2,7 m Chip conveyor: Coolantsystem: interface 4. axis: 4. axis: 560 mm Seperating wall: oil mist extraction: Tailstock: 350 mm / MK 5 elektr. hand wheel: through spindle coolant: 40 bar Travelling column milling machine DECKEL MAHO - DMF 220 Linear - new spindle installed (April 2024) - in ...
x-travel: 800 mm y-travel: 800 mm z-travel: 800 mm Control: iTNC 530 Heidenhain Main spindle:: Max. rpm: 18.000 min/-1 power capacity - main spindel: 28 / 19 kW max. Torque: 121 / 82 Nm tool taper: HSK A63 swivellable: B: 0 - 190 ° swivle time: 1,2 s NC-Rotary table:: table diameter: 900 x 700 mm max. table load: 1.400 kg rotatable: C: 360 ° tool magazin:: number of toolpositions: 60 pos. tool taper: HSK A63 change-time chip to chip: ca. 5,0 sec feeds:: rapid traverse ( X / Y / Z ): 60 m/min rapid traverse: B: 30 m/min rapid traverse: C: 30 m/min feed speeds: max. 60.000 mm/min total power requirement: 64 kVA weight of the machine ca.: 14,0 t dimensions of the machine ca.: 6,0 x 6,5 x 3,2 m Documents: Coolantsystem: high pressure coolant: through spindle coolant: 40 bar turning milling head: NC-rotary table: Tool Magazine: Chip conveyor: test probe: Heidenhain TS 640 tool mo ...
x-travel: 880 mm y-travel: 630 mm z-travel: 630 mm control: iTNC 530 Heidenhain Main spindle:: turning speed range - main spindle: max. 18.000 min/-1 power capacity - main spindel: 28 / 19 kW max. Torque: 121 / 82 Nm tool taper: HSK-A 63 swivellable: B: +30° / -120 ° NC-Rotary table:: table surface area: Ø 700 / 1.250 x 700 mm max. table load: 650 kg rotatable: C: 360 ° max. workpiecediameter: 850 mm max. workpiece height: 550 mm tool magazin:: number of toolpositions: 32 pos. tool taper: HSK-A 63 max. tool diameter: 80 mm max. tool-dia with free toolbox: 160 mm max. tool weight: 8,0 kg change-time chip to chip: 10 sec feeds:: feed speeds: max. 30.000 mm/min rapid traverse: 30 m/min Accelaration: 5 m/s² total power requirement: 48 kVA weight of the machine ca.: 14,0 t dimensions of the machine ca.: 6,5 x 5,0 x 2,9 m Documents: Chip conveyor: Coolantsystem: test probe: Heidenh ...
x-travel: 2.200 mm y-travel: 560 mm z-travel: 720 mm control: 840 D Powerline ShopMill Siemens Main spindle:: turning speed range - main spindle: 20 - 12.000 min/-1 power capacity - main spindel: 35 / 25 kW max. Torque: 130 / 87 Nm tool taper: SK 40 internal coolant system feed: 40 bar work table:: table surface area: 2.600 x 600 mm max. table load: 2.200 kg number of T-slots: 6 T-slot - width: 18 H7 mm T-slot - distance: 100 mm Tool-Presetter:: number of toolpositions: 30 pos. max. tool length: 300 mm max. tool weight: 6 kg max. tool diameter: 80 / 125 mm feeds:: feed speeds: 20.000 mm/min input unit: 0,01 mm rapid traverse ( X / Y / Z ): 100 / 50 / 50 m/min measuring system: Resolution: 0,001 mm total power requirement: 60 kVA weight of the machine ca.: 12,5 t dimensions of the machine ca.: 6,0 x 3,7 x 2,9 m Documents: Chip conveyor: Coolantsystem: high pressure coolant: throu ...
x-travel: 760 mm y-travel: 460 mm z-travel: 560 mm control: Sinumerik 840 D PL - Shop total power requirement: 19/28 kW weight of the machine ca.: 13 t dimensions of the machine ca.: 12 Lademeter m Movie: https://www.youtube.com/watch?v=W7csFFlodrQ No. 4100 Bar machining center 5 axes DECKEL MAHO DMC 60 S Working area: 760 x 460 x 560 Drive: 19/28 kW Control: Sinumerik 840 D - Powerline Shopmill NC swivel milling head (B-axis) -120/+30° 60-fold tool magazine with taper cleaning NC rotary axis (A-axis) with collet chuck Spanntop 65, Tailstock, hydraulically lowerable, NC bar loader 1100 mm Workpiece pick-up device with discharge belt Production package with coolant tank 600 l, INTERLIT SKA 200-760 - IKZ 40 bar through spindle center Chip conveyor, Rotating inspection window BLUM tool measuring system Oil mist extraction Operating mode 4 HSK-A 63 spindle Speed range up to 18,000 min-1 Fe ...
x-travel: 640 mm y-travel: 600 mm z-travel: 500 mm Control: SIEMENS 810D powerline table dimensions: 850 x 630 mm table load capacity: 600 KG tool magacine with: 30 Plätzen spindle turning speed range: 12.000 U/min total power requirement: 42 kW weight of the machine ca.: 6,5 t dimensions of the machine ca.: 3,50 x 3,30 x 3,60 m Tool breakage / measurement BLUM Electronic handwheel 3 leveling elements chip conveyor coolant / belt filter system Interlit SPB 3/600 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 640 mm y-travel: 600 mm z-travel: 500 mm control: Siemens 840 D total power requirement: 19 kW weight of the machine ca.: 8 t dimensions of the machine ca.: 5 x 4 x 3 m No. 5312: Vertical machining center DECKEL MAHO type DMC 64 V linear year of construction 2007 Working area: 640 x 600 x 500 mm Drive power: 13/19 kW Equipment: Table 850 x 600 mm ( WITHOUT the clamping devices shown ) Preparation 4th axis Production package / IKZ 40 bar: BFA 600 cooling lubricant cleaning system Integrated spiral chip conveyor Separate scraper belt chip conveyor documentation Miscellaneous: Spindle ISO 40 Speed range 1-12,000 min-1 Space requirement see sketch Transport dimensions approx. 6.5 loading meters Weight approx. 8.8 tons The machine is ready for operation with wear and tear due to age and use. Short video: https://www.youtube.com/watch?v=sDkgx4BYXeY Special price ex works EXW - free l ...
DMF260/11 → Year of manufacture: 2011 Heidenhain TNC 530 Spindle SK 40 – 18,000 rpm Machine hours: 54,877 Spindle hours: 21,845 Condition: second-hand However, it is currently still in use and will be available in 2027 Find more here - .ucymachines/ Contact us at - sales@ucymachines
x-travel: 1.600 mm y-travel: 1.250 mm z-travel: 1.000 mm size of pallet: 1.000 x 1.250 mm control: SIN840D power capacity at 40 % load: 38,00 KW spindle turning speed - stepless: 20 - 10.000 U/min power capacity at 100 % load: 25,00 kW max. torque at 40% / 100% load: 288 / 187 Nm tool taper: SK50 feed X/Y/Z/-axis: 20 - 15.000 mm/min rapid traverse X/Y/Z: 60,00 m/min B - axis: -150° / +80° x 0,001 ° feed B-axis: 3.600 ° / min C-axis: 360 x 0,001 ° Rapid motion C- axis: 1 - 3.600 U / min. table load: 3.000 Kg tool magacine with: 240 tool diameter: 110 mm wotkpiece diameter with 2 vacant positions: 250 mm tool length - max.: 650 mm weight of tools max.: 15,00 kg total power requirement: 75,00 kW weight of the machine ca.: 55,00 t dimensions of the machine ca.: 12,50 x 8,00 x 4,20 m 5-axis machining center with control SIEMENS Sinumerik 840D incl. ShopMill electronical handwheel operati ...
x-travel: 600 mm y-travel: 700 mm z-travel: 600 mm Control: Siemens type: Millplus Table dimensions: 630x500 mm tool taper: ISO 40 Cooling through the spindle: 40 bar Tool changer: 60 Pos. no. of tables: 2 chip conveyor: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Milling head automatically swivels horizontally/vertically The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward ...
używany
x-travel: 800 mm y-travel: 650 mm z-travel: 550 mm control: Heidenhain Millplus tool taper: SK40 total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Serial Number: 71201389 with angle table 900 x +640 25-station tool changer magazine Coolant treatment Interior lighting The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad ...
