Modelo
(Fabricante: DECKEL MAHO)
CNC vertical machining center Type: DMU 80 T Manufacturer: Deckel Maho Year: 2002 Control: Heidenhain TNC 430 X: 900 mm Y: 650 mm Z: 600 mm Spindle speed: 8000 rpm Spindle taper: SK40 Tilting spindle, can be folded and used as a horizontal boring machine Table: 1100 x 650 mm Tool magazine: 24 positions Through spindle cooling 40 bar Chip conveyor Machine in good condition, under power Find more here - / Contact us at -
x-travel: 660 mm y-travel: 500 mm z-travel: 600 mm table surface area: 630 x 500 mm spindle taper: SK 40 spindle turning speed range: 20 - 6.300 U/min feeds: 30 m/min control: PHILIPS CNC 532 internal coolant system feed: 40 bar total power requirement: 50 kW weight of the machine ca.: 13,3 t with rotary pallet changer and hydr. swivelling head (horiz./vert.) Accessories: chip conveyor, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 1.600 mm y-travel: 1.250 mm z-travel: 1.000 mm size of pallet: 1.000 x 1.250 mm control: SIN840D power capacity at 40 % load: 38,00 KW spindle turning speed - stepless: 20 - 10.000 U/min power capacity at 100 % load: 25,00 kW max. torque at 40% / 100% load: 288 / 187 Nm tool taper: SK50 feed X/Y/Z/-axis: 20 - 15.000 mm/min rapid traverse X/Y/Z: 60,00 m/min B - axis: -150° / +80° x 0,001 ° feed B-axis: 3.600 ° / min C-axis: 360 x 0,001 ° Rapid motion C- axis: 1 - 3.600 U / min. table load: 3.000 Kg tool magacine with: 240 tool diameter: 110 mm wotkpiece diameter with 2 vacant positions: 250 mm tool length - max.: 650 mm weight of tools max.: 15,00 kg total power requirement: 75,00 kW weight of the machine ca.: 55,00 t dimensions of the machine ca.: 12,50 x 8,00 x 4,20 m 5-axis machining center with SIEMENS Sinumerik 840D control electronical handwheel operating mode 4 240-p ...
x-travel: 635 mm y-travel: 510 mm z-travel: 460 mm control: iTNC 530 Heidenhain Main spindle:: power capacity - main spindel: 13 / 9 kW turning speed range - main spindle: 20 - 10.000 min/-1 Torque: 83 / 57 Nm tool taper: SK 40 tension force: 10 kN work table:: table surface area: 790 x 560 mm number of T-slots: 4 + 1 T-slot - width: 4 x 14H12 / 1 x 14H7 mm T-slot - distance: 100 mm max. table load: 600 kg table height over floor: 720 mm Tool-Presetter:: number of toolpositions: 30 pos. max. tool diameter: 80 mm max. tool-dia with free toolbox: 130 mm max. tool length: 300 mm max. tool weight: 6 kg Total weight, approx.: max. 60 kg feeds:: feed speeds: max. 20.000 mm/min Feed force: 5 kN input unit: 0,01 mm rapid traverse: 30 m/min total power requirement: 20 kVA weight of the machine ca.: 4,1 t dimensions of the machine ca.: 4,5 x 4,0 x 2,8 m Documents: Coolantsystem: high pressur ...
x-travel: 880 mm y-travel: 630 mm z-travel: 630 mm control: iTNC 530 Heidenhain Main spindle:: turning speed range - main spindle: max. 18.000 min/-1 power capacity - main spindel: 28 / 19 kW max. Torque: 121 Nm tool taper: HSK-A 63 swivellable: B: +30° / -120 ° NC-Rotary table:: table surface area: Ø 700 / 1.250 x 700 mm max. table load: 650 kg rotatable: C: 360 ° tool magazin:: number of toolpositions: 2x16 pos. tool taper: HSK-A 63 max. tool diameter: 80 mm max. tool-dia with free toolbox: 130 mm max. tool weight: 8,0 kg max. tool length: 315 mm feeds:: feed speeds: max. 30.000 mm/min rapid traverse: 30 m/min total power requirement: 48 kVA weight of the machine ca.: 14,0 t dimensions of the machine ca.: 4,5 x 4,0 x 2,6 m Documents: Chip conveyor: Coolantsystem: elektr. hand wheel: test probe: Heidenhain TS 640 Laser: Blum Operation mode 4: Rotary screen: Signal lamp - 4 ...
x-travel: 880 mm y-travel: 630 mm z-travel: 630 mm control: iTNC 530 Heidenhain Main spindle:: turning speed range - main spindle: max. 18.000 min/-1 power capacity - main spindel: 28 / 19 kW max. Torque: 121 Nm tool taper: HSK-A 63 swivellable: B: +30° / -120 ° NC-Rotary table:: table surface area: Ø 700 / 1.250 x 700 mm max. table load: 650 kg rotatable: C: 360 ° tool magazin:: number of toolpositions: 2x16 pos. tool taper: HSK-A 63 max. tool diameter: 80 mm max. tool-dia with free toolbox: 130 mm max. tool weight: 8,0 kg max. tool length: 315 mm feeds:: feed speeds: max. 30.000 mm/min rapid traverse: 30 m/min total power requirement: 48 kVA weight of the machine ca.: 14,0 t dimensions of the machine ca.: 4,5 x 4,0 x 2,6 m Documents: Chip conveyor: Coolantsystem: elektr. hand wheel: test probe: Heidenhain TS 640 Laser: Blum Operation mode 4: 5 Axis CNC - MachiningCenter Un ...
x-travel: 635 mm y-travel: 510 mm z-travel: 460 mm table surface area: 790 x 560 mm spindle taper: SK 40 spindle turning speed - stepless: 20 - 12.000 U/min spindle drive: 13 kW max. torque on the spindle: 83 Nm feeds x/y/z -stepless: bis 20.000 mm/min rapid traverse: 30 m/min ATC: 20 Pos. tool diameter if 2 vacant positions: 130 mm tool diametre at full load: 80 mm tool length - max.: 300 mm weight of tools max.: 6 kg internal coolant system feed: 12 bar control: HEIDENHAIN, TNC 620 total power requirement: 17 kVA weight of the machine ca.: 3,9 t dimensions of machine L x W x H: 3,0 x 1,92 x 2,35 m Accessories: probe HEIDENHAIN, TS 460, electron. hand panel, chip conveyor, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 630 mm y-travel: 560 mm z-travel: 560 mm control: iTNC 530 Heidenhain NC-Swivle milling head:: turning speed range - main spindle: max. 18.000 min/-1 power capacity - main spindel: 10 / 15 kW max. Torque: 130 / 87 Nm tool taper: HSK-A63 swivellable: NC: +30 / -120 ° work table:: table surface area: 1.000 x 600 mm T-slots: 9x 14 x H7 max. table load: 700 kg tool magazin:: number of toolpositions: 60 pos. tool taper: HSK-A63 total power requirement: 49,7 kVA weight of the machine ca.: ca. 11,0 t dimensions of the machine ca.: 4,5 x 4,5 x 3,5 m Documents: Chip conveyor: Coolantsystem: high pressure coolant: turning milling head: elektr. hand wheel: Rotary screen: paper band filter: Spray gun: exhaust fan: indexing attachment: EA-733.20 Tailstock: CNC - MachiningCenter Universal DECKEL MAHO - DMU 60 monoBLOCK - 5 Axis - Swivel-Millinghead The data for this ad was c ...
reus: 8000 min-1 U/min Weight: 5500 kg Year: 2007 Control: Siemens 840D Dimensions (L/W/H): 3600 x 2800 x 2400 mm travel -x axis: 1035 mm travel -y axis: 560 mm travel -z axis: 510 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 600 mm y-travel: 525 mm z-travel: 500 mm table surface area: 1000 x 543 mm spindle taper: SK 40 spindle taper: DIN 69871 spindle turning speed - stepless: 20 - 12.000 U/min feed X/Y/Z-axis: 20 - 10.000 mm/min rapid traverse X/Y/Z axis: 18 / 18 / 15 m/min table load: max. 350 kg control: HEIDENHAIN MillPlus milling-head swivable +/-: 90 ° total power requirement: 26 kVA weight of the machine ca.: 4,2 t dimensions of machine L x W x H: 2,95 x 2,1 x 2,26 m Accessories: various tool fixtures, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 1035 mm y-travel: 560 mm z-travel: 510 mm Control: Heidenhain type: iTNC 530 table surface area: 1400x650 mm workpiece weight: 1000 kg Tool changer: . spindle taper ISO: SK40 Spindle capacity: 10 KW turning speeds: 8000 U/min total power requirement: 20 kVA weight of the machine ca.: . t dimensions of the machine ca.: . m Serial number: 15425033554 Chip conveyor 2 hydraulic vises Operating hours: 53005 Spindle hours: 12233 The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers ...
x-travel: 980 mm y-travel: 630 mm z-travel: 630 mm Control: iTNC 530 total power requirement: 10 / 15 kW weight of the machine ca.: 9,5 t dimensions of the machine ca.: 442,5 m Equipment: Electronic handwheel Operating mode 4 Manual swivel milling head Motor spindle 12,000 rpm SK 40 / Clamping DIN 69872 32-position tool magazine Rigid table 1250 x 700 mm Chip conveyor Coolant device Special price for collection ex works / EXW foundation EXW D-63110 Rodgau List price ex warehouse The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 500 mm y-travel: 400 mm z-travel: 400 mm Control: TNC 426M Heidenhain Main spindle:: turning speed range - main spindle: 20 - 9.000 min/-1 power capacity - main spindel: 9 / 13 kW max. Torque: 57 / 82 Nm tool taper: ISO 40 DIN 69871 swiveling-rotary-table:: table diameter: 700 x 500 mm swivellable: B: 105° (-10°/+95°) man. rotatable: 360° man. max. table load: 200 kg number of T-slots: 7 T-slot - distance: 63 mm T-slot - width: 14H7 mm center hole: 30H7 mm Tool-Presetter:: number of toolpositions: 16 pos. tool taper: ISO 40 DIN 69871 max. tool length: 290 mm max. tool weight: 6,0 kg max. total weight: 50 kg feeds:: feed speeds: max. 10.000 mm/min rapid traverse: 12 m/min input unit: 0,01 mm total power requirement: 17 kW weight of the machine ca.: 3,2 t dimensions of the machine ca.: 4,0 x 4,0 x 2,5 m Documents: Chip-Tray: Coolantsystem: B-axis: man. C-axis: man. Swi ...
x-travel: 835 mm y-travel: 510 mm z-travel: 510 mm distance spindle nose and table: 120 - 630 mm control: iTNC 530 ERGOLine Heidenhain Main spindle:: turning speed range - main spindle: 20 - 10.000 min/-1 power capacity - main spindel: 13 / 9 kW tool taper: SK 40 DIN 69871 max. Torque: 130 / 87 Nm work table:: table surface area: 1.000 x 560 mm max. table load: 800 kg number of T-slots: 5 T-slot - width: 14 mm T-slot - distance: 100 mm Tool-Presetter:: number of toolpositions: 20 pos. max. tool diameter: 80 mm max. tool-dia with free toolbox: 130 mm max. tool length: 250 mm max. tool weight: 6,0 kg feeds:: rapid traverse ( X / Y / Z ): 30 m/min feed speeds: 1 - 20.000 mm/min total power requirement: 23 kVA weight of the machine ca.: 4,0 t dimensions of the machine ca.: 4,5 x 3,5 x 2,7 m Chip conveyor: Automatic Tool Changer: 20 pos. Coolantsystem: elektr. hand wheel: direct probin ...
x-travel: 1.035 mm y-travel: 560 mm z-travel: 510 mm control: iTNC 530 Heidenhain Main spindle:: turning speed range - main spindle: 20 - 10.000 min/-1 power capacity - main spindel: 13 / 9 kW max. Torque: 83 / 57 Nm tool taper: SK 40 DIN 69871 work table:: table surface area: 1.200 x 560 mm max. table load: 1.000 kg table height over floor: 720 mm Tool-Presetter:: number of toolpositions: 30 pos. max. tool diameter: 80 mm max. tool-dia with free toolbox: 130 mm max. tool length: 300 mm change time: 1,6 sec change-time chip to chip: 7,0 sec feeds:: feed speeds: 20.000 mm/min rapid traverse: 30 m/min Feed force: 5 kN total power requirement: 20 kVA weight of the machine ca.: 4,5 t dimensions of the machine ca.: 3,0 x 3,0 x 2,8 m Chip conveyor: Automatic Tool Changer: 30 pos. Coolantsystem: DXF import function: elektr. hand wheel: Operation mode 4: direct travel-measuring-system: ...
2002 Deckel Maho DMU 50T still in use, can be viewed Find more here - / Contact us at -
The 2005 Deckel Maho DMC 104 V linear is a CNC (Computer Numerical Control) vertical machining center manufactured by Deckel Maho, a part of DMG MORI. This machine is known for its precision and efficiency in machining tasks, including milling, drilling, and tapping. Here are some key features and specifications of the 2005 Deckel Maho DMC 104 V linear: - Travel and Table Size: - X-axis travel: Approximately 1040 mm - Y-axis travel: Approximately 600 mm - Z-axis travel: Approximately 500 mm - Table size: Large enough to accommodate substantial workpieces - Spindle: - Spindle speed: High rotational speeds for efficient cutting - Spindle power: Sufficient for heavy-duty machining tasks - Linear Drives: - Equipped with linear drives for the X, Y, and Z axes, providing higher precision and faster movements compared to traditional ball screw drives. - Control System: - Typically equip ...
Máquina: Vert. Cabeça de fresagem Marca: DECKEL, MAHO, WMW, ... São todos giradores e com pena! A - Cabeça de fresagem universal, DECKEL, de FP3, SK40, com curso de penas 80mm, clampagem de ferramenta com hidráulica e painel de controlo. A girar, preço: 1200,- B - Cabeça de fresagem universal, MAHO, SK40, com pena e automático. Clampagem de ferramentas, rotação, L-33cm, W-30, H-60, dispositivo giratório, flange φ aproximadamente 250mm Preço: 1200,- Também teria fusos de fresagem - SK30 - SK40
Fresadora CNC, cobertura FP3A, máquina de peças sobressalentes, controlo defeituoso / incompleto Vendemos peças. desta máquina, Cabeça de fresagem SK40, com pena, trocador de ferramentas, ... Unidade de controlo, mesa, fusos, motores, porcas do fuso, ... Ou total: Euro 1800,- ex-fábrica
This 5-axis DECKEL MAHO DMU 50V was manufactured in 1996. It features a Millplus control system with software version DV400, an external hydraulic unit for clamping devices, and a Hainbuch hydraulic vise for BZI32 collet. If you are looking to get high-quality milling capabilities, consider the DECKEL MAHO DMU 50V machine we have for sale. Contact us for more information about this machine.
Tipo de controlo: CNC Sinumerik 840D-SL x-way 1135 mm y-way 1050 mm z-way 750 mm tamanho de mesa 1400 x 1050 mm Carga de mesa 2500 kg max. tamanho da peça de trabalho LxWxH 1400 x 1240 x 750 mm Velocidade 10000 rpm velocidades de alimentação X/Y/Z Eixo 40000 mm/min Expressspeeds x/y/z 4000mm/min Suporte de ferramentaHS KSK-A100 HSK Número de lugares na revista de ferramentas 30 lugares max. peso da ferramenta 20 kg comprimento da ferramenta 395 mm max. Diâmetro da ferramenta 110 mm Altura da máquina 3294 mm Potência de acionamento - motor de centrifugação 44 kW peso da máquina aprox. 17,9 t Requisitos de espaço aprox. 15 m2 Informação: Máquina de fresagem universal em design mono BLOCK (3 eixos) - disponível setembro 2019 - apenas 3800 horas de fuso, 13400 horas de alimentação Equipamento / Acessórios: - Sistema de refrigeração - ...
This 5-axis DECKEL MAHO DMU 60T was manufactured in 2001. It features an X-axis travel of 630 mm, Y-axis travel of 560 mm, and Z-axis travel of 560 mm. The machine includes a table size of 1000 x 600 mm and a tool magazine with 2x12 positions. If you are looking to get high-quality machining capabilities, consider the DECKEL MAHO DMU 60T vertical machining centre we have for sale. Contact us for further details.
A máquina encontra-se em bom estado técnico, os testes são possíveis mediante acordo prévio.
A máquina encontra-se em bom estado técnico, os testes são possíveis mediante acordo prévio. Distância de deslocação no eixo X: 1.035 mm Viagem no eixo Y: 560 mm Viagem no eixo Z: 510 mm Travessia rápida no eixo X: 30 m/min Travessia rápida no eixo Y: 30 m/min Rotação rápida no eixo Z: 30 m Comprimento de alimentação no eixo Y: 560 mm Comprimento de alimentação no eixo Z: 510 mm Alimentação no eixo X: 30 m/min Velocidade de avanço no eixo Y: 30 m/min Velocidade de avanço no eixo Z: 30 m/min Potência nominal (aparente): 17 kVA Binário: 83 Nm Fabricante do controlador: Sie 137 mm Largura total: 3.355 mm Largura da mesa: 560 mm Comprimento da mesa: 1.200 mm Carga da mesa: 1.000 kg Peso total: 4.250 kg Velocidade do fuso (mínimo): 20 rpm Velocidade máxima do fuso: 8 000 rpm Funcionamento da ferramenta: 20 Comprimento da ferramenta: 300 mm Diâmetro da ferramenta: 80 ...
A máquina encontra-se em bom estado técnico, os testes são possíveis após acordo prévio. O carregador de ferramentas não funciona, é necessário deslocar a mudança manualmente, caso contrário a operação não tem problemas
A máquina está em boas condições técnicas, os testes são possíveis mediante acordo prévio. X=750, Y=650, Z=550, mesa rotativa r=650 Rpm 20k, sistema iTNC 640, apenas 26.500 horas no fuso, 60 ranhuras
A máquina está em boas condições técnicas, após acordo prévio é possível testá-la. X=880, Y=630, Z=630 Mesa rotativa 360, cabeça basculante +120 /-30 32 ranhuras, transportador de cavacos Rpm=12k
N.º : 5211 Tipo: DMU 80 P Produtor: Deckel Maho Gerado: 2000 Parâmetros: Sistema de controle: Heidenhein TNC 430 Horas de ligação: 87285 h Carga Horária: 34100 h Velocidade mínima do eixo vertical: 20 1/min Velocidade máxima do eixo vertical: 12000 1/min Curso do eixo X: 800 mm Curso do eixo Y: 650 mm Curso do eixo Z: 550 mm Cone: ISO 40 Número de todas as ferramentas: 30 peças Equipamento: IKZ Sonda de peças Transportador Arrefecimento do eixo 2020: Substituição dos contatores PILS Novo módulo E/R Novo módulo X/Y 2019: Substituição de fechadura Substituição do sensor da sonda da peça Substituição da mangueira hidráulica da braçadeira da ferramenta 2018: Novo parafuso do eixo X/Y Substituição da persiana do eixo Y Substituição da caixa de velocidades planetária do eixo B Novo motor e cabo de medição ...
x-travel:635 mm y-travel:510 mm z-travel:460 mm turning speed range:20 - 10.000 U/min tool taper:SK 40 table clamping surface LxW:790 x 560 mm Machine with glass scales Full safety cabin with sliding doors + interior lighting Height-adjustable machine shoes 3 pcs.
