Manufacturer: Biesse Selco, Type: EBT 120, Year: 2008, Bench top saw: 4400x2200, Work piece length min-max mm: 4400, Work piece width min-max mm: 2200, Saw blade protrusion: 122, Vorschub Sägewagen : 1-150, Min-max feed programming slider m/min: 100, Saw Blade Diameter mm: 430, Main motor kW: 15, Feeding speed continous adjustable: yes, Scoring Aggregate : 2,2 kW, Work piece length min-max mm: 4400, Work piece width min-max mm: 2200, Feeding speed continous adjustable: yes, Year :2008
Manufacturer: Biesse, Year: 2014, Control: Biesse Works, Work piece width min-max mm: 100 - 1.000, Work piece length min-max mm: 90 - 2.500, Work piece thickness min-max mm: 8 - 60, 3 axis control: yes, Vertical drilling station from below: 1, Vertical drilling station from above: 1, Drilling heads overall: 2, Number of milling spindles: 2, Milling spindles horizontal: 1, Power kW 1: 3,5, RPM min-max 1: 7.000 - 15.000, Vertical drills-X: 2 x 13, Drill vertical Y: 2 x 5, Horizontal drills-X: 2 x 2, Year :2014
Manufacturer: Biesse, Type: Selco EB 108, Year: 2008, Program: Selco Optiplaning, Optimisation: Selco Osi Plus, Max plate format mm: 4200 X 2200, Saw blade protrusion: 107, Cutting lenght mm: 4200, Working hight mm: 95, Vorschub Sägewagen : 100, Network-capable: yes, Angle pressure fixture: yes, Saw Blade Diameter mm: 400, Säge verstellbar über Steuerung: yes, Number of clamping tools: 9, Main motor kW: 13,5, Feeding speed continous adjustable: yes, Feeding from front side: yes, Feeding speed continous adjustable: yes, Year :2008
Manufacturer: Biesse , Type: Skipper 100, Year: 2007, Control: CNI, Online connection: möglich, Machining stations: 2, Work piece width min-max mm: 150-1000, Work piece length min-max mm: 250-3000, Work piece thickness min-max mm: 10-60, 3 axis control: yes, Vertical drilling station from below: 1, Vertical drilling station from above: 1, Double part drilling: yes, Milling spindles vertical: 2, Power kW 2: ca.4, RPM min-max 2: 1800-24000, Vertical drills-X: 13 von unten und oben, Drill vertical Y: 5 von unten und oben, Horizontal drills-X: 4, Drill horizontal Y: 2, Year :2007
Manufacturer: Biesse Bohrgetriebe 11 Spindeln, Stück Bohrgetriebe : 2, Number of drilling spindles: 11, Grid 32 mm: 9/2, Sonderteillung Y mm: 2, Befestigungschrauben: yes, Winkelgetriebe: yes, Aluausführung: yes, angetrieben mittig: yes, Schnellwechselfutter: yes, Anschlusspindel mm: 16, Preis pro Stück Euro: 900,
Manufacturer: Biesse Bohrgetriebe, Stück Bohrgetriebe : 4, Number of drilling spindles: 9, Grid 32 mm: 32, Befestigungschrauben: yes, Aluausführung: yes, angetrieben mittig: yes, Schnellwechselfutter: no M10, Anschlusspindel mm: 16, Preis pro Stück Euro: 300,
Manufacturer: Biesse Bohrgetriebe Spindeln, Sonderbohrgetriebe: yes, Stück Bohrgetriebe : 2 , Number of drilling spindles: 11, Grid 32 mm: yes, Sonderteilung X mm: 5 , Sonderteillung Y mm: 3 + 3, Befestigungschrauben: yes, Schnellwechselfutter: yes, Preis pro Stück Euro: 500,
Manufacturer: Biesse Bohrgetriebe 17 Spindeln, Sonderbohrgetriebe: Ja, Stück Bohrgetriebe : 2, Number of drilling spindles: 17, Grid 32 mm: 32, Sonderteilung X mm: 9/7/1, Anschlusspindel mm: 64, Preis pro Stück Euro: 500,
Manufacturer: Biesse Bohrgetriebe, Sonderbohrgetriebe: yes, Number of drilling spindles: 19, Grid 32 mm: yes 13, Raster 16 mm: yes 6/3, Stahlbohrkopf: yes, gelaufen auf Maschine: biesse, angetrieben mittig: yes, Schnellwechselfutter: yes,
Manufacturer: Biesse Bohrgetriebe 6 Spindeln, Sonderbohrgetriebe: yes, Stück Bohrgetriebe : 2, Number of drilling spindles: 5, Grid 32 mm: 32, Raster 16 mm: 16 versatzt, Sonderteilung X mm: 32, Sonderteillung Y mm: 32, Aluausführung: yes, angetrieben mittig: yes, Schnellwechselfutter: yes, Preis pro Stück Euro: 350,
Manufacturer: Biesse Bohrgetriebe, Sonderbohrgetriebe: yes, Stück Bohrgetriebe : 2 paar, Number of drilling spindles: 6, Grid 32 mm: 5, Raster 16 mm: 1, Sonderteilung X mm: 5, Sonderteillung Y mm: 1, Befestigungschrauben: yes, Aluausführung: yes, angetrieben mittig: yes, Schnellwechselfutter: yes, Preis pro Stück Euro: 250,
Manufacturer: Biesse Bohrgetriebe, Special bore gearbox: Topfbandbeschlag, Stück Bohrgetriebe : 4, Grid 16 mm: 16, Special division X mm: yes, Befestigungsschrauben: yes, Quick-change lining: yes, Price per unit Euro: 400,
Manufacturer: Biesse Bohrgetriebe, Sonderbohrgetriebe: yes, Stück Bohrgetriebe : 4, Number of drilling spindles: 12, Raster: 32, Sonderteilung X mm: 32, Befestigungschrauben: yes, Doppelreihe: yes, Aluausführung: yes, angetrieben mittig: yes, Doppelreihe: yes, Schnellwechselfutter: yes, Preis pro Stück Euro: 700,
Manufacturer: Biesse Bohrgetriebe 9 Spindeln, Sonderbohrgetriebe: yes, Stück Bohrgetriebe : 3, Number of drilling spindles: 9, Grid 32 mm: 32/64, Befestigungschrauben: yes, Doppelreihe: yes, Aluausführung: yes, angetrieben mittig: yes, Doppelreihe: yes, Schnellwechselfutter: yes,
Manufacturer: Biesse , Type: Stream B1 S3, Year: 2005, Control: NC 1600, Min-max edge material mm: 20, Work piece width min-max mm: 65, Min.-max. workpiece length in mm: 150, Min.-max. workpiece height in mm: 60, Min-max feed m/min: 25, Min.-max. batten magazine mm: 20, Bevel milling: yes, radius milling: yes, Radius scraper: yes, Buffing unit: yes, Year :2005
Sanding width 1350 mm. Workpiece thickness: 3 - 200 mm Equipped with 3 aggregates, 1st steelroller, motor 18,5kW 2nd roller 65° Shore, motor 15kW shared with 3th aggregate 3th Kombi unit, combination roller with 45° Shore and pneumatic controlled sanding shoe Electrical height adjustment of the transport table. Pneumatic sanding belt tension. Sanding belt oscillation. Pneumatic sanding belt cleaning Throughput speed with variator Workpiece thickness measurement with manual setting at the machine feed Sanding belt dimensions: 1370 x 2150 mm 4 rollers on in- and outfeed table
4-axis machining center working area: X Y Z : 3060 x 1080 x 155 mm Movement speed X 100 m/min, Y 100 m/min, Z 30 m/min 14 vertical spindles 4 horizontal spindles in X direction 2 horizontal spindles in Y direction Grooving saw 0° - 90° toolchanger 7 positions toolchanger 10 positions Router 7,5 kW, ISO 30 , 1000 - 24000 r/min, c-axis lock milling aggregate available in option
Working field: axis x: 3200 mm, axis y: 944 mm, axis z: 110mm Max programmable speed: axis x: 100 m/min, axis y: 75 m/min, axis z: 15 m/min Drill holder: diameter 10 mm Spindle speeds: 4000 rpm Grooving saw: diameter 120 mm Drill spindles: 24 horizontal spindles in X, 10 vertical spindles in X line Working pressure air pressure: 6 bar Installed power: max 25 kW Capacity of vacuum tools: 40 m³/h CNC: screen: monochromatic 9” Floppy disk unit
Working field: axis x: 2310 mm, axis y: 628 mm, axis z: 90mm Max programmable speed: axis x: 100 m/min, axis y: 75 m/min, axis z: 15 m/min Drill chuck: diameter 10 mm Spindle speeds: 4000 rpm Grooving saw: diameter 120 mm Drill spindles: 4 horizontal spindles in X, 12vertical spindles in X line Working air pressure: 6 bar Max consumption of compressed air: 0,75 NL/cycle Installed power: max 7.5 kW Capacity of vacuum tools: 40 m³/h CNC: screen: monochromatic 9” Floppy disk unit PLC for control of the machine cycle
Edgebander manufactured in 2008. This BIESSE Edge Stream B1 features a comprehensive set of tools including a PU-gluing machine, pre-milling unit, edge trimmer, and fine milling unit. It also includes rounding and edge scraper units, along with swaying brushes and an edge heater. If you are looking to get high-quality edging capabilities, consider the BIESSE Edge Stream B1 machine we have for sale. Contact us for further details.
This BIESSE Levia 110 belt sander was manufactured in 2005. It features a maximum working width of 43 inches and belt capacity of 44 x 85. Equipped with a steel contact roller and a rubber roller, it ensures precise sanding. The machine includes automatic thickness adjustment with a digital display and a variable speed inverter for optimal control. Reach out for more information about this machine.
BIESSE Stream A / 6.0 Máquina de faixas de borda de um só lado para fixação de vários materiais de borda (Melamina, PVC, ABS, Folheado, Madeira) - Ano de construção: 2018 - Incluindo mesa com almofada de ar - Disponível imediatamente - Incluindo desmontagem e carregamento - Incluindo bacias adicionais de cola de substituição
This 5-axis BIESSE ROVER PLAST A FT 1224 was manufactured in 2023. It features a working area of 2465 mm x 1260 mm and a Z-axis stroke of 378 mm. The machine is equipped with a powerful 13 kW machining unit capable of up to 20,000 RPM. If you are looking to get high-quality CNC wood machining capabilities, consider the BIESSE ROVER PLAST A FT 1224 machine we have for sale. Contact us for further details.
This 5-axis BIESSE Rover A FT 2243 including WINSTORE 3D K1 was manufactured in 2014. It operates on a 400 V power supply. With approximately 1,700 hours of axis movement, this CNC wood machining centre is designed for precision and efficiency. If you are looking to get high-quality wood machining capabilities, consider the BIESSE Rover A FT 2243 machine we have for sale. Contact us for further details.
