marchesini 灌装机 二手 出售

MARCHESINI FILLING MACHINE, MODEL MI 200 D.I. Year of construction: 2011 Automatic double-channel linear filling machine for plastic tubes. A great choice for packaging cosmetic and pharmaceutical products. Usable in sterile environments. The customization allows for the maximum production flexibility. possibility of simultaneous installation of different closure systems (metal and hot air) multiple feeding options and adjustable format change via HMI OUTPUT up to 200 pieces/min PRODUCT RANGE Dosage range: 1 - 320 ml Tube height with cap: 50 - 250mm Tube diameter: 11 - 50mm ELECTRICAL CHARACTERISTICS Nominal voltage: 3x400v +N+PE Frequency: 500 Hz 6 kA 18 A OTHER CHARACTERISTICS Weight: 3800 kg

Automatic labeller for the application of one vignette label on the upper panel of carton. Mechanical speed 400 cartons per minute

Automatic, Continuous motion Horizontal Cartoner Marchesini MA 150 Continous motion horizontal cartoner, entirely made with balcony construction, designed around three basic concepts: versatility, ergonomics and maximum efficiency in a small footprint. Because of its characteristics it is the ideal solution for packaging cosmetic and pharmaceutical products. The Model MA150, working with intermittent motion, is indicated for some product types. Main features: Balcony construction, as per GMP norms All feeding groups are located in ergonomic position, in order to make the loading easy for the operator All main drive mechanism are in oil bath, thus reducing maintenance and noise level Easy and fast changeover, entirely made from operator side Touch Screen control panel, for operator interface and machine management Self diagnosis and help functions Possibility to install an au ...

Neri/Marchesini/Garvens/Multipack labelling & packing line for round plastic bottles consisting of: Bottle infeed table, Neri SL 400 self-adhesive labelling machine for bottles, etc., suitable for containers with a diameter from 15 to 80 mm, label height from 10 to 120 mm, conveyor width 80 mm, capacity up to 220 bottles per minute, bottle outfeed table used as a buffer, Cognex camera inspection of the print of the variable data (batch no., expiry date, etc.) on the labels, Marchesini MA155 horizontal cartoner, continuous motion, carton size range: A: 25 – 100 mm, B: 15 – 85 mm, H: 65 – 190 mm, capacity up to 140 cartons per minute, GUK leaflet folder from stack, bar code reader for leaflet, carton and presence of leaflet in the carton, Garvens S2 inline checkweigher with reject device and reject container, weighing range up to 300g, Multipack F40 collator & stretch bander for car ...

Automatic labeller for the application of self-adhesive vignettes and tamper evident seals. Balcony design. Capacity: up to 180 pcs/min. The machine is equipped with: - PLC SIEMENS, type S7-300. - HMI PC SIEMENS IPC 677 - Dopple REAJET printing system, type HRpro with camera control system - Preparation for Vision System LAETUS WT Commandor - Carton Transport Belt: pitch 250 mm - Various control systems for label presence with ejection etc.

Marchesini 3G20100610 turning conveyor for folding cartons, belt width 70 mm, electrics 1x220V+N+PE/50Hz, max. absorbed power 2 A, max. trip out value 6 kA, machine floor space approx. 1300 x 700 mm (LxW), machine height approx. 1600 mm, machine net weight approx. 130 kg

MARCHESINI CASE PACKER PS-300 Year of manufacturing: 2006 Semi-automatic case packer for small to medium output production requirements. For use in various industries, including pharmaceutical, cosmetics, nutraceutical, FMCG, medical devices. Used, in excellent conditions and complete with manuals. Wide range of cases and products working sizes • Case feeding area safe and free from any mechanical movement • Fully enclosed structure with safety guards • Omron HMI • CE marked Output: up to 20 cases/min (depending on product type, individual box and case sizes) Case sizes • Length: 200 mm to 600 mm; Height 65 mm to 400 mm; Width: 125 mm to 400 mm Individual box sizes • Length: 25 mm to 580 mm; Height: 65 mm to 300 mm;Width: 10 mm to 120 mm DIMENSIONS • Size: 2300 mm x 1500 mm (incl. outfeed roller conveyor) x 1900 mm; Weight: 650 kg

Marchesini complete blistering, cartoning and end packing line for capsules and sets of inhalers or similar, comprising: Marchesini MB432 blister machine for capsules, tablets etc. in ALU-ALU blister, max. blister size 210 x 150 mm, max. forming depth 9 mm, output up to 130 blister/min., with forming station for alu-alu blister, feeding system, perforation and cutting station, Videojet 1620 HR Ink Jet Printer, SEA Vision camera inspection for product presence and variable data print control, with SIEMENS SIMATIC IPC677D (Control System & HMI), chiller unit, dust extractor and blister transfer unit to Marchesini M5768 Robotic Island” for packing a set ("boat”) with inhalers or similar, booklet and blister stack, including blister feeding area, booklet feeding, sleeve feeding, inhaler tray feeding, inhaler sleeve feeding and product transfer for all components (blisters, booklet  ...

TONAZZI TUBE FILLING MACHINE COLIBRI 1001 Year of manufacturing: 2003 Automatic machine for filling and sealing tubes. Used in various industries, like the cosmetic, pharmaceutical, food and chemical. CHARACTERISTICS • Ideal for small to medium and large productions • Intuitive operator interface • Includes devices to protect the operator during operation PRODUCTION • Mechanical speed: up to 100 tubes/min. • Tube Size Range (Ø): 10 ÷ 50 mm • Tube Size Range with cap (H): 50 ÷ 250 mm • Filling Capacity: 3 ÷ 390 ml • Mechanical Speed: up to 100 ENERGY CONSUMPTION • Water Consumption (for plastic or laminate tubes only): 180 l/h • Installed Power for plastic or laminate tubes: 9.2 kW • Installed Power for metal tubes: 6.7 kW • Max. Air Consumption at 5 bar (basic machine): 4000 l/h DIMENSIONS • Size (with stirrer): 2150 x 1260 x 2100 mm; Approx. ...

Originates from prominent pharmaceutical manufacturing in Europe. CE Marked. Excellent used condition. Working Description Marchesini Pack Service PS300 semi-automatic case packer for small to medium output production requirements; suitable for: Contract Packing, Pharmaceutical, Cosmetics, Nutraceutical, Medical Devices and other industries. The pre-formed cases must be placed directly on the loading area. Cartons are fed by conveyor from the machine in front of PS300 into its stacking unit, where they are collated upwards, as it is programmed through the Operator Interface Panel. The case is then automatically fed and discharged on a free running conveyor. Wide range of cases and products working sizes Case feeding area safe and free from any mechanical movement Fast and easy change over, with digital indicators and quick fixing o ...

Originates from prominent pharmaceutical manufacturing in Europe. Fully enclosed and guarded structure – extra safety for operators. Working Description: Marchesini Pack Service PS300 semi-automatic case packer for small to medium output production requirements; suitable for: Contract Packing, Pharmaceutical, Cosmetics, Nutraceutical, Medical Devices and other industries. The pre-formed cases must be placed directly on the loading area. Cartons are fed by conveyor from the machine in front of PS300 into its stacking unit, where they are collated upwards, as it is programmed through the Operator Interface Panel. The case is then automatically fed and discharged on a free running conveyor. - Wide range of cases and products working sizes - Cases feeding area is entirely safe, free from any mechanical movement - Torque overloading control on ...

Originates from a prominent pharmaceutical production site in Europe and it is in excellent overall condition - well looked after and serviced on regular basis. Working Description: Automatic Push-O / Press-On 3-head capper suitable for plug caps (please see photos) with an output up to 90 caps per minute (depending on cap type and bottle being processed). Stainless steel fully guarded construction, lastly used with jars of 29.5mm DIA and with caps at 19mm DIA (12.5mm neck) + 16mm cap height + 11.6mm cap height. Stainless steel construction 720mm DIA rotary cap sorter with Perspex cover and lid. Comes with two additional sets of format parts including star wheel and guides. Suitable for Pharmaceutical, Cosmetics, Nutrition, Contract Manufacturing, Food, Medical Devices, Chemical and others. Technical Information: Size (machine): L: 3000m ...

Marchesini BA400 automatic horizontal cartoner for round products - with infeed for tubes. Marchesini BA400 continuous motion horizontal cartoning machine with mechanical output up to 300 boxes per minute (with average production tested output of 260 boxes per minute) - suitable to pre-break and to open either reverse or straight tuck-in three flap cartons, insert product, which has been delivered to infeed, close cartons and discharge. With integrated Marchesini tube infeed and 3-lane tube infeed conveyor (please see photos). Sectors of use: pharmaceutical, chemical, cosmetics, food, dietary, medical devices, contract manufacturing. Year: 1993; S/N: 393000117 Originates from a high-profile Pharma environment, where machine was well looked after, serviced on regular basis and it is in excellent overall condition. Used for round / cylindrical products and lastly run on tubes, be ...

Lieder cream filling machine Speed 20 - 60 pcs / min. Volume 15 ml - 250 ml Induction sealing Capping machine

IMA VIALS LABELLING MACHINE, MODEL SENSITIVE 350 Year of construction: 2010 Labelling machine for vials and bottles. A simple design for effectively handling cylindrical containers. equipped with one side labelling head, for applying the label with high accuracy thanks to an appropriate spacing between the containers and an easy-to-regulate application group labelling unit is installed in the machine basement for direct access to the labelling reels supervision and monitoring of the process through a PLC with a user-friendly HMI TECHNICAL DATA Production details Bottle maximum height (mm): 220 Bottle diameter (mm): 16-78 Maximum output (pieces/minute): 350 Labels Label length (mm): 15-250 Label height (mm): 10-100 Label reel diameter (mm): 400 Label accuracy (mm): ±1 Electrical usage Standard voltage: 400 V – 50 Hz Installed power (kW):  ...

Manufacturer: Rychiger Model: Z-810 Year of Manufacture: 2021 Technical Specifications: - Power Supply: 400V, 3-phase PE N - Rated Power: 5–20 kW - Compressed Air Requirement: 6 bar, 100 l/min Find more here - / Contact us at -

Manufacturer: Elopak Model: PS 50 Type of Machine: Milk Filling Machine Specifications: with capper and cartoner (including spare parts package) Find more here - / Contact us at -

A ViscoTec volumetric filling machine for filling and dosing low to high viscosity products is available. Filling quantity range: 50ml-20000ml, filling capacity: 25l/min, product contact materials: stainless steel 1.4571, machine dimensions X/Y/Z: approx. 1550mm/550mm/750mm, weight: approx. 200kg. Documentation available. On-site inspection is possible.

Height=1.87 m, Overall length= 1.16 m, Overall width= 0.64 m, Net weight= 115 kg,
