ZAYER machine à vendre

Fabricant ZAYER Modèle TEBAS-5000 Année 2013 CNC HEIDENHAIN iTNC-530 HSCI Table Surface de la table 5.200 x 2.200 mm. Poids max. autorisé sur la table 25.000 kg. Distance maximale entre le nez de la tête à 45º et la table en position verticale 1.410 mm. Distance maximale entre le nez de la tête à 45º et la table en position horizontale 1.465 mm. Distance maximale entre le nez de la tête de sortie directe et la table en position verticale 1.420 mm. Voyages et flux Déplacement longitudinal (axe X) 5.000 mm. Traverse transversale (axe Y) 3.750 mm. Déplacement vertical (axe Z) 1.250 mm. Distance entre les colonnes 3.000 mm. Déplacement rapide 50.000 mm/min Avance de travail max. 30.000 mm/min Poupées Tête d’indexation automatique universelle 45º 0.001º/0.001º Cône DIN 69871 AD 50 Pud ISO 7388-2 B 50 Vitesse de rotation de la broche 6.000 tr/min P ...

Fabricant ZAYER Modèle 30 KMU-5000 Année 1999 CNC HEIDENHAIN TNC-430PA Surface de la table 4.700 x 1.200 mm. Courses (X/Y/Z) 3.400/1.250/2.000 mm. Course de la plume (axe W) 500 mm. Cône ISO-50 Puissance du moteur principal 37 kW Tête automatique 45º INCLUSE Tête automatique 45º 0.001º/0.001º Tête 45º Vitesse max. 3.000 tr/min Cône de tête de 45º ISO-50 Tête torsadée contiguë INCLUSE Vitesse maximale de la tête de torsion 3.000 tr/min Cône à tête tournante ISO-50 Bélier avec plume d’oie INCLUS Diamètre de la plume 150 mm. Cône de plume ISO-50 Tête d’arrosage interne et externe 45º et plume INCLUS Tête tournante externe pour liquide de refroidissement INCLUSE Changement de tête semi-automatique INCLUS Changeur d’outils automatique INCLUS Postes au sein de l’ATC 60 Station de ramassage AITEK pour têtes tournantes et 45º INCLUSES ...

Année 2000 CNC SIEMENS 840 D Déplacement longitudinal (axe X) 22.000 mm Traverse transversale (axe Y) 1.500 mm Déplacement vertical (axe Z) 3.000 mm Table Stoller 6000 X 2000 X 300 mm 2 Unid/ 2 Unités Axe X de traversée rapide 10.000 mm/min Déplacement rapide de l’axe Y – Z 15.000 mm/min Avance maximale de travail 5.000 mm/min Cône ISO 50 DIN 69871 AD 50 Vitesses de braquage 6.000 r.p.m. Tête d’indexation automatique 45 º Tête 360.000 Pos. Coude 360.000 Pos. Puissance du moteur principal 37 kw. Nº Changer de gamme 2 gammes Chargeur d’outil automatique INCLUS Outils à l’ATC 30 Arrosage à travers l’outil 20 bar INCLUS Réservoir d’huile soluble avec papier filtre INCLUS Système de refroidissement de la culasse + boîtier CF INCLUS Convoyeur de copeaux longitudinal INCLUS Plate-forme de l’opérateur avec mouvement vertical de 2000 mm. INC ...

Code 8529 Description Fraiseuse à lit CNC Faire Zayer Type 2200 BF 3 Machine nmb 52248 Année 1986 Contrôle Fagor 8020 Taille de la table 2200 x 800 mm Table de mouvement (X) 1830 mm Bélier transversal (Y) 1016 mm Tête de fraisage à traverse verticale (Z) 1016 mm Cône de broche ISO 50 Poids maximum sur la table 4000 kg Lol de vitesses de broche 18 étapes Vitesses de broche 28 - 1800 tr / min Flux dir. Progr. X-Y-Z 3 – 5000 mm/min Rapides Longitudinal 5 m/min Croix 5 m/min Vertical 5 m/min Poids total 10.000 kg Mainmotor 11 kW Connexion d’alimentation 38 KVA Tension 380 Volt Accessoires Tête de fraisage Horiz./Vert. avec ISO-50 Hydr. dispositif de serrage d’outil Condition La machine est en bon état

Machine fixe de fraisage de lit Zayer 2000BF. Tableau: 2500x700mm. Voyage longitudinal: 2000mm. Voyage en croix: 1000mm. Voyage vertical: 1000mm. ISO50. Vitesses: 18. (28-1800rpm). Puissance: 15cv. Poids: 13000Kgs. Équipé de DRO Fagor.

Machine à moudre universelle avec le bélier de mouvement automatique. Tableau: 1700x700. Voyage longitudinal: 1320mm. Voyage en croix: 1016mm. Voyage vertical: 560mm. ISO50. 18 vitesses (28-1800rpm) 18,75 Hp. Poids: 6200Kg.

x-travel: 5.000 mm y-travel: 3.750 mm z-travel: 1.250 mm Control: iTNC-530 HSCI table-size: 5.200 x 2.200 mm distance between columns: 3.000 mm feeds: 50.000 mm feeds: 30.000 mm/min milling head: 0.001º/0.001º tool taper: DIN 69871 AD 50 number of spindle speeds: 6.000 U/min/rpm transmission ratio: 3 spindle drive: 43 kW tool change unit: 20 - fach ( Vertikal) Internal cooling system: 20 bar Chip coveyor: 2 handwheel: HEIDENHAIN HR-520 total power requirement: 122,89 kVA weight of the machine ca.: 33 t Measuring system: M&H PS 20.41 Headstocks: Universal Auto Indexing Head 45º 0.001º/0.001º Taper DIN 69871 AD 50 Spud ISO 7388-2 B 50 Spindle speed 6.000 rpm Speed ranges 3 Main spindle power 43 kW Direct output head reduction 1:2,29 INCLUDED Taper DIN 69871 AD 50 Spud ISO 7388-2 B 50 Spindle speed 2.000 rpm Automatic support for automatic head change (direct exit head) in th ...

This ZAYER KP 6000 AR Milling machine was manufactured in the year 2002 in Spain and has 48852 working hours. It is equipped with a FIDIA C1 control unit and has 5 axis. The machine has a spindle speed of 5500 rpm.

Bed type milling machine ZAYER 30 KF-5000 Table 5000 x 1000 mm. Max allowed weight on the table 10 Tn. Travels: X 4710 mm. Y 1508 mm. Z 2013 mm. Spindle Taper ISO 50 Spindle speed 35-3000 r.p.m. Spindle power 37 Kw Feedrate 6-5000 mm/min Rapid traverse 15,000 mm / min Machine weight 32,000 kgs. Year 2000 Equipped with: CNC HEIDENHAIN TNC 426 Autoindexing milling head 360.000 pos (0.001º). The 2 bodies rotate at the same time. Cooling equipment Chip conveyor

Travelling column milling machine Model: 30 KCU 16000 AR Travels: - X axis: 16000 mm - Y axis: 1500 mm - Z axis: 3500 mm Spindle taper: HSK 100 DIN 69893 Fast forward axis: 25000 mm / min Work feedrate: 6-10000 mm / min Distances between the base area of ​​the machine: - Universal head in horizontal position (bottom): 1255-4755 mm - Universal head in horizontal position (up): 1770-5270 mm - Universal head in vertical position: 1190-4690 mm Motor power: 40 kW AC Spindle speed: 35-4500 rpm with ZF box Year of manufacture: 2003 Machine equipped with: - Heidenhain iTNC 530 CNC - Heidenhain HR 410 electronic handwheel - Tool magazine: 100 units. Load both horizontal and vertical head position. - Pick-up of heads: A / B: 0.001 ° - 0.001 °. 5 continuous axes. DAndrea mandrel head, type UT 5/500 S - Knoll refrigeration system and Typ 250 processing plant with a cap ...

Zayer 5 axis CNC Milling Maching Fidia Control x:3000 y:1500 z:1200

x-travel: 10000 mm y-travel: 1100 mm z-travel: 1700 mm Control: Heidenhain type: TNC 155 Tool changer: 30 table surface area: 10000x1000 mm chip conveyor: universal head: table height over floor: 800 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 1700 mm y-travel: 800 mm z-travel: 890 mm table surface area: 2000 x 630 mm spindle taper: SK 50 spindle turning speed range: 35 - 3000 U/min spindle drive: 26 kW feeds longditudinal/cross/vertical: 6 - 5000 mm/min rapid traverse: 15 m/min table load: max. 6000 kg control: HEIDENHAIN control: TNC 360 total power requirement: 45 kVA weight of the machine ca.: 13 t dimensions of machine L x W x H: 5,2 x 2,78 x 3,0 m Accessories: vertical head swivelling in 2 planes with hydr. tool clamping, various tool fixtures, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Table length: 3000 mm Table width: 1000 mm Longitudinal X: 2705 mm Cross Y: 1209 mm Vertical Z: 1004 mm Positions ATC: 0   CNC Brand: Heidenhain Bed type milling machine ZAYER - 20 KF 3000  Automatic head 2 x 180 Gr Central lubrication Heidenhain TNC 426 Heidenhain HR-410 Handwheel X-Axis:               2705mm Y-Axis:               1209mm Z-Axis:               1004mm Table Length:         3000mm Table Width:          1000mm Table load:           10000 Power on spindle:     22kW Spindle speeds:       3000Rpm Spindle Taper:        50ISO/Bt/Mk Feed rate X-Axis:     15000mm/min. Feed rate Y-Axis:&nb ...

Table length: 800 mm Table width: 800 mm Longitudinal X: 1415 mm Cross Y: 1202 mm Vertical Z: 982 mm Positions ATC: 60   CNC Brand: Heidenhain CNC Model: Heidenhain TNC 415 X-Axis:         1415mm Y-Axis:         1202mm Z-Axis:         982mm Table Length:   800mm Table Width:    800mm Table load:     1500 Power on spindle:22kW Spindle speeds: 1800Rpm Spindle Taper:  Bt-50ISO/Bt/Mk Feed rate X-Axis:15000mm/min. Feed rate Y-Axis:15000mm/min. Feed rate Z-Axis:15000mm/min. Length:         6005mm Width:          4600mm Height:         3530mm Weight:         18000kg

course x: 4000 mm course y: 800 mm course z: 800 mm contrôle: HEIDENHAIN TNC355 taille de la table: 4000x8000 mm fentes en T: 6x mm plage de vitesse de tournage: 30-1800 U/min avance: 5-5000 mm/min Traversée rapide: 15000 mm /min Conicité de la broche: SK 50 Poids de la machine CA.: 15 t Avec commande HEIDENHAIN TNC 355. La machine peut être inspectée sous tension.

Longueur de la table: 2000 mmLargeur de table: 630 mmLongitudinal X: 1700 mmCross Y: 800 mmVertical Z: 800 mmPositions ATC: 0 CNC Marque: HeidenhainCNC Modèle: TNC 426 MAKE   Zayer Espagne TYPE   ZF 2000 ANNÉE   1996 SPÉCIFICATIONS   X - Course  1700 mm Y - Débattement   800 mm Z - Débattement  800 mm lit / plano / portail / colonne  mobile Fraiseuse de lit Contrôle Heidenhain   TNC 426 Table Longueur x Largeur   2000 x 630 mm Charge de table en kG   6000 Kg Broche Taper   Sk 50kW puissance de la broche  15 kW

Longueur de la table: 3000 mmLargeur de la table: 1000 mmLongitudinal X: 2709 mmCross Y: 1212 mmVertical Z: 1501 mmPositions ATC: 40 CNC Marque: HeidenhainCNC Modèle: TNC 426 Make Zayer KFU 3 Type 20 KFU 3000 Année 1995 Zayer KFU avec TNC 426 bedmiller bedfreesmachine Longueur de la table (mm) L = 3.000 Largeur de la table (mm)W = 1.000 Longitudinal X (mm)X = 2,709 Croix Y (mm)Y = 1,212 Vertical Z (mm)Z = 1,501 CNC Heidenhain TNC 426 Iso 50 / 1800 / 22 kWATC Chaîne 40 positionsNC Hor. / Vert 2 Positions

Longueur de la table: 8500 mmLargeur de la table: 1200 mmLongitudinal X: 7400 mmCross Y: 1250 mmVertical Z: 2000 mmPositions ATC: 0 CNC Marque: HeidenhainCNC Modèle: TNC 426 PB MACH-id    4179 MAKE         Zayer Espagne TYPE          30KM ANNÉE         2005 Spécifications X - Débattement        7400 mm Y - Débattement         1250 mm Z - Débattement           2000 mm Contrôle TNC      426 Pb  Longueur de la table x Largeur     8500 x 1200 mm Charge de table en kG     30000 Kg Broche Taper      Bt50 puissance kW sur broche      37 kW Vitesses de broche / plages       3000 rpm Tête de fraisage aut ...

x-travel: 3.400 mm y-travel: 1.250 mm z-travel: 2.000 mm Control: TNC-430PA table-size: 4.700 X 1.200 mm V- travel: 500 tool taper: ISO 50 milling head -swivable: 0.001º/0.001º Grad main drive: 37 kW Chip coveyor: inkl handwheel: HR-410 Tools changer: 60 pos. milling head: Automatic Head 45º weight of the machine ca.: 35 t - Automatic Head 45º INCLUDED - Automatic Head 45º 0.001º/0.001º - Head 45º Max. Speed 3.000 rpm - 45º Head Taper ISO-50 - Twist Head Contiuous INCLUDED - Twist Head Max Speed 3.000 rpm - Twist Head Taper ISO-50 - Ram with Quill - Quill Diameter 150 mm. - Quill Taper ISO-50 - Pick up station AITEK for 45º and Twist Heads - Rotary Table ZEATZ Ø 1200 INCLUDED - RENISHAW MP 16+SP2/1 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 22.000 mm y-travel: 1.500 mm z-travel: 3.000 mm Control: SIEMENS 840 D milling head -swivable: 0,001/0,001 Grad milling head: Universalfräskopf 45° Internal cooling system: 20 bar Chip coveyor: ja Tools changer: 30 pos. coolant: 1.100 l Tool taper: DIN 69871A ISO 50 total power requirement: 45 kW weight of the machine ca.: 68 t The round table shown in the pictures as well as the plate field are not sold with ! urning Speeds 6.000 r.p.m. AutoIndex Head 45 º Head 360.000 Pos. Elbow 360.000 Pos. Main Motor Power 37 Kw. Nº Change Range 2 Ranges Automatic Tool Charger INCLUDED Tools at ATC 30 Coolant Through Tool 20 Bar INCLUDED Soluble Oil Tank with filter paper INCLUDED Head Coolant System + CF Box INCLUDED Longitudinal Chip Conveyor INCLUDED Operator?s Platformd with 2000 mm Vertical movement. INCLUDED Ready for Rotor Translating Table (Regulator + Wires) /IN ...

x-travel: 12000 mm y-travel: 2500 mm z-travel: 1000 mm control: Heidenhain TNC 415 taper ISO: 50 P.D.B. spindle speeds: 20 - 1800 mm voltage: 380 V total power requirement: 37 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 8000 mm y-travel: 2500 mm z-travel: 1000 mm control: Heidenhain TNC 355 taper ISO: 50 spindle speeds: 20 - 1800 mm voltage: 380 V total power requirement: 27,6 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 4700 mm y-travel: 1000 mm z-travel: 1000 mm control: HEIDENHAIN TNC355 table-size: 5000x1000 mm T-slots: 7x mm turning speed range: 2800 U/min feed: 6-5000 mm/min rapid traverse: 15000 mm/min spindle motor: 30,00 kW spindle taper: SK 50 Table load: 10.000 kg Main drive: 40 PS weight of the machine ca.: 27,00 t dimensions of the machine ca.: m With HEIDENHAIN TNC 355 control. Machine can be inspected under power. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 800 mm y-travel: 800 mm z-travel: 5000 mm control: Siemens tool adaptor: ISO 50 number of spindle speeds: 285-3000 voltage: 380 V total power requirement: 36 kW weight of the machine ca.: t dimensions of the machine ca.: m ATC 40 positions 2x workpiece holders with (2x) hydraulic support The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 6000 mm y-travel: 2000 mm z-travel: 3000 mm Control: heidenhain TNC 415 total power requirement: 34 kW weight of the machine ca.: 31 t dimensions of the machine ca.: 7000 mm m Stocknumber 1110055 Type of machine CNC Floortype milling machine Make ZAYER Type KCU6000 Build in 1992 Type of control Heidenhain TNC 415 X-stroke (mm) 6.000 Y-stroke (mm) 2.000 Z-stroke (mm) 3.000 Speeds (Rpm) 20 - 1.800 Admission in spindlehead BT50 Feeds X (mm/R) 5 - 5000 mm/min Feeds Y (mm/R) 5- 5000 mm/min. Feeds Z (mm/R) 5- 5000 mm/min. Rapid feeds 10.000 mm/min. Total Power (KW) 34 Lenght (mm) 11.000 Width (mm) 2.500 Height (mm) 7.000 Weight 31.000 Kg Additional information Juaristi MG6 turntable: 1500 x 1200 mm Cooling system: 2.5 Bar Tool cooling: 15 Bar The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 4700 mm y-travel: 1000 mm z-travel: 1000 mm control: HEIDENHAIN TNC355 table-size: 5000x1000 mm T-slots: 7x mm turning speed range: 2800 U/min feed: 6-5000 mm/min rapid traverse: 15000 mm/min spindle motor: 30,00 kW spindle taper: SK 50 Table load: 10.000 kg Main drive: 40 PS weight of the machine ca.: 27,00 t dimensions of the machine ca.: m With HEIDENHAIN TNC 355 control. Machine can be inspected under power. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
