pressure: 250 t chamfer lenght: 3550 mm distance between columns: 3000 mm Control: Cybelelc DNC 1200 total power requirement: kW weight of the machine ca.: 18.500 kg dimensions of the machine ca.: 4300x2750x3750 mm Accessories: - 2-hand foot switch - Lasersafe Fisseler - Hydraulic tool clamping at top and bottom - Die shift - Hydraulic crowning - Support arms - Cybelec DNC 1200 control - 1 set of upper and lower tools - Controlled axes y1, y2, x, r, z1, z2, inclined stop - Protective grille The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 80.0 t chamfer lenght: 2050 mm distance between columns: 1550 mm column arm: 250 mm table width: 85.0 / 135 mm stroke: ca. 390 mm dayligth: ca. 585 mm ajustment speed: 180 mm/sec working feed: 1.0 - 10.0 mm/sec return speed: 135 mm/sec work height max.: 1050 mm Number of working hours: 32.495 h oil volume: 200 l operating pressure: 320 bar total power requirement: 11.6 KW weight of the machine ca.: 7300 kg range L-W-H: 3700 x 2000 x 3000 mm Good/well-maintained condition () - in checked conditions - machinevideo - https://www.youtube.com/watch?v=IKyUmzB0WTI ------------------------------------------------- CNC electro-hydraulic press brake with: Increased installation height .. approx. 550 mm Increased cylinder stroke .. approx. 390 mm ------------------------------------------------- Features: - Robust electro-hydraulic press brake MADE IN GERMANY () - CYBELEC CNC control ...
pressure: 200 t chamfer lenght: 3050 mm distance between columns: 2550 mm Control: CYBELEC VisiTouch Pac stroke of ram: 524 mm range L-W-H: 4200x2200x3700 mm weight of the machine ca.: 17.000 kg Equipment: - Control conversion 2023 to CYBELEC VisiTouch Pac - controlled axes: Y1, Y2, X, R, crowning - Hydraulic punch clamping - Hydraulic die clamping - 4-stage pneumatic die displacement The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 200 t chamfer lenght: 3050 mm distance between columns: 2550 mm stroke of ram: 274 mm control: Cybelec ModEva Pac weight of the machine ca.: 17.000 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
sheet width: 4050 mm plate thickness: 20 mm distance between columns: 4100 mm column daylight: 4200 mm no. of strokes: 10-20 Hub/min working pressure: 250 bar total power requirement: 85 kW weight of the machine ca.: 43,6 t dimensions of the machine ca.: 5,5x2,8x2,9 m No. 793 Please note: this machine has no electrical system. The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team ...
pressure: 200 t chamfer lenght: 3600 mm distance between columns: 2650 mm dayligth: 500 mm throat: 300 mm stroke: 250 mm working feed: 10,5 mm/sec return speed: 100 mm/sec ram stroke speed: 150 mm/sec table height: 900 mm oil volume: 500 l total power requirement: 37 kW weight of the machine ca.: 17800 kg dimensions of the machine ca.: 3710 x 1800 x 3390 mm Equipment: - Controlled axes Y1 + Y2 - Manual X-axis with digital position display - Set of upper and lower tools - 2x stop fingers - 2x front support arms - Hand and foot controls - Side + rear safety guard - Operating instructions The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Type de presse : presse synchronisée 2 cylindres, force de pression : 125 t, force de pression nominale : 110 t, longueur de flexion : 3000 mm, course de l’arbre : 360 mm, hauteur d’installation : 540 mm, distance entre les cadres : 2550 mm, pression hydraulique : 256 bar, poids : environ 12000 kg, système de commande : Cybelec DNC 7000 Graphic. Y compris divers outils. Le système de contrôle et l’écran ont été renouvelés à la mi/fin 2025. Une inspection sur site est possible.
pressure: 100 t chamfer lenght: 2050 mm distance between columns: 1550 mm throat: 250 mm stroke: 200 mm adjustment of press crosshead: 200 mm stroke speed - idle stroke downwards: 105 mm/sec stroke speed - idle stroke upwards: 180 mm/sec stroke speed - under load: 9,5 mm/sec table width: 200 mm table height over floor: 900 mm dayligth: 280 - 480 mm back stop - adjustable: 3 - 729 mm control: CYBELEC SYNCHRO control: CNC 7400 PS total power requirement: 7,5 kW weight of the machine ca.: 10 t dimensions of machine L x W x H: 3,70 x 2,45 x 2,80 m Accessories: programmable back gauge, table extensions, various upper and lower dies segments The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Fabricant: Weinbrenner Type: TSV 6 / 3050 Année de construction : Machine de démonstration de fin 2015 Longueur de coupe : 3050 mm Capacité de coupe max.: 6 mm (acier) Heures du moteur: 54 Contrôles: Cybelec DNC 60 Dimensions L/W/H: 4100/2050/2100 mm Hauteur de la table: 1000 mm Poids: 8500 kg Angle de coupe min.: 1 Angle de coupe max. 2.5 Numéro d’AVC min.: 20 min. Numéro d’AVC max.: 25 min. Ajustement de l’écart de coupe : moteur Ajustement de l’angle de coupe : hydraulique Nombre de titulaires: 14 Zone d’arrêt arrière : 1000 mm Sécurité : Protection des barrières légères à l’avant et à l’arrière Remplissage d’huile: 225 l Alimentation électrique: 15 KW Valeurs de connexion: 3x 400 V / 50 Hz Préprotection: 50 A Auxiliaire: Extension de l’arrêt latéral à 2050 mm Arrêt latéral pivotant loin latéralement Un total de ...
Largeur de travail: 3050 mm Épaisseur de la feuille: 6 mm Extension: 200 mm Arrêt arrière: 1000 mm Puissance de conduite : 15 kW Exigence d’espace: 4100 x 2300 x 2100 mm Poids: 8500 kg ciseaux de table hydrauliques très bien conservés contrôlés par CNC, avec le contrôle dans le panneau de commande pivotant, Fabr. CYBELEC, CNC 1000, Heures d’exploitation selon le compteur d’heures d’ouverture: 2700 h
Largeur de travail: 4100 mm Épaisseur de la feuille: 16 mm Extension: 300 mm Arrêt arrière: 1500 mm Puissance: 400 V, 45 kW Exigence d’espace: 4800 x 3500 x 2600 mm Poids: environ 28000 kg
