WALDRICH COBURG machine à vendre

N° inv. : 7015 Type: 17-10 FP NC / 5 Producteur: Waldrich Coburg Création : 1985 GO 2011 Paramètres: Système de contrôle 3D: Siemens Sinumerik 840 Longueur de la table: 5000 mm Largeur de la table: 2500 mm Poids max. de la pièce: 60 t Poids: 125 t ALLER: 1997 2008 2011

Machine de fraisage de type portique CNC pour les pièces extra-larges. Fabricant Waldrich Coburg. Modèle S 22-10 GM 500 NC/16 m. Année 1989. Révisé/modernisé/modernisé 2008. Contrôle Siemens 840D contrôle rétrofité. Taille de la table 15000 x 5000 mm. Charge de table max. 15000 kg/m². Distance entre les colonnes : Avec couvercle de colonne 5800 mm. Sans couvercle de colonne 6000 mm. Distance de la broche à la table max. 5000 mm. Voyages: Course longitudinale du portique X 16000 mm. Selle cross course Y 6800 mm. Fraisage vérin course verticale Z 2000 mm. Débattement vertical du rail transversal L 3400 mm. Avant de la broche de fraisage 200 mm. Moteur de broche nominal 150 KW. Plage de vitesse de la broche 6 - 750 tr / min. Pas d’engrenage 2. Couple max. 12900 Nm. Conicité de broche ISO 60. Section de bélier 630 x 680 mm. Révisé en 2008 pa ...

Waldrich-Coburg Guideway et machine de broyage de surface Type: 0-15 SNC 2520X/3m Longueur de broyage maximale: 3420mm Largeur de broyage maximale: 1450mm Hauteur de travail maximale: 1005mm Longueur de la zone de clampage : 3000mm Largeur de la zone de clampage : 1250mm Accessoires: -Finition de table -Système de filtre à bande de papier -Schipmke-Haan DK150-V -Système de recooling Empreinte: 11,8 millions de livres sterling B-4.9m H 4,7m Poids: 29.4 à. Nous attendons avec impatience vos idées de prix. (S’il vous plaît pour les offres) Nous serons heureux de vous envoyer plus de photos par e-mail.

CONTROLS   CNC controls SIEMENS 840 D WORKING RANGE SURFACE GRINDING   grinding length: 8000 mm   grinding width: 2000 mm   workpiece height (max) with largest wheel: 2000 mm TABLE (SURFACE GRINDING)   table surface (left-right): 8000 mm   table surface (front-back): 1800 mm   workpiece load (max): 18000 kg   magnetic table: no SPINDLESTOCK GRINDING SPINDLE   X-axis travel: 8825 mm   Y-axis travel: 3010 mm AXIS DRIVES   traverse velocity X (min): 1000 mm/min   traverse velocity X (max): 45000 mm/min ELECTRICAL SPECIFICATIONS   mains power supply: 160 kVA   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 24360 mm   space requirements -front/back-: 9550 mm    ...

throat: 1410 mm workpiece height max.: 1150 mm stroke: 1400 mm table diameter: 1400 mm milling-head swivable +/-: 10 ram - range of adjustment: 750 mm pulling power: 50000 N workpiece weight: 10000 kg Ram stroke speed: 30 m/min total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

travel -x axis: 7.200 mm travel -y axis: 4.200 mm travel -z axis: 1.750 mm Control: 840D sl daylight: 2300 mm distance between columns: 3500 mm size of pallet: 5000 x 3000 mm table load: 65 t milling drive: 50 kW spindle taper: ISO 60 c-axis: 7500 Nm spindle diameter: 150 mm turning speed range - milling: 10 - 4000 U/min feed - rapid adjustment: 10 - 15000 mm/min b-axis: +/- 90 ° total power requirement: 92 kW weight of the machine ca.: 380 t Planer-Type Milling M/C - Double Column | WALDRICH COBURG - 15S - 10 FPF 300 NC - heavy-duty double-column milling machine (molds and dies) - 2 pallet stations with 2 pallets (load 65to each) - 2009 retrofit to SIEMENS 840Dsl (including complete electric wiring and new switch cabinet) - in 2011 change of all servo drives - 50kW NC universal milling head (2.5deg Hirth)(WALDRICH USP300C450F15S) - 40kW NC-forkhead (2-axis)(WALDRICH UFN00SZ500) - vari ...

throat: 645 mm workpiece height max.: 550 mm stroke: 360 mm table diameter: 650 mm milling-head swivable +/-: 15/80 no. of strokes: 100 Hub/min total power requirement: 6 kW weight of the machine ca.: 4,3 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

This WALDRICH Coburg 30-15 S 3030 Grinding machine was manufactured in 1971 in Czech Republic. It has a travel range of (X) 5.400mm, (Y) 1.700mm, (Z) 1.545mm. Its table is 5,540mm x 1,500mm. It comes with a maximum grinding length of 6,000mm, width of 1,700mm, and height of 1,545mm. Contact us anytime for further information.

x-travel: 11.700 mm y-travel: 6.400 mm z-travel: 975 mm w-travel: 3.500 mm table:: table load: 200 t table width: 3.200 mm table length: 2 x 5.500 mm Passage height: 3.900 mm max. passage: 3.600 mm diameter of quill: mm spindle turning speed range: max. 650 U/min rapid travel x/y/z: 10 / 2,5 / 2,5 m/min output: 100 kW control: SIEMENS 840D Solutionline quill:: ISO 60 + ISO 50 spindle drive: 75 kW electrics - voltage/frequency: 380/50 V/Hz weight of the machine ca.: t dimensions of the machine ca.: m IKZ (not for heads) attachment head: clamping automactically high-speed spindle 35 kW, nmax. 2.400 rpm spindle extension 650 mm angular milling head 4 x 90°- short L = 475 mm angular milling head 4 x 90°- long L:= 1.400 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 15300 mm y-travel: 4950 mm z-travel: 1000 mm w-axis: 3682 mm distance between columns: 5100 mm table load: 400 t milling slide: 120 kW spindle turning speed range: 5 - 600 U/min max. torque on the spindle: kNm tool taper: ISO 50 / 60 feed in x - axis: mm/min feed in y - axis: mm/min feed range Z-direction: mm/min table-size: 15000 x 4500 mm control: Siemens 840C ram head dimension: 600 x 600 mm workpiece height max.: mm total power requirement: - kVA weight of the machine ca.: - t dimensions of the machine ca.: 41 x 13,7 m Portal milling machine equipped with: - CNC control Siemens 840C - Head changing station with X-stations - Coolant system The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 22000 mm y-travel: 7500 mm z-travel: 1750 mm w-axis: 4400 mm distance between columns: mm table load: 500 t milling slide: 105 kW spindle turning speed range: 2000 U/min max. torque on the spindle: 13 kNm tool taper: feed in x - axis: 10000 mm/min feed in y - axis: 10000 mm/min feed range Z-direction: 10000 mm/min table-size: 22000 x ? mm control: Siemens 840C ram head dimension: 600 x 600 mm workpiece height max.: 5300 mm total power requirement: - kVA weight of the machine ca.: - t dimensions of the machine ca.: - m Portal milling machine equipped with: - CNC control Siemens 840C - tool magazine - Head changing station with X-stations - Coolant system with paper belt filter The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 12200 mm y-travel: 4400 mm z-travel: 1000 mm w-axis: 2320 mm distance between columns: 3700 mm table load: 200 t milling slide: 120 kW spindle turning speed range: 6 - 750 U/min max. torque on the spindle: kNm tool taper: ISO 50 / 60 feed in x - axis: mm/min feed in y - axis: mm/min feed range Z-direction: mm/min table-size: 11000 x 3200 mm control: Siemens 840C ram head dimension: 600 x 600 mm workpiece height max.: mm total power requirement: - kVA weight of the machine ca.: - t dimensions of the machine ca.: 33 x 12 x 7,1 m Portal milling machine equipped with: - CNC control Siemens 840C The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 6000 mm y-travel: 1800 mm workpiece height: 1800 mm Control: total power requirement: 55 kW weight of the machine ca.: 52 t dimensions of the machine ca.: 14,3 x 4,6 x 4,7 m Waldrich Coburg Double column planer with hydraulic, infinitely adjustable drive Model TYPE 8 D 4036 Year of construction 1967 Length 13900mm Planing width 2000 mm Table clamping surface Length 6000mm Width 1800mm Height 1800mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Upper support, cross support, cross table, cross slide table -Upper support comes from a Waldrich Coburg portal milling machine type: 12 D 3232-550 HL -Table surface: mm -Travel: x 350 mm/y 220 mm -Dimensions: 1380/1000/H800 mm -Weight: 800 kg

The machine is formed of the following main assemblies: floor table, left and right beds, gantry assembly (a saddle and a column on the each bed , a cross-rail, and a cross beam ) and two milling heads. The gantry is guided by the slideways of the two beds and the cross rail is guided by the slideways of the two columns. The milling heads travel on the cross rail guideways. Inside of the each milling head is guided a ram with the main spindle. Fixed table length 36 000 mm Fixed table width 6 000 mm Distance between columns with covers / without covers 6 900 / 7 100 mm Gantry travel 30 000 mm Cross rail travel 3 100 mm Milling heads (right and left) travel on cross rail 7 400 mm Vertical travel of right and left rams 1 000 mm Gantry work feeds 0 - 6 000 mm/min Gantry rapid feed 10 000 mm/min Milling heads (right and left) work feeds 0 - 3 000 mm/min Milling heads (right and l ...

table diameter: 900 mm Table load: 3000 kg Daylight: 580 stroke: 95-800 mm total power requirement: kW weight of the machine ca.: 8 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding length: 8400 mm grinding width: 1450 mm workpiece height: 1250 mm surface area: 8000 x 1250 mm table height over floor: 920 mm distance between columns: 1470 mm workpiece weight max.: 59700 kg weight of the machine ca.: 59,7 t dimensions of the machine ca.: 22 x 5 x 5 m Adjustment ranges: -Crossbeam, vertical 1250 mm -Grinding support, horizontal 3100 mm Adjustment speeds: -Machine table (X-axis) infinitely variable 1-45 m/min Table creep speed 5 m/min -Grinding support, horizontal (Y-axis) Rapid traverse 3000 mm/min Feed, step 0.001-0.099 mm Feed rate, continuous 100-3000 mm/min Creep speed 18+1 mm/min Tip infeed 0.001-0.019 mm -Crossbeam (W-axis) Rapid traverse 410 mm/min Table drive: -Oil transmission, Type Iv4 -Cylinder-Ø 185 mm -Piston rod Ø 130 mm -Drive motor 22 kW The data for this ad was created with ModulMWS - the  ...

x-travel: 6300 mm y-travel: 2200 mm workpiece height: 1835 mm Table area: 6000x1835 mm Rest: 2 Side head: 2 number of T-slots: 7 T-slot - distance: 240 mm T-slot - width: 28 mm bed length: 14650 mm column daylight: 2075 mm feed: 5-60 m/min workpiece weight: 15000 kg total power requirement: kW weight of the machine ca.: 55 t dimensions of the machine ca.: 14,65x4,37x4,05 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 6600 mm y-travel: 3200 mm z-travel: 1000 mm w-axis: 1750 mm Control: Siemens 840 D column daylight: 2650 mm distance spindle nose and table: 2500 mm table surface area: 6400 x 2250 mm table load: 50 t tool taper: ISO 60 spindle turning speed range: 5 - 2000 U/min table feed: 10 - 15000 mm/min feeds crossrail-slide horizontal: 10 - 10000 mm/min feed: (W) 10 - 2000 mm/min spindle motor: 55 kW total power requirement: 85 kW weight of the machine ca.: 125 t dimensions of the machine ca.: 18 x 9,5 x 6,5 m Machine general overhauled and equipped with SIEMENS 840 D control in 2003 - new digital motors, drive controllers, measuring systems and switch cabinet - tool changer for 60 tools (45 ISO 50, 15 ISO 60) - 3 angular milling heads (HSD 175, WFD 800) with service device 4 x 90 deg. indexing - hydrostatic table guideways - adjustable crossrail - 2 tables coupled - chip conveyor - cool ...

Machine de rabotage hydraulique unique Fabr. WALDRICH COBURG Type 2E 1515Com. -No: 2110108 construit en 1966porteuse combinée et fraiseuse avec accessoire de fraisage amovibleLongueur du planeur: 2000 mmLargeur de la planche: 900 mmHauteur de planification: 750 mmSurface de table: 2000 x 650 mmperpoids de la pièce: 1550 kgfeuille de fraisage11 vitesses de broche: 112 - 1120 tr/minPuissance: 1,5 kWSpeed: 960 tr/min. Porte-outil: MK 3Max. Diamètre de la fraise: 63 mmRéglage axial de la tête de fraisage: 130 mmRéglage vertical: 170 mmRéglage de la tête de fraisage sur la flèche: 630 mmÉraînement du moteur de la pompe d’alimentation: 3 kWFlux d’alimentation en continu Débit: 10 - 4200 mm / minRéversation: 10 - 2800 mm / minDévitesse de levage: 5 mm / minRéglage longitudinal: 2000 mmAvec fixation de fraisage- Fixation de ponçage- Support en acier de rabotage- panneau de co ...

Longitudinale: 0 mm Diffuseur de la table: 0 mm Longitudinale X: 0 mm Cross Y: 0 mm Diversité verticale Z: 0 mm Positions ATC: 0 Distance entre les montants: 0 mm CNC Marque: 0 CNC Modèle: 0 Données techniques Longéarité de la table: 8000 mm Diffus de la table: 2800 mm Accage: Y: 9000 mm A axe: 1250 mm W: 2200 mm Table de distance à broche max.: 2806 mm Distance entre les colonnes : 3200 mm Charge de table max. : 64000 kg Atteindre dans la broche : 60 Vitesses ISO Découpes : numéro (pas) : 16 à partir de : 20 tr/min à : 600 tr/min exe de : 5 mm/min à : 3000 mm/min Y axe de : 5 mm/min à : 3000 mm/min Z axe de : 5 mm/min à : Axe 2000 mm/min W de : 5 mm/min jusqu’à : 750 mm/min Dépendités de crête : axe X : 5 - 3000 mm/min Y : 5 - 3000 mm/min Z : 5 - 2000 mm/min W : 5 - 50 mm/min age 50 Hz 3x : 380 Volt Moteur à broches : 100 kW Meilles globales environ : Détension : ...

x-travel: 17700 mm y-travel: 4755 mm z-travel: 800 mm milling width: 3450 mm distance table - vertical milling spindle: 3682 mm table height over floor: 500 mm spindle diameter in front bearing: 200 mm turning speed range: 12 - 450 U/min tool taper: ISO 60 axial adjustment of the spindle slide: 800 mm creep feed: 5 und 50 mm/min feed stepless: 10 - 3000 mm/min cross adjustment of cross beam milling head: 4745 rapid traverse: 2 m/min creep feed: 3 und 30 mm/min feed stepless: 6 - 2000 mm/min rapid traverse: 2 m/min creep feed: 3 und 30 mm/min feed stepless: 6 - 2000 mm/min vertical adjustment of cross beam: 3682 mm rapid traverse: 1,5 m/min creep feed: 1,25 und 12,5 mm/min feed stepless: 5 - 1500 mm/min table-size: 17800x2800 mm column daylight: 3600 mm Control: SIEMENS 840 C table load: 50.000/100.000 kg drive of main spindle: 100 kW total power requirement: 170 kW weight of the machine  ...

x-travel: 9700 mm y-travel: 3500 mm z-travel: 640 mm w-axis: 3000 mm Control: Siemens type: 840D PL spindle diameter: 200 mm Spindle capacity: 85 Kw surface area: 9000x2800 mm Table load: 40000 kg high speed spindle taper ISO: 50 chip conveyor: coolant: total power requirement: kW weight of the machine ca.: 193,8 t dimensions of the machine ca.: 22,4x10,2x8,2 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
