Stenner resaw line VHET 105, With System TM de-stacking, infeed, outfeed and stacking
Söderhamn chipper canter line, Consisting of, - Log infeed with step feeder, - Log transport with infeed, - Soderhamn chipper canter 240-15, - Outfeed conveyor, - Merry-go-round conveyor system, - Electric cabinets and control units, - Chip and waste conveyor system
HIT automatic edger line with multiple cross cutting and Bongioanni multi ripsaw, Consisting of:, - S-conveyor for separating the boards, - Automatic infeed system, - Automatic optimization LM-Optim, - HIT autmoatic multiple edger, type ASM200, 3 moveable saws, passage width 750 mm, - Outfeed roller conveyor with splitting, - Cross chain transport, - HIT automatic multiple cross cut saw, 3 moveable saws + one fixed saw, - Feed system, - BONGIANNI multi ripsaw, type MH 650-190, double arbor, cutting height 190 mm, max. width 650 mm, - Outfeed system, - Schiepe automatic stacker, - Zimac automatic stacker, Full line in excellent condition.
SCHULTE horizontal log bandsaw line, type HB 12, - Max. log diamter 1250 mm, - Cutting length up to 12 m, - Motor power 37 kW, - Hydralulic log carriage, - Mudata cutting thickness setup
WACO resaw line BKW-Twin, With Jonab de-stacking, infeed and outfeed
LBL Brenta autmoatic multiple edger, type Oxia 150, Passage width 1000 mm, cutting height 150 mm, Motor 90 Hp
ARTIGLIO log band saw line SNT 140 - Eagle 1100, Manufacture year 2004, Sawmill line suitable for cutting logs up to 18 meters, Consisting of:, - Log infeed conveyor with log loading device, - ARTIGLIO 2 module - hydraulic log carriage, type Eagle 1100, module 1 with 4 pc. hydraulic headridges, module 2 with 2 pc. hydraulic headridges, It is possible to cut with only module 1 or together module 1+2, - ARTIGLIO hydraulic driven rope feeding, Incl. rails and guiding rollers, - ARTIGLIO control unit with controller, Incl. electric cabinets, - ARTIGLIO band saw machine, type SNT 140, - Outfeed conveyor system with reload deck and cross transports
STENNER resaw, type ST130, Resaw requires no pit or any special installation., Machine specifications:, - Flywheel diameter 915 mm, - Max bandsaw width 130 mm, - Max. cutting height 380 mm, - Motor power 22 kW, - HMI touch screen controller, - Programmable fence setting, - Pneumatic adjustment feed roller, - Variable feed speed, - Powered table rollers, - Control unit with electric cabinet
DIMTER automatic optimizing cross cut saw, type OptiCut S50, Manufacture year 2022, Machine specifications:, - Push infeed, max. length 6300 mm, - Automatic length measuring and chalk reader, - Cutting width max. 250 mm, - Cutting height 120 mm, - Max. cross section 220 x 120 / 250 x 100 mm, - Motor 7.5 kW, - OptiCom Pro controller, - Automatic outfeed table with pusher
A full USNR automatic saw mill, - Log yard with debarker and sorting, - canter chipping line, - 3x quadro bandsaw, - 2x automatic edger line, - Almab drop sorting line for main products, - USNR drop sorting line for side products
WACO + KUJAKON resaw line BKW, WACO twin resaw, type BKW-S, Feed speed up to 120 m/min, KUJAKON automation with de-stacking, infeed and stacking
STENNER resaw, type ST100, Resaw requires no pit or any special foundation., Machine specifications:, - Flywheel diameter 915 mm, - Max bandsaw width 100 mm, - Max. cutting height 380 mm, - Motor power 15 kW, - Touchscreen controller, - Digatal saw thinkness readout, - Automatic closing feeding roller, - Manual adjustment saw guide, - Manual adjustment feed roller, - Variable feed, - Blade lubrication
H&M automatic cross cut line, type HM-Z-4, Manufacture year 2008, For straight & (double) angle cutting and equipped with milling unit, Consisting of:, - Cross chain infeed system, - Automatic push infeed, working length 6 meter, - Industrial cnc controller, - Milling unit cnc controlled, - H&M cnc cross cutting machine, type HM-Z-4, Cross cut machine with 5,5 kW motor and saw blade Ø 700 mm., Angle adjustment 0 – 180 ° and incline adjustment 0 – 45 °, Z-axis adjustment 200 mm, max. cutting height 250 mm, - Outfeed system with outfeed station
H&M automatic miter saw, type HM-D Year of construction 2007 Consisting of: - Automatic chain feeding system 5 chains, buffer length 2000 mm - Input conveyor with pusher unit, working length 6100 mm liftable pusher with integrated length measurement and pinstripe reader - Underlying miter saw, type HM-D max. cutting height 150 mm, motor 5.5 kW, saw blade 550 equipped with waste valve - Industrial computer with color screen - Discharge transport with pusher and buffer table
PRIMULTINI log bandsaw line, type SIB-1600-CFK-IFB, Consisting of:, PRIMULTINI hydraulic log carriage, type CFK, - undependable headblock movement, - 5 pc hydraulic headblocks, - Opening headblocks horizontal 1000 mm, - Each headblocks with brushless motor for movement, - Distance between headblocks 1400 – 1750 – 2000 – 3350 mm, - Length log carriage ca. 10,5 meters, - Each headridge with double hydraulic centering pad, - Integrated log turners, PRIMULTINI hydraulic driven rope feeding, type IFB, With separate motor, with 55 kW power, with rails, total length 30 meters, SWECAN chipper canter machine, Motor power 75 kW, Control cabin with MUDATA touch screen controller, RIMULTINI band saw machine, type SIB 1600, - Diameter flywheels 1600 mm, - Width of flywheels 245 mm, - Maximum sawblade 260 mm, - Saw blade protection, - Blade guide with hydraulic pressure, - Electric adjustment bl ...
PRIMULTINI automatic edger line DRC with in and outfeed mechanization, Consisting of:, - Pribo mechanization to edger, - Automic infeed system, - Microtec automatic optimization and alignment system, - Primultini autmoatic multiple edger, type DRC, 6 moveable saws, passage width 750 mm, 2 x 45 kW motor, - Outfeed roller conveyor with splitting, Full line in excellent condition.
RAIMANN multi ripsaw, type KS 310, Machine specifications:, - Max. cutting width 310 mm, - Max. cutting height 120 mm, - Chain width 340 mm, - Motor power 45 kW, - Variable speed feed chain, - Upper part feed unit electric adjustable, - With lasers and accessories, - Incl. 2 pc. belt conveyors
REINHARDT automatic optimizing cross cut line, type Economy Line NC 810 H
BRENTA resaw, type DDP 150, Machine specifications:, - With centre feeding device, - Flywheel diameter 1500, - Flywheel width 185 mm, - Clutch for speed adjustment, - Hydraulic driven feeding rollers, - Motor power 37 kW, - With control unit and accessories
EWD - GILLET log bandsaw line with canter and double-cut, - Heavy duty log loading deck, - EWD hydraulic log carriage, type EW 1000, - GILLET canter, type SL, - GILLET bandsaw machine, type TO1600, - Outfeed conveyor, - Control unit with Mudata controller
WEINIG moulder, type Hydromat 22B, Machine specifications:, Planing width 220 mm, Planing height 120 mm, Feed speed 6 – 60 m/min, Motor power hydraulic feeding 15 kW, Spindle layout:, 1. Horizontal bottom spindle, motor power 11 kW, 2. Vertical right spindle, motor power 7.5 kW, 3. Vertical left spindle, motor power 11 kW, 4. Vertical right spindle, motor power 7.5 kW, 5. Vertical left spindle, motor power 7.5 kW, 6. Horizontal top spindle, motor power 11 kW, 7. Horizontal bottom spindle, motor power 15 kW, 8. Horizontal top spindle, motor power 11 kW, 9. Horizontal bottom spindle, motor power 7.5 kW, - Hydraulic front bearing for spindle 1, 6 - 8, - Equipped with jointers, - Surface table 2500 mm, - Spindle diameter 50 mm, - Automatic lubrication system, - Driven feeding rollers in table, - Heavy duty cardan feeding, - Digital read out feeding speed, - Incl. accessories
LBL BRENTA headrig, type XBE 180 R, Machine specifications:, - Diameter flywheels 1800 mm, - Width of flywheels 285 mm, - Maximum sawblade 311 mm, - Saw blade protection, - Motor 150 Hp
BRENTA resaw, type DK 150, Machine specifications:, - Flywheel diameter 1500, - Flywheel width 185 mm, - Heavy duty feeding by 2 vertical rollers, - Motor power 75 kW, - With control unit and accessories.
Carro de toros ARTIGLIO, tipo CHG 1000, composto por:, - Carro hidráulico de toros ARTIGLIO, tipo CHG 1000, com 6 cabeças hidráulicas, toras de toras, - Alimentação hidrostática com unidade hidráulica, - Serra de corte cruzado com cabeça pivotante, - Unidade de controle com controlador Mudata, - Armários elétricos
Reserra dupla AKE com automação A linha é composta por: - Transportador de rolos para embalagens de madeira - Guincho de inclinação - Transportador de corrente transversal com correia de transporte para empilhamento de varas - Transportador de corrente cruzada com separação - Sistema de correia de alimentação - Serra dupla AKE, tipo BKE volantes 1250 mm 2x 30 kW Velocidade de alimentação máx. 50 m/min painel de controle e gabinete elétrico - Mecanização de saída com separação
