- HeidenHain ND780 3 Axis dro- Variomatic RPM speedrange - Steady rest- Multi fix Tool system
- set off 4 heavy duty jaws for SCHIESS FRORIEP DV DF DZ DKE - Jaw width 90 mm - Jaw height 75 mm - Hole to hole jump length ways 125 mm - Hole to hole jump in width 250 mm
- set off 4 heavy duty jaws for SCHIESS FRORIEP DV DF DZ DKE - Jaw width 90 mm - Jaw height 75 mm - Hole to hole jump 125 mm
MillTurn M100: Complete & Complex machining Turning & MillingEquipped:- ATC 108 double chain for milling tool holders- ATC 10 positions boring bar holders up to 1000 mm- SCHUNK 3 chuck THW 630 - 160R- SMW Steady rest SLU-Z-5 50 - 310 mmField off application:- Aerospace- Oil and Gas- Energy- Engineering- Crankshaft- Hydraulic and Pneumtaics
- X Travel 210- Z Travel 360- Power 22 kW- Driven live tools 7.5 kw / 3000 Rpm - In feed table- Out feed table- Package jaws- Package tool holders - Chip conveyor- Coolant system 9 Bar Grundfos
- Double carriage with 4 position revolver and 840D Siemens- Steady rest 200 - 1090 mm- Roller rest 860 - 1090 mm- 4 chuck 1350 mm- Clamping from 200 - 1100 mm- Bed width 2000 mm- Stoke X Axis 950 mm- Stroke Z Axis 14900 mm
- Chip conveyor- SMW 315 3 chuck- 2 x Radial live tooling holders- 2 x Axial live tooling holders- Spindle bore 80 mm- BMT-Tooling system- Tool measuring probe- Spindle hours 6960 / 6270 Running hours
- 4 chuck 1600 mm- Heidenhain digital read out- Steady rest 710 mm- Powered tailstock- Threath cutting - Triple guide ways cast irion bed design- For turbine rotors, electrical motor anchors , reactor vessels, cylinders, rope pullys, marine propulsion shaft, castings, shafts and cement industry
- Center height 1700 mm- Can be extended or shortend to matching height as they are 2 peices- Central lubrication- Each steady rest equipped with 3 point- Driven / Morotized units
- Cycle controlled machine- Handwheel electronic in Z + X Axis- Parat Tool holders sytem- 3 chuck diameter.. - For manual, cycle and CNC processing up to interactive contour programming- Covered guidance tracks (DGP) for high long-term precision- Direct drive from motor to main spindle for high running smoothness- Oil recirculating lubrication unit with filtering for the lubrication of the precision main spindle bearing- Combination control unit for economically advantageous programming and machine operation, as well as optimum access to the work area
- HeidenHain ND-780 with 3 axis Read-outX, Zo, Z - HeidenHain LS388C Scales- 2 x CE-Chuck cover for 500 & 900 mm- SCHUNK 3 chuck Ø 400-102 - Bison 4 chuck - Steady rest Ø 30 - 210 mm- Steady rest Ø 210 - 370 mm
- Multi-Tasking Machining in a Single Machine Setup- Sub spindle for overtaking with full C-Axis- The INTEGREX IV series can finish all machining processes.- High speed, advanced milling spindle that can tilt up to 240 degrees swiveling.- Lower turret with rotary tool spindle so livew tooling- Chip conveyor with coolant and 15 Bar iKZ- Double chuck KNCS-N 210-53 SMW Autoblock- MAZAK Flex -GL150F Gantry Loader- Gripping range 200 x 120 length x 15 Kg
- Please note: not original pictures its only 3000 length not 5000 mm - 3 Guide way construction- 2 Axis HeidenHain Digital readout- Feed in 3 directions all tool post slide- Central lubrication - Work load flying in chuck 2500 Kg- Work load NOT supported 8500 Kg- Work load supported 10000 Kg - Optional 4 chuck ca 1200 mm- Optional 4 chuck ca 1500 mm- Optional package with 3 steady rest fixed model from to
- 3 chuck 1200 mm- Heidenhain Digital read out syhstem X / Z Axis- Feeds in 2 directions- Multi fix Tool systems with inserts
- X Stroke 1835 mm- Z Stroke 1000 mm- Table load 20 Ton- Ram size 230 x 230 mm - Stroke crossrail 800 mm - Stroke crossrail in 5 steps each 200 mm- Live tools 2000 Rpm- Power live tools 15 kW- ATC 18 station max L = 450 mm- Taper BT50 BIG PLUS- Full C-Axis 360.000 - Under power in AEROSPACE precision plant- 2020 Table bearing replaced- 2020 Ram bearing replaced- 2025 new chip conveyor
- Doubled support carriage- CNC controlled measuring and correction probe- Chip conveyor - internal and external clamping jaws (wheel clamp in and out)- overhauling cost 850k EUR- Under power free 02.2026
- C-Axis rapid traverve 400 Min- Turret indecing time 0,2 sec for 1 station- Heavy duty cutting (depth cut 6mm) 162.7 mL/Min- LNS Bar feeder new 2017- Large package tooling driven / live tools- 8 axis controlled with 2 spindles and turrets
- Chip conveyor - SMW Front and Rear chuck 700 mm - Double revolver 6+8 positions- Big Bore 360 mm- Tailstock with power quill- Tooling package included with inserts and jaws
