usava
Technical DataSpindle taperHSK-E 50 Feed rate longitudinal/transverse/vertical1-80000/1-80000/1-80000 mm/minRapid traverse longitudinal/transverse/vertical80/80/80 m/minGeneralHSC-Precision Centre - Active chiller for main spindle and linear drives - Active chiller for electrical cabinet - Direct absolute measuring system with air purge - Coolant-airblast changeover - MPC (Machine Protection Control); Control: 3D-control Heidenhain iTNC 530 HSCI Working area 1Longitudinal450 mmCross580 mmVertical460 mmTool changerApplicationVertical Type of magazineChain Type of gripperDouble gripper Number of tools30 Rigid tableRigid table, clamping area 460 x 600 mm / 18,11 x 23,62 inch Loading weight max. 600 kg / 1322 lbsSpindle speed up to 40,000rpm with Shaft CoolingSpindle speed 20 up to 40,000 rpm within shaft cooling for tool taper HSK-E50 DIN 69893 AC-Main drive with 19,5/15 kW (100/40%DC) 14, ...
usava
GeneralPrecision centre - Linear drive package - Active cooling for spindle, linear drives and electrical cabinet - Frame temperatur control - Direct measuring system - Chiptray, coolant/airblast changing - Full cabin including 2nd door; Control: 3D-control Siemens 840D sl Operate Technical DataSpindle taperHSK-A 63 Feed rate longitudinal/transverse/vertical1-80000/1-80000/1-80000 mm/minRapid traverse longitudinal/transverse/vertical80/80/80 m/minWorking area 1Longitudinal650 mmCross600 mmVertical380 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools120 Floor space/WeightDimensions (L x W x H)7,28 x 6,63 x 3 mWeight approx.9600 KgRigid tableRigid table clamping area 850 x 600 mm // 33,46 x 23,62 inch loading weight max. 700 kg // 1543,23 lbsSpindle speed up to 28,000rpm Shaft CoolingSpindle speed 20 up to 28,000 rpm within shaft cooling inclusive MPC M ...
usava
GeneralPrecision centre - Linear drive package - Active cooling for spindle, linear drives and electrical cabinet - Frame temperatur control - Direct measuring system - Chiptray, coolant/airblast changing - Full cabin including 2nd door; Control: 3D-control Siemens 840D sl Operate Technical DataSpindle taperHSK-A 63 Feed rate longitudinal/transverse/vertical1-80000/1-80000/1-80000 mm/minRapid traverse longitudinal/transverse/vertical80/80/80 m/minWorking area 1Longitudinal650 mmCross600 mmVertical380 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools120 Floor space/WeightDimensions (L x W x H)7,28 x 6,63 x 3 mWeight approx.9600 KgRigid tableRigid table clamping area 850 x 600 mm // 33,46 x 23,62 inch loading weight max. 700 kg // 1543,23 lbsSpindle speed up to 28,000rpm Shaft CoolingSpindle speed 20 up to 28,000 rpm within shaft cooling inclusive MPC M ...
usava
GeneralHSC-Precision Centre - Active chiller for main spindle and linear drives - Active chiller for electrical cabinet - Direct absolute measuring system with air purge - scraper-type chip-conveyor and bed-flushing; Control: 3D-control Heidenhain iTNC 530 HSCI Technical DataSpindle taperHSK-A 63 Feed rate longitudinal/transverse/vertical1-90000/1-90000/1-90000 mm/minRapid traverse longitudinal/transverse/vertical90/90/90 m/minWorking area 1Longitudinal750 mmCross600 mmVertical560 mmTool changerApplicationVertical Type of magazineWheel Type of gripperPick up Number of tools30 Floor space/WeightDimensions (L x W x H)6,65 x 7,6 x 3,18 mWeight approx.12000 KgSplash guard equipment/cabinSplash guard equipment/cabin with illumination and sliding doors on operators side and front sideMotor spindle with HSK-A 63Drive power (100% DC) 25 kWDrive power (40% DC) 35 kWSpeed range - 18.000 rpmSpind ...
usava
GeneralHSC-Precision Centre - Active chiller for main spindle and linear drives - Active chiller for electrical cabinet - Direct absolute measuring system with air purge - scraper-type chip-conveyor and bed-flushing; Control: 3D-control Siemens 840D sl Operate Technical DataSpindle taperHSK-A 63 Feed rate longitudinal/transverse/vertical1-90000/1-90000/1-90000 mm/minRapid traverse longitudinal/transverse/vertical90/90/90 m/minWorking area 1Longitudinal750 mmCross600 mmVertical560 mmTool changerApplicationVertical Type of magazineWheel Type of gripperPick up Number of tools30 Floor space/WeightDimensions (L x W x H)6,65 x 7,6 x 3,18 mWeight approx.12000 KgSplash guard equipment/cabinSplash guard equipment/cabin with illumination and sliding doors on operators side and front sideHSC75 linear 5-Axis SpecificationHSC 75 linear 5-Axis Specification clamping area Ø 750 mm, Ø 29.52 inch Ti ...
usava
Nº 3701: 1 gebr. Máquina de moagem de consol vertical O Fabr. HESSAPP, tipo HC 50 et, Bauj. 1981 com controlo de rota Heidenhain TNC 135 / Indramat Arb.-Ber.: 600 x 350 x 500 mm, potência de unidade: 2,3 kW Acessórios: Área de mesa 1180 x 330 mm Outros: Gama de velocidade 70 - 6000 rpm
usava
1 máquina de moagem usada vertical no design do consol Fabricante Reckermann Tipo: CONSA V Construído: 2001 Controlo: Heidenhain TNC 124 Eixo X:1000mm Eixo Y: 370mm Eixo Z: 450mm Área de aperto de mesa: 1300 x 400 mm Suporte do fuso: SK 50 Rotação do fuso máximo: 3600 rpm
