Brocas especiais (88)

Lot is defective, missing the drill head and power cable. Auction-ID: A1-50997-33

Drilling cap: 35/30 mm tapping, spindle travel: 195 mm Tilting drill head, total height: 2350 mm, Head travel 1000 mm, Vertical arm travel: 700 mm; Feed: 0.05–0.1–0.2 mm/rev Table: 600 x 500 mm, tilting table, Spindle taper: MT 4; Auction-ID: A1-51499-27

Brand and type unknown Auction-ID: A1-51015-109

automatic feed, Auction-ID: A1-51499-44

Auction-ID: A1-51015-148

Auction-ID: A1-51015-147

spindle travel: 200 m, height of the drill: 2050 mm, Table: 400 mm, Column dia: 150 mm Auction-ID: A1-51499-33

Auction-ID: A1-51015-150

Defective, according to specification, mounted on metal table. Auction-ID: A1-50997-136

470mm height adjustable; pulley system; PLEASE NOTE: The buyer is responsible for moving out the lot. There is a forklift available! Auction-ID: A1-47369-2206

Auction-ID: A1-51499-34

Includes machine clamp. Auction-ID: A1-50997-27

automatic feed Auction-ID: A1-51499-23

Auction-ID: A1-51015-146

Drilling dia: 60/45 mm, automatic feed Auction-ID: A1-51499-28

Auction-ID: A1-51015-149

Used Column Drill Manufacturer: ALZMETAL Type: AB3/ES Year: 1991 Performance: 1.3 kW 380V Total dimensions: approx. 900 x 600 x 1900 mm Lid opened! Scope of delivery see photos! Changes and errors in the technical data, specifications and prices reserved. Viewing on 20.11.26 only with prior registration at r.schober@kobran.de! Attention! We dismantle and load for you. You just have to organize a transport.; For this service, the additional costs shown are.; Auction-ID: A1-51900-9

Optimum B34H pillar drilling machineManufacturer: Optimum Maschinen GermanyModel: B34H, article no. 302 0333Motor: 1.5 / 2.2 kW, 400 V, 50 HzMax. spindle speed: 4,800 rpmWeight: 274 kgControl panel with digital display and emergency stop Auction-ID: A1-51927-320

Auction-ID: A1-50997-13

Defect according to specification Auction-ID: A1-50997-132

drilling dia 45/35 mm, spindle reversal / tapping, spindle travel: 195 mm Max. total height : 2050 mm, Head travel: up to 1000 mm Vertical arm travel : 670 mm; Feed rates: 0.1–0.33 mm/rev Table surface: 500 x 400 mm; taper: MT 4; Auction-ID: A1-51499-22

Auction-ID: A1-51896-43

Radial drilling machine MK 5 x 2500 Spindle mount MK 5 Speed range 30 - 1500 rpm Feeds 0.05 - 0.6 mm/rev Space requirement approx. 3.7 x 1 x 3 m Weight approx. 5 tons (estimated) Working Area: MK 5 x 2500 Drive: 3.7 / 6 kW Auction-ID: A7-51643-4

FORADIA GK 50/1500 – Radial Drilling Machine Manufacturer: FORADIA Model: GK 50/1500 Machine Type: Radial Drilling Machine Country of Manufacture: Spain Condition: Used Year of Manufacture: Not specified Technical Specifications | Specification | Details | Maximum Drilling Capacity | 50 mm | | Radial Arm Length | 1,500 mm | | Column Diameter | 350 mm | | Maximum Spindle-to-Base Distance | 1,300 mm | | Spindle Taper | Morse Taper MT4 | | Spindle Motor Power | Approx. 2.6 kW (3.5 HP) | | Number of Spindle Speeds | 12 | | Spindle Speed Range | 35 – 1,460 rpm | | Number of Automatic Feeds | 6 | | Feed Range | 0.05 – 0 ...

Auction-ID: A3-46115-21042

Auction-ID: A1-51062-19

Equipped with an integrated digital drilling depth and speed display, a massive, height-adjustable and rotatable drilling table with T-slots and flexible coolant injection. Heavy machine base with integrated coolant pump. Accessories: Including 1x heavy, precise drill vise (industrial version with long guide grooves) mounted directly on the table. Drive & speed: Infinitely variable electronically adjustable Auction-ID: A7-51635-3

Equipped with Cekaba-Bon machine vise Auction-ID: A1-51062-111

Projection 220 mm, drilling stroke 80 mm Auction-ID: A1-51062-18

Industrial upright/column drilling machine manufactured by FUM Chocianów, Poland. Specifications: Model: WKA-40 Year: 1969 Serial number: 2720 Power supply: 380 V, 3-phase, 50 Hz Motor power: approx. 6.8 kW Weight: approx. 1,500 kg Includes T-slotted worktable and machine vice Used workshop condition with visible signs of age and use Auction-ID: A1-51282-130

Machine Type Radial Drilling Machine Manufacturer MAS Kovosvit Model VO50 Origin Czech Republic (Sezimovo Ústí) Serial Number 1123 Machine Type Heavy-duty industrial radial drill Working Capacity Item Specification Max Drilling Capacity (Steel) Ø50 mm Max Tapping Capacity approx. M42 Spindle Taper Morse Taper MT5 Spindle Stroke (Quill Travel) approx. 250 – 315 mm Machine Geometry Item Specification Column Diameter approx. 350 – 400 mm Arm Length (Column to Spindle) approx. 1000 – 1600 mm Max Spindle to Base Distance approx. 1600 mm Min Spindle to Base Distance approx. 300 mm Spindle & Feeds Item Specification Spindle Speed Range approx. 25 – 2000 rpm Number of Speeds 12 – 18 gearbox speeds Feed Rates Mechanical automatic feeds Feed Steps Multiple (gearbox controlled) Movements Axis Specification Arm Vertical Movement Motorized Arm Rotation 360° around column Head Trave ...

FORADIA GK 50/1500 – Radial Drilling Machine Manufacturer: FORADIA Model: GK 50/1500 Machine Type: Radial Drilling Machine Country of Manufacture: Spain Condition: Used Year of Manufacture: Not specified Technical Specifications | Specification | Details | Maximum Drilling Capacity | 50 mm | | Radial Arm Length | 1,500 mm | | Column Diameter | 350 mm | | Maximum Spindle-to-Base Distance | 1,300 mm | | Spindle Taper | Morse Taper MT4 | | Spindle Motor Power | Approx. 2.6 kW (3.5 HP) | | Number of Spindle Speeds | 12 | | Spindle Speed Range | 35 – 1,460 rpm | | Number of Automatic Feeds | 6 | | Feed Range | 0.05 – 0 ...

Boom length: 1,400mm. Auction-ID: A1-51529-46

With transport trolley Auction-ID: A1-51529-11

Heavy-duty floor-standing industrial drilling machine with geared drill head, large adjustable worktable and vertical column. Suitable for drilling and related metalworking operations. Auction-ID: A1-51282-15

Incl. threading device with control. Auction-ID: A1-51529-127

Auction-ID: A1-51529-47

Industrial floor-standing pillar drilling machine of heavy cast construction. The machine is equipped with a geared drilling head, vertical column with rack adjustment, manual feed controls and an adjustable worktable with machine vice. Auction-ID: A1-51282-143

380V Geared head 8 spindel speeds 68 up till 1220 RPM MT3 Spindel intake Made in Sweden 76x42x155cm LxHxB Aprox weight: 150KG Auction-ID: A1-47367-3560

380V Geared head 8 Spindel speed’s 100 up till 2900 RPM MT3 Spindel intake Tool ejector Dimensions: 65x40x160CM LxWxH Weight aprox: 180KG Auction-ID: A1-47367-3555

Drilling and milling machine withpowerful 2-speed motor. Mounting MC 3 - B16. Drill chuck 3 - 16 mm.Left / right switch. Spindle protection. Fine adjustment. Ejection wedge. Threaded rod for clamping toolRelated tools. Drilling capacity in steel 32 mmProjection 200 mmDrilling stroke 70 mmCapacity finger milling machine 16 mmSpindle holder MK3Spindle speeds 50 - 3000 rpmTable adjustment transverse 220 mmTable adjustment longitudinal 425 mmTable clamping surface 700 x 210 mmConnection voltage Vmax. Distance between work table and spindle nose 470 mmTotal power requirement 1.5 kWMachine weight approx. 230 kgDimensions approx. 0.75 x 1.05 x 1.2 mCondition: never used / new (5) Auction-ID: A7-51438-501

Gearbox drillingmachinethreading device left / right runtilting work table. Lighting. 2 electr. Speed levels. Depth stop . Gears run in oil. Packaging dimensions:2100 x 400 x 710mmWeight 260KgDrilling capacity in steel 30 mmProjection 250 mmDrilling stroke 130 mmSpindle holder MK 3 MKTable: 380 x 380 mmColumn diameter 98 mmSpeed 75 - 3200 rpmFeeds mm/revTotal power requirement 1.1 kWMachine weight approx. 220 kg. Dimensions L-W-H 0.5 x 0.6 x 2.05 mmCondition: never used / new (5) Auction-ID: A7-51438-425

Radial drilling machine- clamping cube 750 x 500 x 500mm- digital display for boom travel- coolant system- good conditiondrilling performance in steel 40 mmprojection 1600 mmdrilling capacity in cast 60 mmspindle diameter 85 mmquill stroke 350 mmtool holder MK 5speeds 24 - 1050rpm feeds 0.06 - 1.0 mm/revcolumn diameter 345 mmthreading device yesdrilling motor 5.5 kwtotal power requirement 7.5 kWmachine weight approx. 4000 kgspace requirement approx. 2.5 x 1.0 x 2.99 mCondition: functional Auction-ID: A7-51438-599

Drilling and milling machine with- variable spindle speed- cross-support- rotatable spindle head left/right 90°- feed via hand crankDrilling capacity in steel 16 mmProjection 185 mmDrilling stroke 50 mmCapacity finger milling machine 20 mmSpindle holder MK 2Spindle speeds 100-1500 / 200-3 rpmTable adjustment transverse 175 mmTable adjustment longitudinal 280 mmTable clamping area 500 x 180 mmConnection voltage 230 VTotal power requirement 0.85 kWMachine weight approx. 0.12 tDimensions approx. 0.86 x 0.6 x 0.9 mCondition: never used / new (5) Auction-ID: A7-51438-504

Column drilling machine with: automatic feedTapping function. Digital depth display2 stage motorSpindle protectionSwivel tableLED lightingCoolant systemDrilling capacity in steel 40 mmThroat depth 350 mmDrilling stroke 180 mmSpindle holder MK 4 MKTable: 560 x 560 mmColumn diameter 140 mmSpeed 50 - 1450 rpmFeeds 0.1 - 0.2 mm/revTotal power requirement 1.5 kWMachine weight approx. 580 kgCondition: never used / new (5) Auction-ID: A7-51438-487

Column drilling machine with- Right-left-running- Tapping- Coolant- Emergency stopDrilling capacity in steel 50 mmProjection 300 mmDrilling stroke 250 mmSpindle diameter 60 mmSpindle holder MK 5Spindle speeds 18 - 1400 rpmNumber of speeds 12 stagesFeeds 0.1 - 1.6 mm/revNumber of feeds 9 stagesTable clamping area 500 x 500 mmSpindle motor 4 kWTotal power requirement 4.2 kWMachine weight approx. 1.5 tSpace requirement approx. 1.2 x 0.8 x 2.55 mCondition: functional Auction-ID: A7-51438-471

Column drilling machine with:ARBO / CE approved protective cover. Quick-release chuck with pin. Tilting work table. Depth stop. Output wedge. Drilling capacity in steel 32 mmProjection 200 mmDrilling stroke 120 mmSpindle holder MK 4 MKTable: 290 x 270 mmColumn diameter 92 mmSpeed 150 - 2450 rpmTotal power requirement 1.1 kWMachine weight approx. 95 kgDimensions L-W-H 0.66 x 0.8 x 1.7 mCondition: never used / new (5) Auction-ID: A7-51438-473

Column drilling machine with:- variable spindle speed- digital display for speed- digital display for drilling depth- left/right rotation- incl. viceDrilling capacity in steel 30 mmprojection 275 mmDrilling stroke 100 mmHolder MK 4 MKTable size 420 x 340 mmSpeed 80 - 2000 rpmTotal power requirement 0.9 / 1.45 KWMachine weight approx. 0.22 tDimensions L x W x H 0.85 x 0.6 x 1.9 mCondition: functional Auction-ID: A7-51438-593

Quick radials with:- Feed threading deviceTechnical details / accessories / addition: Value unitTechnical data:Drilling capacity in steel (diameter) 32 mmProjection 1230 mmWorkpiece height - max. mmDrilling stroke 180 mmTotal power requirement 3 kWMachine weight approx. 1.8 tSpace requirement approx. 2.2 x 1.8 x2.3 m Auction-ID: A7-51438-437

Column drilling machine with:- Feed via handwheel- Spindle speeds via belt driveDrilling capacity in steel 32 mmProjection 300 mmDrilling stroke 140 mmHolder MK 3Table size 380 x 360 mmFeeds via handwheelSpeed 85 - 1100 rpmTotal power requirement 1.3 KWMachine weight approx. 0.27 tDimensions L x W x H 0.95 x 0.6 x 1.92 mCondition: untested Auction-ID: A7-51438-590
